Mini  CLUBMAN Owner's Manual
Hide thumbs Also See for MINI CLUBMAN:
Table of Contents

Advertisement

Contents
A - Z
OWNER'S MANUAL
MINI CLUBMAN
Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MINI CLUBMAN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mini MINI CLUBMAN

  • Page 1 Contents A - Z OWNER'S MANUAL MINI CLUBMAN Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 2 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 3 Cooper Congratulations on your new MINI Cooper S This Owner's Manual should be considered a permanent part of this vehicle. It should stay with the vehicle when sold to provide John Cooper the next owner with important operating, safety and mainte- Works nance information.
  • Page 4 © 2010 Bayerische Motoren Werke Aktiengesellschaft Munich, Germany Reprinting, including excerpts, only with the written consent of BMW AG, Munich. US English VII/10 Printed on environmentally friendly paper, bleached without chlorine, suitable for recycling. Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG Online Edition for Part no.
  • Page 5: Table Of Contents

    CONTENTS The fastest way to find information on a particu- lar topic or item is by using the index, refer to page 158. Using this Owner's Manual Notes Reporting safety defects AT A GLANCE Cockpit CONTROLS Opening and closing Adjustments Transporting children safely Driving Controls overview...
  • Page 6: Using This Owner's Manual

    Notes Using this Owner's Symbols on vehicle components Manual Indicates that you should consult the rele- vant section of this Owner's Manual for information on a particular part or assembly. We have tried to make all the information in this Owner's Manual easy to find.
  • Page 7: For Your Safety

    For your safety Installation and operation of accessories that have not been approved by the manufacturer of your MINI, such as alarms, radios, amplifiers, Maintenance and repair radar detectors, wheels, suspension compo- Advanced technology, e.g. the use of nents, brake dust shields, telephones, including modern materials and powerful electron- operation of any mobile phone from within the ics, requires specially adapted maintenance and...
  • Page 8: Reporting Safety Defects

    Service and warranty If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety We recommend that you read this publication defect exists in a group of vehicles, it may order thoroughly. a recall and remedy campaign. However, NHTSA cannot become involved in individual problems Your MINI is covered by the following warran- between you, your dealer, or MINI of North...
  • Page 9 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 10 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 11: At A Glance

    AT A GLANCE AT A GLANCE CONTROLS DRIVING TIPS COMMUNICATIONS MOBILITY REFERENCE Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 12: Cockpit

    Cockpit Around the steering wheel: Controls and displays Adjusting the exterior mirrors, folding them High beams in and out Headlamp flasher Parking lamps Roadside parking lamps Low beams Computer Automatic headlamp control Adaptive Light Control Turn signals Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG Online Edition for Part no.
  • Page 13 Tachometer Instrument lighting Resetting the trip odometer Wiper system Switching the ignition on/off and starting/stopping the engine Ignition lock Buttons on steering wheel Continuing cruise control Right: Storing speed and accelerating or decelerating Left: Increase or reduce volume Activating/deactivating cruise control Telephone Accepting and ending a call, start-...
  • Page 14 Displays Tachometer Instrument lighting with indicator and warning lamps Speedometer Display for with indicator and warning lamps > Current vehicle speed Fuel gauge > Indicator and warning lamps Radio display, refer to separate Owner's Manual Resetting the trip odometer Radio, refer to separate Owner's Manual Display for >...
  • Page 15: Indicator And Warning Lamps

    Indicator and warning lamps The concept Indicator and warning lamps can light up in var- ious combinations and colors in indicator area 1 or 2. Some lamps are checked for proper functioning and thus come on briefly when the engine is started or the ignition is switched on.
  • Page 16 Around the center console Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 17 Microphone for voice activation system Rear window defroster and for telephone in hands-free mode Indicator/warning lamp for front passen- Windshield heating ger airbags Reading lamps Air flow rate Color of ambient lighting Switches in the center console Seat heating Glass sunroof, electric Power windows Interior lamps Rear fog lamp...
  • Page 18 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 19: Controls

    AT A GLANCE CONTROLS CONTROLS DRIVING TIPS COMMUNICATIONS MOBILITY REFERENCE Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 20: Opening And Closing

    Opening and closing Keys/remote controls Integrated key Press button 1 to release the key. Remote control The integrated key fits the following locks: Each remote control contains a rechargeable > Driver's door, page 22. battery that is recharged when it is in the igni- tion lock while the car is being driven.
  • Page 21: Central Locking System

    > Settings for the displays in the speedometer unlocked using the lock buttons or door han- and tachometer: dles. The remote control can also be used to switch on/off the welcome lamps and interior > 12h/24h mode of the clock, refer to For- lamps.
  • Page 22 Convenient opening Press and hold the button until the display changes. Hold the button down. Briefly press the button repeatedly until the The power windows are opened and the glass symbol and "SET" are displayed. sunroof is tilted. Convenient closing is not possible by means of the remote control.<...
  • Page 23 Press and hold the button until the display locked again after it is closed. changes. Before and after each trip, check that the Split- door has not been inadvertently unlocked.< Briefly press the button to select, arrow: > Confirmation signal during unlocking Malfunctions >...
  • Page 24: From Inside

    Opening and closing: Using the door lock from inside You can set which parts of the car are unlocked, page 19. When there is no alarm system or Com- The switch locks or unlocks the doors and Split- fort Access , only the driver's door is door when the doors are closed, but the anti- locked with the door...
  • Page 25 Briefly press the button in the turn signal > lever repeatedly until "SET/INFO" is dis- The central locking system automatically played. locks the vehicle as soon as you drive off. > The central locking system automatically locks the vehicle after some time if no door has been opened, or as soon as you drive off.
  • Page 26: Alarm System

    Splitdoor Alarm system* To avoid damage, make sure there is suf- The concept ficient clearance before opening the Split- The alarm system, when activated, reacts if: door.< > A door, the engine compartment lid or the Opening liftgate is opened In some market-specific versions, the >...
  • Page 27 Display on the revolution counter > In duplex garages > When the system is armed, all LEDs pulse. After When being transported on car-carrying approx. 16 minutes one LED flashes. trains, ferries or trailers > If pets are to remain inside the car Switching off the tilt alarm sensor and interior movement detector >...
  • Page 28: Starting The Engine

    Comparison to standard remote controls Windows and glass sunroof, electric* Essentially, it makes no difference whether you If the engine is switched off, you can still operate control the above-mentioned functions using the windows and glass sunroof so long as a door Comfort Access or by pressing the buttons on or the Splitdoor has not been opened.
  • Page 29: Glass Sunroof, Electric

    Glass sunroof, electric* Malfunction Comfort Access may malfunction due to local To prevent injuries, exercise care when radio waves. closing the glass sunroof and keep it in If this happens, open or close the vehicle via the your field of vision until it is shut. buttons on the remote control or using the inte- Take the key with you when you leave the car;...
  • Page 30 Roller sun blind After switching off the ignition The roller sun blind can be opened and closed When the ignition is switched off, the windows independently of the glass sunroof. can still be operated for approx. 1 minute as long as no door is opened. Following interruptions in electrical Take the key with you when you leave the power supply...
  • Page 31: Adjustments

    Adjustments Sitting safely Head restraint A correctly adjusted head restraint reduces the The ideal sitting position can make a vital contri- risk of neck injury in the event of an accident. bution to relaxed, fatigue-free driving. In con- Adjust the head restraint in such a way junction with the safety belts, the head restraints that its center is at approx.
  • Page 32: Seat Adjustment

    Seats Height Note before adjusting Never attempt to adjust your seat while the vehicle is moving. The seat could respond with unexpected movement, and the ensuing loss of vehicle control could lead to an accident. On the front passenger seat as well, do not incline the backrest too far to the rear while the vehicle is being driven;...
  • Page 33: Height Adjustment

    Getting in back Height Adjust the head restraint so that its center is approximately at ear level. Distance Adjust the distance so that the head restraint is as close as possible to the back of the head. Height adjustment Pull up the lever on the seat backrest, arrow 1.
  • Page 34: Seat Heating

    Seat heating* Closing Make sure you hear the lock engage in the belt buckle. The upper belt anchor is suitable for adults of any stature as long as the seat is adjusted prop- erly, page 30. Opening Grasp the belt firmly. Press the red button in the buckle.
  • Page 35: Interior Rearview Mirror

    Mirrors Interior rearview mirror Exterior mirrors The front passenger's mirror is more con- vex than the driver's mirror. The objects seen in the mirror are closer than they appear. Do not gauge your distance from traffic behind you on the basis of what you see in the mirror; otherwise, there is an increased risk of an acci- dent.<...
  • Page 36: Steering Wheel

    Steering wheel Adjustments Do not adjust the steering wheel position while the car is in motion; otherwise, there is a risk of accident due to an unexpected move- ment.< Fold the lever down. Move the steering wheel to the preferred distance and angle to suit your seated posi- tion.
  • Page 37: Transporting Children Safely

    Transporting children safely The right place for Child restraint systems, children installation Do not leave children unattended in the Observe the child restraint system manu- vehicle; otherwise, they could endanger facturer's instructions when selecting, themselves and/or other persons by opening the installing and using child restraint systems.
  • Page 38: Latch Child Restraint Fixing System

    To lock the safety belt Child restraint system with tether strap Secure the child restraint system with the Use the tether strap anchors to secure belt. child restraint systems only; otherwise, the anchors could be damaged.< Pull the belt strap all the way out. Allow the belt strap to retract and pull it taut against the child restraint system.
  • Page 39 Push the head restraint upward. Guide the tether strap between the head restraint holders. Attach the tether strap to the anchor using the hook. Push the head restraint into its lowermost position. Attach the tether strap to the anchor using the hook.
  • Page 40: Driving

    Driving Ignition lock If the start/stop button is pressed while the clutch is depressed in the manual trans- mission or the brake pedal is depressed in the Inserting the key into the ignition lock automatic transmission, the engine starts.< Radio readiness Individual electrical consumers can operate.
  • Page 41: Switching Off The Engine

    Starting the engine Depress the brake. Shift the selector lever into position P or N. Do not allow the engine to run in enclosed Press the Start/Stop button. areas; otherwise, inhalation of the noxious The starter operates automatically for a certain exhaust gases can lead to loss of consciousness time, and stops automatically as soon as the and death.
  • Page 42: Manual Transmission

    Automatic transmission* Releasing with Steptronic In addition to the fully automatic mode, you can shift gears manually using Steptronic, page 41. Parking the vehicle To prevent the vehicle from rolling, always select position P and apply the parking brake before leaving the vehicle with the engine running.<...
  • Page 43 Sport program and manual operation To prevent the vehicle from creeping after you select a driving position, depress the brake until you are ready to start.< A lock prevents accidental shifting into selector lever positions R and P. Overriding the selector lever lock Move the selector lever from position D to the left into the M/S shifting slot: The Sport program is activated and DS is dis-...
  • Page 44 If you do not shift gears with the shift paddles or Move the selector lever into the desired accelerate for a certain amount of time, the position by pressing the button on the front transmission automatically returns to D, auto- of the selector lever.
  • Page 45: Wiper System

    Switch on the ignition, refer to page 38. Briefly press the button to select: > Briefly press the button in the turn signal lever repeatedly until "SET/INFO" is dis- Brief indication of a turn. played. > Triple turn signal. Press and hold the button until the display changes.
  • Page 46 If the car is equipped with a rain sensor, the time Press and hold the button until the display between wipes is controlled automatically and changes. depends on the intensity of the rainfall. The rain sensor is mounted on the windshield, directly in front of the interior rearview mirror.
  • Page 47: Cruise Control

    Window washer nozzles Washer fluid reservoir The window washer nozzles are heated auto- Only refill washer fluid that contains anti- matically while the engine is running or the freeze when the engine is cool, to avoid ignition is switched on. contact with hot engine parts.
  • Page 48: Activating/Deactivating Cruise Control

    Activating Increasing speed Press button 3 repeatedly until the desired speed is reached. Every time you press the but- ton, the speed increases by approx. 1 mph or 2 km/h. Accelerating using the button Press and hold button 3. The vehicle accelerates without pressure on the accelerator pedal.
  • Page 49: Controls Overview

    Controls overview Tachometer Odometer and trip odometer Resetting the trip odometer With the ignition switched on, press knob 3 in the tachometer. Units of measure Select the respective units of measure, miles or km for the odometer as well as 7 or 6 for the outside temperature, page 50.
  • Page 50: Average Fuel Consumption

    Reserve Cruising range Once the fuel level has fallen to the reserve zone Displays the estimated cruising range available of approx. 2.1 gallons/8 liters, the remaining with the remaining fuel. The range is calculated indicator lamps change from orange to red, on the basis of the way the car has been driven arrow.
  • Page 51: Settings And Information

    Settings and information Operating principle Certain settings and information are only Setting formats and units of measure, reset- available when the ignition is switched on, the ting to factory settings vehicle is at a standstill and the doors are closed. Adjusting settings Button for: >...
  • Page 52 Exiting displays Switch on the ignition, refer to page 38. Briefly press the button in the turn signal lever repeatedly until "SET/INFO" is dis- played. Briefly press the button in the turn signal lever repeatedly until "HOME" is displayed. Press the button for a longer period. Current vehicle speed is once again displayed.
  • Page 53: Service Requirements

    Press and hold the button until the display Briefly press button repeatedly until "RESET" changes. is displayed. Press the button briefly to change the for- mat or unit of measure. Press and hold the button until the display changes. The settings are stored. Resetting to factory settings The settings for formats and units of measure can be reset to the factory settings.
  • Page 54: Possible Displays

    Switch on the ignition, refer to page 38. Briefly press the button repeatedly until the corresponding symbol and "SERVICE INFO" Briefly press the button in the turn signal are displayed. lever repeatedly until "SET/INFO" is dis- played. Press and hold the button until the display changes.
  • Page 55: Check Control

    Clock What to do in case of a malfunction The meaning of each lamp in the event of a mal- function and tips on how to respond are listed Setting the time starting on page 141. Setting time, refer to owner's manual for Radio Boost CD.
  • Page 56 Viewing stored Check Control messages Stored Check Control messages can only be dis- played if the driver's door is closed. Briefly press the button in the turn signal lever repeatedly until "SET/INFO" is dis- played. Press and hold the button until the display changes.
  • Page 57: Technology For Driving Comfort And Safety

    Technology for driving comfort and safety Park Distance Control Adjustments PDC* The volume of the acoustic signals can be adjusted, refer to the Owner's Manual for Radio. The concept Malfunction PDC assists you with parking in reverse. Acoustic Indicator lamp comes on: PDC has signals warn you of the presence of an object failed.
  • Page 58: Driving Stability Control Systems

    Driving stability control Dynamic Stability Control DSC systems The concept DSC prevents the driving wheels from losing Your MINI has a number of systems that help to traction when you pull away from rest or accel- maintain the vehicle's stability even in adverse erate.
  • Page 59: Dynamic Traction Control Dtc

    Dynamic Traction Control DTC* Deactivating DTC DTC is a type of DSC that is propulsion optimized Press the button again: the DSC indicator lamps for special road conditions such as uncleared go out. snowy roads. The system ensures maximum Deactivating both DTC and DSC propulsion though with restricted driving stabil- ity.
  • Page 60: Sport Button

    Sport button* Functional requirement The system must have been initialized while the Pressing the button causes your MINI to respond tire inflation pressure was correct; otherwise, even more sportily. reliable signaling of a flat tire is not ensured. > Engine responds more spontaneously to Initialize the system after every correction of the movements of the accelerator.
  • Page 61 Using the button in the turn signal lever Reduce speed and stop the vehicle with cau- tion. Avoid sudden braking and steering Start the engine, but do not start driving. maneuvers. Briefly press the button in the turn signal Check whether the vehicle is equipped with lever repeatedly until "SET/INFO"...
  • Page 62: Tire Pressure Monitor

    Tire Pressure Monitor At the next opportunity, check the air pres- sure in all four tires. TPM* If the inflation pressure in all four tires is cor- rect, the Flat Tire Monitor might not have The concept been initialized. The system must then be Measuring the inflation pressure in the four initialized.
  • Page 63 Using the button in the turn signal lever Start driving. After driving a few minutes, the set inflation Start the engine, but do not start driving. pressures in the tires are accepted as the tar- Briefly press the button in the turn signal get values to be monitored.
  • Page 64 Use the Mobility System to remedy the flat Since the possible driving distance depends to a tire on the damaged wheel, refer to considerable degree on the strain exerted on page 131, or to replace the damaged wheel, the vehicle while driving, it can be shorter or, refer to page.
  • Page 65 Declaration according to NHTSA/ ability. Please note that the TPMS is not a substi- FMVSS 138 Tire Pressure Monitoring tute for proper tire maintenance, and it is the Systems driver's responsibility to maintain correct tire pressure, even if underinflation has not reached Each tire, including the spare, should be the level at which the TPMS low tire pressure tell- checked monthly when cold and inflated to the...
  • Page 66 The airbags are designed to not be triggered in bags for the front passenger are activated or every type of collision, e.g. not in minor acci- deactivated by the system accordingly. dents, certain rollover situations or rear impacts. The indicator lamp above the interior rear- Do not apply adhesive materials to the view mirror shows the current status of cover panels of the airbags, cover them or...
  • Page 67 Airbag system malfunction > The indicator lamp comes on as intended when a child in a specially designated child > The warning lamp does not come on when restraint system is detected on the seat. radio readiness or the ignition is switched The front and side airbags for the front pas- senger are not activated.
  • Page 68: Lamps

    Lamps Parking lamps/low beams Automatic headlamp control* When the switch is in position 3, the low beams are switched on and off automatically depend- ing on ambient light conditions, e.g. in a tunnel, in twilight, or if there is precipitation. Adaptive Light Control is active.
  • Page 69: Daytime Running Lights

    Setting the duration or deactivating the Briefly press the button to select: function > Switch on the ignition, refer to page 38. The function is deactivated. Briefly press the button in the turn signal > lever repeatedly until "SET/INFO" is dis- Select the appropriate duration, e.g.
  • Page 70: Adaptive Light Control

    Adaptive Light Control* Briefly press the button repeatedly until the symbol and "SET" are displayed. The concept Adaptive Light Control is a variable headlamp control system that enables better illumination of the road surface. Depending on the steering angle and other parameters, the light from the headlamp follows the course of the road.
  • Page 71: Instrument Lighting

    Roadside parking lamps, left or right* If the automatic headlamp control is acti- vated, the low beams will come on auto- The vehicle can be illuminated on one side for matically when you switch on the fog lamps.< parking. Comply with local regulations when doing so.
  • Page 72: Interior Lamps

    Interior lamps Ambient lighting* The interior lamps, the footwell lamps and the cargo area lamp are controlled automatically. To reduce the drain on the battery, a short while after the ignition is switched off, refer to Start/Stop button on page 38, all lights in the vehicle's passenger compartment are switched off.<...
  • Page 73: Climate

    Climate Equipment versions Air vents Depending on your vehicle's equipment, your Airflow directed toward the windshield and MINI contains an air conditioner or an automatic side windows climate control Air to the upper body area, draft-free venti- Air conditioner lation Automatic climate control Air to the footwell Online Edition for Part no.
  • Page 74: Air Conditioner

    Air conditioner Air flow rate Rear window defroster Cooling function Air distribution Recirculated-air mode Windshield heating Temperature Air flow rate Recirculated-air mode Adjust the air flow rate. The higher the If the air outside the car has an rate, the more effective the heating or unpleasant odor or contains pollut- cooling will be.
  • Page 75: Automatic Climate Control

    Air distribution Defrosting windows and removing condensation Direct the flow of air to the windows , to the upper body Set air flow rate to the maximum level. area or to the footwell Set air distribution to position Intermediate settings are possible. Condensation is removed from the windows more quickly when the cooling function Windshield heating*...
  • Page 76: Maximum Cooling

    Comfortable interior climate If condensation starts to form on the inside window surfaces, press the AUTO AUTO program 2 offers the ideal air distribution button or switch off the recirculated-air mode and air flow rate for almost all conditions, refer and, if necessary, increase the air flow rate.
  • Page 77: Windshield Heating

    Ventilation Defrosting windows and removing condensation Quickly removes ice and condensa- tion from the windshield and front side windows. For this purpose, also switch on the cooling function. The windshield heating is switched on auto- matically. Windshield heating* The windshield heating is switched Knob for continuous opening and closing off automatically after a certain Jet for direction of air flow...
  • Page 78: Practical Interior Accessories

    Practical interior accessories Integrated universal You can also obtain information on the Internet remote control* www.MINI.com or www.homelink.com The concept HomeLink is a registered trademark of Johnson Controls, Inc. The integrated universal remote control can replace as many as three hand-held transmitters Programming for various remote-controlled devices, such as garage and gate openers and lighting systems.
  • Page 79 To program other original hand-held trans- Press the button on the receiver of the mitters, repeat steps 3 and 4. device to be set. After step 4, you have approx. 30 seconds for the next step 5. The corresponding memory button 1 is now programmed with the signal of the original Press the programmed memory button 1 of hand-held transmitter.
  • Page 80: Glove Compartment

    Glove compartment Center armrest* Opening Storage compartment The center armrest between the front seats con- tains either a compartment or the cover for the mobile phone base plate or the snap-in adapter Press the button to open the cover. The light in the glove compartment comes on. Closing Fold cover up.
  • Page 81: Storage Compartments

    Connecting via the USB audio interface Do not forcibly connect the plug to the USB interface. Do not connect devices such as fans or lamps to the USB audio interface. Do not connect USB hard discs. Do not use the USB audio interface to charge external devices.
  • Page 82: Cupholders And Ashtray

    Clothes hooks There are two additional cupholders in the arm rests in the rear. There are clothes hooks on the grab handles in the rear passenger compartment. Items of clothing hung from the hooks must not obstruct the driver's view. Do not hang heavy objects from the hooks;...
  • Page 83: Cigarette Lighter Socket

    Connecting electrical appliances In your MINI, you can use electrical devices such as a flashlight, car vacuum cleaner, etc., up to approx. 200 watts at 12 volts, as long as one of the following sockets is available. Avoid damag- ing the sockets by attempting to insert plugs of unsuitable shape or size.
  • Page 84 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 85: Driving Tips

    AT A GLANCE CONTROLS DRIVING TIPS DRIVING TIPS COMMUNICATIONS MOBILITY REFERENCE Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 86: Things To Remember When Driving

    Things to remember when driving Break-in period Following part replacement The same break-in procedures should be Moving parts need breaking-in time to adjust to observed if any of the components mentioned each other. Please follow the instructions below above have to be renewed in the course of the in order to achieve the optimal service life and vehicle's operating life.
  • Page 87: Driving Through Water

    Hydroplaning Only use floor mats that have been approved for the vehicle and can be appropriately fastened. When driving on wet or slushy roads, Make sure that the floor mats are securely fas- reduce road speed. If you do not, a wedge tened again after they have been removed, e.g.
  • Page 88: Cargo Loading

    Traces of condensed water under the luggage. vehicle are therefore normal. In the MINI Cooper S, the coolant pump may Removing continue to run for some time after the engine is Pull on the handle to roll the cover up.
  • Page 89: Partition Net

    Partition net* Ensure that the partition net is firmly attached; otherwise, injuries may occur.< The partition net can be mounted in the cargo area or behind the front seats. In the cargo area Fold the rear seat backrest forward if neces- sary, page 87.
  • Page 90: Stowing Cargo

    Level load floor* Subtract the combined weight of the driver and passengers from XXX kilograms or YYY The maximum load of the flat load floor is pounds. 165 lbs/75 kg. Do not exceed a maximum permissible load of 55 lbs/25 kg for the storage The resulting figure equals the available compartment beneath the flat load floor;...
  • Page 91 > Do not stack higher than the top edge of the Heavy or hard objects should not be carried backrests. loose inside the car, since they could be thrown around, for example as a result of heavy braking, > Use the partition net, refer to page 87. sudden swerves, etc., and endanger the occu- Ensure that no objects can penetrate pants.
  • Page 92: Saving Fuel

    Avoid high engine speeds Fasten roof-mounted cargo correctly and securely to prevent it from shifting or falling off Use first gear only for driving off. In second and during the trip. higher gears, accelerate smoothly to a suitable Drive smoothly. Avoid sudden acceleration and engine and road speed.
  • Page 93 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 94 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 95: Communications

    AT A GLANCE CONTROLS DRIVING TIPS COMMUNICATIONS COMMUNICATIONS MOBILITY REFERENCE Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 96: Telephone

    Telephone Overview Suitable mobile phones For precise information about which mobile phones and external devices can be with a Blue- The concept tooth interface are supported by the complete Mobile phones or other external devices, e.g. mobile phone preparation, go to audio players, can be connected to the vehicle www.mini.com/connectivity.
  • Page 97 Operating the mobile phone via the radio To open the menu show above, refer to Pairing a new mobile phone, delete pairing page 100. data of a mobile phone, or switching Blue- tooth on/off Making and receiving phone calls Time >...
  • Page 98: Function Buttons

    Pairing/unpairing mobile 10 Switching displays > "PHONE": telephone phone > "COMP": computer Overview > "CONFIG": adjusting 11 Radio on/off, volume The pairing data of four mobile phones can be stored simultaneously in the vehicle. When the > Press: to switch radio on/off engine is running or the ignition is switched on, >...
  • Page 99 necting or coupling Bluetooth device. The Bluetooth name of the vehicle appears on the mobile phone display. Select the Bluetooth name of the vehicle on Press the button. the mobile phone display. Pairing and connecting Pairing Only pair the mobile phone when the The mobile phone or the radio display will vehicle is stopped;...
  • Page 100 Connecting a particular mobile phone Press the button if necessary. If more than one mobile phone is detected by The following display will appear after the the vehicle, the mobile phone at the top of the mobile phone is paired: list is connected.
  • Page 101 What to do if… > The data volume of the phone book entry is too great, e.g. due to additionally stored For information on suitable mobile phones, refer information such as notes? Reduce the data to page 94. volume. The mobile phone could not be paired or con- The telephone connection quality is low.
  • Page 102: Adjusting Volume

    Adjusting volume Entering phone numbers Dialing a number Press the button. Press the button. Turn the knob until the desired volume is reached. The volume for incoming calls and call volume Press the button. can be adjusted independently of each other. Enter the desired phone number using the The setting is stored for the remote control cur- 0-9 buttons.
  • Page 103 Dialing a phone number from the phone Enter the desired code using the 0-9 but- book tons. The A-Z list is available for phone book entries. If If needed, press and hold the but- entries with different names, but the same ton on the right or left side to enter special phone number are transferred from the mobile characters.
  • Page 104: General Information

    Editing and dialing a phone number Deleting an individual entry from the phone book Select the desired entry from the list. The phone number of an entry can be edited before a call. This change is not stored in the Press the button.
  • Page 105: Operation By Voice

    Operation by voice* Finishing voice input Press the button on the steering wheel briefly The concept > The mobile phone can be operated without {Cancel}. removing your hand from the steering wheel. Possible commands > In many cases, the entry process is sup- ported by means of announcements or Having possible commands read aloud questions.
  • Page 106 Calling Delete the entry. {Delete name}. Dialing phone numbers Say the name when prompted. {Dial number}. Confirm the query with {Yes}. Say the phone number. Delete all entries. {Dial}. {Delete phonebook}. The connection to the desired subscriber is established. The dialog for deleting phone book is opened.
  • Page 107: Snap-In Adapter

    > Always say commands in the language of Insert the snap-in adapter at the front, arrow 1, and press downward, arrow 2, until the voice activation system. it clicks into place. > Keep doors, windows, glass sunroof /pan- orama glass roof , or convertible top closed to avoid noise interference.
  • Page 108 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 109 AT A GLANCE CONTROLS DRIVING TIPS COMMUNICATIONS MOBILITY MOBILITY REFERENCE Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 110: Refueling

    Refueling Manually releasing the fuel filler flap Switch off the engine before refueling; otherwise, fuel cannot be added to the In the event of an electrical malfunction, you can tank and a message will be displayed.< manually release the fuel filler flap: Take all precautionary measures and observe all applicable regulations when handling fuel.
  • Page 111: Fuel Specifications

    Fuel specifications by switching to a recognized high-quality brand such as gasoline that is advertised as Top Tier Do not use leaded gasoline; otherwise, Detergent Gasoline. permanent damage to the catalytic con- Failure to comply with these recommendations verter will result. may also result in unscheduled maintenance.<...
  • Page 112: Wheels And Tires

    Wheels and tires Tire inflation pressures Inflation pressure specifications The tables below provide all the correct inflation pressures for the specified tire sizes at ambient Information for your safety temperature. It is not merely the tires' service life, but also The tire inflation pressures apply to the driving comfort and, to a great extent, driving tire sizes approved and the tire brands...
  • Page 113 MINI Cooper Clubman tire inflation pressures Tire size Pressure specifications in psi/kPa Speeds up to a Speeds including max.
  • Page 114 MINI Cooper S Clubman tire inflation pressures Tire size Pressure specifications in psi/kPa Speeds up to a Speeds including max. of those exceeding 100 mph/160 km/h 100 mph/160 km/h All pressure specifications in the table are indicated in psi/kilopas- cal with cold tires. Cold = ambient...
  • Page 115: Tire Coding

    Tire coding DOT Quality Grades Tread wear Knowledge of the labeling on the side of the tire Traction AA A B C makes it easier to identify and choose the right Temperature A B C tires. All passenger car tires must conform to Federal Safety Requirements in addition Tire size to these...
  • Page 116: Tire Condition

    Minimum tread depth meet under the Federal Motor Vehicle Safety Standard No. 109. Grades B and A represent levels of performance on the laboratory test wheel that exceed the minimum required by law. The temperature grade for this tire is established for a tire that is properly inflated and not overloaded.
  • Page 117: New Wheels And Tires

    Correct wheels and tires recommends tire replacement after no more than 6 years, regardless of the actual wear of the The manufacturer of your MINI recom- tires. mends mounting only wheels and tires that it has specifically approved for use on your particular model.
  • Page 118: Snow Chains

    Recommended tire brands Storage Always store wheels and tires in a cool, dry place with as little exposure to light as possible. Always protect tires against all contact with oil, grease and fuels. Do not exceed the maximum tire inflation pres- sure indicated on the sidewall of the tire.
  • Page 119: Under The Hood

    Under the hood Never attempt to perform any service or Opening repair operations on your vehicle without the required professional technical training. If you are not familiar with the regulations to be observed, have the necessary work on your vehicle carried out only by a MINI dealer or a workshop that has specially trained personnel working in accordance with the specifications of the MINI manufacturer.
  • Page 120: Engine Oil

    Important parts of the engine compartment Battery, under the cover Coolant expansion tank Engine oil dipstick Reservoir for washer fluid for the headlamp and window washer system Engine oil filler neck Engine compartment fuse box Engine oil The oil level should be between the two marks on the dipstick.
  • Page 121 Adding engine oil Alternative oil types If the approved engine oils are not available, up to 1 US quart/1 liter of another oil with the fol- lowing specification may be used: API SM or higher Coolant Do not add the maximum quantity of 1 US Do not add coolant to the cooling system quart/1 liter of engine oil until the oil level has when the engine is hot.
  • Page 122 Topping off Turn the cap of the expansion tank a little counterclockwise to allow any accumulated pressure to escape, then continue turning to open. Slowly fill to the correct fluid level; do not overfill. Turn the cap until there is an audible click. Have the reason for the coolant loss eliminated as soon as possible.
  • Page 123: Maintenance

    Maintenance MINI Maintenance System Make sure that the date in the tachometer is always set correctly, page 53; otherwise, the effectiveness of Condition Based Service CBS is not assured.< Service and Warranty Information Booklet for US models and Warranty and Service Guide Booklet for Canadian models Please consult your Service and Warranty Infor-...
  • Page 124 Emissions The warning lamps come on. The vehicle is producing higher emissions. You can continue your journey, but moderate your speed and exercise due caution. Have the car checked as soon as possible. Under certain circumstances, one of the lamps will flash or light up continuously.
  • Page 125: Care

    Care Car-care products Car washes Preference should be given to cloth car washes. Regular cleaning and care helps to maintain the Do not use automatic high-pressure car value of your MINI. washes; otherwise, water may drip into The manufacturer of your MINI recommends the vehicle around the windows.<...
  • Page 126: Chrome Parts

    Steam jets/high-pressure washers Wax, preservatives and dirt on the win- dows cause streaks when the windshield When using steam jets or high-pressure wipers are on, and can cause premature wear of washers, make sure that you maintain suf- the wiper blades and interfere with the rain sen- ficient distance from the vehicle and do not sor.<...
  • Page 127 Light-alloy wheels* Treat the leather twice a year using a leather lotion since dirt and grease will gradually attack The system produces brake dust that collects on the leather's protective layer. the light alloy wheels. Clean them regularly with acid-free wheel cleaner. Carpets/floor mats* Do not use aggressive, acid-containing, Keep floor mats, carpet, and other objects...
  • Page 128: Vehicle Storage

    Displays To clean displays such as radios or display ele- ments, use a display cleaning cloth or a soft, non-scratching, lint-free cloth. Avoid pressing too hard when cleaning the display as this can cause damage.< Do not use chemical or abrasive house- hold cleaning agents.
  • Page 129: Replacing Components

    Replacing components On-board vehicle tool kit Press into position until you hear it engage. Fold down the wiper arm. To avoid damage, make sure that the wiper arms are against the windshield before you open the hood.< Changing the rear wiper blade Your vehicle comes with an onboard vehicle tool kit that varies with the equipment version;...
  • Page 130: Xenon Lamps

    When working on electrical systems, Have any work on the xenon lamp system, always begin by switching off the con- including bulb replacement, carried out sumer in question; otherwise, short circuits only by a MINI dealer or a workshop that has could result.
  • Page 131 Replacing the bulb Replacing a turn signal bulb Turn the lamp counterclockwise, arrow 1, 21 watt bulb, PY 21 W and remove it, arrow 2. Turn in the wheel. Remove cover 1. To do so, turn the cover counterclockwise. Remove the inside cover. To do so, turn the cover counterclockwise.
  • Page 132 Unscrew the bulb holder counterclockwise. Pull out and replace the bulb. To insert the new bulb and replace the cover, proceed in reverse order. Tail lamps To insert the new bulb and replace the cover, proceed in reverse order. Replacing a fog lamp bulb H8 bulb, 35 watts Turn in the wheel.
  • Page 133: Repairing A Flat Tire

    Repairing a flat tire Disconnect the cable connector if necessary, arrow 1. Safety measures in the event of a break- down: Park the vehicle as far as possible from moving traffic and switch on the hazard warning flash- ers. Turn the steering wheel until the front wheels are in the straight-ahead position and engage the steering wheel lock.
  • Page 134 Compressor Plug and cable for the socket in the vehicle interior, page Connection hose to connect the compressor and sealant bottle or the compressor and wheel On/off switch Pressure gauge for indicating the tire infla- tion pressure Compressor Release button for reducing the tire inflation Wheel stud wrench pressure Vehicle jack...
  • Page 135: Distributing The Sealant

    Distributing the sealant Ensure that the compressor is switched off. Insert the plug 3 into the lighter socket/ Immediately drive approx. 3 mls/5 km to evenly power socket in the vehicle interior, distribute the sealant. page 81. Do not exceed speeds of 50 mph/ With the engine running: 80 km/h.
  • Page 136: Changing Wheels

    Changing wheels Removing the space-saver spare tire The space-saver spare tire is located under the tire change set in the cargo area. Space-saver spare tire* Fold up the floor mat. To change a space-saver spare tire, proceed as follows: Unscrew the nut, arrow, and remove the space-saver spare tire.
  • Page 137: Vehicle Battery

    it from extending to its full support height and Jack the vehicle up until the wheel you are reduce its load-carrying capacity. changing is raised off the ground. Do not lie under the vehicle or start the engine Mounting the space-saver spare tire when the vehicle is supported by the jack;...
  • Page 138: In The Engine Compartment

    In the engine compartment After a battery replacement, have the battery registered on the vehicle by your dealer to ensure that all comfort functions are fully avail- able. Charging the battery Only charge the battery in the vehicle when the engine is off.
  • Page 139: Giving And Receiving Assistance

    Giving and receiving assistance Roadside Assistance Jump-starting Roadside Assistance is available by phone 24 If the car's own battery is flat, your MINI's engine hours a day in many countries. You can receive can be started by connecting two jumper cables assistance there in the event of an emergency.
  • Page 140 Starting the engine Release the tabs on the left and right sides of the positive terminal cover , arrows 1, and Start the engine of the donor vehicle and lift the cover to open, arrow 2. allow it to run for a few minutes at slightly increased idle speed.
  • Page 141: Being Towed

    Switch on the hazard warning flashers, depend- ing on local regulations. Have the MINI Clubman transported with a tow truck with a so-called lift bar or on a flat bed. Manual transmission Do not lift the vehicle by a tow fitting or Gearshift lever in neutral position.
  • Page 142 Tow-starting Avoid tow-starting the vehicle whenever possi- ble; instead, jump-start the engine, page 137. Vehicles with a catalytic converter should only be tow-started when the engine is cold, vehicles with an automatic transmission cannot be tow- started at all. Switch on hazard warning flashers, comply with local regulations.
  • Page 143: Indicator And Warning Lamps

    Indicator and warning lamps Indicator and warning lamps can light up in var- ious combinations and colors in indicator area 1 or 2. See the table for information on causes and how to react. Note whether a lamp comes on alone or in combination with another.
  • Page 144 Cause What to do Lights up briefly: the tank still contains approx. 2.1 US gallons/8 liters of fuel Remains on: Cruising range is no more than approx. 30 miles/50 km, page Engine refuses to start Depress the brake or clutch in order to start the engine, page 38.
  • Page 145 Cause What to do Lights up in red: Service due Arrange a service appointment. Check service requirements, page, 121. Lights up in yellow: The engine will start the next time the Start/Stop button is briefly pressed, possibly without the brake or clutch being depressed Remote control malfunctioning or, in The engine cannot be started.
  • Page 146 Cause What to do Indicator lamp 1 flashes: Engine malfunction under high load. You can continue your journey, but High engine load will result in moderate your speed and exercise damage to the catalytic converter due caution. Have the vehicle checked without delay.
  • Page 147 Cause What to do Indication in US models Lights up in red: Brake fluid level too low Braking action is reduced, stop with care. Contact the nearest MINI dealer. Lights up in yellow: Hill Assist failed. The car will not be Have the system checked as soon as held in place after the brake is possible.
  • Page 148 Cause What to do Indication in Canadian models Vehicle electronics failed You cannot continue your journey. Contact your MINI dealer. Lights up in red: Have the system in question checked without delay. > Starter failed or The engine cannot be restarted. >...
  • Page 149 Cause What to do The Dynamic Stability Control DSC Driving stability limited during accel- and Dynamic Traction Control DTC eration and cornering. have failed. You can continue your journey, but moderate your speed and exercise due caution. Have the system checked as soon as possible.
  • Page 150 Cause What to do Vehicles with Tire Pressure Monitor Light up in yellow and red: Carefully bring the car to a stop. There is a flat tire or substantial loss Observe the information starting on in tire pressure page 60. Vehicles with Tire Pressure Monitor Light up in yellow: Check the inflation pressure and reset...
  • Page 151 Cause What to do Lights up in red: > Transmission limp-home pro- You can continue your journey, but gram active with restricted range moderate your speed and exercise of gears, possibly with reduced due caution. Have the system acceleration checked without delay. >...
  • Page 152 Cause What to do Selector lever position P not engaged. Engage selector lever position P when Ignition cannot be switched off you wish to switch off the ignition, page 38. Cruise control system failed Have the system checked. Park Distance Control failed Have the system checked.
  • Page 153 Cause What to do No service due Set speed limit exceeded Time and date no longer correct Set the time and date, page 53. Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 154 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 155 AT A GLANCE CONTROLS DRIVING TIPS COMMUNICATIONS MOBILITY REFERENCE REFERENCE Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 156: Technical Data

    Technical data In the technical data, only the values that differ from the Cooper S are shown for the John Cooper Works. Engine data Cooper Cooper S John Cooper Works Displacement cu in/ 97.5/ 97.5/ 97.5/ cmμ 1,598 1,598 1,598 Number of cylinders Maximum power out- At engine speed...
  • Page 157 Dimensions All dimensions in inches/mm. Minimum turning radius Δ: 36 ft in/11.0 m. Information after the semicolon: different values for MINI Cooper S. Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 158 Weights Cooper Cooper S John Cooper Works Curb weight, ready for travel, with all optional extras > Manual transmission lbs/kg 2,712/1,230 2,833/1,285 2,833/1,285 > Automatic transmis- 2,789/1,265 2,877/1,305 – lbs/kg sion Approved gross weight > Manual transmission lbs/kg 3,549/1,610 3,671/1,665 3,704/1,680 >...
  • Page 159 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 160: Everything From A To Z

    Everything from A to Z INDEX Airbags Automatic transmission with – sitting safely Steptronic ABS Antilock Brake System – warning lamp – interlock Accessories, refer to Your Airing, refer to Ventilation – overriding selector lever individual vehicle AKI, refer to fuel grade lock Acknowledgment signals for Alarm system...
  • Page 161 Beverage holders, refer to Cargo area doors, refer to Cupholders Splitdoor Black ice, refer to Outside California Proposition 65 Cargo area, expanding temperature warning warning Cargo area lamp Blower, refer to Air flow Call Cargo area partition net, refer rate 72, –...
  • Page 162 Cold start, refer to Starting the Disposal engine – of coolant Comfort Access Dashboard instruments, refer – remote control battery – replacing the battery to Displays – vehicle battery – what to observe before Dashboard lighting, refer to Distance remaining to service, entering a car wash Instrument lighting refer to Service...
  • Page 163 Engine starting, refer to Flat tires, refer to Tire Starting the engine condition Electrical malfunction ESP Electronic Stability Floor mats, care – door lock Program, refer to Dynamic Floor plate, refer to Level load – fuel filler flap Stability Control DSC floor Electronic brake-force Exhaust system, refer to Hot...
  • Page 164 Gasoline, refer to Required Heating Individual settings, refer to fuel – mirrors Personal Profile Gear indicator – rear window 72, Inflation pressure monitoring, – automatic transmission with – seats refer to Tire Pressure Monitor Steptronic Heavy loads, refer to Stowing Gear shifting cargo Initializing...
  • Page 165 Kickdown Locking and unlocking doors Microfilter – automatic transmission with – confirmation signals – for air conditioner Steptronic – from inside – for automatic climate Knock control – from outside control Low beams – MINI Maintenance – automatic System – replacing bulb Microfilter/activated-charcoal Lamps and bulbs, replacing Lower back support, refer to...
  • Page 166 Overheated engine, refer to Coolant temperature Neck support, refer to Head Radio key, refer to Integrated restraints key/remote control Nets, refer to Storage Radio position, refer to Radio compartments Paintwork, care readiness New tires Park Distance Control PDC Radio readiness Number of cylinders, refer to Parking –...
  • Page 167 Replacement remote Safety belts Service requirements control – damage Settings Replacing bulbs, refer to – indicator lamp – clock, 12h/24h mode Lamps and bulbs – reminder Shifting gears Replacing tires, refer to New – sitting safely – automatic transmission with wheels and tires Safety belts, care Steptronic...
  • Page 168 Special oils, refer to Approved Stowage, refer to Storage Tightening the lug bolts engine oils compartments – keys Speed Summer tires, refer to Wheels – torque – with winter tires and tires Tightening torque, refer to Speedo, refer to Switches, refer to Cockpit Tightening lug bolts Speedometer Switching off...
  • Page 169 Tires with emergency Turning circle, refer to Volume operation properties, refer to Dimensions – mobile phone Run-flat tires Tying down loads, refer to Volume of cargo area Tires with safety features, refer Cargo loading to Run-flat tires Tools, refer to On-board vehicle tool kit Warning and indicator Torque...
  • Page 170 Windshield – cleaning – defrosting and removing condensation 73, Windshield wiper blades, changing Windshield wipers, refer to Wiper system Winter tires – storage Wiper blade replacement Wiper system Work in the engine compartment Wrench/screwdriver, refer to On-board vehicle tool Xenon lamps –...
  • Page 171 Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...
  • Page 172 *BL260522600P* DRIVE ME. Online Edition for Part no. 01 40 2 605 226 - © 07/10 BMW AG...

Table of Contents
