Summary of Contents for AMX Classroom Transmitter TX-CT5
- Page 1 instruction manual TX-CT5 Classroom Transmitter Tran s m it t er s...
- Page 2 This warranty extends only to products purchased directly from AMX Corporation or an Authorized AMX Dealer. AMX Corporation is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost savings, incidental damages, or consequential damages. AMX Corporation is not liable for any claim made by a third party or by an AMX Dealer for a third party.
-
Page 3: Table Of Contents
Table of Contents Product Information ...1 Setting the IR Frequency... 1 Using the TX-CT5 ...3 Television Control... 3 Modes... 3 Local Mode... 3 Media Mode ... 3 Office, Security, or Media Center Control... 4 Calls ... 4 System Media Control ... 4 Motion ... - Page 4 Table of Contents TX-CT5 Classroom Transmitter...
-
Page 5: Product Information
Product Information The AMX Synergy Classroom Transmitter (TX-CT5) provides a full range of control options for the AMX Synergy Resource Management System (RMS). It transmits Infrared (IR) format commands to classroom Television Managers. TX-CT5 Specifications Dimensions (HWD): 5.25" (133 mm) x 6.26" (159 mm) x 0.75" (19.05 mm) - Page 6 Product Information TX-CT5 Classroom Transmitter...
-
Page 7: Using The Tx-Ct5
Using the TX-CT5 Television Control The TV control buttons operate the classroom television. The following functions are always available: ON/OFF turns on or off the classroom television power. VOLUME controls the television volume. Press the up or down arrows to manipulate the volume. -
Page 8: Office, Security, Or Media Center Control
Using the TX-CT5 Office, Security, or Media Center Control Calls There are two different kinds of calls that you can send: Office: To send a general emergency call signal to the Paging Console (AXP-PC) or to a Security Panel (AXU-SPL4) press OFFICE then ENTER. To clear the call before you receive a response press OFFICE then CLEAR. -
Page 9: Vcr
1. To access an optional feature, press ALT, 2. Then, choose one of the following number buttons and press ENTER: Tracking up Tracking down Reset counter Clear Text display on/off CD-I Player To control the CD-I mouse, use the buttons labeled in yellow. Then, press one of the eight outer number buttons (1 –... - Page 10 AMX reserves the right to alter specifications without notice at any time. brussels • dallas • los angeles • mexico city • philadelphia • shanghai • singapore • tampa • toronto • york 3000 research drive, richardson, TX 75082 USA • 469.624.8000 • 800.222.0193 • fax 469.624.7153 • technical support 800.932.6993...
