- Page 1 226-408 Winthrop Ceiling Fan Owner’s Manual Winthrop Ventilador de Techo de 1,32 Manual del Propietario...
- Page 2 Winthrop by Hampton Bay ®...
-
Page 3: Table Of Contents
52” Winthrop Thank you for purchasing our ceiling fan. This product has been manufactured with the highest standards of safety and quality. Ceiling Fan by Hampton Bay Date Purchased Table of Contents Store Purchased Safety Rules ....1 226-408 Unpacking Your Fan . -
Page 4: Safety Rules
Safety Rules - Read and Save These Instructions To reduce the risk of electric shock, insure electricity has been turned off After making electrical connections, spliced conductors should be turned at the circuit breaker or fuse box before beginning. upward and pushed carefully up into outlet box. The wires should be spread apart with the grounded conductor and the equipment-grounding All wiring must be in accordance with the National Electrical Code conductor on one side of the outlet box and ungrounded conductor on the... -
Page 5: Unpacking Your Fan
Unpacking Your Fan Unpack your fan and check the contents. You should have the following items: Set of blades (5) Switch housing Blade Attachment Hardware (16 Screws with Fiber Washers) Canopy assembly Light kit Ball/downrod assembly Glass shade Electrical Hardware Coupling cover Pull chains and fobs (2) (3 Plastic Wire Nuts) -
Page 6: Installing Your Fan
Installing Your Fan Provide Strong Support Tools Required Figures 1~3 are examples of different ways to mount the outlet box. Phillips screwdriver, straight slot screwdriver, step ladder and wire cutters. Recessed Ceiling Outlet Box Mounting Plate Mounting Options Figure 3 Outlet Box Note: You may need a longer downrod to If there isn't an existing UL listed mounting box,... -
Page 7: Hanging The Fan
Hanging the Fan Align the holes at the bottom of the downrod with the holes in the coupling on top of the Motor Wires motor housing (Figure 6). Carefully insert the REMEMBER to turn off the power. Follow the Pin in Locked Ball/Downrod clevis pin through the holes in the collar and Positioon... -
Page 8: Installing Fan To The Electrical Box
Installing Fan to UL Listed Outlet Box the Electrical Box WARNING 120V Wires TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR OTHER PERSONAL INJURY. MOUNT Groove FAN ONLY TO AN OUTLET BOX OR SUPPORTING SYSTEM MARKED ACCEPTABLE FOR FAN Ceiling Mounting SUPPORT AND USE THE MOUNTING SCREWS Figure 8... - Page 9 Making the Electrical WARNING SUPPLY CIRCUIT CHECK TO SEE THAT ALL CONNECTIONS ARE Connections TIGHT, INCLUDING GROUND, AND THAT NO BARE WIRE IS VISIBLE AT THE WIRE NUTS. EXCEPT FOR THE GROUND WIRE. Ground REMEMBER to disconnect the power. Conductor WARNING If you feel you do not have enough electrical Outlet Box...
-
Page 10: Attaching The Fan Blades
Finishing the Fan Screws with Fiber Blade Washers Outlet Box Installation Ceiling Mounting Tuck connections neatly into ceiling outlet Bracket box. Screw Slide the canopy up to mounting bracket and place the key hole on the canopy over the Canopy Blade Arm screw on the mounting bracket, turn canopy Figure 11... -
Page 11: Blade Balancing
Blade Balancing The following procedure should correct most fan wobble. Check after each step. Touching Ceiling Check that all blade and blade arm screws are secure. Most fan wobble problems are caused when blade levels are unequal. Check this level by selecting a point on the ceiling above the tip of one of the blades. -
Page 12: Installing The Light Kit
Installing the Light Kit Installing the Switch Housing CAUTION BEFORE STARTING INSTALLATION, DISCON- Remove 1 of the 3 screws from the mounting NECT THE POWER BY TURNING OFF THE CIRCUIT BREAKER OR REMOVING THE FUSE ring and loosen the other 2 screws. (Do not AT FUSE BOX. -
Page 13: Operating Your Fan
Operating Your Fan Warm weather - (Counter-Clockwise direction) Turn on the power and check the operation of the fan. The pull chain controls the fan speed as A downward air flow creates a cooling effect as follows: shown in Figure 16. This allows you to set your air 1 pull - High conditioner on a higher setting without affecting 2 pulls - Medium... -
Page 14: Care Of Your Fan
Care of Your Fan Troubleshooting Here are some suggestions to help you maintain PROBLEM SOLUTION your fan. Fan will not start Check main and branch circuit fuses or breakers. Because of the fan's natural movement, some Check line wire connections to the fan and switch wire connections may become loose. -
Page 15: Specifications
Specifications FAN SIZE SPEED VOLTS AMPS WATTS N.W. G.W. C.F. 0.22 1357 9.0 kgs 10.24 kgs 52” MED. 2.3' 0.39 3025 (19.82 lbs) (22.55 lbs) HIGH 0.59 4920 These are approximate measures. They do not include Amps and Wattage used by the light kit. -
Page 16: Warranty Information
Hampton Bay Lifetime Limited Warranty (lifetime warranty on motor) The Hampton Bay warrants the fan motor to be free from defects in workmanship and material present at time You must present a copy of the original purchase receipt to obtain warranty of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser.
