Model No. IMTL13905.0
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT DI-
RECTLY.
CALL TOLL-FREE:
1-800-753-4645
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.iconservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.imagefitness.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Image IMTL13905.0
Summary of Contents for Image IMTL13905.0
- Page 1 Model No. IMTL13905.0 Serial No. Find the serial number in the location shown below. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you...
-
Page 2: Table Of Contents
LIMITED WARRANTY ............. . .Back Cover Note: An EXPLODED DRAWING is attached in the center of this manual. IMAGE is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
11. Use only a single-outlet surge suppressor that meets all of the specifications described on page 10. To purchase a surge suppressor, see your local IMAGE dealer or call the toll-free telephone number on the front cover of this manual and order part number 146148, or see your local electronics store. - Page 4 22. When using iFIT.com programs, an electronic “chirping” sound will alert you when the speed and/or incline of the treadmill is about to change. Always listen for the “chirp” and be prepared for speed and/or incline changes. In some instances, the speed and/or incline may change before the personal trainer de- scribes the change.
-
Page 5: Before You Begin
® number and serial number before contacting us. The model number of the treadmill is IMTL13905.0. The se- rial number can be found on a decal attached to the treadmill (see the front cover of this manual for the lo- cation). -
Page 6: Assembly
ASSEMBLY To hire an authorized service technician to assemble the treadmill, call toll-free 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. - Page 7 2. Have a second person hold the console assembly near the Upright (111). Insert the wire harness extending from the console assembly through the hole in the top of the Upright. Attach the console assembly to the Upright with four Console Bolts (110) and two Star Washers (114). Firmly tighten the four Console Bolts.
- Page 8 4. Identify the Right Handrail (86) and the Left Handrail (89); the Handrails have indented holes in the outer sides for the heads of the Handrail Bolts (90). Hold the Right Handrail (86) on the right side of the tread- mill.
-
Page 9: How To Move The Treadmill
If you purchase the optional chest pulse sensor (see page 26), follow the steps below to install the re- ceiver included with the chest pulse sensor. 1. Make sure that the power cord is unplugged. 2. Remove the indicated 3/4” Screw (95) and the Access Door (121) from the bottom of the Console Base (98). -
Page 10: Operation And Adjustment
(see drawing 1 at the right). To purchase a surge suppressor, see your local IMAGE dealer or call the toll-free tele- phone number on the front cover of this manual and order part number 146148, or see your local electronics store. -
Page 11: Features Of The Console
Note: If there is a thin sheet of plastic on the face of the console, remove it. FEATURES OF THE CONSOLE The treadmill console offers an impressive array of features designed to make your workouts more effec- tive and enjoyable. When the manual mode of the con- sole is selected, the speed and incline of the treadmill can be changed with the touch of a button. -
Page 12: How To Turn On The Power
HOW TO TURN ON THE POWER Note: To prevent damage to the walking platform, always wear clean shoes when using the treadmill. Plug in the power cord (see page 10). Next, locate the reset/off circuit breaker on the frame near the power cord, and switch the circuit breaker to the reset position. - Page 13 Adjust the cushioning system as desired. The treadmill features a cushioning system that reduces the impact as you walk or run on the treadmill. There are fif- teen firmness levels. To increase the firmness of the walking platform, turn the Active Response Cushioning knob coun- terclockwise.
- Page 14 To see the total number of miles that you have walked or run during a recent period of time, such as the most recent month, press the Odometer button again; the words “My Miles” and the total number of miles will appear in the display. To reset this number, hold down the Odometer button for a few seconds.
-
Page 15: How To Use A Preset Program
HOW TO USE A PRESET PROGRAM Insert the key into the console. See HOW TO TURN ON THE POWER on page Identify yourself as user A, B, C, or D. See step 2 on page 12. Select one of the preset programs. To select one of the fifteen pre-... - Page 16 If the speed and/or incline settings of the program are too high or too low, you can change the inten- sity level of the program at any time by turning the Program Intensity dial. If you wish to save the new intensity level of the program for future workouts, press the Save button.
-
Page 17: How To Create A Custom Program
HOW TO CREATE A CUSTOM PROGRAM Insert the key into the console. See HOW TO TURN ON THE POWER on page Identify yourself as user A, B, C, or D. See step 2 on page 12. Select one of the custom programs. To select a custom pro- gram, press... -
Page 18: How To Use A Custom Program
HOW TO USE A CUSTOM PROGRAM Insert the key into the console. See HOW TO TURN ON THE POWER on page Identify yourself as user A, B, C, or D. See step 2 on page 12. Select one of the custom programs. To select a custom pro- gram, press... -
Page 19: How To Use A Heart Rate Program
Adjust the cushioning system as desired. See step 6 on page 13. Follow your progress with the display. See step 7 on page 13. Measure your heart rate if desired. See step 8 on page 14. Turn on the fans if desired. See step 9 on page 14. - Page 20 The target heart rate setting for the first seg- Current Segment ment will be shown in the flashing Current Segment column of the matrix. The target heart rate settings for the next twelve segments will be shown in the columns to the right. If heart rate program 4 is selected, the...
- Page 21 HOW TO CONNECT THE TREADMILL TO USE IFIT.COM PROGRAMS To use iFIT.com MP3 or CD programs, the treadmill must be connected to your MP3 player, CD player, portable stereo, home stereo, or computer. See pages 21 and 22 for connecting instructions. To use iFIT.com programs directly from our Web site, the treadmill must be connected to your computer.
- Page 22 HOW TO CONNECT YOUR HOME STEREO Note: If your stereo has an unused LINE OUT jack, see instruction A below. If the LINE OUT jack is being used, see instruction B. A. Plug one end of a long 1/8” to RCA stereo audio cable (available at electronics stores) into the input jack on the console.
- Page 23 HOW TO CONNECT YOUR VCR Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV with a built-in VCR, see instruction B. If your VCR is connected to your home stereo, see HOW TO CONNECT YOUR HOME STEREO on page 22.
- Page 24 During the program, an electronic “chirping” sound will alert you when the speed and/or incline of the treadmill is about to change. CAUTION: Always listen for the “chirp” and be prepared for speed and/or incline changes. In some instances, the speed and/or incline may change before your personal trainer describes the change.
- Page 25 HOW TO USE AN IFIT.COM PROGRAM DIRECTLY FROM OUR WEB SITE Our Web site at www.iFIT.com allows you to access programs directly from the internet. Additional options are soon to be available. See www.iFIT.com for details. To use programs from our Web site, the treadmill must be connected to your home computer.
- Page 26 THE INFORMATION MODE/DEMO MODE The console features an information mode that keeps track of the total number of hours that the treadmill has been used and the total number of miles that the walk- ing belt has moved. The information mode also allows you to select miles or kilometers as the unit of mea- surement for the console, to turn on and turn off the demo mode, and to reset all programs to the original...
-
Page 27: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 28 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 10. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.
-
Page 29: Conditioning Guidelines
CONDITIONING GUIDELINES WARNING: Before beginning this or any exercise program, consult your physi- cian. This is especially important for individu- als over the age of 35 or individuals with pre- existing health problems. The pulse sensor is not a medical device. Various factors, including your movement, may affect the accuracy of heart rate readings. -
Page 30: Part List
PART LIST—Model No. IMTL13905.0 To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Foot Rail Cover Left Foot Rail Foot Rail Screw 1/2” Screw Front Left Foot Rail Endcap... -
Page 31: Ordering Replacement Parts
Key No. Qty. Description Pulse Bar Star Washer Control Knob Pulse Bar 15” Wire Harness Key/Clip Short Panel Console Frame Wire Harness Pulse Bar Screw Console Bolt Upright Long Panel Upright Bolt Star Washer Upright Plate Washer iFIT Cable Plastic Tie Releasable Tie Tie Holder Access Door... -
Page 34: How To Order Replacement Parts
• the MODEL NUMBER of the product (IMTL13905.0) • the NAME of the product (IMAGE ADVANCED 2600 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) • the KEY NUMBER AND DESCRIPTION OF THE PART(S) (see the EXPLODED DRAWING in the center of this manual and the PART LIST on pages 30 and 31) ICON Health &...
