  • Page 1 WING U.S. Patent(s) Pending INSTRUCTION MANUAL WARRANTY CERTIFICATE...
  • Page 2 This product is protected by United States Federal and/or State Law, including Patent, Trademark and/or Copyright laws. Manual design and all elements of manual design are protected by U.S. Federal and/or State Law, including Patent, Trademark and/or Copyright laws.
  • Page 4 F823...

  • Page 5: Table Of Contents

    CONTENTS SAFETY RULES..................FINISHING THE INSTALLATION............PACKAGE CONTENTS..............OPERATING THE REMOTE CONTROL/WALL CONTROL ..INSTALLING THE FAN..............CARE OF YOUR FAN................. HANGING THE FAN................. TROUBLESHOOTING................ELECTRICAL CONNECTIONS............SPECIFICATIONS..................1151 W. Bradford Court, Corona, CA 92882 For Customer Assistance Call: 1-800-307-3267...

  • Page 6: Safety Rules

    SAFETY RULES 1. Before you begin installing the fan, shut power off at the circuit breaker of the fuse box. 2. Be cautious! Read all instructions and safety information before installing your new fan. Review accompanying assembly diagrams. 3. Make sure that all electrical connections comply with local codes, ordinances, or National Electrical Codes. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring.
  • Page 7 NOTE: The important safeguards and instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. It must be understood that common sense, caution and care are factors which can not be built into this product. These factors must be supplied by the person (s) installing, caring for and operating the unit.

  • Page 8: Package Contents

    PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: 1. Canopy assembly (hanger bracket, canopy and canopy cover) 2. Extra metal canopy cover 3. Standard downrod ass'y 4. Top housing 5. Fan motor/blades ass'y 6.

  • Page 9: Installing The Fan

    INSTALLING THE FAN Tools Required: Phillips screw driver; slotted screw driver; step-ladder; wire cutters; electrical tape. PARALLEL WOOD BRACE CEILING (MIN. 2" THICK) JOIST MOUNTING OPTIONS CROSS BRACE OUTLET If there isn't an existing mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers.

  • Page 10: Hanging The Fan

    HANGING THE FAN WARNING: All of the parts, hardware and components such as the Step 3. Secure the hanger bracket to the ceiling outlet box using screws hanger bracket and hanger ball have been provided for your safety and included with your outlet box, lock washers included with the fan. the proper installation of your new ceiling fan.
  • Page 11 Step 7. Slip Top Housing, Canopy cover and Canopy onto Downrod. Carefully re-install the Hanger Ball onto the Downrod being sure that it's properly positioned over the Cross Pin and the wires are not twisted, tighten Set Screw. (Fig. 10) HANGER BRACKET Make sure the arrow inside the top housing aligns with the arrow on the motor before installing the top housing onto the blade.
  • Page 12 DOWNROD OUTLET BOX CANOPY DOWNROD CROSS PIN SET SCREWS TOP HOUSING HITCH CANOPY COVER LOCK HANGER SUPPLY BALL SET SCREW WIRES SET SCREWS DOWNROD HANGER BRACKET Fig. 6 Fig. 7 Fig. 8 Fig. 9 HITCH PIN LOCK PIN Fig. 10...
  • Page 13 ARROW INSIDE TOP ARROW HOUSING ON MOTOR REGISTRATION SLOT Fig. 12 Fig. 11...

  • Page 14: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: To avoid possible electrical shock be sure electricity is turned off at the main fuse or breaker box before wiring. ® NOTE: The Aire Control System for this DC motor fans is equipped with a learning frequency FREQUENCY function which has 32 code combinations to prevent potential interference from other remote units.
  • Page 15 Step 2. If your outlet box has a GROUND wire (Green or Bare Copper) connect this wire to the Hanger Ball and Hanger Bracket Ground wires. If your outlet box does not have a Ground Wire, then connect the Hanger Ball and Hanger Bracket Ground Wires together. Secure wire connection with BLACK (HOT) GREEN OR BARE the plastic wire nut provided.

  • Page 16: Finishing The Installation

    FINISHING THE INSTALLATION Step 1. Slide the canopy up towards the hanger bracket and place the key hole on the canopy OUTLET BOX over the screw on the hanger bracket, turn canopy until it locks in place at the narrow section of the key holes.

  • Page 17: Operating The Remote Control/Wall Control

    OPERATING THE REMOTE CONTROL/WALL CONTROL Remote Control only: Install a A23 12 volt battery (included). To prevent damage to transmitter remove the battery if not used for long periods of time. IMPORTANT: THIS REMOTE CONTROL & DC FAN MOTOR ARE DESIGNED TO PERFORM A ONE TIME SELF CALIBRATION TEST. THIS TEST WILL IMPORTANT: THIS REMOTE CONTROL &...
  • Page 18 Note: The auto learning function will only shut off when the self calibration test has power after 30 seconds if interruption occurs. mandate within 60 seconds when turning the finished. The total self calibration test will last Please remove obstacles before re-set. fan’s AC power ON.
  • Page 19 Speed settings for warm or cold weather depend on factors such as room size, ceiling height and number of fans. NOTE: To change the direction of the rotation of the blades the fan must be in operation mode. Warm Weather (forward) A DOWNWARD airflow creates a cooling effect as shown in Figure 16.

  • Page 20: Care Of Your Fan

    CARE OF YOUR FAN Cover small scratches with a light application of shoe polish. Here are some suggestions to help maintain your fan. 4. Use a lint free lightly damp cloth (one included with your fan) with ATTENTION: ATTENTION: Use the white cotton gloves provided when handling the lukewarm water or duster to remove dust from the blades.

  • Page 21: Troubleshooting

    TROUBLESHOOTING SYMPTOM SYMPTOM SYMPTOM SYMPTOM Fan Wobble Fan will not start Fans/Light Turn On Fan Sounds Noisy SOLUTION and Off Unexpectedly SOLUTION SOLUTION Check to make sure the wall switch is turned Allow a 24-hour "break in" SOLUTION Make sure outlet box is secured to period.
  • Page 22 SYMPTOM Frequency Interference SOLUTION Turn the power off to your ceiling fan. Please use a small size tool to change the frequency settings on the control system. Return power to the unit. Note: After the AC power is on, do not press any other button on the transmitter before pressing the "OFF" button, doing so will cause the procedure to fail.

  • Page 23: Specifications

    SPECIFICATIONS These are typical readings. Your actual fan may vary. Fan Size Speed Volts Amps Watts N.W. G.W. C.F. They do not include amps and wattage used by the 0.06 1948 light(s). Medium Low 0.09 2864 6.13 0.14 3686 Medium 4.286' 52"...
  • Page 24 1948 2864 3686 4519 13.5 5370 19.9 5974 30.4...
