Summary of Contents for Tecnik TKL 9290
- Page 1 TKL 9290 WASHER DRYER Instructions manual...
-
Page 2: Instructions For The Installation
INSTRUCTIONS FOR THE INSTALLATION ATTENTION: The washing machine must be trucked from the left hand side only (see packing label). Remove the thermore- tractable film. 1 – Open the porthole door and take out the plastic bag con taining the accessories. Lay down the machine on the left side leaning it on the corner, remove the packing base, and take out the two tub inside supports made by foamed part. -
Page 3: Cleaning And Maintenance
CLEANING AND MAINTENANCE This washing machine does not require any particular maintenance. At the end of each wash it is recommended to leave the door open so that air will circulate and dry the interior of the machine. The external part of the machine should never be cleaned with abrasive detergents since this would ruin the enamel coating as well as the synthetic parts. -
Page 4: Installation Directions
INSTALLATION DIRECTIONS POSITIONING After your washing machine has been placed in the desired location, level it by means of the front left foot, them the COUNTERNUT counternut must be blocked by means of the special key purposely provided. Warning: if the machine is not perfectly SUPPLIED ADJUSTABLE FEET leveled, it will be unstable, noisy and may lead to... -
Page 5: Electrical Connection
INSTALLATION DIRECTIONS ELECTRICAL CONNECTION Make sure that the electrical system can support the maximum current as indicated on the rating plate located on the rear side of the machine. The washing machine should be connected to an electrical outlet with ground, as prescribed by law. This outlet must be easily accessible after the, installation of the washing machine. -
Page 6: Power Indicator
CONTROL PANEL To become familiar with your machine functions, compare the symbols on the control panel with those described below. ON/OFF By pressing this button the machine turns on and executes the set wash cycle. It is used to turn the washing-dryer on and off. POWER INDICATOR when lit it indicates that the washer-dryer is electrically energized HALF-LOAD/DRYING... -
Page 7: Timer Dial
CONTROL PANEL TIMER DIAL Used to select the wash cycles and to display them during operation. To select the cycles, turn the dial clockwise until the mark coincides with the seleceted cycle. WARNING: Do not turn the timer dial while the machine is energized. Do not turn the timer dial counterclockwise. -
Page 8: Controls Panel
CONTROLS PANEL SORTING CLOTHES Each of the following groups should be sorted and washed separately according to the cycle specified in the cycle table : - White and resistant coloured fabrics - non-resistant coloured fabrics - delicate fabrics (silk/rayon, nylon, etc.) - wool The washing/drying machine is designed to WASH only, to DRY only or to WASH + DRY, for instructions on how to dry clothes, read the “DRYING”... - Page 9 FUNCTIONS AND PREPARATION FOR WASHING WARNINGS: Always use the drying cycle best suited to the fabric to be dried. Only dry articles washed with water in the machine. The following articles must not be dried in the machine: - Clothes that have been dry-cleaned with chemical products. - Wool or wool mixture clothes that shrink in hot water.
-
Page 10: Cotton And Linen Cycles
Wash cycle table COTTON AND LINEN CYCLES Cycles Wash cycle Trays Thermostat Type of clothing description position to be used Description Very dirty To wash resistant 1-2 (3-4) 40° - 95° Prewash/ Wash from 40° to fabrics and clothes 95° C - Rinse Intermediate and final spin Dirty To wash resistant... -
Page 11: Wool Cycle
WOOL CYCLE Cycles Trays Thermostat Wash cycle Type of clothing position to be used description Description ❄ ❄ Wool To wash fabrics 2-(4) - 40° Wash from to 40° C and clothes that Rinse - require slow drum Stops with water in drum spinning Rinse To rinse fabrics... - Page 13 — Make holes on the wooden door according to the instructions overleaf. — take hinges (A) out of the bag and fix them to the door. — Take jack (B); its support (C) and fix one to the other by means of screws (G). —...
- Page 16 YOUR TECNIK GUARANTEE READ CAREFULLY Your new appliance is guaranteed for 12 months against electrical/mechanical breakdown due to faulty manufacture. This guarantee does not apply to: a) Any faults which occur due to accidental damage, installation or misuse of the appliance.
