Color Monitor

USER GUIDE
BENUTZERHANDBUCH
MANUEL D'UTILISATION
GUIDA UTENTE
GUIA DEL USUARIO
99G
MODEL:
http://www.lge.co.kr

Advertisement

loading

  Related Manuals for LG 99G

  Summary of Contents for LG 99G

  • Page 1: Color Monitor

    Color Monitor USER GUIDE BENUTZERHANDBUCH MANUEL D'UTILISATION GUIDA UTENTE GUIA DEL USUARIO MODEL: http://www.lge.co.kr...
  • Page 2 AGENCY REGULATORY NOTICE This equipment has been tested and found to comply Compliance with the limits for a Class B digital device pursuant to Statement Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 This Class B digital apparatus meets all Canadian requirements of the Canadian Interference-Causing D.O.C. Equipment Regulations. Notice Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Products with the “CE” Marking comply with the Conformity EMC Directive(89/336/EEC) and LOW VOLTAGE Notice...
  • Page 4 Environmental Labelling of Personal Computers Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
  • Page 5 There are also other characteristics of a computer, such as energy consumption levels, that are important from the viewpoints of both the work (internal) and natural (external) environments. Since all methods of electricity generation have a negative effect on the environment (e.g.
  • Page 6: Environmental Requirements

    Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances.
  • Page 7 CFCs (freons) The relevant TCO’99 requirement states that neither CFCs nor HCFCs may be used during the manufacture and assembly of the product. CFCs (freons) are sometimes used for washing printed circuit boards. CFCs break down ozone and thereby damage the ozone layer in the stratosphere, causing increased reception on earth of ultraviolet light with e.g.
  • Page 8: Table Of Contents

    Table of Contents Introduction Features ....................Monitor Registration ......................Notice Trademark Acknowledgments ..............Important Precautions ....................On Safety On Installation ....................A4 On Cleaning ....................A4 On Repacking ....................A4 Connecting the monitor ........Connection to any IBM VGA PC compatible system Connecting to an Apple Macintosh PC ............A6 Location and Function of Controls ....................
  • Page 9: Features

    Introduction Thank you for purchasing a high resolution monitor. It will give you high resolution performance and convenient reliable operation in a variety of video operating modes. Features The monitor is a 19-inch (18.0-inch viewable ) intelligent, microprocessor based monitor compatible with most analog RGB (Red, Green, Blue) display standards, including IBM PC ®...
  • Page 10: Monitor Registration

    Serial No. Notice All rights reserved. Reproduction in any manner, in whole or in part, is strictly prohibited without the written permission of LG Electronics Inc. Trademark Acknowledgments LG is a trademark of LG Electronics Inc. IBM is a registered trademark and VGA is a trademark of International Business Machines Corporation.
  • Page 11: Important Precautions

    Important Precautions This unit has been engineered and manufactured to assure your personal safety, but improper use can result in potential electrical shock or fire hazard. In order not to defeat the safeguards incorporated in this monitor, observe the following basic rules for its installation, use, and servicing.
  • Page 12: On Installation

    Do not add accessories that have not been designed for this monitor. During a lightning storm or when the monitor is to be left unattended for an extended period of time, unplug it from the wall outlet. Do not bring magnetic devices such as magnets or motors near the picture tube.
  • Page 13: Connecting The Monitor

    Connecting the Monitor Connection to any IBM VGA PC compatible system Figure 1 shows the signal cable connections from the monitor to the Video Graphics Array (VGA) port typical in an IBM PC or PC compatible. This also applies to any graphics video card for PC-CAD or workstation that has a 15 pin high density (3 row) D-Sub connector.
  • Page 14: Connecting To An Apple Macintosh Pc

    Connecting to an Apple Macintosh PC Figure 2 shows the connection to an Apple Macintosh, using a separately purchased adapter. Power OFF both the monitor and the PC. Locate the appropriate MAC to VGA adapter block at your local computer store. This adapter changes the high density 3 row 15 pin VGA connector to the correct 15 pin 2 row connection to mate with your MAC.
  • Page 15: Location And Function Of Controls

    Location and Function of Controls Location and Function of Controls Front View Power ON/OFF button Power (DPMS) Digital Control Panel Indicator Contrast Adjustment Control Brightness Adjustment Control Rear View ID Label AC Power Socket D-Sub Signal Connector...
  • Page 16: Control Panel Function

    Control Panel Function Front Panel Controls OSD Exit Button Power(DPMS) Indicator OSD Enter Button Power On/Off Button OSD Select /Adjustment Button Brightness Contrast Control Function Use this button to start/enter and exit from OSD Enter Button the On Screen Display (OSD). If there is no OSD on the screen, One click (press) of this button will show the Main Menu.
  • Page 17: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Making adjustments to the image size, position and operating parameters of the monitor are quick and easy with the On Screen Display Control system, using only the Enter button and Adjustment Control buttons. A quick example is given below to familiarize you with the use of the controls.
  • Page 18: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selection and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the items that are shown on the Menu. OSD Adjust Description H Position...
  • Page 19: Osd Adjust

    OSD Adjust Description Pincushion (side) To correct the bowing in and out of the image. G E O M E T R Y Trapezoid 6 8 . 6 k H z / 8 5 H z E N T E R : S E L : To correct geometric distortion.
  • Page 20 OSD Adjust Description H Moire (Horizontal Moire) Reduce horizontal moire when interference patterns of dark steady wary I M A G E lines appear on your screen. The moire 6 8 . 6 k H z / 8 5 H z adjustments may affect the focus of the E N T E R : S E L :...
  • Page 21 OSD Adjust Description 9300 9300K To appear the display’s color temperature. Slightly bluish white. C O L O R 6 8 . 6 k H z / 8 5 H z 6500K 6500 E N T E R : E N T E R : S E L : S E L : To appear the display’s color temperature.
  • Page 22 OSD Adjust Description H Position (Horizontal Position) This item lets you adjust the OSD horizontal position. O S D A D J U S T 6 8 . 6 k H z / 8 5 H z E N T E R : S E L : V Position (Vertical Position)
  • Page 23 OSD Adjust Description Degauss Used to demagnetize the screen if minor color impurity occurs. M I S C E L L A N E O U S 6 8 . 6 k H z / 8 5 H z E N T E R : S E L : Information To inform users of preset and user mode...
  • Page 24: Video Memory Modes

    Video Memory Modes The monitor has 31 memory locations for display modes, 5 of which are factory preset to popular video modes. Display Modes (Resolution) Display Modes (Resolution) Horizontal Freq.(kHz) Vertical Freq.(Hz) 43.269 VESA 640 x 480 53.674 VESA 800 x 600 68.677 VESA 1024 x 768...
  • Page 25: Energy Saving Design

    Energy Saving Design This monitor complies with the EPA's Energy Star program, which is a program designed to have manufacturers of computer equipment build circuitry into their products to reduce power consumption during time of non-use. This monitor also goes into its energy saving mode if you exceed the monitor's operating limits, such as the maximum resolution of 1600x1200 or the frequency refresh rates of 30-96kHz horizontal or 50-160Hz vertical.
  • Page 26: Low Radiation Compliance (Mpr Ii)

    Low Radiation Compliance (MPR II) This monitor meets one of the strictest guidelines available today for low radiation emissions, offering the user extra shielding and an antistatic screen coating. These guidelines, set forth by a government agency in Sweden, limit the amount of emission allowed in the Extremely Low Frequency (ELF) and Very Low Frequency (VLF) electromagnetic range.
  • Page 27: Troubleshooting

    Troubleshooting Self diagnostics message. The signal cable is not connected. OUT OF FREQUENCY message appears. The frequency of the sync input is outside the operating range of the monitor. O U T O F F R E Q U E N C Y *Horizontal Frequency: 30-96kHz H F : 1 2 0 .
  • Page 28: Service

    Service Unplug the monitor from the wall outlet and refer servicing to qualified service personnel when : The power cord or plug is damaged or frayed. Liquid has been spilled into the monitor. The monitor has been exposed to rain or water. The monitor does not operate normally following the operating instructions.
  • Page 29: Specifications

    Specifications Sync Signal Types Type H. Sync V. Sync Green Separate Sync H. Sync V. Sync Composite Sync H/V Sync Sync On Green H/V Sync (N.C : No Connection) Signal Connector Pin Assignment Signal(D-Sub) Signal(D-Sub) Green Ground Blue Ground Ground Self-Test Hori.
  • Page 30 : 10% to 90% non-condensing Storage condition Temperature : 0˚C to 60˚C Humidity : 5% to 90% non-condensing Information in this document is subject to change without notice and does not represent a commitment on the part of LG Electronics Inc.
