PARTS LIST
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE
IEC SYMBOL
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN
! ! !
BE OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN
THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE
THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO
CAUTION :
Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4W carbon and chip type and 0 ohm chip resistors.
Regular type capacitors are less than 50V and less than 1000µF of Ceramic and chip type and Electrolytic type.
PACKING & ACCESSORIES
REF.NO.
PART NO.
645 057 5273 ADAPTOR AC/DC,VDE
645 057 7598 BLISTER BOTTOM(SP)
645 057 7581 BLISTER TOP(SP)
645 063 8688 CARD BLISTER CLAMSHE(SP)
645 063 8619 GIFT BOX(990/XE)
645 063 8602 GIFT BOX,
645 057 5563 INSTER PAPER(990/XE)
645 057 5563 INSTER PAPER(990A/XE)
645 063 8640 INSTRUCTION MANUAL,
645 063 8626 INSTRUCTION MANUAL,
645 063 8633 INSTRUCTION MANUAL,
645 057 5457 POLYBAG,EARPHONE(XE)
645 057 5464 POLYBAG,
645 057 5464 POLYBAG,I/B(XE)
645 057 7475 POLYBAG,PACKING(SP)
645 063 8589 POLYBAG,UNIT(SP)
645 057 7604 SPEAKER BOX,1PAIR(990A/XE)
645 063 8480 STEREO EARPHONE
CABINET & CHASSIS
REF.NO.
PART NO.
1
645 063 8275 ASSY CD LID
2
645 057 5419 CD DOOR PIN
3
645 063 8558 BUTTON SET L,REPEAT
4
645 063 8565 BUTTON SET R,PLAYMODE
5
645 063 8541 BUTTON FUNCTION,
6
645 057 5600 CD DOOR SPRING,STEEL
7
645 063 8497 CABINET TOP
8
645 057 7451 KNOB OPEN,DOOR
9
645 057 5402 CD DOOR LOCKER
10
645 057 5426 CD DOOR LOCK SPRING,STEEL
11
645 057 5594 RUBBER CUSHION,
14
645 057 5235 BATT CONTACT SPRING+
15
645 057 5310 BATT LID
16
645 057 4993 ASSY CABINET BOTTOM
17
645 057 5587 CD MECHANISM
FIXING PARTS
REF.NO.
PART NO.
Y01
645 057 5433 SCR 1.7X4,CD BD
Y02
645 057 5440 SCR 2X10,TOP CAB TO BTM CAB
DISPLAY P.W.BOARD ASSY
REF.NO.
PART NO.
71
614 325 7691 ASSY,PWB,DISPLAY
CN400
645 057 5204 14P FILM CABLE CON.
D0401
645 016 8956 SW DIODE 1N4148
D0402
645 016 8956 SW DIODE 1N4148
D0403
645 016 8956 SW DIODE 1N4148
LCD01
645 057 5259 LCD DISPLAY
645 057 5242 CONNECTION PLATE
PRODUCT SAFETY NOTICE
DESCRIPTION
FOR UNIT&SPK.BOX(990A/XE)
1AD6P1P1798—(990/XE)
1AD6P1P1908—(SP)
1AD6P1P1910—(990A/XE)
I/B & WARRANTY CARD(SP)
DESCRIPTION
CLEAR/TRANS/ABS
FOR CD MECHA
DESCRIPTION
DESCRIPTION
, USE ONLY THE REPLACEMENT PARTS
! ! !
CD MAIN P.W.BOARD ASSY
REF.NO.
PART NO.
72
614 328 3836 ASSY,PWB,CD MAIN
C0102
403 056 8905 POLYESTER 1000P M 50V
CN101
645 057 5167 6P WAFER
CN401
645 057 5181 14P FILM CABLE R/A C
or
645 057 5174 14P FILM CABLE R/A C
D0101
645 016 9250 RECTIFIER
D0102
645 016 9250 RECTIFIER
D0103
645 057 5099 DIODE 1N5818
D0104
645 016 8956 SW DIODE 1N4148
D0400
645 016 8956 SW DIODE 1N4148
D0404
645 016 8956 SW DIODE 1N4148
D0405
645 016 8956 SW DIODE 1N4148
IC101A
645 057 5020 IC FAN8038B
IC201A
645 057 5037 IC SIL9223B02-TORO
IC301A
645 057 5044 IC S5L9286F02-TORO
IC401A
645 057 5051 IC S3C70F4X11-SOB4
IC601A
645 057 5013 IC FAN7000D
J0101
645 027 1434 DC JACK 3PINS(DC-014)
J0302
645 026 8663 STEREO JACK EJS-3-0935G
L0101
645 057 5136 CHOKE COIL
L0102
645 057 5143 CHOKE COIL
L0103
645 057 5129 CHOKE COIL
CN201A
645 057 5198 16P FILM CABLE R/A C
Q0102
645 057 5068 TR 2SA1585SR
Q0103
645 057 5075 TR 2SC4115SR
Q0104
645 057 5075 TR 2SC4115SR
Q0201
645 057 5082 TR 2SA933SR
SW402
645 057 5150 SW TACT
VR601
645 057 5112 ROTARY VOL,R1016G21B1-A50K
X0401
645 020 3572 CERAMIC RESONATOR,
645 057 5211 BATT CONTACT SPRING
645 057 5228 BATT CONTACT SPRING
- 2 -
DESCRIPTION
MXW040-TF01
