- Page 1 OWNER’S MANUAL ELECTRIC RANGE Please read this guide thoroughly before operating and keep it handy for reference at all times. LSE3090ST LSE3092ST www.lg.com (REV.01 130910)
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS iMPORTANT SAFETY iNSTRUCTiONS LOWER OVEN CONTROLS (ON SOME MOdELS) OVERViEW Using the lower oven Accessories CARE ANd CLEANiNG Range overview Cleaning the glass/ceramic cooktop. Control panel overview Self clean FEATURES Cleaning the exterior Changing the oven light Clock Removing and replacing the oven door and Timer on/off... -
Page 3: Important Safety Instructions
Always contact your service agent or manufacturer about problems that you do not understand. Download this owner's manual at: http://www.lg.com. This is the safety alert symbol. This symbol alerts you to potential hazards that can result in property damage and/or serious bodily harm or death. -
Page 4: Safety Precautions
IMPORTANT SAFETY INSTRUCTIONS Anti-tip Wall plate • Remove the warming or storage bracket drawers and visually inspect that the Screw must enter wood rear leveling legs are fully inserted into approximately or concrete the anti-tip brackets. 0.65”(16.5mm) • Be certain that your appliance is properly installed and grounded by a qualified technician. •... - Page 5 IMPORTANT SAFETY INSTRUCTIONS WARNING • DO NOT step or sit on the oven door. Install the anti-tip brackets packed with range. - The range could be tipped and injury might result from spilled hot liquid, food, or the range itself. - If the range is pulled away from the wall for cleaning, service, or any other reason, ensure that the anti-tip brackets are properly re-engaged when the range is pushed back against the wall.
-
Page 6: Electrical Safety
IMPORTANT SAFETY INSTRUCTIONS ELECTRICAL SAFETY • Protective Liners. Do not use aluminum foil or any other material to line the oven bottom. Improper installation of these liners may result in a risk of electric shock or fire. • Do Not allow aluminum foil or the temperature probe to contact heating elements. •... -
Page 7: Child Safety
IMPORTANT SAFETY INSTRUCTIONS • Should an oven fire occur, leave the oven door closed and turn the oven off. If the fire continues, throw baking soda on the fire or use a fire extinguisher. • Should an oven fire occur, DO NOT put water or flour on the fire. Flour may be explosive and water can cause a grease fire to spread and cause personal injury. - Page 8 IMPORTANT SAFETY INSTRUCTIONS • NEVER store items of interest to children in cabinets above the range. Children climbing on the range or on the oven door to reach items could be seriously injured. • Let hot utensils cool in a safe place, out of reach of small children. •...
-
Page 9: Safety When Cleaning
IMPORTANT SAFETY INSTRUCTIONS • If cabinet storage is provided directly above cooking surface, limit it to items that are infrequently used and can be safely stored in an area subjected to heat. Temperatures may be unsafe for items such as volatile liquids, cleaners or aerosol sprays. •... -
Page 10: Overview
Cleaning pad NOTE • Contact LG Customer Service if any accessories are missing. • For your safety and for extended product life, only use authorized components. • The manufacturer is not responsible for product malfunction or accidents caused by the use of separately purchased, unauthorized components or parts. -
Page 11: 1 Range Overview
Heavy racks Insert Broil Pan Gliding rack Split rack Oven door Anti-tip bracket Lower oven drawer Model and serial number plate For model : LSE3090ST Single element Single element Single element Dual element Ceramic glass Automatic oven light switch Gasket... -
Page 12: Control Panel Overview
200˚F 250˚F 450˚F 300˚F 400˚F 350˚F Clear Off Button Number Buttons Start/Lockout Button For model : LSE3090ST Hot Surface Indicator Cooktop Element Oven Controls Features Cooktop Element Clear Off Button Start/Lockout Button NOTE Cooktop Element Controls are set up in the same order as the corresponding elements. -
Page 13: Features
FEATURES FEATURES Minimum & Maximum default settings All of the features listed have a minimum and a maximum time or temperature setting that may be entered into the CLOCK control. An entry acceptance beep will sound each time a control key is pressed. The clock must be set to the correct time of day in order for the automatic oven timing functions to work properly. -
Page 14: Timer On/Off
FEATURES TIMER ON/OFF NOTE The TIMER ON/OFF serves as an extra timer in the If the remaining time is not in the display, recall the kitchen that will beep when the set time has run out. remaining time by pressing the Timer ON/OFF button. It does not start or stop cooking. -
Page 15: Oven Temperature Adjustment
FEATURES OVEN TEMPERATURE PREHEATING ALARM LIGHT AdJUSTMENT When the oven reaches its set temperature the preheating alarm light will flash until the oven door is opened. You may find that your new oven cooks differently than You can activate or deactivate the preheating alarm light. the one it replaced. -
Page 16: Lockout
FEATURES LOCKOUT NOTE The Lockout feature automatically locks the oven door • To cancel the DELAYED TIMED COOK function, press and prevents most oven and cooktop controls from being the CLEAR OFF button at any time. turned on. It does not disable the clock, timer or the •... -
Page 17: Cook Time
FEATURES COOK TIME (TIMEd COOK) The oven will continue to cook for the set amount of time and then turn off automatically. When the cooking time The TIMED COOK feature allows you to set the oven to has elapsed: cook for a specific length of time. This feature can only be •... -
Page 18: Using The Cooktop
ZONE TRIPLE DUAL NOTE Hot surface indicator light • Hi is the highest temperature available. For model : LSE3090ST • Lo is the lowest temperature available. CAUTION SINGLE SINGLE • NEVER leave food on the cooktop unattended. Spillovers can cause smoke. Greasy spillovers may catch on fire. - Page 19 USING THE COOKTOP To turn on the dUAL element : NOTE There is one dual element located in the left front position. • Hi is the highest temperature available. You are able to use the dual element as a dual or single •...
-
Page 20: Using The Proper Cookware
USING THE COOKTOP Recommended surface cooking settings USING THE PROPER COOKWARE Using the proper cookware can prevent many problems, Element Level Recommended Use such as food taking longer to cook or achieving Dual • Large diameter cookware inconsistent results. Proper pans will reduce cooking Triple •... -
Page 21: Using The Oven
USING THE OVEN USING THE OVEN Rack and Pan Placement REMOVING ANd REPLACING THE OVEN RACKS CAUTION • Replace oven racks before turning the oven on to prevent burns. • DO NOT cover the racks with aluminum foil, or any other material, or place anything on the bottom of the oven. -
Page 22: Bake
USING THE OVEN BAKE Tips for baking Follow the recipe or convection food directions for BAKE is used to prepare foods such as pastries, breads baking temperature, time and rack position. Baking time and casseroles. The oven can be programmed to bake at and temperature will vary depending on the ingredients, any temperature from 170°F (77°C) to 550°F (288°C). -
Page 23: Convection Bake
This is normal operation. (LSE3092ST) (LSE3090ST) • The oven fan will run while convection baking. The fan will stop when the door is open, but the heat The CONV. BAKE pad controls the Convection Bake will not turn off. -
Page 24: Convection Roast
USING THE OVEN CONVECTION ROAST Roasting Rack Instructions When preparing meats for convection roasting, use the The Convection Roast feature is designed to give broiler pan and grid along with the roasting rack. The optimum roasting performance. The Convection Roast broiler pan will catch grease spills and the grid will help feature uses the convection fan while cooking to roast prevent grease splatters. -
Page 25: Healthier Roast (On Some Models)
USING THE OVEN HEALTHIER ROAST NOTE (On Some Models) • During oven operation, it is possible that the oven cooling fan will operate to cool the control panel. The Healthier Roast function is designed to lower the fat This is normal operation. content of meat and poultry. -
Page 26: Broil
USING THE OVEN BROIL Smoking Due to the intense heat associated with broiling, it is The Broil function uses intense heat from the upper normal to experience smoke during the cooking process. heating element to cook food. BROIL works best for This smoke is a natural byproduct of searing and should tender cuts of meat, fish, and thinly cut vegetables. -
Page 27: Recommended Broiling Guide
USING THE OVEN RECOMMENdEd BROILING GUIdE The size, weight, thickness, starting temperature, and your preference of doneness will affect broiling times. This guide is based on meats at refrigerator temperature. For best results when broiling, use a pan designed for broiling (refer to Fig.1) Fig.1 Broiling Chart... -
Page 28: Favorite
USING THE OVEN Broiling Tips FAVORITE • Preheat oven 5~7 minutes for best broiling results. The FAVORITES feature is used to record and recall your • Brush fish and poultry with butter or oil to prevent favorite recipe settings. This feature may store and recall sticking. -
Page 29: Warm
USING THE OVEN WARM PROOF The Warm function will maintain an oven temperature of The Proof feature maintains a warm environment for 170°F and will keep cooked food warm for serving up to 3 rising yeast leavened products before baking. To avoid hours after cooking has finished. -
Page 30: Meat Probe (On Some Models)
USING THE OVEN MEAT PROBE (on some models) To change the Meat Probe temperature during cooking: The meat probe accurately measures the internal 1. Press PROBE. temperature of meat, poultry and casseroles. It should not be used during broiling, self clean, warming or 2. -
Page 31: Lower Oven Controls (On Some Models)
LOWER OVEN CONTROLS LOWER OVEN CONTROLS The lower oven uses less energy than a standard oven. It takes more time for preheating than a standard oven. (On Some Models) Allow the following approximate times for preheating: Lower oven Preheat Time USING THE LOWER OVEN Temperature The purpose of the lower oven is to bake foods using the... -
Page 32: Care And Cleaning
CARE AND CLEANING CARE ANd CLEANING Burned-On Residue 1. While the cooktop is still hot, remove any burnt- on deposits or spilled food from the glass/ceramic CLEANING THE GLASS/CERAMIC cooking surface with a suitable metal razor scraper (similar to scraping paint off of a windowpane - it COOKTOP will not damage the decorated cooking surface). -
Page 33: Self Clean
CARE AND CLEANING SELF CLEAN IMPORTANT: If any sugar or food containing sugar (preserves, ketchup, The Self Clean cycle uses extremely hot temperatures tomato sauce, jellies, fudge, candy, syrups, chocolate, to clean the oven cavity. While running the Self Clean etc.), plastic or foil melts on the cooktop, remove the cycle, you may notice smoking or an odor. - Page 34 • Remove oven racks and accessories before starting Cycle Setting the self clean cycle. Soil Level • If oven racks are left in the oven cavity during the LSE3090ST LSE3092ST self clean cycle, they will discolor and become Lightly Soiled Oven Cavity 3 Hour 2 Hour difficult to slide in and out.
- Page 35 CARE AND CLEANING during Self Clean After the Self Clean Cycle • The self clean cycle uses extremely hot temperatures • The oven door will remain locked until the oven to clean the oven cavity. While running the Self Clean temperature has cooled.
-
Page 36: Cleaning The Exterior
CARE AND CLEANING CLEANING THE EXTERIOR Broiler Pan and Grid Painted and decorative Trim For general cleaning, use a cloth with hot soapy water. For more difficult soils and built-up grease, apply a liquid detergent directly onto the soil. Leave it on for 30 to 60 •... -
Page 37: Removing And Replacing The Oven Door And Drawer
CARE AND CLEANING REMOVING ANd REPLACING THE Replacing the oven door OVEN dOOR ANd dRAWER 1. Firmly grasp both sides of the door at the top. CAUTION • Be careful when removing and lifting the door. • DO NOT lift the door by the handle. •... - Page 38 CARE AND CLEANING Removing the drawer Replacing the drawer 1. Pull the bearing glides to the front of the chassis WARNING glide. Disconnect the electrical power to the range at 2. Align the glide on each side of the drawer with the the main fuse or circuit breaker panel.
-
Page 39: Faqs
FAQs FAQs What types of cookware are recommended Can I leave my racks in the oven when to use with my cook top? running a Self Clean cycle? • The pans must have a flat bottom and straight sides. No. Although it will not damage the racks, it will discolor •... -
Page 40: Troubleshooting
TROUBLESHOOTING BEFORE REQUESTING SERVICE Review this Troubleshooting section before calling for service. This section contains common occurrences that are not a result of defective workmanship or materials. Problem Possible Causes / Solutions Range is not level. • Poor installation. Place oven rack in center of oven. Place a level on the oven rack. Adjust leveling legs at base of range until the oven rack is level. - Page 41 TROUBLESHOOTING Problem Possible Causes / Solutions Oven will not work • Plug on range is not completely inserted in the electrical outlet. - Make sure electrical plug is plugged into a live, properly grounded outlet. • A fuse in your home may be blown or the circuit breaker tripped. - Replace the fuse or reset the circuit breaker.
- Page 42 TROUBLESHOOTING Problem Possible Causes / Solutions Food does not broil • Aluminum foil used on the the broiling pan and grid has not been fitted properly and slit as properly recommended. - See the Using the Oven section. • In some areas the power voltage may be low. - Preheat the broil element for 5-7 minutes - See the Broiling Guide, page 27.
- Page 43 TROUBLESHOOTING Problem Possible Causes / Solutions Excessive smoking • Excessive soil. - Press the CLEAR/OFF button. Open the windows to rid the room of smoke. Wait until the during a self clean cycle self clean mode is cancelled. Wipe up the excess soil and reset the Self Clean function. The oven door is not •...
-
Page 44: Warranty
WARRANTY: Should your LG Electric Oven (“Product ”) fail due to a defect in material or workmanship under normal home use during the warranty period set forth below, LG Canada will at its option repair or replace the Product upon receipt of proof of original retail purchase. This warranty is valid only to the original retail purchaser of the product and applies only to a product distributed in Canada by LG Canada or an authorized Canadian distributor thereof.
