Britax KID II User Instructions

PAGE I

1. PRODUCT OVERVIEW

01
Seat cushion
Belt guide (bright red)
01
03
Belt holder Compartment for user manual
02 04

4. USE IN THE VEHICLE

Please observe the instructions for using children's restraining systems in the operating
instructions of your vehicle. The seat can be used in vehicles with a 3-point belt.
Please find the information on the seats approved for child safety seats of the weight classes 15
to 36 kg in the operating instructions of your vehicle.
The KID II is approved for one method of installation:
Symbol Installation type Approval type
with the vehicle's 3-point seatbelt universal
a)
This means that the child safety seat may only be used in vehicles that are listed in the
vehicle type list enclosed. This type list is consistently kept up to date. The latest version
can be obtained from us or from www.britax.eu / www.roemer.eu.
You can use your child safety seat as follows:
In the direction of travel yes
1)
against the direction of travel no
15–36 kg
with 2-point belt no
2)
with 3-point belt yes
3)
on front passenger seat yes
on outer rear seat yes
on centre rear seat (with
4)
yes
3-point belt)
1) Use is permitted on a rearward-facing vehicle seat (e.g. in a van or minibus) only if the
vehicle seat is also approved for use by adults. The seat may not be in the area of effect of
an airbag.
2) The safety belt must be approved to ECE R 16 or a comparable standard (see test label on
belt with an "E" or "e" in a circle).
3) If there is a front airbag: Slide the vehicle seat a long way back and refer to any instructions
in vehicle owner's manual.
4) Cannot be used if the vehicle seat is equipped with only a 2-point belt.
05
06
02
07
03
04
Headrest Backrest
05 07
Headrest adjustment handle
06

5. CARE AND MAINTENANCE

Please ensure that you only use the original BRITAX RÖMER replacement seat
covers, as the seat cover is an integral part of the child safety seat and fulfils
important functions to ensure the smooth operation of the system. Replacement
seat covers are available from your dealer or from an ADAC office.
• The cover can be removed and washed with a mild detergent in the delicates
programme of the washing machine (30 °C). Please observe the instructions
on the washing label of the cover.
• The plastic parts can be cleaned using soapy water. Do not use any caustic
cleaning agents (such as solvents).
DANGER! The child seat must not be used without the seat cover.
Removing the seat cover
1. Moving the headrest of the vehicle seat into the top
position.
2.
Unhook the cover hooks 20 on the rear of the back-
20
rest 07 .
3.
Remove the upper part of the cover.
4. Unhook the cover loops 21 at the bottom on the rear
of the backrest 07
5.
Pull off the cover from the seat cushion 03 .
21
Removing the headrest cover
6.
Unhook the cover loops 21 on the back of the head-
rest 05 .
21
7.
Unhook the cover hooks 20 on the front of the back-
rest 07 .
8. Pull off the cover of the headrest 05 .
► The cover can now be washed. Please observe the
05
instructions on the washing label of the cover:
20
Re-fitting the cover
Proceed in reverse order to put on the cover.

2. INTRODUCTION

Thank you for choosing KID II to keep your child safe through a new stage of
their life.
KID II
In order to protect your child correctly, the must always be used
and installed as described in these instructions.
If you have any further questions regarding its use, please feel free to contact
us:
BRITAX RÖMER
Kindersicherheit GmbH
T.: +49 (0) 731 9345-199/-299
Blaubeurer Straße 71 F.: +49 (0) 731 9345-210
D-89077 Ulm E.: service.de@britax.com
Germany
www.britax.eu
BRITAX EXCELSIOR
LIMITED
1 Churchill Way West T.: +44 (0) 1264 333343
Andover F.: +44 (0) 1264 334146
Hampshire SP10 3UW
E.: service.uk@britax.com
United Kingdom www.britax.eu
These instructions use the following symbols stated below:
Symbol Keyword Explanation
DANGER! Risk of severe personal injury
WARNING! Risk of minor personal injury
CAUTION!
Risk of material damage
TIP: Useful notes
Instructions that follow a set sequence are numbered.
Example:
1. Press the button...
18
Belt guide colours
For better differentiation, the two vehicle seat
belts are highlighted in different colours. The di-
agonal seat belt 18 in dark red and the lap belt
in bright red. The colour of the belt guides
17
on the child safety seat follows the same colour
17
scheme.

6. DISASSEMBLY AND DISPOSAL

UNFASTENING YOUR CHILD:
1. To unfasten your child, use the release button of your vehicle seat buckle.
REMOVAL:
1. Operate the release button of your vehicle seat
buckle.
2. Pull out the diagonal belt from the dark red belt
18
holder 02 on the headrest 05 .
The child safety seat can now be removed.
19
DANGER! the child safety seat must always be
secured when it is in the vehicle, even if no child is
being transported.
18 05
02
DISPOSAL:
Please observe the waste disposal regulations in your country.
Disposal of packaging Container for cardboard boxes
Seat cover Residual waste, thermal utilisation
Plastic parts According to the labelling in the corre-
sponding container
Metal parts Container for metals
Belt straps Container for polyester
buckle and tongue Residual waste

3. Certification

BRITAX RÖMER Testing and certification
Child safety seat In accordance with ECE* R 44/04
Group Body weight
II+III 15 to 36 kg
KID II
*ECE = European Standard for Child Safety Equipment
The child safety seat has been designed, tested and certified according
to the requirements of the European Standard for Child Safety Equipment
(ECE R 44/03). The seal of approval E (in a circle) and the approval number
are located on the orange approval label (sticker on the child safety seat).
DANGER! This approval will be invalidated if you make any modifica-
tions to the child safety seat. Only the manufacturer is permit-
ted to make modifications to the child safety seat.
WARNING! Use the KID II exclusively for securing your child in your
vehicle. It is in no way suitable as a seat or toy in the home.
DANGER! Never secure your child or the child safety seat with a 2-point
belt. If you secure your child in the child seat with only a
2-point belt, then in the event of an accident this may cause
serious injuries to your child, possibly resulting in death.
15 to 36 kg
(~4 to 12 years
of age)
KID II
User instructions
www.britax.eu
