Faber Jewel JEWL2430 Dimensions And Installation

Jewel - Custom Tilt Out Range Hood
Integrated custom range hood
For a seamless look in the kitchen, the Jewel is your integrated solution. The Jewel tilts in, flush with your cabinets, neatly tucking
the hood away. You supply your own custom cabinet face to integrate the Jewel in with your other cabinets. The hood is 18" tall
which replaces your standard upper cabinet with an attractive stainless steel range hood with a 600 cfm PRO motor.
Model # Size | Color
JEWL2430
24 / 30
JEWL36
36
front panel is unfinished, ready to accept a custom wood panel -
* Note – ran 30 minutes a day on low speed with the lights on, 365 days, using the North American average of 12.2 cents per kWh.
p.o. box 435 • Wayland, MA 01778 • tel: (508) 358-5353 • fax: (508) 358-5730 • e-mail: info@faberonline.com • www.faberonline.com
Performance Range
200 - 600 CFM
200 - 600 CFM
Product Dimensions
Convertible to Ductless / Recirculating Yes - charcoal kit needed
Controls
Lighting
Ducting Top
Grease Filters
Auto On / Off
Integrate front panel
Adjustable Mounting Hardware
Pro Motor with Metal Impellers
AC Input
AC Power
Annual Electricty Costs
Sound Levels
3.5 - 6.5 sones
3.5 - 6.5 sones
15 lb. maximum
Feature Chart
22 3/16" or 34" (W) x 18 7/8" (H) x 11" (D)
3 Speed Push
2 X 20 (W) Halogen
6" Round
dishwasher safe mesh
Yes - fan turns on when pulled out
Yes - Use your own custom wood front
Yes - up/down & in/out
Yes
120 V - 60 hz
Max 490 W at 4.1 A
$5.29 / Year *
The Jewel comes with an unfinished metal front
which you can attach your own custom cabinet
face to. When tilted out the Jewel extends for a
total depth of 20.5" from front to back, providing
adequate coverage for most cook tops.
