Planning Your System - Infinity TSS 3-IN-1 Owner's Manual

I
NTRODUCTION
Infinity Total Solutions
The Infinity Total Solutions TSS 3-in-1 loudspeaker is actually
three discrete loudspeakers built into a single enclosure.The
TSS 3-in-1 incorporates the front left, center and right channels
of a home theater system. Simply add a Total Solutions powered
subwoofer and satellites for the surround channels to complete
a high-performance home entertainment speaker system.The
TSS 3-in-1 uses identical drivers to provide exceptional dialogue
reproduction and a seamless transition between the front
channels.The horizontal design allows for maximum placement
flexibility.
About This Guide
Please read this guide completely before connecting and
operating the TSS 3-in-1 center channel speaker. Maximum
performance is dependent upon following these instructions, as
well as those in the owner's manuals of associated components
in your home theater system. Save these instructions for future
reference.
Unpacking the Speaker
Finish unpacking the speaker and check the contents. If you
suspect damage from transit, report it immediately to your
dealer. Keep the shipping carton and packing materials for
future use.
Contents
Please verify that the package contains the following items:
(1) TSS 3-in-1 speaker
Part A
Part B
(2) Wall-mount end caps
(attached to TSS 3-in-1)
(1) Speaker base
(1) Wall bracket with wall bracket cover
TSS 3- -1
2
IN
™
(1) Allen
wrench
P Y S
LANNING OUR YSTEM
Before deciding where to best place your speakers, survey your
room and study Figures 1 and 2. The TSS 3-in-1 should be placed
directly above or below the TV.
TSS 3-in-1
(above or below TV)
Couch
Left
Surround Channel
(not included)
Figure 1. In this overhead view of a typical installation, the
TSS 3-in-1 is used to reproduce the front channels, and satellite
speakers are used to reproduce sound for the surround channels.
The powered subwoofer provides bass for movie effects and for
music.
Placement
Figure 2.This example shows the TSS 3-in-1 being placed on
top of a television.The speaker can also be placed below the
television and tilted up (see Figure 3).
NOTE: If placing the TSS 3-in-1 on top of a television, be sure
the top of the television has a flat surface large enough to
accommodate the speaker base. Do not set the speaker on top
of any surface without using the included base.
Infinity
Subwoofer
(not included)
Right
Surround Channel
(not included)
Speaker base
