Summary of Contents for Passion Veneto
- Page 1 OWNER’S MANUAL Veneto | Tuscany | Roma | Sicilia | Amore...
- Page 2 European 1x32A Wiring Diagram Jumper L1-L2-L3...
- Page 3 S t a r t u p Important – Read these step-by-step startup procedures before starting your spa. Failure to follow any of these steps listed may result in damage to the equipment and may void your warranty. Caution: Running the spa pump dry (without water running through it) can cause IMMEDIATE damage and will void the warranty! Be sure that the spa is installed properly in accordance with the instructions in this...
- Page 4 Before Adding Water Before adding water, go through these simple steps now to prevent common issues when setting up your spa for the first time. Verify that the following have all been rechecked. 1. Turn off all power to the spa at the main breaker panel. 2.
- Page 5 Filling Your Spa Now it's time to fill your spa with water. Do not turn on the electricity yet until the spa is completely filled. To properly fill your spa: 1. Make sure that the filters (in the filtration canister) are gently screwed into place. Turn them clockwise until they stop being careful not to over-tighten them (this avoids cracking the filter).
- Page 6 1. Turn on the breaker and test the operation of the Ground-Fault Circuit Interrupter (GFCI) breaker by pushing the small button. This should automatically trip the spa's circuit breaker. DANGER: If this breaker does not trip, immediately call your electrician. Do not use your spa! Only if pushing this button successfully trips this circuit breaker should you reset this breaker and proceed to the next step.
- Page 7 6. Press the Pump 1 button a third time to turn Pump 1 off. A built- in timer automatically turns Pump 1 off after 20 minutes, unless the pump manually has been deactivated first. 7. Press the Pump 2 button .
- Page 8 Topside Control Panel The topside control panel uses a paged-style menu system to access various features and options. The above display shows the normal spa mode where you control the most frequently used devices. Basic button functions are described below. Press the Mode button to display the three operating modes (Spa or Options).
- Page 9 Spa Mode Spa mode allows you to control the basic devices of your spa plus access Standby and Economy features. To access Spa mode, first press to access the main menu and then select the Spa mode with . Press next to the feature or device you wish to operate on that page to turn it on or off.
- Page 10 Options Mode In options mode, the system shows you which option you wish to program or alter (spa, keypad, or clock). To access Options mode, first press to access the main menu and then select the Options mode with...
- Page 11 Spa Submenus This submenu allows you to personalize operating settings of your spa such as the total filtration time, economy times, a maintenance reminder, and to display any warning messages. Filter Purge Settings Purge Purge Since filtration runs constantly in your spa, the filter purge cycle turns on all pumps for 30 seconds to flush water and air in the lines.
- Page 12 Start – Press +/- to set the starting hour of economy mode. Press > to select minutes. Press +/- to set the starting minute of economy mode. Press to go to the next screen. Stop – Press +/- to set how long economy mode runs in hours. Press >...
- Page 13 Video – Press +/- to set a normal or inverse video display. Press to go to the next screen. Orientation – Press +/- to set a normal or inverted display. Press the checkmark function button to save the settings. Sound Settings These settings control how the audible beep functions.
- Page 14 Security Setting This submenu allows you to personalize the keypad security of your spa to prevent unauthorized changes to the settings. When the keypad is locked the lock icon is displayed. A Partial keypad lock allows access to basic spa functions (pumps, blower, light) but blocks access to the temperature set point and Programming mode.
- Page 15 Information Submenus This sub-menu allows you to view spa equipment data such as spa controller, and heater and keypad software version. Also, here it's possible to reset programmed settings back to default factory values, and finally to upgrade keypad software. Info Keypad Default This submenu allows you to reset the keypad setting to the factory default.
- Page 16 What is the insulation made of? Freestyle Spas uses a five-step process to fully insulate all of its hot tubs. First, the bottom of each shell is blanketed with a thick layer of solid-cell, high- density insulating foam. Second, an outer layer of insulation is added.
- Page 17 How do I bleed air from my system? When draining and refilling your spa, the pump may become air locked. An air-locked pump stops water from flowing in your spa and is easily resolved by bleeding off the trapped air. To do this: Turn off all pumps •...
- Page 18 T r o u b l e s h o o t i n g PROBLEM CAUSE SOLUTION Breaker trips Wiring error Spa Neutral wire not connected to GFCI (connected to Neutral bus) Wrong GFCI GFCI breaker is wrong size Circulation Temperature This is normal.
- Page 19 PROBLEM CAUSE SOLUTION Nothing Breaker has Check and reset breaker. If problem works tripped persists, check for loose electrical connections. Check for Neutral wiring error at GFCI. Pump not No power to Reset circuit breakers on GFCI panel running and main circuit breaker panel Pump runs Normal Spa is equipped with constant...
- Page 20 Error Codes CODE DESCRIPTION CORRECTIVE ACTION bL Er Device not • Open the access panel to spa pack CP Er detected and reseat corresponding plug O3 Er Air-locked P1 Er pump • Reset GFCI breaker P2 Er • Reset Br and LL settings P3 Er •...
- Page 21 5 seconds. Use the Change button to set LL=(see below) even if it is the present value. Press Select to save. For Veneto (model 1301), LL=01 For Roma (model 1302), LL=05 For Amore (model 1303), LL=01 For Tuscany (model 1304), LL=05...
-
Page 22: Specifications
S p e c i f i c a t i o n s VENETO (MODEL 1301) Specifications* Dimensions 200L x 200”B x 88D Seats Water Jets Air Jets Capacity 250 USG /946 L Dry Weight 690 Lbs/313 Kg Filled Weight... - Page 23 VENETO (MODEL 1301) CALLOUTS Part# Description Part# Description 820559 6-spk Jet, Clust Dir 2" (Gr) 14 612584 Suction 200GPM 2"Slip (Gr) 6-spk Jet, Clust Dir 2" (Bl) Suction 200GPM 2"Slip (Gr) 820558 612583 606533 Compensator Ring 2" 606543 Comp ring 606526 Body, Jet 2"...
- Page 24 TUSCANY (MODEL 1302) Specifications* Dimensions 211L x 211B x 92D Seats 6 (w. lounger) Water Jets Air Jets Capacity 260 USG /985 L Dry Weight 795 Lbs/360 Kg Filled Weight 2960 Lbs/1345 Kg Electrical 230VAC 32A 50Hz GFCI * Specifications are subject to change without notice.
- Page 25 TUSCANY (MODEL 1302) CALLOUTS Part# Description Part# Description 820559 6-spk Jet, Clust Dir 2" (Gr) 11 621574 6-spk Waterfall Valve 1" (Gr) 6-spk Jet, Clust Dir 2" (Bl) 6-spk Waterfall Valve 1" (Bl) 820558 621573 606533 Compensator Ring 2" 13 612480 Drain (Gr) 606526 Body, Jet 2"...
- Page 26 ROMA (MODEL 1303) Specifications* Dimensions 239L x 239B x 91D Seats Water Jets Air Jets Capacity 400 USG /1515 L Dry Weight 935 Lbs/424 Kg Filled Weight 4267 Lbs/1935 Kg Electrical 230VAC 32A 50Hz GFCI * Specifications are subject to change without notice.
- Page 27 ROMA (MODEL 1303) CALLOUTS Part# Description Part# Description 820559 6-spk Jet, Clust Dir 2" (Gr) 620080 Galaxie Air Injector (Gr) 6-spk Jet, Clust Dir 2" (Bl) Galaxie Air Injector (Bl) 820558 620470 606533 Compensator Ring 2" 10 621586 6-spk Valve Air control 1" (Gr) 606526 Body, Jet 2"...
- Page 28 SICILIA (MODEL 1304) Specifications* Dimensions 250L x 250B x 91D Seats Water Jets Air Jets Capacity 290 USG /1098 L Dry Weight 865 Lbs/ 393 Kg Filled Weight 3280 Lbs/ 1490 Kg Electrical 230VAC 32A 50Hz GFCI * Specifications are subject to change without notice.
- Page 29 SICILIA (MODEL 1304) CALLOUTS Part# Description Part# Description 820559 6-spk Jet, Clust Dir 2" (Gr) 612480 Drain (Gr) 6-spk Jet, Clust Dir 2" (Bl) Drain (Bl) 820558 612481 606533 Compensator Ring 2" 609084 Drain Valve, Economy 606526 Body, Jet 2" 612584 Suction 200GPM 2"Slip (Gr) 606530...
- Page 30 AMORE (MODEL 1305) Specifications* Dimensions 221L x 16 4B x 86D Seats Water Jets Air Jets Capacity 160 USG /606 L Dry Weight 635 Lbs/288 Kg Filled Weight 1970 Lbs/894 Kg Electrical 230VAC 32A 50Hz GFCI * Specifications are subject to change without notice.
- Page 31 AMORE (MODEL 1305) CALLOUTS Part# Description Part# Description 820559 6-spk Jet, Clust Dir 2" (Gr) 14 612584 Suction 200GPM 2"Slip (Gr) 6-spk Jet, Clust Dir 2" (Bl) Suction 200GPM 2"Slip (Gr) 820558 612583 606533 Compensator Ring 2" 606543 Comp ring 606526 Body, Jet 2"...
