CENTRAL VACUUM KIT
HOUSEHOLD TYPE
!
!
CXKIT350A
MODEL NO. SFDB-DF
AB0030
HOMEOWNERS OPERATING INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
Broan-NuTone Canada Inc.;
Mississauga, Ontario
www.broan.ca
1-888-882-7626
To register this product, visit www.broan.ca
30042461 Rev. C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CXKIT350A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Broan CXKIT350A

  • Page 1 CENTRAL VACUUM KIT HOUSEHOLD TYPE CXKIT350A MODEL NO. SFDB-DF AB0030 HOMEOWNERS OPERATING INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS Broan-NuTone Canada Inc.; Mississauga, Ontario www.broan.ca 1-888-882-7626 To register this product, visit www.broan.ca 30042461 Rev. C...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. When using an electric appliance, basic precautions should always be followed, including the following: WARNING O REDUCE THE RISK OF FIRE ELECTRIC SHOCK OR PERSONAL INJURY • Do not use on wet surfaces or outdoors. •...
  • Page 3: Operation

    1. OPERATION The power unit is located away from the everyday living areas of your home — usually in the garage, basement or utility room. Through a network of strong, lightweight tubing, the power unit connects to inlets strategically placed throughout your home.
  • Page 4: Bag Replacement

    APER RING AO0026 AO0032 AG STOPPER NOTE: A set of 3 replacement bags (model 391C) may be purchased from your local Broan-NuTone Sales Outlet. To locate your nearest Broan-NuTone Sales Outlet, call toll free 1-888-882-7626. - 4 -...
  • Page 5: Secondary Filter

    SLEEVES AO0033 NOTE: A replacement secondary filter (part no. 10941310) may be purchased from your local Broan-NuTone Sales Outlet. To locate your nearest Broan-NuTone Sales Outlet, call toll free 1-888-882-7626. WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves.
  • Page 6: Power Unit Installation

    • If the power unit is located in a closet or a small utility room, make sure the area is well-ventilated (e.g.: with door louvers). NOTE: Visit www.broan.ca for the central vacuum system installation instructions. 6.2 MOUNTING POWER UNIT CAUTION...
  • Page 7 6. POWER UNIT INSTALLATION ( ’ CONT ETAINING SCREW LOCATIONS 4. Use the mounting bracket as a template to OUNTING BRACKET mark the position of its screws. Drill the CENTER OPENING upper and lower screw holes into the stud using a 3/16” drill bit. AA0006 5.
  • Page 8: Grounding Instructions

    7. GROUNDING INSTRUCTIONS WARNING Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service person if you are in doubt as to whether the outlet is properly grounded. Do not modify the plug provided with the appliance —...
  • Page 9: Accessory Kit

    8. ACCESSORY KIT The following kit is included with the power unit: • Multi-Surface brush for carpet, tile, wood and ceramic AA0007 • 30’ Low-voltage crushproof hose with 360° rotating handle. Deluxe hose hanger included AA0008 • Standard tool set: - 10”...
  • Page 10: Troubleshooting Guide

    10. TROUBLESHOOTING GUIDE ROBLEMS OSSIBLE CAUSES OSSIBLE EMEDY 1. Loss or • The plastic cap is not installed on • Cover the unused inlet opening decrease the unused inlet. with the included plastic cap. of vacuum • Disposable bag is completely full. •...
  • Page 11 10. TROUBLESHOOTING GUIDE ( ’ CONT ROBLEMS OSSIBLE CAUSES OSSIBLE EMEDY 2. Power unit • Defective inlet. Check other wall • Replace defective wall inlet. does not inlets. start or • Turn the unit off by using the • Power unit overcurrent protector stops power switch on the unit.
  • Page 12 INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. During these time periods, Broan-NuTone Canada will, at its option, repair or replace the power unit or part without charge, which is found to be defective under normal use and service. THIS WARRANTY DOES NOT APPLY TO THE INSTALLATION OR THE PARTS USED IN THE INSTALLED TUBING SYSTEM.
