TORMENT
ECX03008 | ECX03008AU | ECX03008I
INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
MANUEL D'UTILISATION
MANUALE DI ISTRUZIONI
®
™
BRUSHLESS
BRUSHLESS
1/10 ELECTRIC
SHORT COURSE TRUCK
Congratulations on your purchase of the ECX
ment
Brushless Short Course Truck. This 1/10-scale
™
model introduces you to the sport of RC driving.
Herzlichen Glückwunsch zum Kauf des ECX Torment
Brushless Short Course Truck. Dieses 1/10 Scale
Model öffnet Ihnen die Welt des RC Car Sports.
Nous vous félicitons pour l'achat du ECX Torment
Brushless Short Course Truck. Ce modèle 1/10 vous
initie à la conduite RC.
Congratulazioni per l'acquisto di questo Torment
Brushless Short Course Truck ECX. Questa vettura in
scala 1/10 vi introdurrà nel mondo dei modelli RC.
Tor-
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ECX Torment ECX03008AU
Summary of Contents for ECX Torment ECX03008AU
- Page 1 Brushless Short Course Truck. Dieses 1/10 Scale Model öffnet Ihnen die Welt des RC Car Sports. MANUALE DI ISTRUZIONI Nous vous félicitons pour l’achat du ECX Torment Brushless Short Course Truck. Ce modèle 1/10 vous initie à la conduite RC.
-
Page 2: Table Of Contents
NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, Inc. For up-to-date product literature, visit http://www.horizonhobby.com and click on the support tab for this product. Meaning of Special Language: The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury. -
Page 3: Water-Resistant Vehicle With Waterproof Electronics
WATER-RESISTANT VEHICLE WITH WATERPROOF ELECTRONICS Your new Horizon Hobby vehicle has been designed and built with • Even minimal water contact can reduce the life of your motor if it has not been certified as water-resistant or waterproof. If the a combination of waterproof and water-resistant components to al- motor becomes excessively wet, apply very light throttle until low you to operate the product in many “wet conditions,”... -
Page 4: Components
COMPONENTS 1. ECX ® Torment ™ 1/10-scale Short Course Truck 2. Spektrum DX2E Transmitter ™ 3. AA (4) Batteries 4. DYN4113 2A Peak Battery Charger 5. Dynamite ® Speedpack™ 8.4V Ni-MH battery (DYN1072EC) VEHICLE PREPARATIONS CHARGING THE VEHICLE BATTERY It may take as many as 2 to 4 restarts to complete your fi rst one or two full charge cycles. -
Page 5: Installing Transmitter Batteries
INSTALLING TRANSMITTER BATTERIES We recommend using only alkaline AA batteries in the transmitter, however, it is possible to use rechargeable NiMH batteries. CAUTION: If using rechargeable batteries, charge only rechargeable batteries. Charging non-rechargeable batteries may cause the batteries to burst, resulting in injury to persons and/or damage to property. -
Page 6: Transmitter Controls
TRANSMITTER CONTROLS REVERSE SWITCH Allows you to change the direction of steering (ST. REV) and throttle (TH. REV) controls (default settings are “N” for steering and “R” for throttle). STEERING RATE STEERING TRIM Adjusts the amount the front wheels move when the Adjust to make the vehicle steering wheel is turned left or right. -
Page 7: Getting Started
GETTING STARTED 3. Power on the ESC. 1. Power on the transmitter. 2. Connect a fully charged battery to the ESC. 4. Do a test of the transmitter’s control of the vehicle with 5. Start driving slowly, and, if the vehicle does not go the vehicle’s wheels off the ground. -
Page 8: Operation
OPERATION • ALWAYS turn on your transmitter before you turn on the • ALWAYS operate your vehicle in a wide open area. Operating receiver in the vehicle. Always power off the receiver before the vehicle in a small space or indoors can cause overheating turning your transmitter off. -
Page 9: Maintenance
MAINTENANCE SETTING THE GEAR MESH The gear mesh has already been set at the factory. Setting the gear mesh is only necessary when changing motors or gears. You must remove the vehicle’s gear cover (A) to make this adjust- ment. Proper gear mesh (how the gear teeth meet) is important to the performance of the vehicle. -
Page 10: Electrical Diagram
Programmable Value Default Settings Programmable Items Forward/Reverse 1 Running Mode Forward with Brake with Brake 2 Drag Brake Force Low Voltage Cutoff non-protection 2.6V/Cell 2.8V/Cell 3.0V/Cell 3.2V/Cell 3.4V/Cell (LVC) Threshold 4 Start Mode Level 1 Level 2 Level 3 Level 4 5 Max Brake Force 100% DESCRIPTIONS... -
Page 11: Shock Cleaning
SHOCK CLEANING REAR SHOCK FRONT SHOCK Oil-fi lled shocks will require regular maintenance due to the ECX1037 ECX1037 oil breaking down or getting dirty. This maintenance should be ECX1043 performed after about every 3 to 5 hours of use, depending on ECX1043 the conditions that the vehicle is used in. -
Page 12: Binding
BINDING Binding is the process of programming the receiver to recognize 5. The LED on the receiver will glow solid when the transmitter the GUID (Globally Unique Identifi er) code of a single specifi c and receiver are bound. transmitter. The DX2E and SR201 are bound at the factory. If you 6. -
Page 13: Limited Warranty
LIMITED WARRANTY What this Warranty Covers enable Horizon to better answer your questions and service you in the event that you may need any assistance. For questions or assistance, please visit Horizon Hobby, Inc., (Horizon) warrants to the original purchaser that the our website at www.horizonhobby.com, submit a Product Support Inquiry, or product purchased (the "Product") will be free from defects in materials and workmanship at the date of purchase. -
Page 14: Fcc Information
No. HH2013050301 serve natural resources and ensure that it is recycled in a manner Product(s): ECX Torment 1:10 2wd SCT Brushless: RTR that protects human health and the environment. For more (Spektrum DX2E Transmitter and SR201 Receiver included) information about where you can drop off your waste equipment... -
Page 15: Parts Diagrams
PARTS DIAGRAM | EXPLOSIONSZEICHNUNG | VUE ÉCLATÉE DES PIÈCES | ESPLOSO DEL MODELLO CON REFERENZA PEZZI RECOMMENDED ITEMS EMPFOHLENE WERKZEUGE M3X10 OUTILS RECOMMANDÉS ATTREZZI CONSIGLIATI M3X10 M3X10 M3X12 M3X18 M3X12 2 mm 1.5 mm M3X12 M3X12 M3X18 M3X25 M3X10 M3X12 M3X12 M3X10 M3X15... - Page 16 PARTS DIAGRAM | EXPLOSIONSZEICHNUNG | VUE ÉCLATÉE DES PIÈCES | ESPLOSO DEL MODELLO CON REFERENZA PEZZI The slipper clutch can be adjusted using M3X3 this locknut (ECX1060). Fully tighten the locknut, then loosen the nut two full M2.5X8 turns. M2.5X4 22 34 Die Rutschkupplung kann durch diese Stopmutter eingestellt werden (ECX1060).
- Page 17 Replacement Parts / Ersatzteile / Pièces de rechange / Pezzi di ricambio Part # | Nummer Description Beschreibung Description Descrizione Numéro | Codice ECX2008 Main Chassis Chassis Châssis principal Telaio principale ECX1028 Servo Saver Set Servo Saver Set Sauve servo Set salvaservo Cover and Rear Mount Abdeckung und hinterer...
- Page 18 Nerf Bar Set Seitenaufprallschutz Set de protection latérales Set protezione laterale ECX4007 Mud Flap Set Schmutzfängerset Set de bavettes Set paraspruzzi Body, Silver/Blue: ECX Torment Karosserie Carrosserie argent/bleue - ECX230011 Carrozz. Blu/Arg Torment Torment Silber / Blau Torment SPM2300 Transmitter Sender Émetteur...
- Page 19 Created 3/2013 © 2013 Horizon Hobby, Inc. ECX, the ECX logo, Torment, DSM, DSM2, Dynamite and Speedpack are trademarks or registered trademarks of Horizon Hobby, Inc. WD-40 is a registered trademark of WD-40 Manufacturing Company. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
