ASSEMBLY AND OPERATING INSTRUCTIONS
MIRAGE 605
OUTDOOR STAINLESS STEEL GAS GRILL
DANGER
NOTICE TO INSTALLER:
IF YOU SMELL GAS:
• Shut off gas to the appliance.
LEAVE THESE INSTRUCTIONS
• Extinguish any open flame.
WITH THE GRILL OWNER FOR
• Open lid.
FUTURE REFERENCE
• If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department
DO NOT TRY TO LIGHT THIS APPLIANCE WITHOUT READING LIGHTING INSTRUCTIONS
SECTION OF THIS MANUAL
NAPOLEON APPLIANCE CORPORATION.,
214 BAYVIEW DR., BARRIE, ONTARIO, CANADA L4N 4Y8 PHONE: (705)726-4278
FAX: (705)725-2564 EMAIL: care@nac.on.ca WEB SITE: www.napoleongrills.com
N415-0157 APR 11/07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIRAGE 605 and is the answer not in the manual?

Questions and answers

Related Manuals for Napoleon MIRAGE 605

Summary of Contents for Napoleon MIRAGE 605

  • Page 1 ASSEMBLY AND OPERATING INSTRUCTIONS MIRAGE 605 OUTDOOR STAINLESS STEEL GAS GRILL DANGER NOTICE TO INSTALLER: IF YOU SMELL GAS: • Shut off gas to the appliance. LEAVE THESE INSTRUCTIONS • Extinguish any open flame. WITH THE GRILL OWNER FOR • Open lid.
  • Page 2 Any damages to the gas grill due to weather damage, hail, rough handling, damaging chemicals or cleaners will not be the responsibility of NAPOLEON. The bill of sale or copy will be required together with a serial number and a model number when making any warranty claims from NAPOLEON. The warranty registration card must be returned within fourteen days to register the warranty or you can register on-line at www.napoleongrills.com.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS WARNING WARNING Do not store or use gasoline or other Failure to follow these instructions could flammable liquids or vapor in the vicinity of result in property damage, personal this or any other appliance. An L.P. cylinder injury or death. Read and follow all not connected for use must not be stored in warnings and instructions in this manual the vicinity of this or any other appliance.
  • Page 4 CYLINDER SPECIFICATIONS/GAS HOOK UP CAUTION This gas barbecue is certified under Canadian and American national standards, CAN/CSA-1.6-2005 and ANSI Z21.58 -2005 respectively for outdoor gas grills and should be installed to conform with local codes. In absence of local codes, install to the current CAN/CGA-B149.1 Propane Installation Code in Canada or to the National Fuel Gas Code, NFPA54/ANSI Z223.1 in the United States.

  • Page 5: Lighting Instructions

    LIGHTING INSTRUCTIONS OPEN LID. ENSURING BURNER CONTROLS ARE IN THE OFF POSITION, TURN ON THE GAS SUPPLY VALVE. LEFT REAR CENTER RIGHT SIDE INFRARED BURNER BURNER BURNER BURNER BURNER BURNER REAR BURNER LIGHTING SIDE BURNER LIGHTING MAIN BURNER LIGHTING (ROTISSERIE BURNER) 1.

  • Page 6: Operating The Grill

    Cooking meat with a high degree of fat content, may create flare-ups. Either trim some fat or reduce temperatures to prevent this. Should a flare-up occur, move food away from flames, reduce heat. Leave the lid open. See 'Your All Season Grill' cookbook by Napoleon for more detailed instructions. DIRECT COOKING: Place food to be cooked on the grill directly over the heat.

  • Page 7: Infrared Heat

    The glowing briquettes emit infrared energy to the food being cooked, with very little drying effect. Any juices or oils that escape from the food drip down onto the charcoal and vaporize into smoke giving the food its delicious grilled taste. The Napoleon infrared burner cooks in the same way.

  • Page 8: Maintenance/Cleaning Instructions

    The pan should be scraped out with a putty knife or scraper, and all the debris should be scraped into the disposable grease tray. This tray should be replaced every two to four weeks, depending on gas grill usage. For supplies, see your Napoleon Gas Grill dealer.
  • Page 9 Porcelain enamel components must be handled with additional care. The baked on enamel finish is glass like, and will chip if struck. Touch-up enamel is available from your Napoleon Gas Grill dealer. Exterior grill surfaces should be cleaned while warm to the touch, with warm soapy water. To clean stainless surfaces, use a stainless steel cleaner or a non- abrasive cleaner.

  • Page 10: Troubleshooting

    Allow burner to cool and inspect very closely for cracks. If Cracked ceramic tile. any cracks are found, contact your authorized Napoleon dealer for ordering a replacement burner assembly. Leaking gasket surrounding the Contact your authorized Napoleon dealer for instructions ceramic tile, or a weld failure in on ordering a replacement burner assembly.

  • Page 11: Ordering Replacement Parts

    -costs for service calls to diagnose problems -discoloration of stainless steel parts -part failure due to lack of cleaning and maintenance, or use of improper cleaners (ovencleaner). NAPOLEON APPLIANCE CORPORATION ACCESSORIES / PARTS ORDER FORM FAX TO: 1-705-727-4282 PLEASE PRINT CLEARLY...

  • Page 12: Assembly Instructions

    ASSEMBLY INSTRUCTIONS CAUTION: During unpacking and assembly it is recommended that you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners may be sharp and can cause cuts if handled incorrectly during assembly.
  • Page 13 2 x N430-0002 MAGNET CATCH Magnet Installation Snap magnets into slots in front of bottom shelf. 16 X 16 X N570-0073 (1/4-20 X 3/8”) N450-0027 (1/4-20) Caster Installation Attach (4) casters using (4) 1/4 - 20 X 3/8” screws and (4) 1/4-20 lock nuts for each caster.

  • Page 14: Left And Right Cart Panel Installation

    PROPANE ONLY Propane Tank Ring Installation Insert propane tank ring into slots in bottom shelf as shown. Fold tabs over to secure in place. N570-0080 (#14 X 1/2") Left and Right Cart Panel Installation Install end cart panels ensuring slots in panel are to the top, rest panel on bottom shelf and line up holes.
  • Page 15 N570-0080 (#14 X 1/2") Rear Cart Panel Installation Fit rear cart panel between the two end panels, ensure large hole in panel is to the bottom right hand corner as illustrated. Fasten using (6) #14 x 1/2” screws, three on each side. Condiment Basket / Propane Tank Mount Installation Rotate basket slightly to allow wire to enter the holes in the side panel.
  • Page 16 2 x N430-0002 N570-0080 (#14 X 1/2") MAGNET CATCH Front Cabinet Support Installation Fasten top rail assembly to the front of side panels using (4) #14 x 1/2” screws. For ease of installation, start all screws before tightening completely. Attach magnet brackets to bottom of top rail using (2) #14 x 1/2”...

  • Page 17: Grill Head Installation

    N570-0073 (1/4-20 x 3/8”) Grill Head Installation PROPANE ONLY - To avoid assembly difficulties, prior to mounting the grill head, remove zip tie holding regulator up under control panel. This was installed at the factory to protect the regulator hose during shipping and is no longer re- quired.

  • Page 18: Side Shelf Installation

    10 x N570-0073 (1/4-20 x 3/8") Assembling End Caps to Side Shelf / Side Burner Peel protective coating from side shelf / side burner. Attach corresponding end cap as shown using (5) 1/4-20 x 3/8” screws. Bend Tabs on front of shelf up with a flat head screw driver, insert screw through tab and into end cap.

  • Page 19: Side Burner Installation

    N160-0016 N735-0001 (1 1/16” insulated washer) N570-0082 (1/4-20 x 5/8") Side Burner Installation Insert (4)1/4-20 x 5/8” screws through washers into threaded holes in side of base. Do not tighten all the way. Slide assembled side burner over screw heads and finish tightening.
  • Page 20 N570-0080 (#14 X 1/2") Front Fascia Installation Attach front fascia to center of support beam. Slide top of fascia up under sup- port beam as shown, resting bottom on bottom shelf. Fasten with (4) #14 x 1/2” screws. PROPANE ONLY Tank Inhibitor Rod Installation Insert one end of tank inhibitor rod into hole in back panel and other end into hole in back side of fascia as illustrated.
  • Page 21 16 X N570-0080 (#14 X 1/2") Assembling Side Enclosures Take (1) side enclosure panel and place on solid surface. Fasten top and bottom to side using (8) #14 x 1/2” screws. Repeat for other side. 12 X N570-0080 (#14 X 1/2") Side Enclosure Installation Insert (2) #14 x 1/2”...
  • Page 22 8 x N120-0010 THREAD CAPS Thread Cap Installation Attach the supplied thread caps to the threads of the screws inside your grill cabinet as illustrated, both top and bottom. 4 x N430-0002 6 x N105-0011 DOOR BUSHING MAGNET CATCH Bushing and Magnet Installation Insert bushing into either end of bottom shelf and into either end of side enclo- sures both top and bottom.

  • Page 23: Cabinet Door Installation

    4 x N570-0073 4 X N735-0003 (1/4-20 X 3/8") (1/4” LOCK WASHER) Cabinet Door Installation Install door handle onto front of door using (2) 1/4-20 x 3/8” screws and (2) 1/ 4” washers per door. Insert pivot rod through hole on inside top of door. Holding door in one hand, direct pivot rod into hole in underside of front beam.
  • Page 24 4 x N570-0073 4 X N735-0003 (1/4-20 X 3/8") (1/4” LOCK WASHER) Side Enclosure Door Installation Install door handle onto front of door using (2) 1/4-20 x 3/8” screws and (2) 1/4” lock washers per door. Insert pivot rod through hole on inside top of door. Holding door in one hand, direct pivot rod into top bushing on the enclosure.
  • Page 25 3 X N305-0057 3 X N305-0060 1 X N520-0024 Sear Plate,Grill and Warming Rack Installation. Insert sear plates into base, positioning one over each tube burner with slots down to allow drippings to travel through. Rest warming rack on brackets inside hood, and insert grills into unit so they sit on back and front lip of base.

  • Page 26: Grease Tray And Holder Installation

    Grease Tray and Holder Installation Clip the wire grease tray holder into the two holes located in the center of the back panel. Place the aluminum grease tray into the grease tray holder. Drip Pan Installation Slide drip pan into rear of base as shown. Ensure drip pan rides along rails on bottom of base.
  • Page 27 PROPANE ONLY CLIP HOSE TO SIDE PANEL USING HOSE RETAINER CLIP SUPPLIED NATURAL GAS ONLY 1x105-0002 INSTALL BUSHING INTO CLIP HOSE TO SIDE PANEL USING HOSE BACK PANEL RETAINER CLIP SUPPLIED THIS MUST BE PERFORMED BY A LICENSED GAS FITTER. DO NOT USE PIPE DOPE OR TEFLON TAPE ON THIS CONNECTION...

  • Page 28: Leak Testing Instructions

    LEAK TESTING INSTRUCTIONS DO NOT USE A FLAME TO LEAK TEST. LEAK TESTING: This must be done before initial use, annually and whenever any gas components are replaced or serviced. No smoking while performing this test, and remove all sources of ignition. See Leak Testing Diagram for areas to check. 1.

  • Page 29: Parts List

    PARTS LIST Item Part # Description N135-0024K left side lid casting N385-0129 NAPOLEON logo W450-0005 logo spring clips N510-0010 black silicone lid bumper N685-0003 temperature gauge N051-0004 temperature gauge bezel N335-0044 stainless steel lid insert N585-0042 heat shield lid N010-0517...
  • Page 30 PARTS LIST Item Part # Description N725-0037 rear burner valve N475-0183P left / right side panel cabinet enclosure N555-0018 door pivot rod N010-0506 cart door assembly N325-0048 door handle N570-0073 door handle screw s N590-0150P bottom shelf N010-0515 front cabinet support N475-0189P rear cart panel N585-0041P...
  • Page 32 NOTES...
