Color Monitor USER GUIDE BENUTZERHANDBUCH MANUAL D'UTILISATION GUIDA UTENTE GUIA DEL USUARIO MODEL : StudioWorks 57T5... -
Page 2: Fcc Compliance Statement
- Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by LG Electronics Inc. for compliance could void the user's (or your) authority to operate the equipment. Only peripherals (digital input/output devices, terminals, printers, etc.) certified to comply with the Class B limits may... -
Page 3: Table Of Contents
Table of Contents Introduction ..................1 Monitor Registration................2 Important Precautions............... 3 Installing the Tilt/Swivel Base............5 Installation..................6 Location and Function of Controls ............ 7 Control Panel Function ..............8 On Screen Display (OSD) Control Adjustment ......... 9 On Screen Display(OSD) Selection and Adjustment ......10 Power Management System.............14 Video Memory Modes ...............15 Low Radiation Compliance (MPR II)..........17... - Page 4 184 Kongdan-dong, Kumi-city Kyoungbuk, Korea declare under our sole responsibility that the product The model name of color monitor : StudioWorks 57T5 Trade name : GoldStar to which this declaration relates is in conformity with the following standard or other normative documents:...
-
Page 5: Introduction
Introduction Thank you for purchasing a GoldStar color monitor. This monitor supports OSD and DDC2B. It will give you high resolution performance and operation in a variety of video operating modes. It is compatible with standard PC type personal computers. The 15-inch (13.8 inches viewable) flat Square Tube design is excellent for use in a Windows or desktop publishing environment, where smaller screen sizes result in images difficult to see easily. -
Page 6: Monitor Registration
Serial No. Notice All rights reserved. Reproduction in any manner, in whole or in part, is strictly prohibited without the written permission of LG Electronics Inc. Trademark Acknowledgments GoldStar is a trademark of LG Electronics Inc. IBM is a registered trademark and VGA is a trademark of International Business Machines Corporation. -
Page 7: Important Precautions
Important Precautions This unit has been engineered and manufactured to assure your personal safety, but improper use can result in potential electrical shock or fire hazard. In order not to defeat the safeguards incorporated in this monitor, observe the following basic rules for its installation, use, and servicing. - Page 8 Keep children from dropping or pushing objects into the monitor's cabinet openings. Some internal parts carry hazardous voltages. Do not add accessories that have not been designed for this monitor. During a lightning storm or when the monitor is to be left unattended for an extended period of time, unplug it from the wall outlet.
-
Page 9: Installing The Tilt/Swivel Base
Installing the Tilt/Swivel Base Turn off the equipment and all attached options. Carefully set the monitor face-down with the underside facing you. Installation 1.Align the hooks on the tilt/swivel stand with the matching slot on the base (underside of the monitor). The open hooks of the stand should face the front of the monitor. -
Page 10: Installation
Installation The supply voltage is marked on the ID label located on the rear panel of the monitor. If your local voltage is different, do not use the monitor and contact your supplier before using the display. Connections To connect your monitor after the video adapter is properly installed: 1. -
Page 11: Location And Function Of Controls
Location and Function of Controls Front View Power ON/OFF Button OSD ON/OFF Power (DPMS) Indicator Enter button Contrast OSD Select/Adjustment Control Brightness Rear View ID Label D-Sub Signal Cable AC Power Socket... -
Page 12: Control Panel Function
Control Panel Function Power Indicator Power ON/OFF OSD ON/OFF Enter Button Button Brightness Contrast OSD Select /Adjust Control Increase Increase Decrease Decrease Buttons on the front of the monitor allow you to adjust image easily through an OSD menu. As you choose controls, the selected icon shows you what the chosen control will do. -
Page 13: On Screen Display (Osd) Control Adjustment
OSD ON/OFF Enter button Use this button to start/enter and exit from the On Screen Display (OSD). If there is no OSD on the screen, One press of this button will show the Main Menu. To remove the display, wait 10 seconds. OSD Select/Adjustment Control Use this buttons for selecting (highlighting) an OSD icon to be adjusted. -
Page 14: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selection and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the items that are shown on the Menu. OSD Adjust Description Horizontal Position... - Page 15 OSD Adjust Description Trapezoid To correct geometric distortion. Makes the screen image narrower at T R A P E Z O I D the top. 1 0 2 4 X 7 6 8 / 8 5 H z Moves the screen image wider at the top. A D J : M E N U : Rotate Screen...
-
Page 16: Osd Adjust
OSD Adjust Description Color To select color temperature, 9300 K/ 7200 K/ user. C O L O R Decreases the amount of color in the 9 3 0 0 7 2 0 0 U S E R M E N U : image. - Page 17 OSD Adjust Description Information To inform users of preset and user mode data. I N F O R M A T I O N 1 0 2 4 X 7 6 8 / 8 5 H z U S E R M O D E : 5 P R E S E T M O D E : 6 S E L : M E N U :...
-
Page 18: Power Management System
Power Management System This monitor incorporates new circuitry for lowering energy usage during idle time, following the Display Power Management Signalling (DPMS) guide lines of the Video Electronics Standards Association (VESA), and is certified as exceeding the EPA's Energy Star program for reduced power usage. -
Page 19: Video Memory Modes
Video Memory Modes This multi-synchronous auto-scanning monitor can automatically detect and display several video modes falling within the monitor's scanning range of 30-69kHz Horizontal and 50-110Hz Vertical. In the PC area, this relates to a maximum flicker free usable resolution of 1280 x 1024 at a non-interlaced refresh rate of 60Hz Vertical. - Page 20 A note about the video memory modes: There is a total of 31 video memory modes, generally more modes than you will use at any one time. Of these 31 modes, 6 are permanent, factory fixed modes that cannot be changed. The remaining 25 modes are left blank (empty).
-
Page 21: Low Radiation Compliance (Mpr Ii)
Low Radiation Compliance (MPR II) This monitor meets one of the strictest guidelines available today for low radiation emissions, offering the user extra shielding and an anti- static screen coating. These guidelines, set forth by a government agency in Sweden, limit the amount of emission allowed in the Extremely Low Frequency (ELF) and Very Low Frequency (VLF) electromagnetic range. -
Page 22: Troubleshooting
Troubleshooting Symptom: SELF DIAGNOSTICS message. Possible causes: The signal cable is not connected. Symptom: OUT OF FREQUENCY message appears. Possible causes: The frequency of the sync input is outside the operating range of the monitor. O U T O F F R E Q U E N C Y HORZ: 30kHz-69kHz H F : 1 2 0 . -
Page 23: Service
Service 1. Unplug the monitor from the wall outlet and refer servicing to qualified service personnel when : The power cord or plug is damaged or frayed. Liquid has been spilled into the monitor. The monitor has been exposed to rain or water. The monitor does not operate normally following the operating instructions. -
Page 24: Specifications
Specifications Sync Signal type Type Green video H. sync V.sync Separate sync Video H. sync V. sync Signal Connector Pin Assignment Separate Sync Green Blue Ground Self-Test Red Ground Green Ground Blue Ground Ground Ground Horiz.Sync Vert.Sync... - Page 25 360 x 390 x 328 mm/14.2 x 15.4 x 12.9 inches Weight ( net ) 13.5 (29.8 lbs) Information in this document is subject to change without notice and does not represent a commitment on the part of LG Electronics Inc.
-
Page 26: Environmental Labelling Of Personal Computers
FOR THE UNITED STATES AND CANADA LG Electronics U.S.A., Inc. will repair or at its option replace, without charge, your product which proves to be defective in material or workmanship under normal use, during the warranty period listed below from the date of original purchase.
