Tools and Parts
Gather the required tools and parts before starting installation.
The parts supplied are in the washer drum.
Tools needed for connecting the water inlet hoses
■
Pliers (that open to 1
9
/
16
■
Flashlight (optional)
Tools needed for connecting the drain hose
■
Locking pliers (that open to 1
Tools needed for installation
■
Open end wrenches 17 mm and 13 mm
■
Level
■
Wood block
■
Ruler or measuring tape
NOTE: Replace inlet hoses after 5 years of use to reduce the risk
of hose failure. Record hose installation or replacement dates for
future reference.
INSTALLATION REQUIREMENTS
" [39.5 mm])
/
" [39.5 mm])
9
16
Parts supplied:
A
D
E
A. Drain hose form
B. Inlet hose (2)
C. Inlet hose washer (4)
D. Transport bolt hole plug (4)
E. Beaded strap
F. Drain hose
G.Hose clamp
B
C
F
G
3
