2. Knowing the Parts

Front Side

Refer to the diagram below to identify the components on the front side of the Notebook PC.
308mm

Display Panel Latch

CD
Left Email/CD
Power & Right
CD Control Buttons
Speaker Charge Indicator Speaker
Indicators
Display Panel Latch
One display panel latch is used to lock the display panel in the closed position. To open the display
panel, slide the latch to the left with your thumb and lift up on the display panel at the same time.

Power Indicator

The green LED lights to indicate that the Notebook PC is turned ON and blink when the Notebook PC
is in the Suspend-to-RAM (standby) mode. This LED is OFF when the Notebook PC is in the Suspend-
to-Disk (hibernation) mode.
Charge Indicator
Indicates that the battery is being charged when ON and fully charged when OFF. This LED only lights
when the power adapter is used. This LED does not light up if there is no installed battery. Slow flash
means the battery power is low and requires charging. Quick flashing means that the battery pack
cannot be charged and needs a replacement.
CD Control Buttons & CD Indicator
(described in section 3)
Email Indicator
Flashes when there is one or more new email(s) in your email program's inbox. This function requires
software setup and may not be currently configured on your Notebook PC. This function is designed for
Microsoft email software only and may not work with email software from other companies.
Speaker
The built-in stereo speakers allow you to separately hear left and right channel audio without additional
attachments. The multimedia sound system features an integrated digital audio controller that produces
rich, vibrant sound in high quality 16-bit stereo. All audio features are software controlled.
18
