Sno-Tek 1695875 Operator's Manual

Single stage snowthrower
Hide thumbs
Table of Contents

Advertisement

Quick Links

en
Operator's Manual
fr
Manual de l'opérateur
es Manual del Operador
Single Stage Snowthrower
Model No.
1695875
Souffleuse à neige mono-étagée
Modèle n°
1695875
Lanzadora de nieve de una etapa
Número de Modelo
1695875
Description
Single Stage Snowthrower, 8.00 TP / 22 Inch
Description
Souffleuse à neige mono-étagée, électrique, 8.00 C.B./22 pouces
Descripción
Lanzadora de Nieve de Una Etapa, 8,00 TP / 55 cm (22 pulg.)
Ariens 21547466 / 1750870-A
Revision A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1695875 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sno-Tek 1695875

Summary of Contents for Sno-Tek 1695875

  • Page 1 Operator’s Manual Manual de l’opérateur es Manual del Operador Single Stage Snowthrower Model No. Description 1695875 Single Stage Snowthrower, 8.00 TP / 22 Inch Souffleuse à neige mono-étagée Modèle n° Description 1695875 Souffleuse à neige mono-étagée, électrique, 8.00 C.B./22 pouces Lanzadora de nieve de una etapa Número de Modelo...

  • Page 2: General Information

    The Illustrated Parts List for this machine can be downloaded from www.ariens.com. Please provide model and serial number when ordering replacement parts. Copyright © 2010 Briggs & Stratton Power Products Group, LLC All rights reserved. ARIENS and SNO-TEK are trademarks of Ariens Company and are used under license by Briggs & Stratton Power Products Group, LLC.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents Operator Safety ..............Hazard Symbols and Meanings ..........Control Symbols on Equipment ..........Safety Alert Symbols and Signal Words ........Safety Decals ................Features and Controls ............10 Snowthrower Controls and Operation Decals ......Engine Controls .................

  • Page 4: Operator Safety

    Operator Safety Hazard Symbols and Meanings Control Symbols on Equipment Read the Operator’s Manual for oper- On / O Key Switch ating and safety instructions Shuto engine and remove key before performing maintenance and Turn Choke Closed to Start repair work Thrown Objects Hazard Turn Choke Open to Run Fire Hazard...

  • Page 5: Safety Alert Symbols And Signal Words

    Operator Safety Safety Alert Symbol and Signal Words WARNING The safety alert symbol and signal word (DANGER, WARN- ING, CAUTION, or NOTICE) is used to indicate the likelihood and Read, understand, and follow all the instruc- potential severity of personal injury and/or damage to the product. tions on the snowthrower and in the operator’s In addition, a hazard symbol may be used to represent the type of manual before operating this unit.
  • Page 6 Operator Safety DANGER DANGER Keep hands, feet, and clothing away from Tragic accidents can occur if the operator is rotating parts. Rotating parts can contact or not alert to the presence of children. Children entangle hands, feet, hair, clothing, or acces- are often attracted to the unit and the operating sories.
  • Page 7 Operator Safety WARNING WARNING Fuel and its vapors are extremely ammable Safe operation of the snowthrower requires the and explosive. Always handle fuel with extreme proper care and maintenance of the engine. care. Failure to observe these safety instructions can cause a re or explosion which will result in severe burns or death.
  • Page 8 Operator Safety This snowthrower is only as safe as the opera- WARNING tor. If it is misused, or not properly maintained, it can be dangerous. Remember you are re- This snowthrower must be properly maintained sponsible for your safety and those around you. to ensure safe operation and performance.

  • Page 9: Safety Decals

    Operator Safety Safety Decals Before operating your snowthrower, read the safety decals installed on your snowthrower. The cautions and warnings are for your safety. To avoid a personal injury or damage to your snowthrower, understand and follow all the safety decals.

  • Page 10: Features And Controls

    Features and Controls Figure 2 Snowthrower Controls and Operation Decals (Figure 2) 1739977 A — Auger Control B — Deflector Control Lever C — Electric Start Button D — Power Cord Receptacle E — Starting Instructions / Steps 1-3 F — Starting Instructions / Step 4 & 5 Engine Controls G —...

  • Page 11: Operation

    Operation WARNING The operation of any snowthrower can result in foreign objects being thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields before beginning snowthrower operation. Check / Add Oil NOTICE: The engine was shipped from the factory without oil.

  • Page 12: Fuel Recommendations

    Operation Fuel Recommendations Add Fuel Fuel must meet these requirements: WARNING • Clean, fresh, unleaded gasoline. Fuel and its vapors are extremely ammable • A minimum of 87 octane/87 AKI (91 RON). and explosive. High altitude use, see below. Fire or explosion can cause severe burns or •...

  • Page 13: Start The Engine

    Operation Start the Engine WARNING The electric starter is equipped with a three- wire power cord and plug designed to operate on AC household current. The power cord must be properly grounded at all times to avoid the possibility of electric shock. If your house does not have a three-wire grounded system, do not use this electric starter.

  • Page 14: Stop The Engine

    Operation Stop the Engine WARNING If the extension cord is damaged, it must be WARNING replaced by the manufacturer (or its service agent) or a similarly quali ed person to avoid a Gasoline and vapors are extremely ammable hazard. and explosive. Fire or explosion can cause severe burns or death.

  • Page 15: Operate The Snowthrower

    Operation Operate the Snowthrower WARNING Before operating, make sure the area in front of the snowthrower is clear of bystanders or obstacles. DO NOT discharge snow toward a building as hiddenobjects could be thrown with sufficient force to cause damage. 1.

  • Page 16: Stop The Snowthrower

    Operation Stop the Snowthrower WARNING Read Operator’s Manual before operating machine. This ma- chine can be dangerous if used carelessly. • Never operate the snowthrower without all guards, covers, and shields in place. • Never direct discharge towards windows or allow bystanders near machine while engine is running.

  • Page 17: Discharge Chute And De Ector

    Operation Discharge Chute and De ector Manual Chute Rotation Grasp the chute handle (A, Figure 10) in the deflector handle and rotate the discharge chute to the left, right, or any forward position. A tension plate holds the chute in the desired position.

  • Page 18: Maintenance

    Maintenance Change the Oil Snowthrower Remove Oil After Each Use Used oil is a hazardous waste product and must be Remove accumulated snow and slush from the unit to prevent disposed of properly. Do not discard with household waste. freezing of controls Check with your local authorities, service center, or dealer for safe disposal / recycling facilities.
  • Page 19 Maintenance Add Oil Access the Spark Plug 1. Place engine level. To access the spark plug, the snow hood must be removed as follows: 2. Clean the oil fill area of any debris. 1. Remove the ON/OFF key (A, Figure 14) or pull out the 3.
  • Page 20 Maintenance Auger Cable Adjustment WARNING Do not over-tighten, as this may lift the lever and cause the auger drive to be engaged without depressing the auger drive control. WARNING The auger must stop within 5 seconds after releasing the con- trol.

  • Page 21: Storage

    Storage Storage Remove from Storage 1. Raise the upper handle to the operating position and tighten the knobs that secure the upper handle. WARNING 2. Fill the fuel tank with fresh fuel. Fuel and its vapors are extremely flammable 3. Check the spark plug. Make sure the gap is correct. If and explosive.

  • Page 22: Troubleshooting

    Troubleshooting PROBLEM LOOK FOR REMEDY Auger does not stop Auger control cable out of Adjust auger control cable. Refer to “Cable Adjustment” in the within 5 seconds adjustment Maintenance section of this manual. If the auger does not stop after control lever is within 5 seconds, see authorized dealer for repair.

  • Page 23: Warranty

    Two-Year Limited Warranty Ariens Company (Ariens) warrants to the original purchaser that Sno-Tek brand products will be free from defects in material and workmanship for a period of two years after the date of purchase. An authorized Ariens dealer will repair any defect in material or workmanship, and repair or replace any defective part, subject to the conditions, limitations and exclusions set forth herein.
  • Page 24 Warranty Exclusions – Items Not Covered by This Warranty • Engines and engine accessories are covered only by the engine manufacturer’s warranty and are not covered by this warranty. • Parts that are not genuine Ariens service parts are not covered by this warranty and may void the warranty.

  • Page 25: Emission Statement

    Emission Statement...

  • Page 26: Specifications

    Specifications Model No. 938022 / 1695940 ENGINE: Brand Briggs & Stratton ™ Model Series Snow Series Gross Torque* 8.00 T.P. @ 3060 rpm Type 4-Cycle - OHV Displacement 12.48 cu in. (205 cc) Starting System Recoil, 110V Electric with Cord Alternator None Oil Capacity...
  • Page 27 Notes...
  • Page 29 Ariens Company 920-756-2141 655 West Ryan Street www.ariens.com Brillion, WI 54110-1072...
