Century 400 Ninja 411-222MO Operating Instructions Manual

Portable extractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

PORTABLE EXTRACTOR
MODELS:
411-222MO
10070300
411-225MO
10070320
Y
86038590 03/28/07
PRV NO. 98833
Read these instructions before using the machine
Operating Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ninja 411-222MO and is the answer not in the manual?

Questions and answers

Related Manuals for Century 400 Ninja 411-222MO

Summary of Contents for Century 400 Ninja 411-222MO

  • Page 1 PORTABLE EXTRACTOR Operating Instructions MODELS: 411-222MO 10070300 411-225MO 10070320 Read these instructions before using the machine 86038590 03/28/07 PRV NO. 98833...
  • Page 2 For the name and address of your dealer contact: Windsor Industries Phone Number: _________________________________________________________________________________________ OVERVIEW The Ninja is an electric powered carpet extractor intended for commercial use. This appliance applies a cleaning solution to the carpet and then vacuums the soiled water back into the recovery tank.

  • Page 3: Table Of Contents

    Equipment Set-up ..........3-3 Priming the Pump ..........3-3 Emptying & Cleaning Tanks......3-3 MAINTENANCE Daily Maintenance..........4-1 Periodic Maintenance...........4-1 Monthly Maintenance ...........4-1 Semi-annually ............4-1 Lubrication............4-1 Storage..............4-1 Vacuum Motor Replacement .......4-2 Solution Pump Replacement........4-2 Pump Replacement Kits........4-3 Pressure Regulator ..........4-4 Machine Troubleshooting........4-5 NINJA 86038590 03/26/07...

  • Page 4: How To Use This Manual

    NOTE: If a service or option kit is installed on your machine, be sure to keep the KIT INSTRUCTIONS which came with the kit. It contains replacement parts numbers needed for ordering future parts. SERIAL # TAG NINJA 86038590 03/26/07...

  • Page 5: Important Safety Instructions

    This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices for more than normal housekeeping purposes. Maintenance and repairs must be done by qualified personnel. If foam or liquid comes out of machine, switch off immediately. SAVE THESE INSTRUCTIONS NINJA 86038590 03/26/07...

  • Page 6: Hazard Intensity Level

    Unless Operation Guide is Read and understood. In Flammable or Explosive areas. In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. NINJA 86038590 03/26/07...

  • Page 7: Safety Label Location

    SAFETY LABEL LOCATION NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become illegible, promptly replace them. LABEL WARNING 86242230 PRV NO. 500009 LABEL CIRCUIT INTERRUPTER 86200570 PRV NO. 170-41 NINJA 86038590 03/26/07...

  • Page 8: Grounding Instructions

    The green colored rigid ear, lug, or wire extending from the adaptor must be connected to a permanent ground such as a properly grounded outlet box cover. Whenever the adaptor is used, it must be held in place by a metal screw. NINJA 86038590 03/26/07...

  • Page 9: Technical Specifications

    Weight-Full Solution 200 lbs (440 kg) Height 36 inches (91.44 cm) Length 29 inches (73.66 cm) Width 19.5 inches (49.53 cm) Power cord 22 feet (6.71 m) LENGTH WIDTH HEIGHT CENTURY 400 PUMP VACUUM #1 VACUUM #2 NINJA 86038590 03/26/07...

  • Page 10: Controls

    CONTROLS CENTURY 400 Pump Switch Vacuum #1 Switch Vacuum #2 Switch NINJA 86038590 03/26/07...

  • Page 11: Machine Operation

    2. Press lever (located above the accessory connection; front of machine) toward machine. 3. Do this for 30 seconds or until there is a steady flow of water flowing through the sight tube (located on right side of recovery tank.) NINJA 86038590 03/26/07...

  • Page 12: Maintenance

    (mixed as directed) colder climates. This heater will freeze and through the extractor, turning pump switch possibly crack voiding your warranty. on/off several times, flush with clean water. This will prevent build-up of alkaline residue in the system. NINJA 86038590 03/26/07...

  • Page 13: Vacuum Motor Replacement

    Periodically check the length of the carbon brushes. Replace both carbon brushes when either is less than 3/8" (9.5mm) long. 8 [9.5mm] Periodically check the length of the carbon brushes. Replace both carbon brushes when either is less than 3/8" (9.5mm) long. NINJA 86038590 03/26/07...

  • Page 14: Pump Replacement Kits

    PUMP REPLACEMENT KITS CAM & BEARING KIT 500 PSI 86201040 PRV NO. 250-73C MOTOR ONLY 86200800 PRV NO. 53262 VALVE & O-RINGS KIT (BOTH SIDES) 86201030 PRV NO. 250-73B PLUNGER & SEALS KIT 86201080 PRV NO. 250-75A NINJA 86038590 03/26/07...

  • Page 15: Pressure Regulator

    5. Lubricate the piston and u-cup with Superlube. 6. Reassemble regulator. 7. With pump ON, re-adjust pressure regulator for normal operation. LUBRICATE U-CUP WITH SUPERLUBE MONTHLY. U-CUP SPRING RETAINER PLATE PISTON SPRING (BLUE- 200 PSI) (SILVER-500 PSI) NINJA 86038590 03/26/07...
  • Page 16 Light carpet with no brown Go over carpet with browning prevent only prevention Solution hose connection Check for positive connection Solution not flowing Faulty pump Repair or replace properly Faulty floor tool valve Repair or replace Faulty pump switch Repair NINJA 86038590 03/26/07...
  • Page 17 NOTES THIS PAGE LEFT BLANK INTENTIONALLY NINJA 86038590 03/26/07...

  • Page 18: Frame Group (200 Psi)

    FRAME GROUP (200 PSI) NINJA 86038590 03/26/07...
  • Page 19 SCR, 1/4-20 X 1/2 HHCS SS NP 86199430 040-03 CASTER SWIVEL 4” SWIVEL 86002450 22015 COUPLER, 1/4 QD 86200670 500359 LABEL, NINJA 3 SWITCH NO HEAT 86091030 62900 PLATE, NINJA 3 SWITCH NO HEAT 86256960 72142 SWITCH, SPST 15A EURO ROCKER 86271380 57196...

  • Page 20: Frame Group (500 Psi)

    FRAME GROUP (500 PSI) NINJA 86038590 03/26/07...
  • Page 21 70020 SCR, 1/4-20 X 1/2 HHCS SS NP 86256960 72142 SWITCH, SPST 15A EURO ROCKER 86091030 62900 PLATE, NINJA 3 SWITCH NO HEAT 86200670 500359 LABEL, NINJA 3 SWITCH NO HEAT 86276290 70626 SCR, #10 X 3/4 PPHST HI-LO BLK...

  • Page 22: Pump Group (200 Psi)

    PUMP GROUP (200 PSI) NINJA 86038590 03/26/07...
  • Page 23 CLAMP, 3/8 HOSE (D-SLOT) 86280750 151-38A HOSE, 1/2 WIREBOUND X 21” 86197570 40028 HOSEBARB, 1/4 MPT X 1/2 DL 86199230 250-33 BPR PUMPTEC NINJA 200PSI 86005590 56014 NIPPLE, 1/4 CLOSE 86197360 31016 ELBOW, 1/4 NPT STREET 86272730 66017 PLUG, 1/4 BRASS PIPE...

  • Page 24: Pump Group (500 Psi)

    PUMP GROUP (500 PSI) NINJA 86038590 03/26/07...
  • Page 25 HOSE, PULSE 20.0 1/4 MPT X 3/8 MPT 86282310 39699 HOSE, 3/8 WIREBOUND X 35” 86197550 40014 HOSEBARB, 1/4MPT X 3/8 DL 86258970 84193 VALVE, KNGSTN 3” LVR 500 PSI 86197670 56023 NIPPLE, 1/4 X 1.5 86197760 78308 TEE, 1/4 STREET NINJA 86038590 03/26/07...

  • Page 26: Recovery And Solution Tank Group

    RECOVERY & SOLUTION TANK GROUP NINJA 86038590 03/26/07...
  • Page 27 LID, NJA DLX LT GRY ALL 86200290 260-33 HOSEBARB, 1.5MPT X 1.5 86199840 090-12A FLOAT CAGE ASSY COMPLETE SLIP 86033240 090-17 NINJA STAND PIPE ASSY 86064760 31082 ELBOW, 1.5FS X 1.5FPT PVC MCHD 86090850 065-42 FLOOD MACHINE BAFFLE 86279610 87190...

  • Page 28: Vacuum Motor Group

    VACUUM MOTOR GROUP NINJA 86038590 03/26/07 5-11...
  • Page 29 86233430 81431 CLAMP, 2.50” WORM GEAR 86005710 57105 NUT, 1/4-20 HEX W/ STAR WASHER 86075210 20062 CLAMP, 3/8 NYLON MCHND 86282300 39698 HOSE, 3/8 CLR PLYURTHN X 24” 86003500 31076 ELBOW, 1/4MPT X 3/8 TUBE, QC 5-12 NINJA 86038590 03/26/07...

  • Page 30: Wiring Group (200 Psi)

    WIRING GROUP (200 PSI) NINJA 86038590 03/26/07 5-13...

  • Page 31: Wiring Group (500 Psi)

    WIRING GROUP (500 PSI) 5-14 NINJA 86038590 03/26/07...
