Internal Connections And Jumpers - C-Media CMI8738 User Manual

and sub-woofer while six channel speakers mode is enabled
This 5.1 Channel PCI Sound Card also has the following internal
connection and jumpers:
J1
J2
J3
JP1&JP2
MN4000000055
The Function
Analog CD/IN Port(Signals: L-G-G-R)
Analog CD/IN Port(Signals: G-R-G-L)
Aux-in
1-2 close Center/Bass channel in normal mode
2-3 close Center/Bass channel in inverse mode
Page 5
