Traxxas Jato 3.3 5507 Owner's Manual

2wd nitro racing truck
Hide thumbs Also See for Jato 3.3 5507:
Table of Contents

Advertisement

Quick Links

MODEL 5507
owners manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jato 3.3 5507 and is the answer not in the manual?

Questions and answers

Vickie Griffin
June 6, 2025

How do you connect a servo to the receiver on the Traxxas jato nitro buggy

0
Vickie Griffin
June 6, 2025

How do I connect a new servo to the receiver

0

Related Manuals for Traxxas Jato 3.3 5507

Summary of Contents for Traxxas Jato 3.3 5507

  • Page 1 MODEL 5507 owners manual...
  • Page 2 Thank you again for going with Traxxas. We work hard every day to assure you the highest level of customer satisfaction possible. We truly want you to enjoy your new Jato 3.3!
  • Page 3 Traxxas service needs. Maintenance and replacement trademarks of Traxxas. Other identified by the icons below. Be sure to read them! parts may be purchased directly from Traxxas by phone or online brand names and marks are at BuyTraxxas.com. You can save time, along with shipping...
  • Page 4 SAFETY PRECAUTIONS BELOW TEXT HAS BEEN UPDATED on 3-14-07 All of us at Traxxas want you to safely enjoy your new Jato. Operate your • Do not cut the antenna “stinger” or any other part of the antenna wire. Jato sensibly and with care, and it will be exciting, safe, and fun for you and Cutting the antenna will reduce range.
  • Page 5 10% quart - #5010 20% quart - #5020 33% quart - #5030 10% gallon - #5060 20% gallon - #5070 33% gallon - #5080 Traxxas Top Fuel After-run oil to protect Small flat-blade screwdriver ™ 8 AA alkaline batteries see page 18...
  • Page 6 ANATOMY OF THE JATO 3.3 EZ-Start Air Filter Fuel Line Steering Servo Plug Engine Shut-off (under top plate) Slipper Clutch Clamp Throttle/Brake Roll hoop Suspension Arm Spur Gear Servo Battery Box, Brake Tension Mid Location Fuel Pull Ring Oil Shock (Damper) Adjuster On/Off Switch Throttle Return...
  • Page 7 QUICK START: GETTING UP TO SPEED The following guide is an overview of the procedures for getting your Jato running, from opening the box to breaking in and tuning your engine. Refer to the pages indicated for details on each step. Look for the Quick Start logo on the bottom corners of Quick Start pages. The Quick Start Guide is not intended to replace the 1.
  • Page 8 TRAXXAS TQ RADIO SYSTEM INTRODUCTION NiMH - Abbreviation for nickel-metal hydride. Rechargeable NiMH Your model includes the latest Traxxas TQi 2.4GHz transmitter with To prevent loss of radio range batteries offer high current handling, and much greater resistance Traxxas Link ™...

  • Page 9: Transmitter And Receiver

    RADIO SYSTEM Your model is equipped with the TQi 2.4 GHz transmitter with Traxxas Link Model Memory. The transmitter has two channels for controlling your throttle and steering. The receiver inside the model has 5 output channels. Your model is equipped with two Jato has a provision for servos and a receiver.

  • Page 10: Installing Receiver Batteries

    Traxxas’ integrated TRX Power System is the easiest way to add the 5. Replace the rear battery compartment cover and reinstall the four power and economy of rechargeable batteries to your Jato 3.3.

  • Page 11: Installing Transmitter Batteries

    TRAXXAS TQ RADIO SYSTEM INSTALLING TRANSMITTER BATTERIES Your TQi transmitter uses 4 AA batteries. The battery compartment Using the mid battery is located in the base of the transmitter. compartment provides improved center-of-gravity for better on-road performance. When using the mid battery...
  • Page 12 TRAXXAS TQ RADIO SYSTEM 5. When looking down at model, the RADIO SYSTEM BASIC ADJUSTMENTS front wheels should be pointing When the engine is running, Throttle Neutral Adjustment straight ahead. If the wheels are do not use the throttle trim...
  • Page 13 TRAXXAS TQ RADIO SYSTEM TQi Binding Instructions Decreased Steering Sensitivity (Negative Exponential) For proper operation, the transmitter and receiver must be By turning the Multi- Turning Range Effective Turning To prevent loss of radio range Range on Model at Transmitter electronically ‘bound.’...

  • Page 14: Air Filter Maintenance

    INTRODUCTION The TRX 3.3 Racing Engine is the next generation of TRX nitro ® Traxxas strongly discourages power. The larger displacement and advanced porting generate changing or modifying any class-leading horsepower while still maintaining the TRX Racing part of the TRX 3.3 Racing Engine.
  • Page 15 THE TRX 3.3 RACING ENGINE TRX 3.3 RACING ENGINE ILLUSTRATED Jato’s fuel tank is equipped Air Filter Head Protector with a built-in sintered Housing bronze fuel filter. Cylinder head Idle Speed Screw EZ-Start Drive Unit EZ-Start Motor High-Speed Needle Low-Speed Needle Fuel Intake Crankcase Air Intake...
  • Page 16 The break-in procedure can be different for Flame-out - Occurs when the engine stops running at high rpm. different makes of engines. Follow the Traxxas directions for break- Usually the fault of an excessively lean fuel mixture or glow in exactly.
  • Page 17 Leaning the mixture - Turning either the high-speed and/or low- to the tank. On a Traxxas model this is done by holding your finger speed needle(s) clockwise to decrease the amount of fuel the over the exhaust tip for one or two seconds while the engine is engine receives.
  • Page 18 10% nitro blend is more economical for the sport user. 10% also • Top Fuel is the only fuel which is 100% certified for use in Traxxas engines. fuel dispensing bottle on provides greater latitude with the needle settings for easier tuning.
  • Page 19 Use only the supplied filter. You will not improve engine performance by switching to an aftermarket filter, and you may risk 5. Oil the foam element with foam filter oil. Use the supplied Traxxas engine damage due to poor filtration.
  • Page 20 THE TRX 3.3 RACING ENGINE THE FUEL MIXTURE NEEDLES THE CARBURETOR The amount of fuel metered and atomized by the carburetor is Understanding the Carburetor adjustments See page 26 for more controlled by the two mixture needles, the high-speed needle and information on how air The carburetor performs several functions.
  • Page 21 THE TRX 3.3 RACING ENGINE EZ-START ELECTRIC STARTING SYSTEM Lean Rich The Traxxas EZ-Start brings the convenience of push-button electric Factory Needle Settings engine starting to your Jato. The EZ-Start consists of a hand-held control If your factory preset unit and an on-board motorized starter.
  • Page 22 THE TRX 3.3 RACING ENGINE Installing the EZ-Start Battery to the motor and the controller. This may occur, for example, if the engine floods with fuel during starting. The starter spins at first but 1. Press the tab in the end of the battery Using Other Chargers when excessive fuel in the combustion chamber begins to lock up the Another convenient option...
  • Page 23 THE TRX 3.3 RACING ENGINE BREAKING IN YOUR TRX 3.3 RACING ENGINE • Keep extra Traxxas glow plugs handy. The break-in process can cause The TRX 3.3 Racing Engine uses a ringless, aluminum-brass-chrome See Important Points to deposits to form on the plug leading to plug failure.
  • Page 24 Only use the Traxxas break-in over a 3-second count, hold for 2 more seconds, and then thousand two, and then stop. Repeat this starting and stopping procedure.
  • Page 25 THE TRX 3.3 RACING ENGINE Winter Break-in Tips During the break-in process, the piston and sleeve wear into • We do not recommend that you operate your engine below 35° When tuning for each other to form a precise fit. The engine needs to heat up to a Fahrenheit.
  • Page 26 THE TRX 3.3 RACING ENGINE Before you begin tuning, the engine should be warmed up to its normal Low-Speed Fuel Mixture Adjustment operating temperature and running slightly rich. All final tuning adjustments The low-speed mixture is always set after the high-speed needle is When adjusting the low must be made to the engine at its normal operating temperature.
  • Page 27 . If engine temperature is exceeding 270°F with proper cooling optional infrared temperature probe or and no signs of abnormal running, then avoid running the engine at its on-board temperature gauge (Traxxas maximum lean setting. Watch closely for any signs of overheating. on-board digital temperature gauge, part Richen the fuel mixture slightly to provide a safety margin of additional #4091).
  • Page 28 DRIVING YOUR JATO INTRODUCTION Driving Tips Your TRX 3.3 Racing Engine is broken in, the fuel mixture is balanced, • Jato is very fast. Select a large area to drive with few opportunities and the idle is set…now it’s time to have some fun! This section for collision until you become familiar with Jato’s speed and contains instructions on making adjustments to your Jato.
  • Page 29 Optional springs available from Traxxas are listed below. Refer to your Adjustment procedures for alignment, spring rate, damping, steering, controlling wheelies can parts list for a complete part number listing. Higher rate springs are be difficult.
  • Page 30 BASIC TUNING ADJUSTMENTS Upper Shock Mounting Positions Replacing Shock Oil The upper shock mounting positions will For easier service, the shocks should be removed Important: The shocks are have suspension effects opposite from the from the vehicle and disassembled to change the oil. assembled at the factory lower shock mounting positions.

  • Page 31: Steering System

    BASIC TUNING ADJUSTMENTS Static Camber Adjustment When to Use the Thick (Black) vs. the Thin (Silver) Bar The wheels can be set to have either positive The stock white swaybars should be adequate for most situations. For caster and roll center or negative camber (see illustrations right).

  • Page 32: Brake Setup & Adjustment

    Loosen each of the shoulder bolts by 1 turn. with non-Traxxas servos. 4. Verify that the servo horn is positioned Brake Linkage Adjustment Less Brake...
  • Page 33 BASIC TUNING ADJUSTMENTS 2. Protecting the drivetrain from sudden impact or shock loads (such as 5. Turn the adjustment screw 1/8 turn landing from a jump with the engine at full throttle). clockwise to raise the shift point (shifts later). Turn the adjustment screw counter- Shift From the factory the slipper clutch is set for minimal slippage, just Later...
  • Page 34 • Perform after-run maintenance on the engine. This clears the engine crankcase, crankshaft, and Traxxas engine whenever the model will be stored for of destructive moisture and other corrosive deposits. This is extremely engine bearings are made longer than a few hours.
  • Page 35 A 5/16 or 8mm nut driver will also work. 3. Turn the model upside down and plug in the EZ-Start controller. If you have questions or need technical assistance, call Traxxas at 1-888-TRAXXAS 4. Push the EZ-Start button for several seconds to clear the engine of excess fuel.
  • Page 36 ADVANCED TUNING ADJUSTMENTS This advanced tuning guide will take you one step further into the 3. Disconnect the throttle return spring from the molded chassis brace. 4. Remove the two 4x18-countersunk machine innovative adjustment possibilities that have been designed into Jato.
  • Page 37 ADVANCED TUNING ADJUSTMENTS Camber Gain Down Travel Limiters (optional) Jato has provisions for adjusting the camber gain geometry of An optional kit is available separately for the front and rear suspension. The camber gain of the vehicle can installing suspension down travel limiters be changed by moving the camber link attachment to a different on the front and rear of Jato.

  • Page 38: Transmission And Differential Tuning

    The performance of the differential can be tuned for different driving conditions and performance requirements. The differential is filled with If you have questions or need technical assistance, call Traxxas at silicone differential fluid, and is sealed to maintain consistent 1-888-TRAXXAS long-term performance.
  • Page 39 Traxxas Link Model Memory. remembers the throttle trim turn, thus making the model easier to drive throughout the rest of the Multiple Settings and the Multi-Function Knob setting.
  • Page 40 To delete a model: in your collection and simply turn them on and drive. With Traxxas Link At some point, you may wish to delete a model you no-longer drive Model Memory, there is no need remember which transmitter goes from the memory.
  • Page 41 3. Press SET. The red LED will blink in single intervals to indicate Steering Dual Rate has been selected. Unlock Model Locking Press Traxxas-Link Press 4. Press MENU twice. The red LED will blink three times repeatedly to One Blink Green One Blink Red Four Blinks Green indicate Steering Percentage has been selected.
  • Page 42 ADVANCED TUNING GUIDE Set Multi-Function MENU TREE FORMULAS knob for STEERING Press/hold MENU Press SET Press SET to confirm Press/hold MENU SENSITIVITY (Expo) To select functions and make adjustments to the TQi transmitter without green LED blinks red LED blinks green LED blinks (x8) returns to driving mode referencing the menu tree, turn your transmitter on, find the function in the...
  • Page 43 The TQi radio system automatically keeps track of what vehicles it has bound to and what settings were used for each--up to 30 models total! Traxxas Link provides a visual interface to name the models, customize their settings, attach profiles, and lock them into memory.
  • Page 44 MODEL 5507 1100 Klein Road, Plano, Texas 75074 1-888-TRAXXAS 120213 KC1435_R01...
