DC TO AC POWER INVERTER
POWER : 600W
PI600M
for input voltage 12V
PI60024
for input voltage 24V
OVERLOADING THIS DEVICE OR CONNECTING IT WITH AN INDUCTIVE LOAD (e.g. refrigerator, fan,
drill) WILL DAMAGE IT AND AUTOMATICALLY VOID THE WARRANTY !!
HET TOESTEL ZAL WORDEN BESCHADIGD INDIEN U HET OVERBELAST OF ER EEN INDUCTIEVE
BELASTING (vb. koelkast, boormachine, ventilator) OP AANSLUIT. DE GARANTIE VERVALT DAN
AUTOMATISCH !!
LA SURCHARGE DE L'APPAREIL OU LA CONNEXION D'UNE CHARGE INDUCTIVE (p.ex. ventilateur,
réfrigérateur, perceuse) ENDOMMAGERONT L'APPAREIL ET LA GARANTIE SERA INVALIDEE
AUTOMATIQUEMENT !!
DIE GARANTIE ERLISCHT UND DER SPANNUNGSWANDLER KANN BESCHÄDIGT WERDEN, WENN SIE
IHN ÜBERLASTEN ODER MIT EINER INDUKTIVEN LAST VERBINDEN (z.B. Kühlschrank, Lüfter,
Bohrmaschine).
ATTENTION – OPGELET - ACHTUNG
User Manual
Gebruikershandleiding
Manuel d'utilisation
Bedienungsanleitung
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Velleman PI600M
Summary of Contents for Velleman PI600M
- Page 1 DC TO AC POWER INVERTER POWER : 600W PI600M for input voltage 12V PI60024 for input voltage 24V ATTENTION – OPGELET - ACHTUNG OVERLOADING THIS DEVICE OR CONNECTING IT WITH AN INDUCTIVE LOAD (e.g. refrigerator, fan, drill) WILL DAMAGE IT AND AUTOMATICALLY VOID THE WARRANTY !! HET TOESTEL ZAL WORDEN BESCHADIGD INDIEN U HET OVERBELAST OF ER EEN INDUCTIEVE BELASTING (vb.
- Page 2 When connected to an appliance, remember to turn on the inverter before turning on the appliance. If the buzzer sounds during operation, this indicates that the battery voltage is very low and that the inverter will be disconnected in 5 minutes. then the Switch on device inverter PI600M & PI60024 v2...
- Page 3 VOID THE WARRANTY AND MAY DAMAGE THE INVERTER The battery's voltage must never exceed 15VDC (30 VDC for a 24V inverter). CONNECTING THE INVERTER TO A DC POWER SOURCE GREATER THAN 15VDC (30VDC) WILL VOID THE WARRANTY AND MAY DAMAGE THE INVERTER. PI600M & PI60024 v2...
- Page 4 NOTE : The earthing terminal of the AC outlet is connected to the neutral terminal. This is the same as with a standard household power point where the neutral connection is bonded to earth and there is no voltage between the two. PI600M & PI60024 v2...
- Page 5 IMPORTANT ! During operation, make sure the fan keeps revolving. Check the inverter for possible malfunctions if the fan does not work when this unit is being used. Make sure the fan is not blocked in order to avoid poor ventilation. GOOD PI600M & PI60024 v2...
- Page 6 (B) Not exposed to direct sunlight or any other heat source (C) Inaccessible to children (D) Safe from water/moisture, oil or grease (E) Safe from any flammable substance If the inverter is connected in the wrong way, this will void the warranty. PI600M & PI60024 v2...
- Page 7 WARNING : DO NOT DISASSEMBLE THIS UNIT AS DOING SO MAY CAUSE HAZARDOUS VOLTAGES !! RETURN THIS UNIT TO THE DEALER IN CASE OF TROUBLE !! IMPORTANT : DO NOT CONNECT ANY INDUCTIVE LOADS WITH THIS DEVICE ! PI600M & PI60024 v2...
