SERVICE MANUAL
CD RECEIVER
KD-S670
Contents
COPYRIGHT
2001 VICTOR COMPANY OF JAPAN, LTD.
KD-S670
Area Suffix
J
Northern America
COMPACT
DIGITAL AUDIO
1- 2
1- 3
1- 4
1-11
1-12
1-14
1-14
1-15~27
No.49588
Jan. 2001
