Secondary Filter; Reinstalling Filter - Broan SFDB-DA User Manual

7. HOW TO EMPTY DEBRIS PAIL
To empty the debris pail, release both latches on the sides of the unit by pulling
out and then pushing up. Holding the pail by the latches, lower it from the unit.
Carry pail to trash receptacle and dispose of debris. Put the pail back in its place.

8. SECONDARY FILTER

A secondary safety filter, located at the top of the vacuum chamber provides
protection against dirt being pulled into the motor if the disposable bag or permanent
filter should accidentally be torn. This filter should be checked and cleaned if
necessary, when replacement bag is installed or when optional permanent filter is
removed for cleaning. Simply brush filter clean. If the filter is excessively soiled,
wash in a mild detergent and let it dry completely before reinstalling.
Operating the power unit without the secondary filter will void the warranty.
8.1 REMOVING FILTER
Remove debris pail and disposable bag or
permanent filter. Remove both locking sleeves
from the retaining hooks. Carefully pull filter
down to remove.

8.2 REINSTALLING FILTER

To reinstall the secondary filter, reverse the steps
described above.
NOTE: A replacement secondary filter (part no. 10941310) may be purchased
from your local Broan-NuTone Sales Outlet. To locate your nearest
Broan-NuTone Sales Outlet, call toll free 1-888-882-7626.
When performing installation, servicing or cleaning the unit, it is
recommended to wear safety glasses and gloves.
CAUTION
! WARNING
- 6 -
AO0029
R
ETAINING
HOOKS
S
ECONDARY
FILTER
L
OCKING
SLEEVES
