This manual is based on firmware version 9.41-
1710. If you have an older or newer firmware ver-
sion some of the functions mentioned in this manu-
al may not be present or may operate differently.
We are committed to your satisfaction with this product. If you have any ques-
tions or require technical assistance please contact us at any of the coordinates
below:
Flanders Scientific, Inc.
470 Satellite Blvd. NE
Suite P
Suwanee, GA 30024
Phone: 678.835.4934
Fax: 678.804.1882
E-Mail:
Support@FlandersScientific.com
www.FlandersScientific.com
Click Here to Open Print Friendly
Version of this Document
Many of the topics covered in this
manual are also covered by our
Video Manual available at:
www.FlandersScientific.com
LCD Monitor User Manual
LM-1760W & LM-1760WF
Version 2.7 (Updated 5.23.2011)
LM-0750W
LM-1770W
LM-2450W
LM-2460W
LM-2461W
LM-2470W
