Summary of Contents for LG-Ericsson GDC-400H
- Page 1 DECT Wireless Handset User Guide GDC-400H...
- Page 3 European Standard for Electromagnetic Compatibility (EMC) ; ETSI EN 301-489-1/-6 3. Privacy: GDC-400H implements security and encryption technologies appropriate for DECT however, privacy of communications may not be ensured when using this telephone. Copyright© 2010 LG-Nortel Co. Ltd. All Rights Reserved This material is copyrighted by LG-Nortel Co Ltd.
- Page 4 • The Charger/base unit should only be used on a dry level surface. Keep the Charger/base away from the edges of the surface to avoid the potential of a fall. • Avoid situations where you might drop the handset. While the GDC-400H is a rugged mobile device, dropping it on to the floor may cause critical damage.
- Page 5 GDC-400H Wireless Handset User Guide Important Safety Information...
- Page 6 GDC-400H Wireless Handset User Guide...
- Page 7 GDC-400H Wireless Handset User Guide...
- Page 8 GDC-400H Wireless Handset User Guide...
- Page 9 GDC-400H Wireless Handset User Guide...
- Page 10 GDC-400H Wireless Handset User Guide...
-
Page 11: Table Of Contents
Enabling Subscriptions ..................... 10 2.6.2 Subscribing to the System ....................10 2.6.3 Terminating a Subscription ....................11 2.7 Authentication ......................12 2.8 Subscribing the GDC-400H to a LWS-BS (LG-Nortel Wireless SOHO-Base Station).........................13 2.8.1 Enabling Subscriptions ..................... 13 2.8.2 Subscribing to the LWS-BS ....................13 2.8.3... - Page 12 5.19 Responding to an Authorization (PIN) Request...........30 5.20 System Voice Announcements................31 5.21 Using System Voice Mail ..................31 5.22 User Program Codes ...................31 6. GDC-400H User Menu Features ............33 6.1 Call Register (Call Log)..................33 6.2 Image & Sound ....................34 6.2.1 Images ..........................34 6.2.2...
- Page 13 6.5.10 Missed Call Mode ......................43 6.5.11 Range Out beep ....................... 43 6.5.12 Clock Display ........................44 6.5.13 Auto Answer Mode ......................44 6.6 Direct Call ......................44 7. Troubleshooting..................45 8. Specifications..................46 9. Dial pad Character Charts ..............47 10. GDC-400H User Menu (Updated) ............49...
-
Page 15: Description
GDC-400H Wireless Handset User Guide Handset Buttons and Features Number Button Description Navigation button: Left arrow – idle state=view missed call, other states=left navigation Right arrow – Idle state=place call (host intercom dial tone), active call state=press to Transfer call, or press and hold 1 second to place call on hold, in User Menu=right navigation. - Page 16 GDC-400H (rear view) External Ear-Mic jack w/cover If an Ear Microphone/Headset is attached to a GDC-400H, it can receive or release a call. It is recommended to use a Headset meeting JIS C-6560 Specification. Press the button on the Ear Microphone/Headset to receive an incoming call when ringing, and do the same action to release the call.
-
Page 17: Gdc-400H Display
User Guide 1.1.2. GDC-400H Display The GDC-400H has a large 128 x 128 pixel full-color LCD (Liquid Crystal Display). The display indicates the status of the handset and provides visual feedback for dialing and other actions. Various icons, detailed in the chart below, are shown at the top of the display. -
Page 18: User Guide
GDC-400H Wireless Handset User Guide Icon Name & Description Alarm clock icon Indicates an Appointment is set. Battery icon Vertical lines indicate battery charge state. At one (1) bar charging is recommended, and call quality may be affected. Common System and Handset Messages... -
Page 21: Charger/Base Unit
At low battery levels (less than 1 battery power bar), the display backlight turns OFF to maximize battery charge. Use only with batteries provided for the GDC-400H. Use of other types of batteries may cause harm to the unit or explosion. -
Page 22: Installing The Belt Clip
Installing the Belt Clip The GDC-400H comes with a belt clip that can be installed on the unit. To install the belt clip, refer to the figure and instructions below. 1. From the back of the unit, place the belt clip on the left side of the unit at an angle of about 90 2. -
Page 23: Subscribing The Gcd-400H To A System
Subscribing the GCD-400H to a System Prior to accepting a connection with a GDC-400H, a subscription to services must be entered into the WMI of your telephone system. This is accomplished in a two step process: the Attendant station enables subscription of a phone to the system, then the GDC-400H subscribes to the system for services. -
Page 24: Terminating A Subscription
User Guide 10. If the subscription fails, repeat procedure from Step 3 to 6 at the Attendant Station and Step 1 to 9 from the GDC-400H (refer to Note). Note: Depending on the system or radio channel environment, the system or the wireless terminal may not recognize that the system has the subscribed wireless terminal or the wireless terminal is subscribed to the system. -
Page 25: Authentication
GDC-400H Wireless Handset User Guide Press Flexible button 8. Enter the Station No. Press [HOLD/SAVE] button and confirmation tone is heard. Confirmation tone (or error tone) will be heard at the Station, and the corresponding Attendant Station. To unsubscribe locally at the wireless terminal:... -
Page 26: Station)
Registering the GDC-400H to a LWS-BS (LG-Nortel Wireless SOHO-Base Station) Prior to accepting a connection with a GDC-400H, a registration to services must be entered into your LWS system. This is accomplished in a two step process: the LWS-BS enables registration of a phone to the system, then the GDC-400H subscribes to the LWS-BS for services. -
Page 27: Terminating A Subscription From Lws-Bs
Note: DEREGISTER STATION : You want to erase registration information of both Base Station (LWS-BS) and Wireless terminals (GDC-400H). STATION FORCED ERASE : You want to erase registration information of the relevant Wireless Terminal. (e.g. in case that the terminal is OFF or missed) In this case, the registration information will be kept on the terminal itself. -
Page 28: Using The Basic Features
Admin, codes are referenced by name. Code digits are available from your System Administrator, or perhaps the Attendant. Turning the GDC-400H ON and OFF Your new Wireless handset operates on two NiMH rechargeable batteries. When not in-use, it should be turned OFF to extend the life of the batteries. -
Page 29: Muting Your Microphone
GDC-400H Wireless Handset User Guide Muting your Microphone During a call, you can mute the microphone so that the connected party can not hear what is said in your vicinity. While the mic is muted you will still hear the connected party. -
Page 30: Placing A Call On Hold
Placing a Call on Hold While you are on a call using the GDC-400H, you may place the caller in a waiting state where the caller hears music on hold. This allows you to place another call or answer a call waiting. -
Page 31: Last Number Redial
) button. The wireless terminal goes to an idle state. 3.10 Last Number Redial The GDC-400H stores the last ten (10) numbers called in memory. These can be internal or external phone numbers. These numbers can be accessed and a number selected quickly for redialing. -
Page 32: System Save Number Redial
GDC-400H Wireless Handset User Guide 3.13 System Save Number Redial You can save a number in the host system memory for quick access at a later time. To Save a number while on an outgoing call: 1. Press Speed/Program ( ) button twice during a call. -
Page 33: Phonebook
User Guide 4. Phonebook The GDC-400H incorporates a Phonebook that stores up to 60 contact records and each record has a name and phone number. The name can be up to 14 digits in length (characters and numbers). From the Phonebook, menu records can be searched, called, added, modified or deleted. -
Page 34: Modifying Records In The Phonebook
GDC-400H Wireless Handset User Guide 5. Select whether or not to use the CO Access code (refer to Edit CO Code) and press the OK ( left soft button. Selecting the CO Access Code will insert the access code in front of the number during dialing. -
Page 35: Using Advance System Features
GDC-400H Wireless Handset User Guide 5. Using Advance System Features Program a System User Name You can store a name in the host system for use as your id when you are called or call another station. The User name is also employed with Dial-by-Name. -
Page 36: Camping-On To A Busy Station
GDC-400H Wireless Handset User Guide To leave a return call request: 1. When your call to another station is unanswered or you receive DND tone, press the ( ) button, you will receive confirmation or, if available, the option to leave a voice message. -
Page 37: Using Station Speed Dialing
GDC-400H Wireless Handset User Guide 2. Dial the Group Call Pick-up code. Refer to your System Administrator or, perhaps the Attendant for the dial code. Note: In certain situations such as private line calls, callbacks, etc., you will not be permitted to pick up a ringing call. -
Page 38: Using System Speed Numbers
GDC-400H Wireless Handset User Guide To use a Station Speed Dial: 1. Press the Talk ( ) button, you receive dial tone. 2. Press the Speed/Program ( ) button. 3. Dial the Speed dial bin location. Using System Speed Numbers In addition to Station Speed Dials, the host system includes memory to store system speed dial numbers available to all stations connected to the system. -
Page 39: Pre-Defined & Custom Text Messaging
GDC-400H Wireless Handset User Guide 5.10 Pre-defined & Custom Text Messaging You can select a text message to be shown on the display of a calling station. When active, incoming intercom callers see the text message in the phone’s LCD. There are ten Pre-defined messages (01-10), ten system wide Custom messages and one User Custom Message. -
Page 40: Responding To A Message Wait Indication
GDC-400H Wireless Handset User Guide 5.11 Responding to a Message Wait Indication Your system supports a number of message formats including station callback message and voice mail. Depending on the host system and configuration, you may receive missed external call messages and internal Short Message Service (SMS). -
Page 41: Blocking Outgoing Calls W/Temporary Cos
GDC-400H Wireless Handset User Guide 5.12 Blocking Outgoing Calls w/Temporary COS As an alternative to the handset Keypad Lock, you can block external calls from the handset employing the host system by activating Temporary Class-of-Service. When Temporary COS is active, the handset can make internal calls but cannot make external calls. -
Page 42: Call Park
4. When done, press the End ( ) button. 5.15 Conference Room GDC-400H cannot initiate a conference. It can, however, create, join, and delete a conference room. To activate (create) a conference room: 1. Press the Talk ( ) button, you receive dial tone. -
Page 43: Using The System Alarm Clock
GDC-400H Wireless Handset User Guide 5.17 Using the System Alarm Clock In addition to the handset Appointment feature, the host system incorporates a wake-up or alarm clock feature. When the alarm time is reached, The system alerts you with ring signal and displays “WAKEUP RING.”... -
Page 44: System Voice Announcements
GDC-400H Wireless Handset User Guide 5.20 System Voice Announcements If the host system includes an integrated voice response system, your handset can play various announcements as well as voice mail features. Announcements include the Date & Time, Station Number and Status. The status prompt includes: •... - Page 45 GDC-400H Wireless Handset User Guide User Pgm Code Description Display Remark Retrieval [2] CL: CALLER ID MSG [3] VS: SYSTEM VOICE MAIL [4] VM: COMMERCIAL VOICE MAIL [5] US: UMS SERVER VM [6] SMS MESSAGE Station No. + 33 & System PIN...
-
Page 46: Gdc-400H User Menu Features
GDC-400H Wireless Handset User Guide 6. GDC-400H User Menu Features GDC-400H incorporates a menu you employ to control various features and attributes of the handset. The Appendix GDC-400H User Menu displays the Menu tree. The main sub-menus are: Call Register (Call Log) ... -
Page 47: Image & Sound
GDC-400H Wireless Handset User Guide Options under the delete selection allow you to delete all records in a specific call log or all records in all the logs. To delete records in a log or all logs: 1. Select the Call Register menu from the User Menu. - Page 48 GDC-400H Wireless Handset User Guide To set the internal or external ring options: 1. Select the Image and Sound menu from the User Menu. 2. Select the Sound. 3. Press the OK ( ) left soft button. 4. Use the Navigation ( ) button to highlight a selection.
-
Page 49: Phone Register
7. Enter the Authorization code (available from the System Administrator, as needed). 8. Press the OK ( ) button; confirmation tone will be heard is received at the GDC-400H and the Attendant’s LCD will display “Subscription Done”. 9. Press the End ( ) button. -
Page 50: Subscription To Lws-Bs
) button and press the OK ( ) button. 5. The GDC-400H searches for the system and displays “Searching..1”. When a system is found, its RFPI, is displayed (verify with your System Administrator, or the Attendant). 6. Press the OK ( ) button to subscribe to the system (RFPI shown). -
Page 51: Base Id
) button. Creating & Modifying an Appointment Your GDC-400H Wireless handset has an Appointment Reminder feature. When set, the handset will remind you of an Appointment with a display of the appointment text and an appointment alert (alarm sound) or vibration alert (if in silent mode). In addition to the time, you can enter the appointment text and set the appointment as daily, monthly or annual. -
Page 52: Phone Settings
GDC-400H Wireless Handset User Guide Annual 3. Use the Navigation ( ) button to highlight a selection. 4. Press the OK ( ) left soft button to access the sub-menu. 5. Use the dial pad to enter For daily, enter the time of day as hh:mm in a 24 hour format. -
Page 53: Clock, Date And Time Display
) button before dialing, the display will change to the system time and date. The Clock Display must be enabled to display the handset time. 6.5.2 Alarm Clock The GDC-400H incorporates an Alarm Clock feature. When the handset clock reaches the alarm time, you are notified by the alarm. To set the Alarm Clock: 1. -
Page 54: Display
OFF until the handset batteries are re charged. 6.5.5 Language The GDC-400H supports multiple languages; you can select one of for languages for use in the display of handset messages. To select a language: 1. -
Page 55: Silent Mode
All other buttons are ignored if pressed, and calls cannot be placed. 6.5.8 S/W Version For maintenance purposes you can request the GDC-400H display the handset software version. To display the current software version of the handset: 1. Select the Phone Setting menu from the User Menu. -
Page 56: Edit Co Code
) button. 6.5.9 Edit CO Code The GDC-400H can subscribe to four (4) DECT zones simultaneously. Each zone may have access to a different set of external lines with different codes. The code is used to place calls from the handset Phonebook as well as for incoming call look-up in the Phonebook. -
Page 57: Clock Display
) button. Direct Call The GDC-400H can be configured to dial a specific number when any button on the handset is pushed. The Direct Call or Hotline number can be enabled and the number to call specified. The direct call (emergency) number is transmitted on input from any key. -
Page 58: Troubleshooting
GDC-400H Wireless Handset User Guide 7. Troubleshooting Problem Possible Cause Solution Assure batteries are properly installed LCD is blank No power and charged. Press and hold the End/Power button for 1 second. “NO CHANNEL” displayed All DECT channels are Wait until a channel is available. -
Page 59: Specifications
Frequency band 1880~1900MHz RF Modulation GSFK Range from Base Station to Handset Maximum=100 meters, Typical=70 meters GDC-400H Wireless DECT Handset Item Spec Size: 133mm × 44mm × 20mm (H×W×D) Weight: 92 grams Color: Warm gray Maximum power:... -
Page 60: Dial Pad Character Charts
User Guide 9. Dial pad Character Charts The integrated GDC-400H Phonebook permits names to be associated with a Phonebook record. The following charts provide the correlation between the dial pad digits and characters. Charts are available for English, Italian, Spanish and Russian. To insert a character, each dial pad button is pressed one or more times to select the desired character. - Page 61 GDC-400H Wireless Handset User Guide Spanish Language Character Chart Dial Pad Button depressions button < > á à é è í ì Ç ñ ó ò ú ù € & Russian Language Character Chart Dial Pad Button depressions button <...
-
Page 62: Gdc-400H User Menu (Updated)
GDC-400H Wireless Handset User Guide 10. GDC-400H User Menu (Updated) - Page 63 GDC-400H Wireless Handset User Guide...
- Page 64 www.lgericsson.com...
