- Page 1 HRS 130 User Manual This product complies with European Union EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EC) © German Physiks 2007-2023 Revision m Released 7 June, 2023 We reserve the right to change the information contained in this manual without notice. For the...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION ........................... 3 2. UNPACKING YOUR LOUDSPEAKERS ..................3 3. THE PRINCIPAL FEATURES OF THE HRS-130 ................. 5 4. CONNECTING YOUR LOUDSPEAKERS ..................6 High Frequency Level Control ....................6 Loudspeaker Cables ......................... 7 Input Terminal Connections ....................... 7 Single Wire Connection ...................... -
Page 3: Introduction
Each HRS-130 is packed in single carton. This must be kept horizontal as shown in figure 1. Before opening the cartons, please inspect them for damage. If you see any damage, please contact the supplying audio dealer immediately and provide them with a full description of the damage. - Page 4 Hex key for removing transit screws from base Self-adhesive felt pads – for use under spike cups Cleaning cloth If any of these items is missing, please contact the supplier. 3. Remove the top packing piece figure 3. Figure 3. HRS-130 shipping carton top packing piece...
-
Page 5: The Principal Features Of The Hrs-130
Such damage is not covered by the warranty. Should you require replacement packing, please contact your German Physiks dealer, the national distributor or the factory directly. Please also be aware that if it is necessary to ship the loudspeakers, they must be shipped securely strapped to a Euro size pallet. -
Page 6: Connecting Your Loudspeakers
The HRS-130 is a 2-way design with separate input terminals for the low frequency and high frequency sections of the crossover. These drive the woofer and DDD drivers respectively and are labelled accordingly. -
Page 7: Loudspeaker Cables
Do not use pliers or any other tools as this may damage the terminals. There are two recommended methods of connecting the HRS-130 to the amplifier. Single Wire Connection This uses one cable to connect each loudspeaker to the power amplifier. The two red terminals and the two black terminals on the input terminal plate should be linked together as shown in figure 6. -
Page 8: Loudspeaker Placement And Set-Up
The converse will be true as you move the loudspeakers away from the front wall. In most cases, the HRS-130 should not be placed closer than 1m from the front wall. If the loudspeakers are too close to the front wall, not only... -
Page 9: Distance From The Side Wall
in early reflections. Aim to find a position that provides an even bass response, combined with the best- defined and most realistic stereo image when you are seated at the listening position. Distance from the Side Wall We recommend that the distance of the listening position from the loudspeakers be 1.5 to 2 times the distance between the centres of the loudspeakers –... -
Page 10: Fitting And Adjusting The Spikes
The HRS-130 is supplied with four double-ended spikes, which screw into inserts in the cabinet base plate. One end of the spike is pointed and is intended to be used on carpeted floors. The other end is rounded and may be used together with a spike cup on hard floors. -
Page 11: Loudspeaker Break-In
Do not use any tools. 7. LOUDSPEAKER BREAK-IN Like all audiophile equipment, German Physiks loudspeakers require a break-in period from new before they reach their optimum level of performance. Initially the sound may seem harsh. Please do not be concerned. -
Page 12: Care Of Your Loudspeakers
This may be done by completing the registration form at the end of the user manual and returning it to German Physiks together with a copy of the sales receipt, or by using the product registration form on the German Physiks web site. This may be found under the menu items Contact/Product Registration. - Page 13 Media/Product Resources. Alternatively, scanning the QR code below with your mobile phone camera should take you to the Product Resources page on the German Physiks web site, from where you will be able to download a copy of the manual.
-
Page 14: Service And Support
• Description of the problem They will then contact German Physiks via the local distributor. We will liaise with them to diagnose the fault and decide the best way to affect a repair. If the dealer/seller or local distributor is unable to assist you, please contact German Physiks using the contact form which may be found under the Contact menu item on our web site at www.german-... - Page 15 German Physiks dealer, local distributor or the factory. The customer is responsible for all costs involved in shipping the product(s) to and from German Physiks. German Physiks accepts no liability for any loss or damage to the product that may occur during shipping.
-
Page 16: How To Contact Us
11. HOW TO CONTACT US If you wish to get in touch with us, please use the contact information shown below. Please note that our office hours are from 10.00 a.m. to 5.00 p.m. Monday to Friday, excluding public holidays and that we cannot respond to enquiries outside of these hours. -
Page 17: Hrs-130 Specifications
12. HRS-130 SPECIFICATIONS Impedance 4 ohms Frequency Response 29 - 24,000Hz Power Handling Nominal 120W Short term 200W Amplification required Minimum 70W/4 ohms Crossover frequency 220Hz Crossover slopes DDD section 12dB/octave electronic & 18dB/octave acoustic Woofer section 12dB/octave electronic & 18dB/octave acoustic... -
Page 18: Warranty Registration
D-63477 Maintal GERMANY Alternatively, you can: Email scans of this registration form and proof of purchase to us at: registration@german-physiks.com Complete the product registration form on the German Physiks web site at: https://bit.ly/3BytSJM Title (Mr, Mrs, Dr. etc) Name Address...
