Partition Net - Mini Clubman Owner's Manual

If the rear seat backrests are positioned at
a steeper angle, do not install child-
restraint systems in the rear of the vehicle as
their protective features may be

Partition net*

Ensure that the partition net is firmly
attached; otherwise, injuries may
The partition net can be mounted in the cargo
bay or behind the front seats.
In the cargo bay
1. Fold the rear seat backrest forward if neces-
sary, page 98.
2. Insert each partition net mounting pin all the
way into its respective rear mount in the
headliner, arrow 1, and push it forward.
3. Hang the hooks of the partition net into the
eyelets on the cargo bay floor, arrow 2.
Behind the front seats
1. Fold down the rear seat backrests, refer to
Expanding the cargo bay.
2. Insert each partition net mounting pin all the
way into its respective front mount in the
headliner, arrow 1, and push it forward.
ineffective.<
occur.<
Online Edition for Part no. 01 41 2 602 919 - © 08/09 BMW AG Online Edition for Part no. 01 41 2 602 919 - © 08/09 BMW AG
3. Fold up the eyelets on the rear seat and
hook the partition net into them, arrow 2.
Level load floor*
The maximum load on the level load floor
is 165 lbs/75 kg. Do not exceed a cargo
weight of 55 lbs/25 kg in the storage compart-
ment under the load floor as this may result in
damage.<
Raise the level load floor and fold it up toward
the front, arrow.
Removing
1. Fold up the level load floor.
2. Pull the load floor back slightly.
3. Then take it out toward the top.
Determining cargo limit
1. Locate the following statement on your
*
vehicle's placard :
The combined weight of occupants
and cargo should never exceed
XXX kg or YYY lbs. Otherwise, damage to the
vehicle and unstable driving situations may
result.<
99
