- Page 1 Instruction Manual MT-1890 Video Transmitter With Bi-directional 4-Wire Audio And Bi-directional Contact Closure © Copyright 2007, American Fibertek, Inc. 0726JD...
- Page 2 The MT-1890 converts a video input, an audio input, and a contact input into an optical output using a 1300 nm wavelength source. The MT-1890 also converts an optical input signal returning on the same fiber into a single audio output and a contact output using an 850 nm wavelength detector.
- Page 3 Please note that Audio In on the MT-1890 becomes Audio Out on the MR-1890 or RR-1890 after going across the fiber. The reverse flow follows the same orientation. For optimum performance the audio cables should be the...
- Page 4 The MT-1890 provides the following LED status indicators to aid in installation and troubleshooting: A bi-color LED indicator is provided for the video input to the MT-1890. Internal DC power and video status associated with this LED is summarized below.
