Summary of Contents for Iluv i199
-
Page 1: Instruction Manual
® Stereo Audio System for Your iPod Instruction Manual Model: i199 Please read this manual carefully before operating and save it for future reference. Have a question? Please visit www.i-Luv.com... - Page 2 Stereo Audio System for Your iPod V11M11_IM_EN_01122007 - 1 - www.i-Luv.com...
-
Page 3: User Safety Guide
Stereo Audio System for Your iPod USER SAFETY GUIDE INSTRUCTIONS ON ENVIRONMENT PROTECTION Do not dispose of this product in the usual household garbage at the end of its life cycle; bring it to a collection point for the recycling of electrical and electronic appliances. - Page 4 Stereo Audio System for Your iPod USER SAFETY GUIDE IMPORTANT SAFETY INSTRUCTIONS – CONTINUED POWER SOURCES – The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance itself. CLEANING –...
- Page 5 Stereo Audio System for Your iPod USER SAFETY GUIDE FCC NOTICE (USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 6: About Electromagnetic Interference (Emi)
Stereo Audio System for Your iPod USER SAFETY GUIDE About Electromagnetic Interference (EMI) This device is designed and manufactured not to exceed the exposure limit for radio frequency energy, which is set by the Federal Communications Commission of the U.S government. The term “EMI”... - Page 7 Stereo Audio System for Your iPod V11M11_IM_EN_01122007 - 6 - www.i-Luv.com...
-
Page 8: Table Of Contents
Stereo Audio System for Your iPod TABLE OF CONTENTS Getting Started General features ……………………………………………………………………………………………………………………………………………...… Installing the AC Power …………….……………………………………………………………..…………………………………………………………… Installing the backup battery for clock and alarm settings ………………..……………………….………………………………………………………. Installing the remote control battery …...………………………………………………………………………………………………………….………… Installing the AM loop antenna ………………………………………………………………………………………………………………………….…….. Installing the dock adapter …………………………………………………………………………………………………………………………………….. -
Page 9: Getting Started
GETTING STARTED Congratulations on your purchase of the new iLuv i199 for your iPod. Uniquely designed to work with your iPod, this iLuv stereo audio system with built-in universal dock provides advanced audio and radio performance that brings out the best in your music. Remember to keep this manual for future reference. -
Page 10: Installing The Ac Power
Installing the Backup Battery for Clock and Alarm Settings In order to offer consistent clock settings and alarm functions, the i199 uses a Backup Battery system. This means that in the event of a power failure, all the settings of the i199 will remain saved. For example, after the installation of the Backup Battery, the AC cord is disconnected or a power failure occurs, the display will NOT remain lit, but the time and date settings will be temporarily maintained. - Page 11 Stereo Audio System for Your iPod GETTING STARTED Installing the Backup Battery for Clock and Alarm Settings -Continued Locate the battery compartment on the bottom of the unit and open. Insert two (2) “AA” batteries, following the correct polarity (+/-) drawings inside the battery compartment. For longer battery life, alkaline batteries are suggested.
-
Page 12: Installing The Remote Control Battery
Stereo Audio System for Your iPod GETTING STARTED Installing the Remote Control Battery The remote control battery is included. Before operation, please install it to the battery compartment of remote control. Locate the battery compartment on the bottom of remote control and open. Insert a “CR2025”... -
Page 13: Location Of Controls On The Main Unit
Stereo Audio System for Your iPod GETTING STARTED Location of Controls on the Main Unit MULTI/DISPLAY USB port Docking door OPEN 10. VOLUME+/-( 13. WAKE TO 16. FR/Down 19. ALARM 1 22. TIME SET EJECT BluePin dock SLEEP 11. Power ON/OFF/ Alarm off 14. -
Page 14: Location Of Controls On The Remote Control
Stereo Audio System for Your iPod GETTING STARTED Location of Controls on the Main Unit- continued 25. AC Power cord 28. AM Loop Antenna Socket Location of Controls on the Remote Control POWER PLAY/PAUSE PRESET VOLUME +/- SLEEP STOP/ AM/FM 11. -
Page 15: Location Of Indications On The Lcd Screen
Stereo Audio System for Your iPod V11M11_IM_EN_01122007 GETTING STARTED Location of Indications on the LCD Screen - 14 - www.i-Luv.com... -
Page 16: Operational Instructions
Press the ALARM 1 or ALARM 2 buttons again to secure the setting and exit the alarm setting mode. Notes: Make sure the alarm volume level set to desired level and the i199’s display has icon indicating alarm armed. Using the Alarm Function To preview the alarm setting, press Wake to Button and display will scroll through current alarm setting. -
Page 17: Adjusting The Brightness Of The Lcd Screen
Set your iPod to the repeat mode if you’ve selected Wake to iPod, and your iPod has less than one hour of songs. • If you have selected the Wake To iPod, CD or USB setting, yet no iPod, CD or USB is present at the alarm time, the i199 will automatically switch to the BUZZER mode. -
Page 18: Setting The Sleep Time
Listening to Your Favorite Radio Stations For the best FM radio clarity, fully extend the pig-tail wire antenna, located on the rear of the i199. It is important not to alter, obstruct or attach other antennas to this wire antenna. To achieve the best AM reception, a distance of 12” between the AM antenna, the unit and iPod is recommended. Rotate the AM loop antenna to have the better reception. -
Page 19: Programming Preset Stations
To listen to music, make sure that your iPod is in play mode. NOTE: If the i199 fails to play or you do not hear any sound coming out from the unit, make sure your iPod is securely docked in the Built-In Universal dock and press the PLAY/PAUSE button on the i199 or on the Remote Control for music play to begin. -
Page 20: Listening To Cds/Mp3-Cds
Stereo Audio System for Your iPod OPERATIONAL INSTRUCTIONS Listening to CDs/MP3-CDs The i199 features a slide-in mechanism for easy loading and unloading 1. Press FUNC. button to select the CD mode. 2. Insert the MP3-CD/CD disc in the loading bay. - Page 21 Stereo Audio System for Your iPod V11M11_IM_EN_01122007 OPERATIONAL INSTRUCTIONS Selecting a Different Track During Play -Continued 3. Press and hold buttons to search through the track. Programming Tracks Up to 32 tracks can be stored in the memory. 1. Load an MP3-CD/CD as described previously. 2.
- Page 22 Stereo Audio System for Your iPod OPERATIONAL INSTRUCTIONS Clearing Program Tracks Press MEMORY button, the LCD will display the first programmed tracks, pressing the STOP button will erase all programmed tracks. REPEAT or INTRO or RANDOM PLAY (For CD) Press PLAY MODE button until the display indicates one of the following: •...
-
Page 23: Listening To Your Favorite Music On A Usb Storage Device
Using AV-out port to watch Videos from your iPod on an External Monitor or TV The i199 has an AV port to send video signal of your video iPod (5G, 5.5G) to the external display devices, such as TV or a monitor. - Page 24 Using AV out port to watch Video on your iPod from an External Monitor or TV – Continued Note: The line output is not affected by the volume setting on the i199. Please use the volume control of the external device to increase or decrease the volume level.
-
Page 25: Listening To Other Audio Devices Using The Line-Out Port
Listening to Other Audio Devices using line-in port You can still listen to the first, second, and third generations of iPod, or any other audio players other then iPod, with the i199 by simply using the AUX-IN port, located on the rear of the i199. -
Page 26: Bluepin Setup And Operating Instructions
Bluetooth Mode Indicator NOTE: Certain devices with Bluetooth technology might not be compatible with the BluePin product for this operation is iLuv Stereo Headsets with Bluetooth technology which are fully compatible with the BluePin Overview: is connected to i199 you will see a flashing Bluetooth icon on the display. - Page 27 Bluetooth logo, after successfully connected to a Bluetooth device, display will show “TX CONN” or RX CONN” for a few seconds and Bluetooth icon lights steadily, i199 will display “BT--RX” mode when BluePin is set to “RX”...
- Page 28 The switch for TX and RX is located on the left side of the BluePin TX/RX Switch Example (RX Mode): If you have a MP3 cell phone with Bluetooth Stereo Profile (A2DP) could transmit the music on your cell phone to your i199 w/ BluePin to enjoy the music on the i199 (For this operation the BluePin as TX or RX depending on the purpose.
- Page 29 • You can use the PLAY/PAUSE, PREV, NEXT buttons of i199 to remote control the MP3 cell phones or other devices that support AVRCP profile. Note: Depending on the device, these functions might be disabled due to differences in software.
- Page 30 When both units are no longer flashing red and blue lights, and a blue light flashes steadily you are now connected and can send music from i199 to Headset with Bluetooth wireless technology. The speakers of the i199 will be muted after it connected to a headset with Bluetooth technology, you can press the MUTE button or VOLUME buttons to release mute.
-
Page 31: Maintenance & Troubleshooting Guide
Apple Computer’s website: http://www.apple.com. You are using the first, second, or third generation iPod. The i199 does not recognize first, second and third generation iPod. Use the line-in jack for the first, second, and third generation of iPod. - Page 32 The remote control does not operate properly. The installed battery is weak. Replace with a new battery. It is not aimed to the i199 or too far away from it. Move within 20 feet of the unit and point the remote control toward the i199. •...
- Page 33 Please check your device manual, or check with manufacturer to see if device has matching A2DP Bluetooth Stereo Profile) • There seems to be noticeable delay between the devices with Bluetooth wireless technology and i199. This is normal when using devices using Bluetooth wireless technology. •...
-
Page 34: Specifications
Stereo Audio System for Your iPod SPECIFICATIONS General • Power Requirement Main Unit: AC 120V/60Hz (USA) 230V50Hz (EURO) • Output Power: 8W (RMS) into 8 ohm • Power consumption: 40W Radio • Frequency Ranges: MW 522 - 1620kHz / FM 87.5 - 108MHz (EURO); AM 530 – 1710kHZ / FM 87.5 – 108MHz (USA) Compact Disc •... - Page 35 Stereo Audio System for Your iPod V11M11_IM_EN_01122007 - 34 - www.i-Luv.com...
- Page 36 Electronics Corp. iPod is a trademark of Apple Computer Inc. iPod is not included in this package. Features and specifications are subject to change without prior notification. BluePin is a trademark of jWIN Electronics Corp. The Bluetooth word mark and logos are owned by Bluetooth SIG, Inc.
