Summary of Contents for minkaAire Gilera F733

  • Page 1 GILERA...
  • Page 2 This product is protected by United States Federal and/or State Law, including Patent, Trademark and/or Copyright laws. Manual design and all elements of manual design are protected by U.S. Fede ral and/or State Law, including Patent, Trademark and/or Copyright Laws.
  • Page 3 warranty is for one (1) year from the date of purchase from an authorized Minka-Aire dealer. This warranty is only valid to the original purchaser or user against all defects in material and workmanship (light bulbs excluded) for one (1) full year. Additionally, Minka-Aire warrants the motor only for the lifetime of the Minka Aire ceiling fan (excluding wall controls and electrical components), to the original purchaser or user.
  • Page 4 Warranty Service Information To obtain warranty servic during the warranty period, the purchaser should return the fan with the sales receipt to the original place of purchase. The authorized Minka-Aire dealer, at its sole discretion, will either repair or replace the fan after verifying the legitimacy of the warranty ®...
  • Page 5: Table Of Contents

    CONTENTS SAFETY FIRST ATTACHING THE FAN BLADES PACKAGE CONTENTS OPERATING THE REMOTE CONTROL/WALL CONTROL MAINTENANCE BEGIN INSTALLATION TROUBLESHOOTING HANGING THE FAN ELECTRICAL CONNECTIONS SPECIFICATIONS INSTALLING THE WALL TRANSMITTER FINISHING THE INSTALLATION 1151W. Bradford Court, Corona CA 92882 For Customer Assistance Call: 1-800-307-3267...
  • Page 6: Safety First

    SAFETY FIRST 1. Before you begin installing the fan, shut power off at the circuit breaker of the fuse box. 2. Be cautious! Read all instructions and safety information before installing your new fan. Review accompanying assembly diagrams. 3. Make sure that all electrical connections comply with local codes, ordinances, or National Electrical Codes. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring.
  • Page 7 NOTE:The important safeguards and instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. It must be understood that common sense, caution and care are factors which can not be built into this product. These factors must be supplied by the person (s) installing, caring for and operating the unit.
  • Page 8: Package Contents

    PACKAGE CONTENTS Minimum 3-1/2" length downrod (for close 1. Fan motor/housing ass'y to ceiling mounting only) 2. Canopy 9. Blade holder 3. Fan blade 10. Wall control transmitter include below pcnts 4. Hanger bracket plate 1) big wall plate (2 pcs) 4a .
  • Page 9: Begin Installation

    Tools Required: Phillips screw driver; slotted screw driver;pliers;wire cutters; electrical tape. BEGIN INSTALLATION MOUNTING OPTIONS CEILING JOIST PARALLEL WOOD BRACE (MIN. 2" THICK) If there isn' t an existing mounting box,then read the following instructions.Shut the CROSS BRACE OUTLET power off at the circuit breaker or fuse box. NOTE: THIS CEILING FAN EXCEEDS THE MAXIMUM WEIGHT SPECIFIED BY UL FOR OUTLET BOX HANGING FROM A STANDARD OUTLET BOX.
  • Page 11 CANOPY FLAT OUTLET COUPLING WASHERS SPRING WASHERS COVER HANGER KNOCK HEX NUTS BRACKET Fig.5 Fig.7 SCREW HITCH PIN LOCK PIN OUTLET SET SCREW SET SCREW HANGER REGISTRATION BRACKET SLOT PLATE STAR WASHERS Fig.10 LOCK WASHERS FLAT WASHERS Fig.8 Fig.9 Fig.6 WOOD SCREWS...
  • Page 12: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING:To avoid possible electrical shock be sure electricity is turned off at the main fuse or breaker box before wiring.
  • Page 13 (Fig. 11 & 12) (Fig. 13 & 14) Fig. 11 Fig. 12...
  • Page 14 CONNECT Fig. 13 Fig. 14...
  • Page 15: Installing The Wall Transmitter

    INSTALLING THE WALL TRANSMITTER WARNING! HOOK UP "IN SERIES" ONLY. DO NOT CONNECT NEUTRAL SUPPLY WIRE OF ELECTRIC CIRCUIT TO THE TRANSMITTER WALL SWITCH, DAMAGE TO THE TRANSMITTER WALL SWITCH AND POSSIBLE FIRE COULD OCCUR. Step 1.Remove the existing wall plate and switch from the wall outlet box. Step 2.Make the electrical connections as shown in Fig.15.
  • Page 16: Finishing The Installation

    FINISHING THE INSTALLATION Step 1. Remove 1 of the 2 screws from the bottom of the hanger bracket and loosen the other one half a turn from the screw head. Step 2. Slide the canopy up towards the hanger bracket and place the key hole on the canopy over the screw on the hanger bracket, turn canopy until it locks in place at the narrow section of the key holes.
  • Page 17: Attaching The Fan Blades

    ATTACHING THE FAN BLADES Step 1. Attach the blade holder onto the motor using the screws provided. Tighten screws securely. Repeat for remaining blade holders.(Fig. 17). ring Step 2. Attach the fan blade to the blade holders.(Fig. 18) blade holder screw Fig.17 Fig.18...
  • Page 19 Speed settings for warm or cold weather depend on factors such as room size, ceiling height and number of fans. NOTE: To change the direction of the rotation of the blades the fan must be in operation mode. Warm Weather (forward) A DOWNWARD airflow creates a cooling effect as shown in Figure 19.
  • Page 20: Care Of Your Fan

    CARE OF YOUR FAN Here are some suggestions to help you maintain your fan. additional protection and enhanced beauty. Cover small scratches with a light application of shoe polish. 1. Because of the fan's matural novement,some connections may become loose. Check the support connections,brackets, and blade attachments 5.
  • Page 21: Troubleshooting

    TROUBLESHOOTING SYMPTOM SYMPTOM SYMPTOM SYMPTOM Lights shut off and will not Fan sounds noisy Fan Wobble Fan will not start come back on. SOLUTION SOLUTION SOLUTION SOLUTION 1. Allow a 24-hour "break in" 1.NOTE: All blade sets are grouped by 1.Check to make sure the wall switch is turned on.
  • Page 22 SYMPTOM Frequency interference SOLUTION 1.Turn the power off to your ceiling fan. 2.lease use a small size tool to change the frequency setting on the control system. 3.Return power to the unit Note: After the AC power is on,do not press any other button on the transmitter before pressing the “Stop”...
