IMPORTANT MANUAL
REPAIR PARTS MANUAL
MODEL:
PO175A42LT
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan.com
532 44 67-46
DO NOT THROW AWAY
5000
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so
can re sult in serious in ju ry.
09.28.11 BD
Printed in the U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PO175A42LT and is the answer not in the manual?

Questions and answers

Related Manuals for Poulan Pro PO175A42LT

Summary of Contents for Poulan Pro PO175A42LT

  • Page 1 Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so PO175A42LT can re sult in serious in ju ry. LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan.com 09.28.11 BD 532 44 67-46 Printed in the U.S.A.

  • Page 2: Table Of Contents

    The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “Tractor” • MODEL NUMBER - “PO175A42LT (96048002400)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................3...

  • Page 3: Schematic

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 SCHEMATIC SCH11 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) WHITE WHITE ATTACHMENT CLUTCH (CLUTCH OFF) BLACK CLUTCH/BRAKE GRAY (PEDAL UP) REVERSE SWITCH BLACK (NOT IN REVERSE) BLACK BLACK BLACK...

  • Page 4: Electrical

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 ELECTRICAL T06S With 12V Outlet Option With Service Minder Option...

  • Page 5: Electrical

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 ELECTRICAL PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 19 32-28 Box Battery 532 17 61-38 Switch Interlock 532 17 56-88...

  • Page 6: Chassis

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 CHASSIS Chassis-tex_ALPHA_3...

  • Page 7: Chassis

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 CHASSIS PART DESCRIPTION 532 41 17-64 Dash 532 40 61-79 Hood 532 42 67-41 Grille 532 18 75-69 Insert Reflective 532 19 61-25 Plate Engine 817 06 05-12 Screw 5/16-18 x 3/4...

  • Page 8: Drive

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 DRIVE drive-tex_VATR_6...
  • Page 9 TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 DRIVE PART PART DESCRIPTION DESCRIPTION – – – – – – Transmission, Gentrans 532 41 56-77 Shaft Asm Shift (415663) (Order parts 532 19 62-14 Arm.Clevis.Rod.Shift from transaxle manufacturer.) 532 19 74-56 Spring.Shift.Gt.2006...

  • Page 10: Engine

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-tex_BS_36...

  • Page 11: Engine

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 ENGINE PART DESCRIPTION – – – – – – Engine, B&S 31C707-3487-G1 (438654) (Order parts from engine manufacturer.) 532 13 73-52 Muffler Exhaust B&S 532 19 43-19 Keeper Belt...

  • Page 12: Steering

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 STEERING ASSEMBLY steering-tex_STDHRR_2_r2...
  • Page 13 TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 STEERING ASSEMBLY PART DESCRIPTION 532 42 45-43 Wheel, Steering 532 41 81-68 Axle Asm., Front 532 40 30-87 Spindle Asm., LH 532 40 30-88 Spindle Asm., RH 532 12 49-31 Washer Thrust 0.75 x 1.23...

  • Page 14: Mower Deck

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 MOWER DECK 42_D_man-tex_LT_32_r1...

  • Page 15: Mower Deck

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 19 99-11 Mower Housing 532 19 90-92 Spacer, Retainer 532 19 51-86 Arm Suspension 817 00 06-16 Screw Hexwsh Thd 3/8-16 x 1 532 41 63-58 Screw #10 x 0.750 BOS Thread...

  • Page 16: Mower Lift

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 MOWER LIFT 101* lift-tex_17_r3 *Key 91 may be substituted for Key 101 PART PART DESCRIPTION DESCRIPTION 532 42 20-27 Shaft Asm., Cross Lift 532 19 51-81 Link Lift Susp Mower Rear 532 19 52-31 Lever Asm., Lift RH...

  • Page 17: Seat

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 SEAT ASSEMBLY seat-tex_knob_3 PART PART DESCRIPTION DESCRIPTION 532 40 30-17 Seat 532 13 43-00 Spacer Split 532 18 01-66 Bracket Pivot Fender 532 12 37-40 Spring CPRSN Plate 532 14 06-75...

  • Page 18: Decals

    TRACTOR - MODEL NO. PO175A42LT (96048002400), PRODUCT NO. 960 48 00-24 DECALS PART PART DESCRIPTION DESCRIPTION 532 16 03-96 Decal, V-Belt Sch. 532 44 68-01 Decal, Fender RH/LH Set 532 43 19-83 Decal, Hood RH/LH 532 44 66-06 Decal, Replacement...
  • Page 19 SERVICE NOTES...

  • Page 20: Parts And Service

    Model Number/Manufacturer's I.D. Number b. Description of part. For Technical Assistance: call 1-800-829-5886 For a Parts Manual, go to our website: www.poulan.com NOTE: HOP provides parts and service through its au thor ized dis tribu tors and dealers; there fore, all requests for parts and service should be directed to your local dealer(s).
