FILE NO. SVM-02005(2)

SERVICE MANUAL

AIR-CONDITIONER
SPLIT WALL TYPE
RAS-13UKP-ES / RAS-13UA-ES
RAS-10UKP-ES / RAS-10UA-ES
RAS-07UKP-ES / RAS-07UA-ES
07 Class
10/13 Class
Revised on January, 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAS-13UKP-ES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toshiba RAS-13UKP-ES

Summary of Contents for Toshiba RAS-13UKP-ES

  • Page 1: Service Manual

    FILE NO. SVM-02005(2) SERVICE MANUAL AIR-CONDITIONER SPLIT WALL TYPE RAS-13UKP-ES / RAS-13UA-ES RAS-10UKP-ES / RAS-10UA-ES RAS-07UKP-ES / RAS-07UA-ES 07 Class 10/13 Class Revised on January, 2005...

  • Page 2: Table Of Contents

    4. SPECIFICATION OF ELECTRICAL PARTS 4-1 Indoor Unit 4-2 Outdoor Unit (RAS-13UA-ES) 4-3 Outdoor Unit (RAS-10UA-ES, RAS-07UA-ES) 5. REFRIGERATION CYCLE DIAGRAM 5-1 RAS-13UKP-ES / RAS-13UA-ES 5-2 RAS-10UKP-ES / RAS-10UA-ES 5-3 RAS-07UKP-ES / RAS-07UA-ES 6. CONTROL BLOCK DIAGRAM 7. OPERATION DESCRIPTION...
  • Page 3 FILE NO. SVM-02005(1) 10. PARTS REPLACEMENT 10-1 Indoor Unit 10-2 Outdoor Unit (RAS-13UA-ES) 10-3 Outdoor Unit (RAS-10UA-ES) 10-4 Outdoor Unit (RAS-07UA-ES) 11. EXPLODED VIEWS AND PARTS LIST 11-1 Indoor Unit (E-Parts Assy) 11-2 Indoor Unit 11-3 Outdoor Unit (RAS-13UA-ES) 11-4 Outdoor Unit (RAS-10UA-ES) 11-5 Outdoor Unit (RAS-07UA-ES) •...

  • Page 4: Specifications

    FILE NO. SVM-02005(1) 1. SPECIFICATIONS MODEL RAS-13UKP-ES RAS-10UKP-ES RAS-07UKP-ES RAS-13UA-ES RAS-10UA-ES RAS-07UA-ES ITEM Cooling 220V 240V 220V 240V 220V 240V Capacity 3.70 3.75 2.65 2.70 2.15 2.18 Phase 1∅ Power source 220 – 240 Power consumption 1.25 1.29 0.77 0.83 0.66...
  • Page 5 Outdoor unit inlet air temperature (WB) 24 °C Note : 2 • Charge refrigerant according to the table below. RAS-10UKP-ES / RAS-10UA-ES Refrigerant RAS-13UKP-ES / RAS-13UA-ES RAS-07UKP-ES / RAS-07UA-ES No need to charge 15m or less 10m or less refrigerant – 4 –...

  • Page 6: Construction Views

    FILE NO. SVM-02005(1) 2. CONSTRUCTION VIEWS 2-1. Indoor Unit Front panel Air filter Air inlet Heat exchanger Back body Air outlet Knock out system Knock out system Hanger Connecting pipe (0.43m) Drain hose (0.54m) (Flare ∅6.35) Hanger Connecting pipe (0.33m) Flare (∅9.52) For stud bolt (∅8~∅10)

  • Page 7: Outdoor Unit (Ras-13Ua-Es)

    FILE NO. SVM-02005(1) 2-2. Outdoor Unit (RAS-13UA-ES) Gas side (Flare ∅9.52) Detail Drawing Liquid side (Flare ∅6.35) ∅6 hole ∅11x14 hole 8-∅6 hole (for fixing outdoor unit) ∅25Drain outlet 4-∅11x14 hole (for ∅8-∅10 anchor bolt) Handle Fan guard Electric parts cover ∅420 Service port...

  • Page 8: Outdoor Unit (Ras-10Ua-Es)

    FILE NO. SVM-02005(1) 2-3. Outdoor Unit (RAS-10UA-ES) Detail Drawing Gas side (flare ∅9.52) ∅25 Drain hole Liquid side (flare ∅6.35) ∅6 Hole ∅11x14 Hole 8-∅6 Holes (For fixing the outdoor unit) Handle 4-∅11x14 Long holes (For anchor bolt ∅8-∅10) Fan guard ∅420 Electric parts cover...

  • Page 9: Outdoor Unit (Ras-07Ua-Es)

    FILE NO. SVM-02005(1) 2-4. Outdoor Unit (RAS-07UA-ES) B Detail Drawing (Front Leg) A Detail Drawing (Back Leg) R 15 ∅6 Hole ∅6 Hole R 15 ∅11x14 Hole R 5.5 ∅25Drain outlet 2-∅11x14 hole (for ∅8-∅10 anchor bolt) Fan guard Cover PV ∅420 (11) 273.5 (pitch)

  • Page 10: Wiring Diagram

    FILE NO. SVM-02005(1) 3. WIRING DIAGRAM Louver motor INFRARED RAYS RECEIVE AND INDICATION PARTS 4 5 6 7 8 9 10 11 CN25 4 5 6 7 8 9 10 11 4 5 6 7 8 9 10 11 CN04 CN07 CN13 SG01...

  • Page 11: Specification Of Electrical Parts

    FILE NO. SVM-02005(1) 4. SPECIFICATION OF ELECTRICAL PARTS 4-1. Indoor Unit Parts name Type Specifications Fan motor (for indoor) MMF-240-20-4A-1 AC Motor with 135°C thermo fuse Thermo sensor (TA-sensor) ——— 10kΩ at 25°C Switching transformer (T01) SWT-47 Microcontroller unit (IC30) TMP87CM40AN-2C67 Heat exchanger sensor ———...

  • Page 12: Outdoor Unit (Ras-10Ua-Es, Ras-07Ua-Es)

    FILE NO. SVM-02005(1) 4-3. Outdoor Unit (RAS-10UA-ES, RAS-07UA-ES) Parts name Type Specifications Output (Rated) 750W, 2poles, 1 phase, 220 – 240V, 50Hz PA98X1T-4FZ Compressor Winding resistance (Ω) (RAS-10UA-ES) (at 20°C) 3.81 5.09 Output (Rated) 605W, 2poles, 1 phase, 220 – 240V, 50Hz PA79X1T-4FZ5 Winding resistance (Ω) (RAS-07UA-ES)

  • Page 13: Refrigeration Cycle Diagram

    FILE NO. SVM-02005(1) 5. REFRIGERATION CYCLE DIAGRAM 5-1. RAS-13UKP-ES / RAS-13UA-ES Indoor unit Heat exchanger Cooling 0.49m 0.39m (Connecting pipe) (Connecting pipe) ∅6.35 ∅9.52 Cross flow fan O.D.:9.52mm O.D.:6.35mm Packed valve Packed valve (∅9.52) (∅6.35) Cooling Cooling Compressor PA150X2T-4FM Capillary tube ∅1.5x900S...

  • Page 14: Ras-10Ukp-Es / Ras-10Ua-Es

    FILE NO. SVM-02005(1) 5-2. RAS-10UKP-ES / RAS-10UA-ES Indoor unit Evaporator Cooling 0.39m 0.49m (Connecting pipe) (Connecting pipe) ∅9.52 ∅6.35 Cross flow fan O.D.:9.52mm O.D.:6.35mm Packed valve Packed valve (∅9.52) (∅6.35) Cooling Cooling Compressor PA98X1T-4FZ Capillary tube ∅1.5x1200S Condenser Refrigerant R-22 : 0.65 kg. Propeller fan Outdoor unit Cooling...

  • Page 15: Ras-07Ukp-Es / Ras-07Ua-Es

    FILE NO. SVM-02005(1) 5-3. RAS-07UKP-ES / RAS-07UA-ES Indoor unit Evaporator Cooling 0.39m 0.49m (Connecting pipe) (Connecting pipe) ∅9.52 ∅6.35 Cross flow fan O.D.:9.52mm O.D.:6.35mm Packed valve Packed valve (∅9.52) (∅6.35) Cooling Cooling Compressor PA79X1T-4FZ5 Capillary tube ∅1.2x650S Condenser Refrigerant R-22 : 0.65 kg. Propeller fan Outdoor unit Mark(...

  • Page 16: Control Block Diagram

    FILE NO. SVM-02005(1) 6. CONTROL BLOCK DIAGRAM Main Unit Control Panel M.C.U. Operation Heat Exchange sensor Functions Display Timer • Louver Control Display Thermo. Sensor Filter Sign Display • 3-minutes Delay at Restart Infrared Rays Signal Reciver for Compressor Hi Power Sign Display •...

  • Page 17: Operation Description

    • Receiving of information of the operation status and judging of the information or indication of error MED+HIGH Table 7-1-1 RAS-13UKP-ES RAS-10UKP-ES RAS-07UKP-ES Model Motor speed Air flow level Motor speed Air flow level Motor speed Air flow level (rpm)

  • Page 18: Description Of Operation Circuit

    FILE NO. SVM-02005(1) 7-2-2. Cooling operation 7-2. Description of Operation Circuit ([MODE] button on the remote control is set (1) When turning on the breaker, the operation lamp to the cooling operation.) blinks. This means that the power is on (or the (1) The compressor, outdoor fan and operation power supply is cut off.) display on the remote control are controlled as...

  • Page 19: Cooling Operation

    (4 to 6 minutes). While the compressor is turning off, the indoor fan motor operates in the SUPER LOW position. The pattern of operation depending on the relation between room temperature and preset RAS-13UKP-ES temperatures is shown in Fig. 7-2-5. RAS-10UKP-ES RAS-07UKP-ES Room temp.

  • Page 20: Hi Power Mode

    If the difference between the preset as shown in Fig. 7-5-1 and 7-5-2. temperature and room temperature is big, the air conditioner operates at maximum airflow RAS-13UKP-ES level. If the difference between the preset temperature and the room temperature is small, Heat exchanger...

  • Page 21: Auto Restart Function

    FILE NO. SVM-02005(1) 7-6. Auto Restart Function 7-6-1. How to set auto restart function To set the auto restart function, proceed as follows: The indoor unit is equipped with an automatic The power supply to the unit must be on; the function restarting function which allows the unit to restart will not set if the power is off.

  • Page 22: Filter Check Lamp

    FILE NO. SVM-02005(1) 7-6-2. How to cancel auto restart function To cancel auto restart function, proceed as follows: Repeat the setting prodedure: the unit receives the signal and beeps three times. The unit will be required to be turned on with the remote control after the main power supply is turned off.

  • Page 23: Installation Procedure

    FILE NO. SVM-02005(1) 8. INSTALLATION PROCEDURE 8-1. Safety Cautions For general public use Power supply cord of parts of appliance for Outdoor use shall be at least polychloroprene sheathed flexible cord (design H07 RN-F), or cord designation 245 IEC 66. CAUTION New Refrigerant Air conditioner Installation •...
  • Page 24 Also, make sure the equipment is properly earthed. • Appliance shall be installed in accordance with national wiring regulations. If you detect any damage, do not install the unit. Contact your TOSHIBA dealer immediately. CAUTION • Exposure of unit to water or other moisture before installation could result in electric shock.

  • Page 25: Installation Diagram Of Indoor And Outdoor Units

    FILE NO. SVM-02005(1) 8-2. Installation Diagram of Indoor and Outdoor Units For installation of the indoor unit, use the paper pattern on the back of the installation manual. Before installing the For the rear left and left wireless remote control piping Hook •...

  • Page 26: Installation

    FILE NO. SVM-02005(1) 8-3. Installation 8-3-1. Optional installation parts Part Parts name Q'ty Code Refrigerant piping Liquid side : ∅6.35 mm each : ∅9.52 mm Gas side Pipe insulating material (polyethylene foam, 6 mm thick) Putty, PVC tapes each <Fixing bolt arrangement of outdoor unit> RAS-13UA-ES RAS-10UA-ES 600 mm...
  • Page 27 FILE NO. SVM-02005(1) 8-3-2. Accessory and installation parts Part Part Part Part name (Q'ty) Part name (Q'ty) Part name (Q'ty) Mounting screw ∅4 x 25 s x 6 Installation plate x 1 Remote control holder x 1 Pan head wood screw ∅3.1 x 16 s x 2 Wireless remote control x 1 Zeolite filter x 1...
  • Page 28 FILE NO. SVM-02005(1) 8-3-3. Installation/Servicing tools <Changes in the product and components> In the case of an air conditioner using R-410A, in order to prevent any other refrigerant from being charged accidentally, the service port diameter of the outdoor unit control valve (3 way valve) has been changed. (1/2 UNF 20 threads per inch) •...

  • Page 29: Indoor Unit

    FILE NO. SVM-02005(1) 8-4. Indoor Unit 8-4-2. Cutting a hole and mounting installation plate 8-4-1. Installation place <Cutting a hole> • A place which provides the spaces around the When installing the refrigerant pipes from the rear. indoor unit as shown in the above diagram. •...
  • Page 30 NOTE • Ensure all wiring is used within its electrical rating. Projection 15 mm or less 5 mm dia. hole Model RAS-13UKP-ES RAS-10UKP-ES RAS-07UKP-ES Power source 50 Hz, 220 – 240 V Single phase 7 Mounting screw Maximum ∅4 x 25s s s s s 7.5A...
  • Page 31 FILE NO. SVM-02005(1) 8-4-4. Wiring connection <Stripping length of the connecting cable> <How to connect the power cord> 40 mm Earth line 10 mm For the air conditioner that does not have power cord, connect a power cord to it as mentioned below.
  • Page 32 FILE NO. SVM-02005(1) <How to connect the connecting cable> <How to install the air inlet grille on the indoor unit> • When attaching the air inlet grille, the contrary of Wiring of the connecting cable can be carried out without removing the front panel. the removed operation is performed.
  • Page 33 FILE NO. SVM-02005(1) 8-4-5. Piping and drain hose installation How to fix the drains cap 1) Insert hexagonal wrench (4 mm) in a center <Piping and drain hose forming> head. * Since dewing results in a machine trouble, make sure to insulate both the connecting pipes. (Use polyethylene foam as insulating material.) 4 mm Rear right...
  • Page 34 FILE NO. SVM-02005(1) <Left-hand connection with piping> 8-4-6. Indoor unit fixing Bend the connecting pipe so that it is laid within 43 mm 1. Pass the pipe through the hole in the wall, and hook above the wall surface. If the connecting pipe is laid the indoor unit on the installation plate at the upper exceeding 43 mm above the wall surface, the indoor hooks.

  • Page 35: Outdoor Unit

    FILE NO. SVM-02005(1) 8-4-7. Drainage 8-5. Outdoor Unit 1. Run the drain hose sloped downwards. 8-5-1. Installation place • A place which provides the spaces around the NOTE outdoor unit as shown in the left diagram. • Hole should be made at a slight downward slant on •...
  • Page 36 FILE NO. SVM-02005(1) 8-5-2. Refrigerant piping connection (Unit : N·m) Outer dia. 1. Cut the pipe with a pipe cutter. Tightening torque of copper pipe ∅6.35 mm 16 to 18 (1.6 to 1.8 kgf·m) Roughness Warp Obliquity 90° ∅9.52 mm 33 to 42 (3.3 to 4.2 kgf·m) •...
  • Page 37 FILE NO. SVM-02005(1) 8-5-3. Evacuating <Packed valve handling precautions> • Open the valve stem all the way out; but do not try After the piping has been connected to the indoor unit, you can perform the air purge together at once. to open it beyond the stopper.

  • Page 38: How To Set Remote Control Selector Switch

    FILE NO. SVM-02005(1) 8-5-4. Wiring connection 8-6. How to Set Remote Control Selector Switch 1. Remove the electric parts cover from the outdoor unit. 2. Connect the connecting cable to the terminal as When two indoor units ae installed in seperated rooms, identified with their respective matched numbers on there is no need to change the selector switch.

  • Page 39: Others

    FILE NO. SVM-02005(1) 2. Set the remote control selector switch with the 8-7. Others remote control 8-7-1. Gas leak test [B] is indicated on the liquid crystal display when For RAS-07UA-ES setting remote control selector switch to B. [A] is not indicated on the display even if the selector switch is set to A.
  • Page 40 FILE NO. SVM-02005(1) 8-7-3. Auto restart setting This product is designed so that, after a power failure, it can restart automatically in the same operating mode as before the power failure. Information The product was shipped with Auto Restart function in the off position.

  • Page 41: Troubleshooting Chart

    FILE NO. SVM-02005(1) 9. TROUBLESHOOTING CHART 9-1. Troubleshooting Procedure 9-2-2. Incorrect cable connection between indoor and outdoor units Follow the details of 9-2. Basic Check Items. The indoor unit is connected to the outdoor unit with If there is no trouble corresponding to 9-2, check 3 cables.

  • Page 42: Primary Judgement

    FILE NO. SVM-02005(1) 9-3-2. Failure diagnosis 9-3. Primary Judgement The indoor unit diagnoses the operation condition and 9-3-1. Role of indoor unit controller indicates the information of the self-diagnosis with the The indoor unit controller receives the operation lamps on the display panel of the indoor unit. commands from the remote control and executes them.

  • Page 43: Self-Diagnosis By Remote Control (Check Code)

    FILE NO. SVM-02005(1) 9-4. Self-Diagnosis by Remote Control (Check Code) (1) If the lamps are indicated as shown B to H in Table 9-3-1, exchanger the self-diagnosis by the remote control. (2) When the remote control is set to the service mode, the indoor controller diagnoses the opera- tion condition and indicate the information of the self-diagnosis on the display of the remote control...
  • Page 44 FILE NO. SVM-02005(1) Table 9-4-1 Diagnosis function Block level Judgement and action Check Check Block Symptom Conditioner Condition code code status Indoor Thermo. sensor short/ Continued Indicated 1. Check thermo sensor. P.C. board break. operation. when detected 2. If it is OK, check P.C. abnormal board.

  • Page 45: Troubleshooting Flowcharts

    FILE NO. SVM-02005(1) 9-5. Troubleshooting Flowcharts 9-5-1. Power can not be turned on (No operation at all) <Preliminary checks> Operation (1) Is the supply voltage normal? (2) Is the connection to the AC output OK.? Check Items Main cause Shut off the power supply from AC outlet once and Countermeasure turn it on after 5 seconds.
  • Page 46 FILE NO. SVM-02005(1) 9-5-2. Power can not be turned on after replacing indoor P.C. board <Checking Procedure> Connect the AC Power supply Return the wiring of the Does the OPERATION Is it wired as shown power relay is returned to lamp blink? in Figure below? the normal procedure.
  • Page 47 FILE NO. SVM-02005(1) 9-5-3. Outdoor unit does not operate Shut off the power supply from AC outlet once and turn it on after 5 seconds. Does the OPERATION lamp blink? See “ Power can not be turned on”. Does the power turn on by pushing See “...
  • Page 48 FILE NO. SVM-02005(1) 9-5-4. Only compressor does not operate Shut off the power supply from AC outlet once and turn it on after 5 seconds. Does the OPERATION lamp blink? See “ Power can not be turned on”. Does the power turn on by See “...
  • Page 49 FILE NO. SVM-02005(1) 9-5-5. Only outdoor Fan does not operate Shut off the power supply from AC outlet once and turn it on after 5 seconds. Does the OPERATION lamp blink? See “Power can not be turned on”. Does the power turn on by See “Power can not be turned on”.
  • Page 50 FILE NO. SVM-02005(1) 9-5-6. Only the indoor fan does not operate <Check procedure> Shut off the power supply once. Turn the power supply. Does the fan stop in Replace the P.C. board. Control P.C. board is defective. no operating status? Start the operation with low fan setting in cool operation.

  • Page 51: Troubleshooting For Remote Control (Including The Indoor P.c. Board)

    FILE NO. SVM-02005(1) 9-6. Troubleshooting for Remote Control (Including the Indoor P.C. Board) There is no been from the indoor unit. Push the START/STOP button. The operation lamp of the air conditioner main unit does not light. Does the transmission indicator blink? Short-circuit the metal terminal at the side of the...
  • Page 52 FILE NO. SVM-02005(1) 9-6-1 How to check the P.C. board (2) Inspection procedres (1) Operating precautions 1) when a P.C. board is judged to be defective, check for disconnection, burning, or 1) When removing the front panel or the P.C. discoloration of the copper foil pattern or this board, be sure to shut off the power supply.
  • Page 53 FILE NO. SVM-02005(1) (3) Checking procedure Table 9-6-1 Procedure Check Point (Symptom) Causes 1. • Application of shock voltage. Shut off the power supply and 1. Is the fuse blown? • Overload by short-circuit of the remove the P.C. board assembly from the electronic parts base.
  • Page 54 FILE NO. SVM-02005(1) Table 9-6-2 Approximate resistance value of thermo sensor (kΩ) Temperature 0°C 10°C 20°C 25°C 30°C Resistance value 35.8 20.7 12.6 10.0 7.92 9-6-2. How to shorten time of restart delay timer 1 Press [CLR] button while pressing [CHECK] button with a tip of a pencil.
  • Page 55 FILE NO. SVM-02005(1) 9-6-3. P.C. board layout Top View Bottom View – 54 –...

  • Page 56: Part Replacement

    FILE NO. SVM-02005(1) 10. PART REPLACEMENT 10-1. Indoor Unit Part name Procedures Remarks Front panel How to remove the front panel 1) Stop the operation of the air conditioner and turn off its main power supply. 2) Pull the air inlet grille toward you to open it and remove the air inlet grille.
  • Page 57 FILE NO. SVM-02005(1) Part name Procedures Remarks Heat exchanger 1) Remove the front panel, electrical part and the horizontal louver following procedure 3. 2) Remove the pipe holder at the rear side of main unit. 3) Remove the 2 screws on the heat exchanger at the base bearing.
  • Page 58 FILE NO. SVM-02005(1) 10-2. Outdoor Unit (RAS-13UA-ES) Part name Procedures Remarks Common 1) Stop the operation of air-conditioner, and procedure disconnect the power cord from the AC supply. 2) Remove Electric parts cover. Remove 7-Screws ∅4 x 10L (2-Screws ∅4 x 10L) 3) Remove the cord clamp (2-Screws ∅4 x 22L) and disconnect the connecting cable.
  • Page 59 FILE NO. SVM-02005(1) 10-3. Outdoor Unit (RAS-10UA-ES) Part name Procedures Remarks Common 1) Stop the operation of air-conditioner, and procedure disconnect the power cord from the AC supply. 2) Remove Electric parts cover. (2-Screws ∅4 x 10L) Remove 7-Screws ∅4 x 10L 3) Remove the cord clamp (2-Screws ∅4 x 22L) and disconnect the connecting cable.
  • Page 60 FILE NO. SVM-02005(1) 10-4. Outdoor Unit (RAS-07UA-ES) Part name Procedures Remarks 2-Screws ∅4 x 22L Common 1) Stop the operation of air-conditioner, and procedure disconnect the power cord from the AC supply. 2) Remove packed valve cover and Electric parts cover. (2-Screws ∅4 x 10L) 3) Remove the cord clamp (2-Screws ∅4 x 22L) and disconnect the connecting cable.

  • Page 61: Exploded Views And Parts List

    43T62003 Cord Clamp 3P AC300V, 20A 43T69076 P.C. Board 43T69004 Sensor, Heat Exchanger (RAS-10UKP-ES) 10kΩ 25°C 43T69078 P.C. Board 43T69005 Sensor, Thermostat 10kΩ 25°C (RAS-13UKP-ES) 43T69079 P.C. Board ASSY, WRS-LED 43T69324 P.C. Board MCC-861 (RAS-07UKP-ES) 43T60077 Fuse, Temperature, 77°C – 60 –...
  • Page 62 43T47006 Pipe, Delivery ∅6.35 43T85327 Owner’s Manual 43T47005 Pipe, Suction ∅9.52 43T62302 Terminal Cover 43T49009 Spring 43T60317 Cord Motor Louver 43T11301 Pipe Shield (RAS-10UKP-ES, 43T60359 Cord Motor Fan RAS-07UKP-ES) 43T07303 Holder Pipe 43T11302 Pipe Shield (RAS-13UKP-ES) 43T01004 Mark – 61 –...
  • Page 63 FILE NO. SVM-02005(1) 11-3. Outdoor Unit (RAS-13UA-ES) 15,17 14,16 Location Part Location Part Description Description 43005144 Cabinet, Front 43T43303 Condenser 43005143 Cabinet, Back 43T46308 Valve, Packed 6.35 43042446 Base 43T46011 Valve, Packed 9.52 43T19007 Guard-Fan 43T47020 Bonnet, 6.35 DIA 43T19005 Handle 43T47021 Bonnet, 9.52 DIA 43T19002 Guard-Stopper 43T47008 Tube, Capillary, 1.5 DIA...
  • Page 64 FILE NO. SVM-02005(1) 11-4. Outdoor Unit (RAS-10UA-ES) 10, 11 8, 9 13 2 15, 21 7 : CAPILLARY TUBE Location Part Location Part Description Description 43T19001 Guard, Fan 43T47021 Bonnet, 9.52 DIA 43T20001 Fan, Propeller 43T21323 Motor, Fan 43005037 Cabinet, Front 43T47001 Nut, Flange 43T43302 Condenser 43T19005 Handle...
  • Page 65 FILE NO. SVM-02005(1) 11-5. Outdoor Unit (RAS-07UA-ES) 10, 11 08, 09 Location Part Location Part Description Description 43T19311 Guard, Fan 43T47001 Nut, Flange 43T20306 Fan, Propeller 43T19312 Handle 43T00362 Cabinet, Front 43T49001 Cushion, Rubber 43T43324 Condenser 43T41402 Compressor, PA79X1T-4FZ5 43T62304 Cover, E-Parts 43T62305 Cover, Packed Valve 43T00363 Cabinet, Back 43T00364 Cabinet, Upper...
  • Page 66 FILE NO. SVM-02003(1) TOSHIBA CARRIER (THAILAND) CO.,LTD. 144/9 MOO 5, BANGKADI INDUSTRIAL PARK, TIVANON ROAD, TAMBOL BANGKADI, AMPHUR MUANG, PATHUMTHANI 12000,THAILAND. – 71 –...
