IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this manual
for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased:
___________________
Installation & Operation Manual
MKG24, MKG36, MKG48, MKG60 & MKG72
All Options
C
E T
R
I
F E D
I
I
L25-055 Rev. 0 (05/12)
Advertisement
Table of Contents
Related Manuals for Magikitch'n MKG24
Summary of Contents for Magikitch'n MKG24
- Page 1 Please complete this information and retain this manual for the life of the equipment: Model #: ___________________________ Serial #: ___________________________ Date Purchased: ___________________ Installation & Operation Manual MKG24, MKG36, MKG48, MKG60 & MKG72 All Options F E D L25-055 Rev. 0 (05/12)
- Page 2 TO THE PURCHASER, OWNER AND STORE MANAGER Please review these warnings prior to posting them in a prominent location for reference. WARNING TO THE PURCHASER The appliance is NOT jet stream approved. DO NOT clean the Post in a prominent location the instructions to be appliance with a water jet.
-
Page 3: Table Of Contents
Table of Contents MKG Series Gas Griddle 1. INSTALLATION ....................... 4 1.1. C ....................4 HECKING RIDDLE ) ........................4 LECTRICAL ONNECTION 1.3. I ......................5 NSTALLATION LEARANCES 1.4. G ) ........................5 ONNECTION 1.4.1. Fuel Type(s)...........................5 1.4.2. Quick Disconnect Connection ......................5 1.4.3. -
Page 4: Installation
Installation MKG Series Gas Griddle 1. Installation 1.1. Checking Your New Griddle Your new MagiKitch’n appliance has been carefully packed into one crate. Every effort has been made to ensure that it is delivered to you in perfect condition. As you unpack your new appliance, inspect each of the pieces for damage. -
Page 5: Installation Clearances
Installation MKG Series Gas Griddle 1.3. Installation Clearances Your new MagiKitch’n Griddle needs clearance around it for proper operation. Adequate clearances allow for servicing and proper burner operation. The clearances shown below are for installation in combustible and non-combustible construction. The appliance can be serviced from the front of the unit, however it may need to be pulled away from the wall for access to the gas supply and electrical supply connections. -
Page 6: Installation Setup
1.6.1. Counter Use With Legs CAUTION To prevent equipment damage, DO NOT tilt your MagiKitch'n griddle on only two legs, or on its sides. (See Figure 2) A set of 4” (10.2cm) legs is shipped with the appliance (unless appliance Figure 2 was specifically ordered without legs). -
Page 7: Equipment Stand
Installation MKG Series Gas Griddle 1.6.3. Equipment Stand ATTENTION Rear mounting brackets should be installed to the Equipment Stand prior to placing griddle on the stand. IMPORTANT Install the griddle so that the locking casters are at the front of the unit. The casters should be LOCKED before the unit is placed into operation. -
Page 8: Leveling Instructions
Installation MKG Series Gas Griddle 1.6.4. Leveling Instructions NOTICE Equipment stands are shipped from the factory with the legs or casters set to the minimum height adjustment. Units should be leveled at time of installation, failure to do so could cause the griddle to operate improperly. -
Page 9: Gas Settings
Installation MKG Series Gas Griddle regulator, see Figure 6 & 6a. To check the supply pressure to the appliance use the pressure test point supplied on the manual shut off valve, also see Figure 6 & 6a. 3. Use pipe joint compound that is suitable for use with LP gas on all threaded connections. 4. -
Page 10: Gas Table
Operations MKG Series Gas Griddle 1.7.3. Gas Table AT, BG, CH, CZ, DK, EE, FI, GB, GR, HU, IE, IT, LT, LV, NO, PL, PT, RO, ES, SI, SK, SE, TR 1.85 mm 15.8 2ESI MK24 17.6 G20/G25 1.85/2.1 20/25 1.7/2.0 G20/G25 2ELL... -
Page 11: Operation
Operations MKG Series Gas Griddle 2. Operation Ensure that a proper installation has been performed on the appliance and that all warnings, cautions, and notices contained in this manual have been read, understood and adhered to before proceeding. 2.1. Lighting Instructions 2.1.1. -
Page 12: Initial Startup
Operations MKG Series Gas Griddle CAUTION If Pilot Ready light(s) does not illuminate, Turn all Thermostat "I/O" switches for that pilot to “O”(OFF), wait five minutes before attempting to re-light. WARNING If the gas supply and/or the electrical power is interrupted, or if pilot(s) extinguish, turn the thermostat knobs and the gas shut off valve to the "OFF"... -
Page 13: Thermostat Calibration Section
Calibration MKG Series Gas Griddle 3. Thermostat Calibration Section Each control typically operates a pair of burners with a Snap action, Electric or Solid State. The controls were set at the factory. However, if the griddle’s surface temperature varies greatly from the setting on the thermostat knob, adjust the thermostat using the following procedure: 3.1. -
Page 14: Basic Operation
Basic Operation MKG Series Gas Griddle 4. Basic Operation 4.1. Operational Helpful Hints 1. Each thermostat controls 12" (30.5cm) of griddle surface, whenever possible, use the leftmost or rightmost thermostats for the lowest cooking temperatures. The adjacent thermostats set at higher temperatures will effect centrally located thermostats. -
Page 15: Cleaning & Maintenance Section
Shine the Chrome griddle cooking surface with Magi Kleans'r, water and a soft cloth. Rinse with clean water and wipe away any residue with a dry cloth. 5.3. Monthly Maintenance NOTICE Regular maintenance of your MagiKitch'n griddle is Recommended to keep the appliance operating properly. 5.3.1. Monthly Preventative Maintenance Food debris and grease can buildup in and around the griddle . -
Page 16: Annual/Periodic Preventative Maintenance And Inspection
Cleaning & Maintenance MKG Series Gas Griddle Make sure that all gas connections have not been tampered with or damaged, check for leaks with a soapy water solution. Never use an open flame to check for leaks. Check to see that the flue exhaust area has no food debris, or blocked in any way. Never allow the flue to become excessively dirty. -
Page 17: Trouble Shooting Charts
Griddle Stays Hot Or Overheats NOTICE All parts and service for your MagiKitch'n griddle should be ordered and installed by a MagiKitch'n Authorized Service and Parts (ASAP) dealer. Failure to do so might result in the warranty being voided. L25-055 Rev. 0 (05/12) -
Page 18: Accessories
Scraper, (W/ Blade and Cover Part No. 9825-1528001 Replacement Blades Part No. 9825-1528002 Using MagiKitch'n chrome griddle accessories are important to maintaining the life of the griddle's chrome surface 6.2. Optional To order accessories for your griddle, call your local MagiKitch’n dealer for prices and availability. -
Page 19: Cutting Boards
Accessories MKG Series Gas Griddle WORKSHELVES WITH AND WITHOUT TOWEL BARS TOWEL BAR ONLY PAN CUTOUTS AND CUTTING BOARDS ARE AVAILABLE ON LARGER WORKSHELVES 6.2.2. Cutting Boards Size Part No. 8" X 12" (20.3 cm X 30.5 cm) Cutting Board 1604-0643600-C 8"... -
Page 20: Warming Shelves, Rear
Accessories MKG Series Gas Griddle 6.2.3. Warming Shelves, Rear Shelf Model Part No. C/A, Shelf Rear MKG24 5225-1535701-C C/A, Shelf Rear MKG36 5225-1535702-C C/A, Shelf Rear MKG48 5225-1535703-C C/A, Shelf Rear MKG60 5225-1535704-C C/A, Shelf Rear MKG72 5225-1535705-C Shelf Kits can be attached to existing models. The Stainless Steel shelf is removable from the shelf framework for easier cleaning if necessary. -
Page 21: Equipment Stands
It should also be noted that when ordering an equipment stand for your MKG appliance, you will also need to order and MKG Joining Kit, Part No. 7225-1512101. Equipment Stand Model Part No. MKG24, W/ Legs 5225-1512001-C MKG24, W/ Casters 5225-1512002-C... -
Page 22: Miscellaneous
Accessories MKG Series Gas Griddle 6.2.5. Miscellaneous Your appliance can also be used with the following miscellaneous accessories so you can customize your operation to your specific demands.. The wall spacers listed below insure that you cannot push the appliance too close to the rear wall. The Utensil box gives you a handy location to store your cooking tools. - Page 24 In the event of problems with or questions In the event of problems with or questions about your order, please contact about your equipment, please contact the MagiKitch’n factory at: MagiKitch’n Authorized Service and Parts representative (ASAP) covering your area, PH- (603) 225-6684 World Wide or contact Pitco at the numbers listed to the Website- www.magikitchn.com...
