IMPORTANT MANUAL
REPAIR PARTS MANUAL
MODEL:
PO19542LT
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan.com
532 44 06-24
DO NOT THROW AWAY
02494
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so
can re sult in serious in ju ry.
Advertisement
Table of Contents
Related Manuals for Poulan Pro PO19542LT
Summary of Contents for Poulan Pro PO19542LT
- Page 1 Read this Man u al and follow all Warnings MODEL: and Safety Instructions. Fail ure to do so can re sult in serious in ju ry. PO19542LT LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan.com 532 44 06-24...
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “TRACTOR” • MODEL NUMBER - “Po19542lt (96012012100)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 SCHEMATIC SCH03 BATTERY STARTER FUSE AMMETER (OPTIONAL) WHITE CLUTCH / BRAKE ATTACHMENT CLUTCH (PEDAL UP) (CLUTCH OFF) BLACK BLACK SEAT SWITCH (NOT OCCUPIED) BLACK BLACK GRAY GRAY REVERSE SWITCH... -
Page 4: Electrical
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 ELECTRICAL... - Page 5 REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 ELECTRICAL PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 17 66-89 Box Battery 532 17 61-38 Switch Interlock...
-
Page 6: Chassis
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 CHASSIS Chassis-stlt_Alpha_18... - Page 7 REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 CHASSIS KEY PART DESCRIPTION 532 17 46-19 Chassis 532 17 65-54 Drawbar, Stretch 532 15 52-72 Bumper, Hood/Dash 532 43 33-53 Dash 872 14 06-08 Bolt, Carriage 3/8-16 x 1...
-
Page 8: Drive
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 DRIVE drive-stlt_Peerless_fender_13_r1... -
Page 9: Drive
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 DRIVE PART PART DESCRIPTION DESCRIPTION – – – – – – Transaxle Peerless 206-545C 532 17 54-10 Engine Pulley (165670) (Order parts from trans- 532 17 39-37 Bolt Hex... -
Page 10: Engine
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-stlt_bs_23... -
Page 11: Engine
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 ENGINE PART DESCRIPTION 532 17 05-51 Control Th/ch Flag 817 72 04-08 Screw Hex Thd Cut 1/4-20 x 1/2 – – – – – – Engine, B&S 31P677-4373-G1 (440009) (Order parts from engine manufacturer) 532 13 73-52 Muffler Exhaust B&S... -
Page 12: Steering
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 STEERING Steering-lt_OPP_1... - Page 13 REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 STEERING PART DESCRIPTION 532 42 45-43 Wheel Steering 532 41 81-68 Axle Asm 532 16 98-40 Spindle Asm LH 532 16 98-39 Spindle Asm RH 532 12 49-31 Bearing Race Thrust Harden 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
-
Page 14: Decals
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 DECALS PART PART DESCRIPTION DESCRIPTION 532 42 41-02 Decal, Warning Spark 532 43 19-85 Decal, Fender RH/LH Set 532 43 19-83 Decal, Hood RH/LH 532 43 84-26 Decal, Replacement... -
Page 15: Seat
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 SEAT seat-stlt_knob_1 PART PART DESCRIPTION DESCRIPTION 532 18 87-13 Seat 872 05 04-12 Bolt Rdhd Sht Nk 1/4 - 20 x 1 -1/2 532 14 05-51 Bracket Seat Pivot 532 13 43-00 Spacer Split .28 x .96... -
Page 16: Mower Deck
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 MOWER DECK... -
Page 17: Mower Deck
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 16 58-92 Mower Deck Assembly, 42" 532 12 47-88 Retainer 872 14 05-06 Bolt 532 13 77-29 Screw, Thdrol 1/4-20 x 5/8 T 532 13 80-17 Bracket Asm Fr. -
Page 18: Mower Lift
REPAIR PARTS TRACTOR - MODEL NUMBER PO19542LT (96012012100), PRODUCT NO. 960 12 01-21 MOWER LIFT 16 17 lift-rh.1piece_3 PART PART DESCRIPTION DESCRIPTION 532 40 49-81 Plunger Asm Lift Lever 532 17 32-88 Link Front 532 15 94-71 Shaft Asm Lift RH... - Page 19 SERVICE NOTES...
-
Page 20: Limited Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in mate- rials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
