CRAFTSMAN 40 VOLT BLOWER – MODEL NUMBER 138. xxxxx
The model number will be found on a label attached to the motor housing. Always mention the model
number when calling to order replacement parts. To order parts, call 1-800-469-4663
Item No. Part No.
1 34102220
2 32201459
3 31101213
4 36103207
5 34201213
6 34106220
7 34104220
8 34107220
9 34108220
10 34106213-1
11 34107213-2
12 33301213
13 3220102
14 3110273
15 3110273
16 33203505-1
17 34103220
18 34105220
19 34106976
20 34101220
21 31102996

PARTS LIST

DescrIPtIoN
Right housing
Hex. Screw
PCB
Motor
Rubber ring
Right decoration
Right volute
Blowing pipe button
Blowing pipe
Blower tube (black)
Nozzle button
Spring washer
Screw
Fan assembly
Motor fixing plate
Screw and toothed washer assy.
Left volute
Left decoration
Housing insert plate
Left housing
Battery
11
Qty
1
12
1
1
1
1
1
1
1
1
1
1
2
1
1
2
1
1
1
1
1
