5. ▲ Up Arrow (*)
Primary Function: Automatically adjusts
the display to the most optimal setting
possible. (VGA mode only)
Secondary Function: Allows for vertical
scrolling in the OSD menu.
▼
6. Down Arrow
Allows for vertical scrolling in the OSD
menu.
7. SOURCE (*)
Used to select different input sources.
Press the UP or DOWN arrow to scroll
through the available sources, and press
SOURCE arrow to confirm selection.
8. MENU
Turns the OSD window on.
Turns the OSD window off and moves
from sub menu to top menu in the OSD
window.

Changing a monitor parameter

1. Press the MENU button on the front
panel to obtain the OSD menu screen.
2. Use UP-DOWN buttons to select the
menu.
3. Use AUTO or SOURCE button to select
the submenus.
4. Use Up-Down buttons to select a
submenu function.
5. Press AUTO or SOURCE button, then
using left-right buttons you can make
adjustments as necessary.
6. To exit, press MENU.
User Manual

Hot keys

Selects signal in order. VGA -
SOURCE
HDMI - CAM
When there is no OSD, if you
▲
(UP/AUTO)
press this ▲ (UP/AUTO)
button, you can use the best
display performance fit for a
current mode
When there is no OSD, you
◀ ▶
can adjust the volume directly
(VOLUME)

Adjustment procedure

OSD function

Configure the monitor using the on-screen
display (OSD) menus and submenus.
Changes are immediately saved and
implemented.
5
