Installation & Operation Manual
MKH24, MKH36, MKH48, MKH60 & MKH72
All Options
C
E T
R
I
F E D
I
I
L25-053 Rev. 1 (12/11)
Advertisement
Table of Contents
Related Manuals for Magikitch'n MKH24
Summary of Contents for Magikitch'n MKH24
- Page 1 Please complete this information and retain this manual for the life of the equipment: Model #: __________________________ Serial #: __________________________ Date Purchased: ___________________ Installation & Operation Manual MKH24, MKH36, MKH48, MKH60 & MKH72 All Options F E D L25-053 Rev. 1 (12/11)
- Page 2 TO THE PURCHASER, OWNER AND STORE MANAGER Please review these warnings prior to posting them in a prominent location for reference. TO THE PURCHASER WARNING Post in a prominent location the instructions to be followed If the appliance is equipped with a power cord and it is in the event that an operator smells gas.
-
Page 3: Table Of Contents
Table of Contents MKH Series Gas Griddle 1. INSTALLATION SECTION..................4 1.1. C ....................4 HECKING RIDDLE 1.2. E ) ......................4 LECTRICAL ONNECTION 1.3. I ......................5 NSTALLATION LEARANCES 1.4. G ) ........................5 ONNECTION 1.4.1. Fuel Type(s)..........................5 1.4.2. Quick Disconnect Connection ....................... 5 1.4.3. -
Page 4: Installation Section
Installation MKH Series Gas Griddle 1. Installation Section 1.1. Checking Your New Griddle Your new griddle has been carefully packed into one crate. Every effort has been made to ensure that your new griddle is delivered to you in perfect condition. As you unpack your new appliance, inspect each of the pieces for damage. -
Page 5: Installation Clearances
Installation MKH Series Gas Griddle 1.3. Installation Clearances Your new MagiKitch’n Griddle needs clearance around it for proper operation. Adequate clearances allow for servicing and proper burner operation. The clearances shown below are for installation in combustible and non-combustible construction. The appliance can be serviced from the front of the unit, however it may need to be pulled away from the wall for access to the gas supply and electrical supply connections. -
Page 6: Installation Setup
Counter Use With Legs CAUTION To prevent equipment damage, DO NOT tilt your MagiKitch'n griddle on only two legs, or on its sides. (See Figure 2) A set of 4” legs is shipped with the appliance (unless appliance was specifically ordered without legs). -
Page 7: Leveling Instructions
Installation MKH Series Gas Griddle NOTICE Larger models have 6 threaded receiving holes, but require only the four 1/2" bolts on each corner to mount the griddle. 1. Remove (4) existing 1/4-20 nuts and bolts from the rear corners of the equipment stand. -
Page 8: Final Gas Connection
Installation MKH Series Gas Griddle 1.7. Final Gas Connection A properly installed gas supply system will deliver adequate pressure (7 to 8 inches w.c. for natural gas, 11 to 12 inches w.c. for propane) to all appliances connected to the line, operating at full demand. 1.7.1. -
Page 9: Operation Section
Operations MKH Series Gas Griddle 2. Operation Section Ensure that a proper installation has been performed on the appliance and that all warnings, cautions, and notices contained in this manual have been read, understood and adhered to before proceeding. 2.1. Lighting Instructions 2.1.1. -
Page 10: Griddle Surface Seasoning
Operations MKH Series Gas Griddle Seasoning is not required on a Chrome Plated Cooking surface, but the following procedure may be performed to improve the non-stick qualities of the chrome plated cooking surface. 2.2.1. Griddle Surface Seasoning 1. To season the griddle, Light all pilots and turn all the thermostat controls to 200°F. As the unit heats up to 200°F, apply a light film of cooking oil or beef suet over the entire cooking surface, wiping off any excess build up. -
Page 11: Thermostat Calibration Section
Calibration MKH Series Gas Griddle 3. Thermostat Calibration Section Each control typically operates a pair of burners with a Snap action, Electric or Solid State. The controls were set at the factory. However, if the griddle’s surface temperature varies greatly from the setting on the thermostat knob, adjust the thermostat using the following procedure: 3.1. -
Page 12: Basic Operation
Basic Operation MKH Series Gas Griddle 4. Basic Operation 4.1. Operational Helpful Hints 1. Each thermostat controls 12" of griddle surface, whenever possible, use the leftmost or rightmost thermostats for the lowest cooking temperatures. The adjacent thermostats set at higher temperatures will effect centrally located thermostats. -
Page 13: Cleaning & Maintenance Section
Shine the Chrome griddle cooking surface with Magi Kleans'r, water and a soft cloth. Rinse with clean water and wipe away any residue with a dry cloth. 5.3. Monthly Maintenance NOTICE Regular maintenance of your MagiKitch'n griddle is Recommended to keep the appliance operating properly. 5.3.1. Monthly Preventative Maintenance Food debris and grease can buildup in and around the griddle . -
Page 14: Annual/Periodic Preventative Maintenance And Inspection
Cleaning & Maintenance MKH Series Gas Griddle ü Visually check the appearance of the main burners, all burners should have a nice blue flame. ü Make sure that all gas connections have not been tampered with or damaged, check for leaks with a soapy water solution. -
Page 15: Trouble Shooting Charts
Griddle Stays Hot Or Overheats NOTICE All parts and service for your MagiKitch'n griddle should be ordered and installed by a MagiKitch'n Authorized Service and Parts (ASAP) dealer. Failure to do so might result in the warranty being voided. L25-053 Rev. 1 (12/11) -
Page 16: Accessories
Scraper, (W/ Blade and Cover Part No. 9825-1528001 Replacement Blades Part No. 9825-1528002 Using MagiKitch'n chrome griddle accessories are important to maintaining the life of the griddle's chrome surface 6.2. Optional To order accessories for your griddle, call your local MagiKitch’n dealer for prices and availability. -
Page 17: Cutting Boards
Accessories MKH Series Gas Griddle WORKSHELVES WITH AND WITHOUT TOWEL BARS TOWEL BAR ONLY PAN CUTOUTS AND CUTTING BOARDS ARE AVAILABLE ON LARGER WORKSHELVES 6.2.2. Cutting Boards Size Part No. 8" X 12" Cutting Board 1604-0643600-C 8" X 24" Cutting Board 1604-0643700-C 8"... -
Page 18: Warming Shelves, Rear
Accessories MKH Series Gas Griddle 6.2.3. Warming Shelves, Rear Shelf Model Part No. C/A, Shelf Rear MKG24 5225-1535701-C C/A, Shelf Rear MKG36 5225-1535702-C C/A, Shelf Rear MKG48 5225-1535703-C C/A, Shelf Rear MKG60 5225-1535704-C C/A, Shelf Rear MKG72 5225-1535705-C Shelf Kits can be attached to existing models. The Stainless Steel shelf is removable from the shelf framework for easier cleaning if necessary. -
Page 19: Equipment Stands
Accessories MKH Series Gas Griddle 6.2.4. Equipment Stands Equipment stands can be ordered with legs or casters (stands with casters shipped after May 2006 are equipped with adjustable casters). NOTE: It should also be noted that when ordering an equipment stand for your MKG appliance, you will also need to order and MKG Joining Kit, Part No. -
Page 20: Miscellaneous
Accessories MKH Series Gas Griddle 6.2.5. Miscellaneous Your appliance can also be used with the following miscellaneous accessories so you can customize your operation to your specific demands.. The wall spacers listed below insure that you cannot push the appliance too close to the rear wall. The Utensil box gives you a handy location to store your cooking tools. -
Page 21: Notes Page
Notes MKH Series Gas Griddle 7. Notes Page L25-053 Rev. 1 (12/11) - Page 22 In the event of problems with or questions In the event of problems with or questions about your order, please contact about your equipment, please contact the MagiKitch’n factory at: MagiKitch’n Authorized Service and Parts representative (ASAP) covering your area, PH- (603) 225-6684 World Wide or contact Pitco at the numbers listed to the Website- www.magikitchn.com...
