Introduction

Thank you for choosing a Traxxas Revo. We believe you have
3 Before You
Proceed purchased the finest, most technologically advanced R/C monster
truck available. Revo proudly demonstrates Traxxas' passionate
4 Safety
commitment innovation, ultimate performance, and unmatched
Precautions
engineering. Revo's radically advanced suspension, chassis, and
transmission design takes performance to a higher level. Now with
5 Tools, Supplies
larger TRX 3.3 Racing Engine, Revo pushes the performance envelope
and Required
even further with relentless, over-the-top horsepower. We've
Equipment
engineered the Revo to allow you to experience power, control, and
responsiveness that surpasses anything else you've driven.
6 Anatomy of
Your Revo
The new TRX 3.3 Racing Engine is the most powerful engine of its size
ever available in a Ready-To-Run truck. Advanced engineering and
7 Quick Start:
design, along with thousands of hours of testing, puts the TRX 3.3 in a
Getting Up to
class by itself. Each part of the TRX 3.3 - from the air filter on the slide
Speed
carburetor, to the tip on the dyno-tuned exhaust system - has been
carefully engineered to provide maximum power over the broadest
8 Gluing the Tires
rpm range.
and Decorating
Your Revo
Revo is equipped with the patent pending OptiDrive
transmission control. Advanced electronic reduce the number of
9 The Traxxas
moving parts inside the transmission for less weight, smooth
TQ-3 Radio
engagement and efficient performance.
System
Traxxas was the first with standard on-board electric starting.
18 The TRX 3.3
The EZ-Start has evolved into an incredibly advanced and reliable
Racing Engine
starting solution, featuring thermal protection for the motor and
built-in diagnostics to monitor the condition of the glow plug.
33 Driving
Your Revo
We know you're excited about getting your new Revo on the road,
but it's very important that you take some time to read through the
34 Basic Tuning
Owners Manual. This manual contains all the necessary set-up, break-
Adjustments
in, tuning, and operating procedures that allow you to unlock the
incredible performance and adjustment potential that Traxxas
40 Maintaining
engineers designed into Revo. Even if you are an experienced R/C
and Storing
enthusiast, it's important to read and follow the procedures in this
Your Revo
manual. Revo contains new technologies in the engine, suspension,
42 Advanced Tuning
and transmission operation that you may not be familiar with. Pay
Adjustments
particular attention to the fuel and break-in requirements for the
engine.
46 Index
special break-in procedure that has been developed and proven to
2 • Revo 3.3
The advanced design of the TRX 3.3 Racing Engine has a
Traxxas Support
Traxxas support is with you every step of the way.
Refer to the next page to find out how to contact
us and what your support options are.
Quick Start
This manual is designed with a Quick Start path
that covers only the necessary procedures to get your model
up and running in the shortest time possible. If you are an
experienced R/C enthusiast you will find it helpful and fast.
Be sure and read through the rest of the manual to learn
about important safety, maintenance, and adjustment
procedures. Turn to page 7 to begin.
produce the best-performing engine possible. Using traditional or
old-fashioned procedures could reduce engine performance and
™
electronic
longevity.
Revo is made to be a complete package that starts with the highest
level of engineering; a professionally produced DVD to acquaint you
with the starting, racing, and maintenance procedures; and is
equipped stock with the most powerful Ready-To-Race® engine
available. We want you to feel confident that you own the best-
performing truck in the market and that it is backed by a team of
professionals who aim to provide the highest level of factory support
possible. Revo is about experiencing total performance and
satisfaction, not just with your truck, but also with the company that
stands behind it.
Thank you again for going with Traxxas. We work hard every day
to assure you the highest level of customer satisfaction possible.
We truly want you to enjoy your new Revo!
