DIAGRAM KEY
1 Dial Mode Switch (Pulse/Tone)
2 Audio Output Socket
3 Telephone Line Connection
4 Ring Tone Switch
5 Ringer Volume Switch
6 Telephone Number Directory
7 Memory Buttons
8 Redial Button
9 Flash/Recall Button

IMPORTANT SAFETY INFORMATION

Please read the following instructions before use:
When using your telephone equipment these basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and injury to persons
including the following:
Read and understand all instructions.
Follow all warnings and instructions marked on the telephone.
Please ensure this product is disconnected from the telephone line cable before
installing or replacing batteries.
Do not dispose of batteries in a fire. They may explode. Take empty batteries to
a collection point for chemical waste.
Do not install or use this telephone near water.
Avoid using a telephone (other than a cordless type) during a storm. There may be
a remote risk of electrical shock from lightning.
Unplug this telephone from the wall outlets before cleaning. Do not use liquid
cleaners or aerosol cleaners on the telephone. Use a damp cloth for cleaning.
Do not cover the slots and openings on this telephone. This telephone should never
be placed near or over a radiator or heat register. This telephone should not be
placed in a built-in installation unless proper ventilation is provided.
Do not place anything on the telephone line cable. Install the telephone where
no one will step or trip on the cable.
Never push any objects through the slots in the telephone. They can touch
dangerous voltage points or short out parts that could result in a risk of fire or
electrical shock. Never spill liquid of any kind on the telephone.
5
10 Volume Control
11 Low Battery Indicator
12 Visual Ring Indicator
13 Amplify Button
14 Amplify Indicator
15 Programme Button
16 Call On Hold Indicator
17 Tone Control
18 Call Hold Button
To reduce the risk of electrical shock, do not take this phone apart. Opening or
removing covers may expose you to dangerous voltages or other risks. Incorrect
reassembly can cause electric shock when the appliance is subsequently used.
Never install telephone wiring during a lightning storm.
Hereby, Plantronics BV declares that the eircom dB30 Amplified Telephone is in
compliance with the essential requirements and all other relevant provisions of
Directives 1999/5/EC and 93/42/EEC.
To view the Declaration of Conformity for this product please see
www.plantronics.com/documentation
Class I medical device
When the Amplified Indicator (14) is illuminated, the volume may be very loud and
in excess of 118dB (decibels). This mode is intended specifically for hearing
impaired users.
GETTING STARTED
INSTALL BATTERIES
Please ensure this product is disconnected from the telephone line cable before
installing or replacing batteries.
To add extra brightness to the eircom dB30 Visual Ring Indicator (12), install one 9
Volt alkaline battery (included).
TO INSTALL THE BATTERY
Fig. A Use a pen to open the battery door (see instructions underneath the
telephone unit)
Slide open the battery compartment cover on the bottom of the telephone,
install the battery, and replace the cover.
SETTING THE DIALLING MODE
Set the Dial Mode Switch (1) to T (tone) if you have touch tone DTMF service.
Otherwise set the switch to P (pulse).
CONNECTING FOR WALL MOUNT OR DESKTOP USE
WALL MOUNTING
Drill two holes in the wall 10.2cm (4") apart adjacent to the mounting holes on
the telephone. Use the correct screws to hang the telephone on the wall.
Fig. B Pull the handset hook out as shown in Fig. B and reverse its position so that
the hook points up and will hold the handset when you hang up.
Fig. C Insert the tabs of the phone base into the slots in the lower position of the
base as shown in Fig. C. Push the mounting bracket in and down firmly until
it snaps into place. Position on the wall close to your telephone wall socket.
