Mini HARDTOP 2 DOOR 2023 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CONTENT
A-Z
OWNER'S MANUAL.
MINI HARDTOP 2 DOOR / 4 DOOR.
Online Edition for Part no. 01405A7DAD4 - II/23

Advertisement

Table of Contents
loading

Related Manuals for Mini HARDTOP 2 DOOR 2023

Summary of Contents for Mini HARDTOP 2 DOOR 2023

  • Page 1 CONTENT OWNER'S MANUAL. MINI HARDTOP 2 DOOR / 4 DOOR. Online Edition for Part no. 01405A7DAD4 - II/23...
  • Page 3 The more familiar you are with the vehicle, the better control you will have on the road. We therefore strongly suggest the following: Read this Owner's Manual before starting off in your new MINI. Also use the Integrated Owner's Manual in the vehicle. It contains important notes on vehicle operation that will help you make full use of the technical features available in your MINI.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Navigation, Entertainment and Communication can be called up via the Integrated Owner's Manual in the vehicle. NOTES Information..........................QUICK REFERENCE Getting in..........................Set-up and use........................20 On the road..........................AT A GLANCE Dashboard..........................Central Information Display (CID)..................36 Voice activation system....................General settings........................
  • Page 5 Interior equipment......................212 Storage compartments.....................223 Cargo area..........................227 DRIVING TIPS Things to remember when driving................Reducing fuel consumption................... MOBILITY Refueling..........................246 Fuel............................Wheels and tires........................250 Engine compartment......................272 Engine oil..........................275 Coolant..........................279 Maintenance........................Replacing components....................Breakdown Assistance....................Vehicle Care........................297 REFERENCE Technical data........................Appendix..........................306 Everything from A to Z....................308 ©...

  • Page 6: Integrated Owner's Manual In The Vehicle

    Selecting the Owner's Manual Owner's Manual for Navigation, Press the button. Entertainment, Communication "My MINI" The Owner's Manual for Navigation, Enter- "Owner's Manual" tainment, and Communication is available Select the desired method of accessing as a printed book from an authorized serv- the contents.
  • Page 7 "Owner's Manual" Internet Opening when a Check Control message is displayed Vehicle information and general informa- tion on MINI, e.g., on technology, are availa- Directly from the Check Control message on ble on the Internet: www.miniusa.com. the control display: "Owner's Manual"...
  • Page 8 NOTES Information When using these functions and systems, Icon Meaning the applicable laws and regulations must be ›...‹ Verbal instructions to use with the observed. voice activation system. For any options and equipment not descri- ››...‹‹ Responses generated by the voice bed in this Owner's Manual, refer to the activation system.
  • Page 9 MINI parts and accessories were tested the vehicle to potentially differing operating by the manufacturer of the MINI for their conditions and registration requirements. safety and suitability in MINI vehicles. Noncompliance with homologation require-...
  • Page 10 Specifications for maintenance measures: in a well-ventilated area and wear gloves – MINI maintenance system or wash your hands frequently when Maintenance, refer to page 281. servicing the vehicle. For more informa- tion go to www.P65Warnings.ca.gov/pas- –...
  • Page 11 Information NOTES Data memory Electronic components, e.g. control units and vehicle keys, contain components for storing technical information. Information General information about the vehicle condition, component us- age, maintenance recommendations, events Electronic control devices are installed in or faults can be stored temporarily or per- the vehicle.
  • Page 12 NOTES Information The data is collected, processed, and used This data is only transmitted to third parties by the relevant organizations in the service upon personal request as part of the use of network. The data documents technical con- online services. The transmission depends ditions of the vehicle, which can be used to on the selected settings for the use of the determine vehicle maintenance status, and...
  • Page 13 Information NOTES Services from the vehicle a vehicle’s systems performed. The EDR is designed to record data related to vehicle manufacturer dynamics and safety systems for a short pe- Where online services from the vehicle riod of time, typically 30 seconds or less. manufacturer are concerned, the corre- The EDR in this vehicle is designed to re- sponding functions are described in the ap-...
  • Page 14 NOTES Information Engine compartment Left nameplate For 3-door models: The engraved vehicle identification number can be found in the engine compartment, on The vehicle identification number can be the right-hand side of the vehicle. found on the nameplate, on the left-hand side of the vehicle.
  • Page 15 National Highway Traffic Safety Administration NHTSA, in addition to noti- fying MINI of North America, LLC, P.O. Box 1227, Westwood, New Jersey 07675-1227, Telephone 1-800-831-1117. If NHTSA receives similar complaints, it...

  • Page 16: Quick Reference

    QUICK REFERENCE Getting in Getting in Opening and closing Buttons for the central locking system Buttons on the vehicle key Overview 1 Unlocking Buttons for the central locking system. 2 Locking 3 Unlocking the tailgate Locking 4 Panic mode Pressing the button locks the vehi- cle if the front doors are closed.
  • Page 17 Getting in QUICK REFERENCE The vehicle automatically detects the vehi- – Unlock the vehicle and then press the cle key when it is in close proximity or in button on the outer side of the tailgate. the interior. – Press and hold the button on the vehicle key for approx.
  • Page 18 QUICK REFERENCE Getting in Central Information Display (CID) Principle The Central Information Display (CID) com- bines the functions of a multitude of switches. These functions can be operated via the Controller. Buttons on the Controller 1 Power windows Button Function 2 Exterior mirrors Press once: calls up the main For 5-door models:...
  • Page 19 Getting in QUICK REFERENCE This icon indicates that the voice acti- vation system is active. If no other commands are available, oper- ate the function via the Central Information Display (CID). Ending the voice control system Press the button on the steering wheel or ›Cancel‹.

  • Page 20: Set-Up And Use

    QUICK REFERENCE Set-up and use Set-up and use Seats, mirrors and steering Adjusting the exterior mirrors wheel Manually adjustable seats 1 Adjusting 2 Selecting a mirror, Automatic Curb Mon- itor 3 Folding in and out 1 Longitudinal direction 2 Thigh support Adjusting the steering wheel 3 Height 4 Backrest tilt...
  • Page 21 Set-up and use QUICK REFERENCE Entering the rear Button Function Pull lever up to the stop. Programmable memory buttons. Changeover of wave range/satel- lite radio. Navigation destination input Entering a destination via address State/province Fold backrest forward. "Navigation" Push the seat forward. "Enter address"...
  • Page 22 Incoming call can be accepted via the Cen- (CID), the steering wheel buttons and spo- tral Information Display (CID) or the button ken instructions. on the steering wheel. "My MINI" Via the Central Information Display (CID) "System settings" "Accept" "Mobile devices"...
  • Page 23 If necessary, the setting for mobile data must be activated on the iPhone. – Wi-Fi and Bluetooth are enabled in the vehicle. Turning on Bluetooth and CarPlay Via the Central Information Display (CID): "My MINI" "System settings" "Mobile devices" "Settings" Select the following settings: – "Bluetooth®"...

  • Page 24: On The Road

    QUICK REFERENCE On the road On the road Driving Manual transmission: switching off With the vehicle at a standstill, press the Start/Stop button. Starting and stopping the engine Shift into first gear or reverse. Ignition on/off Set the parking brake. –...
  • Page 25 On the road QUICK REFERENCE Raise lever slightly, press the button and To prevent the vehicle from creeping after guide the lever down. you select a gear position or reverse, main- tain pressure on the brake pedal until you Set the electrical parking brake are ready to drive off.
  • Page 26 QUICK REFERENCE On the road Turn signal, high beams, headlight Canada: roadside parking light flasher, roadside parking lights Turn signal To illuminate the vehicle on one side. – On: with the radio-ready state switched off, press the lever either up or down past the resistance point for approx.
  • Page 27 On the road QUICK REFERENCE Window wiper system Rain sensor Activate/deactivate Turning the wipers on/off and flick wipe Turning on To activate: press the lever up once from its basic setting, arrow 1. To deactivate: press the lever back into the Press the lever up until the desired position basic setting.
  • Page 28 QUICK REFERENCE On the road Canada: window wiper system Rain sensor Activate/deactivate Turning the wipers on/off and flick wipe Turning on Press the button on the wiper lever. Set interval period or sensitivity of the Tap up the lever or press it past the resist- rain sensor ance point.
  • Page 29 On the road QUICK REFERENCE Climate control Button Function AUTO program. Air conditioning system Air recirculation mode. Button Function Temperature. Adjusts the air flow, manual. Air conditioning. Air distribution, manual. Air recirculation mode. Defrosts and defogs the windows. Adjusts the air flow, Heated windshield.
  • Page 30 Displaying the engine oil level Via the Central Information Display (CID): "My MINI" "Vehicle status" "Engine oil level" For 5-door models: The engine oil level is displayed.
  • Page 31 This service can be reached around the clock in many countries. "MINI Connected" "MINI Assist" "MINI Roadside Assistance" The contact to the MINI Roadside Assis- tance is established. A telephone number is displayed, if needed. Select to dial the telephone number on a connected mobile phone.

  • Page 32: At A Glance

    AT A GLANCE Dashboard Dashboard Vehicle features and options able in the vehicle, e.g., due to the selected options or country versions. This also ap- plies to safety-related functions and sys- This chapter describes all standard, coun- tems. When using these functions and sys- try-specific and optional equipment offered tems, the applicable laws and regulations with the series.
  • Page 33 Dashboard AT A GLANCE Automatic headlight control Roadside parking lights Cornering light On-board computer Automatic High Beam Assis- tant Instrument lighting 7 Instrument cluster 8 Pitman arm, right Wipers 5 Steering wheel buttons, left Wiper on Canadian models Camera-based cruise control on/off Rain sensor Cruise Control on/off...
  • Page 34 AT A GLANCE Dashboard Increase volume 11 Steering wheel heating 12 Adjusting the steering wheel 13 Unlocking the hood Reduce volume 14 Depending on the equipment: using tail- gate Horn, entire surface In the vicinity of the center console Hazard warning system PDC Park Distance Control Rearview camera Intelligent Safety...
  • Page 35 Dashboard AT A GLANCE Dynamic Stability Control Steptronic transmission selector lever 8 Controller with buttons MINI Driving Modes switch 9 Parking brake, manual Parking brake, electric 7 Manual transmission gearshift lever In the vicinity of the headliner Emergency Call, SOS...

  • Page 36: Central Information Display (Cid)

    AT A GLANCE Central Information Display (CID) Central Information Display (CID) Vehicle features and options Input and display Main menu This chapter describes all standard, coun- try-specific and optional equipment offered with the series. It also describes features General information and functions that are not necessarily avail- The main menu is divided into two areas.
  • Page 37 Access to apps and vehicle functions. Ad- ditional apps and vehicle functions can be Function is activated. purchased from the MINI Connected Store. Function is deactivated. Notifications Status information Access to all incoming messages in the ve- hicle, for instance Check Control messages.
  • Page 38 AT A GLANCE Central Information Display (CID) Switching the split screen on/off Icon Meaning Reminder. Press the button. "Split screen" Sending not possible. Selecting the display Entertainment The display can be selected in menus which support the split screen function. Icon Meaning Tilt the Controller to the right until the...
  • Page 39 Central Information Display (CID) AT A GLANCE Control display no operation is performed on the vehicle for several minutes. General information Switching on/off manually To clean the control display, follow the vehi- The control display can also be switched off cle care instructions, refer to page 301.
  • Page 40 AT A GLANCE Central Information Display (CID) – With navigation system: tilt in four di- Button Function rections to switch between displays, for With navigation system: opens example. destination input menu for navi- gation. Call up the CarPlay menu. With navigation system: opens navigation map.
  • Page 41 Adjusting menu contents The display of menus "Media/Radio", Going to the Options menu "Communication" and "MINI Connected" can be adjusted, for instance to remove the en- Press the button. tries of functions that are not used from the menu.
  • Page 42 Via the Central Information Display (CID): General information Depending on the equipment version, the "My MINI" control display is equipped with a touch- "Contents of main menu" screen. Touch the touchscreen with your fingers.
  • Page 43 Central Information Display (CID) AT A GLANCE Entering letters and numbers Storing a function Select the function via the Central Infor- Input mation Display (CID). Tap the icon on the touchscreen. Press and hold the desired but- A keyboard is displayed on the control ton, until a signal sounds.

  • Page 44: Voice Activation System

    AT A GLANCE Voice activation system Voice activation system Vehicle features and options activation system. To set the language, refer to page 47. – Always say commands in the language This chapter describes all standard, coun- of the voice activation system. try-specific and optional equipment offered with the series.
  • Page 45 The following is displayed in the top area of Via the Central Information Display (CID): the control display: – Some possible commands for the current "My MINI" menu. "System settings" – Some possible commands from other "Language"...
  • Page 46 AT A GLANCE Voice activation system situations, the voice and vocal pitch can change. This can unnecessarily delay the establishment of a telephone connection. Instead, use the SOS button, refer to page 290, close to the interior mirror. System limits –...

  • Page 47: General Settings

    Via the Central Information Display (CID): with the series. It also describes features and functions that are not necessarily avail- "My MINI" able in the vehicle, e.g., due to the selected "System settings" options or country versions. This also ap- plies to safety-related functions and sys- "Date and time"...
  • Page 48 Principle year. If vehicle tracking has been activated, the current vehicle position can be displayed in Setting the date format the MINI app. Via the Central Information Display (CID): Activating/deactivating "My MINI" Via the Central Information Display (CID): "System settings"...
  • Page 49 General settings AT A GLANCE Control display Setting the color world Via the Central Information Display (CID): Brightness "My MINI" Via the Central Information Display (CID): "System settings" "My MINI" "Displays" "System settings" "Color scheme" "Displays" Select the desired setting.
  • Page 50 Navigation, for instance stored destina- tions. Principle – Phone book. The vehicle offers various functions which require data to be transferred to MINI or a – Office data, for instance voice memos. service provider. The data transfer can be – Login accounts.
  • Page 51 Note and follow the instructions on the con- trol display. Making calls via the hands- Bluetooth. Via the Central Information Display (CID): free system. Using phone functions via "My MINI" the Central Information Dis- "System settings" play (CID). "Data privacy" Using the smartphone Of- fice functions.
  • Page 52 General information Via the Central Information Display (CID): Information on compatible mobile devices "My MINI" is available as follows: "System settings" – On the MINI homepage. "Mobile devices" – Via Hotline/Customer Support "Settings" – At an authorized service center or an- "Bluetooth®"...
  • Page 53 All prerequisites are met and all required steps were completed in the specified order. Via the Central Information Display (CID): Despite that, the mobile device does not "My MINI" function as expected. In this case, the following explanations can "System settings"...
  • Page 54 AT A GLANCE General settings Why can phone functions not be used via center or another qualified service center or the Central Information Display (CID)? repair shop. – The mobile phone may not be config- USB connection ured correctly, for example, as a Blue- tooth audio device.
  • Page 55 Turning on Bluetooth and CarPlay the USB storage device, refer to the op- Via the Central Information Display (CID): erating instructions of the device. Not compatible USB devices: "My MINI" – USB hard drives. "System settings" – USB hubs.
  • Page 56 Via the Central Information Display (CID): contact the hotline, an authorized service center, or another qualified service center "My MINI" or repair shop. "System settings" "Mobile devices" Managing mobile devices Select the desired device.
  • Page 57 General settings AT A GLANCE Via the Central Information Display (CID): Software update "My MINI" General information "System settings" The vehicle supports a large number of mo- "Mobile devices" bile devices, for instance mobile phones and MP3 players. Software updates are available Select device.
  • Page 58 You can restore the software to the version prior to the last update or to its factory settings. The software may only be restored when the vehicle is stationary. Via the Central Information Display (CID): "My MINI" "System settings" "Software update" "Restore software" 5. – "Previous version"...
  • Page 59 General settings AT A GLANCE Online Edition for Part no. 01405A7DAD4 - II/23...

  • Page 60: Opening And Closing

    CONTROLS Opening and closing Opening and closing Vehicle features and options Safety information This chapter describes all standard, coun- Warning try-specific and optional equipment offered The vehicle key has a button cell battery. with the series. It also describes features Batteries or button cell batteries can be and functions that are not necessarily avail- swallowed and lead to serious or fatal in-...
  • Page 61 – The interior lights, refer to page 149, not leave children or animals unattended and the MINI logo projection are in the vehicle. Take the vehicle key with switched on, provided that the interior you when exiting and lock the vehicle.
  • Page 62 There is a risk of injury or risk of The MINI logo projection is also switched damage to property. Cover the edges and ensure that pointed objects do not hit the windows.
  • Page 63 Opening and closing CONTROLS – Press the button on the vehicle Slide the integrated key in the cover of key and hold for at least 3 sec- the battery compartment and raise the onds. cover. – Briefly press the button on the vehicle key three times in succession.
  • Page 64 The vehicle key is in direct proximity of – The options provided by the Remote the wireless charging tray. Services of the MINI Connected app in- Place the vehicle key in a different loca- clude the ability to lock and unlock a tion.
  • Page 65 Opening and closing CONTROLS Integrated key To do this, slide the integrated key into the opening to the stop from below and remove the cover cap. General information The driver's door can be locked and un- locked without the vehicle key using the integrated key.
  • Page 66 CONTROLS Opening and closing Comfort Access Overview Principle The vehicle can be accessed without operat- ing the vehicle key. Carrying the vehicle key with you, e.g., in your pants pocket, is sufficient. The vehicle automatically detects the vehi- cle key when it is in close proximity or in the interior.
  • Page 67 Opening and closing CONTROLS pressing the button on the door handle Closing again does not unlock the other vehicle ac- cess points. Rather, the vehicle is locked again. If the vehicle was locked automatically af- ter driving off or using the central locking system button from the inside, note the following: If a door on a locked vehicle is opened from the inside using the door...
  • Page 68 CONTROLS Opening and closing Do not carry the vehicle key in close proximity to other electronic devices. Warning Wet or snowy conditions may disrupt the Sharp-edged or pointed objects can hit the locking request detection on the door han- windows and heating elements while driv- dles.
  • Page 69 Opening and closing CONTROLS With manual transmission: Warning With the vehicle stationary, press the button in the driver's footwell twice in Sharp-edged or pointed objects can hit the quick succession. windows and heating elements while driv- ing. There is a risk of injury or risk of damage to property.
  • Page 70 There is an additional guest profile available – Head-up display. that is not assigned to any vehicle key: it – MINI Driving Modes. can be used to apply settings in the vehicle – Intelligent Safety. without changing the personal driver pro- files.
  • Page 71 CONTROLS Via the Central Information Display (CID): Exporting is helpful when storing and re- trieving personal settings, for instance "My MINI" prior to a workshop visit. The stored driver "Driver profiles" profiles can be taken into another vehicle. Via the Central Information Display (CID): "Drive off (guest)"...
  • Page 72 System limits Tailgate Via the Central Information Display (CID): A clear assignment between the vehicle key and driver may not be possible in the fol- "My MINI" lowing cases, for example. "Vehicle settings" – The front passenger unlocks the vehicle "Doors/Key"...
  • Page 73 – Changes in the vehicle inclination, such as during attempts at stealing a wheel or Via the Central Information Display (CID): when towing the vehicle. "My MINI" – Disconnected battery voltage. "Vehicle settings" – Improper use of the socket for OBD on- board diagnostics.
  • Page 74 CONTROLS Opening and closing Opening the doors with the alarm When the still open access points are closed, the interior motion sensor and system switched on tilt alarm sensor will be switched on. The alarm system is triggered when a door –...
  • Page 75 Opening and closing CONTROLS The tilt alarm sensor and the interior mo- Safety information tion sensor can be switched off in such sit- uations. Warning Switching off the tilt alarm sensor and When operating the windows, body parts and objects can be jammed. There is a risk interior motion sensor of injury or risk of damage to property.
  • Page 76 CONTROLS Opening and closing Opening Safety information – Press the switch to the resistance Warning point. Accessories on the windows such as an- The window opens while the switch is tennas can impact jam protection. There is being held. a risk of injury. Do not install accessories in the area of movement of the windows.
  • Page 77 Opening and closing CONTROLS The LED illuminates if the safety function is The window closes. switched on. Continue holding the switch pulled to the resistance point. Malfunction The window opens and closes once or twice after approx. 15 seconds, depend- General information ing on the vehicle's equipment.
  • Page 78 CONTROLS Opening and closing Tilting the glass sunroof Closing glass sunroof Press back the switch up to With the glass sunroof open or beyond the resistance point – Slide switch forward to the and release it. resistance point and hold. The glass sunroof is raised.
  • Page 79 The system must be initialized in this case. MINI recommends having this work per- formed by an authorized service center or Online Edition for Part no. 01405A7DAD4 - II/23...

  • Page 80: Seats, Mirrors And Steering Wheel

    CONTROLS Seats, mirrors and steering wheel Seats, mirrors and steering wheel Vehicle features and options Warning With a backrest inclined too far to the This chapter describes all standard, coun- rear, the protective effect of the seat belt try-specific and optional equipment offered can no longer be ensured.
  • Page 81 Seats, mirrors and steering wheel CONTROLS Longitudinal direction Backrest tilt Warning Unexpected movements of the seat while driving may occur if the seat is unlocked. Vehicle control could be lost. There is a risk of accident. After adjusting, move the seat forward or back slightly, making sure the seat engages properly.
  • Page 82 CONTROLS Seats, mirrors and steering wheel Thigh support gages correctly by slightly moving forward and back. Fold the seat backrest forward Pull lever up to the stop. Pull the lever at the front of the seat and adjust the thigh support. In 3-door models: entering the rear Fold the seat backrest forward.
  • Page 83 Seats, mirrors and steering wheel CONTROLS Front seat heating though airbags enhance safety by providing added protection, they do not replace seat belts. Overview If needed, detach the seat belt in the rear from the belt retainer on the side. All belt fastening points are designed to achieve the best possible protective effect of the seat belts with proper use of the seat...
  • Page 84 CONTROLS Seats, mirrors and steering wheel Buckling the seat belt Warning Guide the seat belt slowly over shoulder With a rear seat backrest that is not and hip to put it on. locked, the protective effect of the middle Insert the buckle tongue into the seat seat belt is not guaranteed.
  • Page 85 Seats, mirrors and steering wheel CONTROLS if objects are placed on the front passenger seat. Warning Body parts can be jammed when moving the head restraint. There is a risk of injury. Seat belt reminder for rear seats Make sure that the area of movement is clear when moving the head restraint.
  • Page 86 CONTROLS Seats, mirrors and steering wheel After setting the height, make sure that the – Before driving, install the removed head restraint engages correctly. head restraints on the occupied seats. – Adjust the head restraint so its center supports the back of the head at as Removing: John Cooper Works close to eye level as possible.
  • Page 87 Seats, mirrors and steering wheel CONTROLS Adjusting the height Fold down the rear seat backrest, refer to page 229, in question. – To lower: press the button, arrow 1, and Pull head restraint up against the resist- push the head restraint down. ance.
  • Page 88 CONTROLS Seats, mirrors and steering wheel Overview Automatic Curb Monitor Principle If reverse gear is engaged, the mirror glass on the passenger's side is tilted downward. This improves your view of the curb and other low-lying obstacles when parking, for instance. Activating 1 Adjusting slide the switch to the driver's...
  • Page 89 Seats, mirrors and steering wheel CONTROLS Steering wheel Turn button Safety information Warning Steering wheel adjustments while driving can lead to unexpected steering wheel movements. Vehicle control could be lost. There is a risk of accident. Adjust the steering wheel while the vehicle is station- Turn the button to reduce the blinding glare ary only.
  • Page 90 CONTROLS Seats, mirrors and steering wheel Steering wheel heating Turning on/off Press the button. – On: the LED illuminates. – Off: the LED goes out. If the trip is resumed within approx. 15 mi- nutes after an intermediate stop, the steer- ing wheel heating turns on automatically if the function was turned on at the comple- tion of the last trip.

  • Page 91: Transporting Children Safely

    Transporting children safely CONTROLS Transporting children safely Vehicle features and options Warning A hot vehicle may result in death to per- This chapter describes all standard, coun- sons, especially children, or animals. There try-specific and optional equipment offered is a risk of injury or danger to life. Do with the series.
  • Page 92 CONTROLS Transporting children safely Safety information Warning The stability of the child restraint system Warning is limited or compromised with incorrect The seat belt cannot be fastened correctly seat setting or improper installation of the on children shorter than 5 ft/150 cm child seat.
  • Page 93 Transporting children safely CONTROLS Do not use child restraint systems which PASSENGER AIRBAG OFF indicator light have been damaged or exposed to an acci- illuminates. dent. Before installing a child restraint system in If attachment systems have been damaged the front passenger seat, make sure that the or strained by an accident, have them front, knee and side airbags on the passeng- checked and replaced by an authorized...
  • Page 94 CONTROLS Transporting children safely Locking the seat belt Safety information Pull out the belt strap completely. Warning Secure the child restraint system with the seat belt. If the lower mountings of the child re- straint system are not correctly engaged, Allow the belt strap to be pulled in and the protective effect of the child restraint pull it tight against the child restraint...
  • Page 95 Transporting children safely CONTROLS Position Child restraint systems with tether strap Icon Meaning Safety information The corresponding icon shows the mounts for the lower LATCH anchors. Warning Seats equipped with lower If the upper retaining strap is incorrectly mountings are marked with used for the child restraint system, the a pair (2) of LATCH icons.
  • Page 96 CONTROLS Transporting children safely ON 5-door models: Locking tether are marked with this icon. It can be found on the rear seat backrest or the rear the doors and windows shelf. Doors Routing the retaining strap Push the locking lever on the rear doors up. 1 Driving direction The door can now be opened from the out- 2 Head restraint...

  • Page 97: Driving

    Driving CONTROLS Driving Vehicle features and options Most of the indicator/warning lights in the instrument cluster illuminate for a varied length of time. This chapter describes all standard, coun- To save battery power when the engine is try-specific and optional equipment offered off, switch off the ignition and any unneces- with the series.
  • Page 98 CONTROLS Driving – When the front doors are opened if – When the vehicle is locked using the there is no other person sitting in the central locking system. front seats. – Shortly before the battery is discharged – The low beams switch to parking lights completely, so that the engine can still after some minutes of no use.
  • Page 99 Driving CONTROLS Engine stop NOTICE Repeated attempts to start the engine or Safety information repeated starting of the vehicle in rapid succession can cause the starter to over- heat. This also results in unburned or inad- Warning equately burned fuel, and can cause the Unattended children or animals in the ve- catalytic converter to overheat.
  • Page 100 CONTROLS Driving Manual transmission Engine stop Switching off the engine Functional requirements The engine is switched off automatically With the vehicle at a standstill, press during a stop under the following condi- the Start/Stop button. tions: The engine is switched off. Manual transmission: The radio-ready state is switched on.
  • Page 101 Driving CONTROLS Displays in the instrument cluster – Window condensation when the auto- matic climate control is switched on. Instrument cluster without enhanced – The vehicle battery charge is very low. features: display – At higher elevations. The display indicates that the –...
  • Page 102 CONTROLS Driving – Steptronic transmission: change from Switching the system on/off selector lever position D to R, N or M/S. Using the button – Steptronic transmission: change from selector lever position P to R, N, D or M/S. – The vehicle begins rolling. –...
  • Page 103 Driving CONTROLS Engine start as usual via Start/Stop button. The indicator light illuminates red. The parking brake is set. Automatic deactivation Lower light: indicator light in Cana- dian models In certain situations, the Auto Start/Stop function is deactivated automatically for safety reasons, for instance if no driver is If for once use during driving is required, detected.
  • Page 104 CONTROLS Driving In order to ensure that the vehicle is se- Setting the parking brake cured against rolling away, follow the fol- lowing: With a stationary vehicle – Set the parking brake. Pull the switch. – On uphill grades or on downhill The LED illuminates.
  • Page 105 Driving CONTROLS The LED and the indicator light go out. After a power interruption The parking brake is released. Commissioning Automatic release in cars with Turn on the ignition. Steptronic transmission Press the switch while stepping For automatic release, step on the accelera- on the brake pedal or with selector lever tor pedal.
  • Page 106 Window wiper system The triple turn signal duration can be ad- justed. Via the Central Information Display (CID): Safety information "My MINI" "Vehicle settings" Warning "Lighting" If the wipers start moving in the folded away state, body parts can be jammed or "Exterior lighting"...
  • Page 107 Driving CONTROLS Press the lever up until the desired position out the rain sensor, the interval of the wiper is reached. operation is predefined. – Resting position of the wipers, posi- Safety information tion 0. – Intermittent operation or rain sensor, position 1.
  • Page 108 CONTROLS Driving Setting the interval period or Cleaning the windshield sensitivity of the rain sensor Pull the lever. Turn the thumbwheel. The washer fluid is sprayed on the wind- shield, and the wipers are turned on briefly. With deactivated rain sensor: set the inter- val period.
  • Page 109 Driving CONTROLS – In resting position: turn the switch Folding out the wipers downward, arrow 3. The switch auto- Switch the ignition on and off again. matically returns to its idle position Press and hold the wiper lever down un- when released.
  • Page 110 CONTROLS Driving Canada: window wiper system Tap up the lever or press it past the resist- ance point. – Normal wiper speed: tap up once. Safety information – Fast wiper speed: tap up twice or tap once beyond the resistance point. Warning The lever automatically returns to its basic If the wipers start moving in the folded...
  • Page 111 Driving CONTROLS Safety information Setting the interval period or sensitivity of the rain sensor NOTICE If the rain sensor is activated, the wip- ers can accidentally start moving in car washes. There is a risk of damage to prop- erty. Deactivate the rain sensor in car washes.
  • Page 112 CONTROLS Driving Cleaning the windshield – In resting position: turn the switch downward, arrow 3. The switch auto- matically returns to its idle position when released. – In intermittent operation: turn the switch further, arrow 2. The switch au- tomatically returns to its interval posi- tion when released.
  • Page 113 Driving CONTROLS Washer fluid Folding out the wipers Switch the ignition on and off again. General information Press the wiper lever up past the point of resistance and hold it for approx. All windshield washer jets are supplied 3 seconds, until the wipers remain in from one tank.
  • Page 114 CONTROLS Driving Manual transmission NOTICE Silicon-containing additives in the washer Safety information fluid for the water-repelling effect on the windows can lead to damage to the car wash. There is a risk of damage to prop- Warning erty. Do not add silicon-containing addi- An unsecured vehicle can begin to move tives to the washer fluid.
  • Page 115 Driving CONTROLS Shifting In order to ensure that the vehicle is se- cured against rolling away, follow the fol- lowing: General information – Set the parking brake. Depending on the motorization, the RPM during a shifting operation is adjusted auto- –...
  • Page 116 CONTROLS Driving R reverse Engaging selector lever positions Engage selector lever position R only when General information the vehicle is stationary. To prevent the vehicle from creeping after N neutral you select a gear position or reverse, main- tain pressure on the brake pedal until you The vehicle may be pushed or roll without are ready to drive off.
  • Page 117 Driving CONTROLS cally returns to the center position when Start the engine while pressing on the released. brake pedal. If necessary, release the parking brake. Depress the brake pedal. Touch the selector lever lock and en- gage selector lever position N. Switch the engine off.
  • Page 118 CONTROLS Driving Activating the Sport program Manual mode M/S becomes active and the gear is changed. The engaged gear is displayed in the instru- ment cluster, for instance M1. Shifting – To downshift: press the selector lever forward. – Upshifting: pull the selector lever rear- wards.
  • Page 119 Driving CONTROLS Ending the manual mode Shifting Press the selector lever to the right. D is displayed in the instrument cluster. Shift paddles for Steptronic Sport transmission Principle The shift paddles on the steering wheel al- low you to shift gears quickly while keeping –...
  • Page 120 N, until selector lever position N is While the engine is running: displayed in the instrument cluster. A Check Control message is displayed. Press button and select SPORT with the MINI Driving Modes switch. Release the selector lever. Online Edition for Part no. 01405A7DAD4 - II/23...
  • Page 121 Driving CONTROLS The instrument cluster displays TRAC- TION in combination with SPORT. The DSC OFF indicator light illuminates. Engage selector lever position S. With the left foot, forcefully press down on the brake. Press and hold down the accelerator pedal beyond the resistance point, kick- down.

  • Page 122: Displays

    CONTROLS Displays Displays Vehicle features and options able in the vehicle, e.g., due to the selected options or country versions. This also ap- plies to safety-related functions and sys- This chapter describes all standard, coun- tems. When using these functions and sys- try-specific and optional equipment offered tems, the applicable laws and regulations with the series.
  • Page 123 Displays CONTROLS Instrument cluster with enhanced features: overview 1 Tachometer 4 Vehicle speed 2 Display/reset kilometers 5 Indicator/warning lights 3 Electronic displays 6 Fuel gauge Online Edition for Part no. 01405A7DAD4 - II/23...
  • Page 124 1 Driver assistance systems Total kilometers/trip odometer Messages, for instance Check Control On-board computer Time 2 Selector lever position Outside temperature Gear shift indicator Selection lists 3 MINI Driving Modes switch status Online Edition for Part no. 01405A7DAD4 - II/23...
  • Page 125 1 Selector lever position Range Gear shift indicator 5 Messages, for instance Check Control 2 Time Selection lists MINI Driving Modes switch status Navigation instructions 3 Driver assistance systems 6 Total kilometers/trip odometer 4 Outside temperature On-board computer Check Control...
  • Page 126 CONTROLS Displays Red lights Brake system Brake pads are worn or there is a Seat belt reminder fault in the brake system. Indicator light flashes or is illumi- The braking assistance may not be nated: seat belt on the driver or pas- operational.
  • Page 127 Displays CONTROLS Warning light flashes: Conditions are not Dynamic Stability Control, refer to adequate for the system to work. page 176, and Dynamic Traction Control, refer to page 178. The system was deactivated but applies the brakes until the driver actively resumes control of the vehicle by pressing on the Flat tire monitor brake pedal or accelerator pedal.
  • Page 128 CONTROLS Displays Have the vehicle checked by an authorized Instrument cluster with enhanced service center or another qualified service features: bad weather light center or repair shop. Bad weather light is switched on. Bad weather light, refer to page 148. Emissions –...
  • Page 129 Lane Departure Warning messages The indicator light illuminates: the Via the Central Information Display (CID): system is activated. At least one lane "My MINI" marking was detected and warnings can be issued. "Vehicle status" Lane departure warning, refer to page 170.
  • Page 130 CONTROLS Displays Tachometer Messages after trip completion Certain messages displayed while driving are displayed again after the ignition is Always avoid engine speeds in the red switched off. warning field. In this range, the fuel supply is reduced to protect the engine. Fuel gauge Odometer and trip odometer Principle...
  • Page 131 Displays CONTROLS Outside temperature Date General information The date is displayed in the instrument cluster. If the indicator drops to +37 ℉/+3 ℃, a Set the date on the Central In- signal sounds. formation Display (CID), refer A Check Control message is displayed. to page 47.
  • Page 132 More information on the type of service required may be displayed on the control display. Current consumption Via the Central Information Display (CID): "My MINI" Principle "Vehicle status" Displays the current fuel consumption. Tilt the Controller to the left. Check whether you are currently driving in an efficient and environmentally-friendly "Service required"...
  • Page 133 You can check when your authorized serv- Steptronic transmission: displaying ice center was notified. Via the Central Information Display (CID): Example Description "My MINI" Efficient gear is set. "Vehicle status" Tilt the Controller to the left. Depending on the equipment "Teleservice Call"...
  • Page 134 CONTROLS Displays from the rain sensor, and will be displayed instrument cluster or via the on-board com- depending on the situation. puter. With the navigation system, the system takes into account the information stored in the navigation data and also displays speed limits present on routes without signs.
  • Page 135 Displays CONTROLS – When driving toward bright lights or Activating a list and adjusting the strong reflections. setting – When the windshield in front of the in- terior mirror is fogged up, dirty or cov- Button on the Function steering wheel ered by a sticker, etc.
  • Page 136 Repeatedly pressing the but- Via the Central Information Display (CID): ton on the turn signal lever calls up the following informa- "My MINI" tion: "System settings" "Displays" – Range. "Instrument panel"...
  • Page 137 Displays CONTROLS GREEN info General information If the engine oil or coolant, and thus the The achieved range extension may be dis- engine, become too hot, a Check Control played as a bonus range. message is displayed too. Average fuel consumption When the engine temperature is The average consumption is calculated for too high, a red indicator light is dis-...
  • Page 138 Displays The distance to the destination is adopted Resetting the on-board computer automatically. Via the Central Information Display (CID): "My MINI" Arrival time "Driving information" Depending on the vehicle equipment, the estimated arrival time is displayed if a desti- "Onboard info"...
  • Page 139 "Speed warning" "Technology in action" "Sport displays" Applying current speed as the "Vehicle and surroundings" speed warning Via the MINI Driving Modes switch: Via the Central Information Display (CID): Activate SPORT. "My MINI" "Sport displays" "Vehicle settings" "Vehicle and surroundings"...
  • Page 140 CONTROLS Displays LED ring on the central in- Switching on/off LED ring strument cluster Via the Central Information Display (CID): "My MINI" Principle "System settings" The LED ring displays light animations to "Displays" represent specific functions. "Center Instrument" Basic displays "Center Instrument"...
  • Page 141 Displays CONTROLS MINI Head-up display Overview Principle The Head-up display projects important in- formation in the driver's field of view, for instance the speed. General information Follow the instructions for cleaning the Head-up display. For additional information, The Head-up display is switched on.
  • Page 142 Selecting displays in the Head-up "Displays" display "Head-Up Display" Via the Central Information Display (CID): "Height" "My MINI" Turn the Controller until the desired height is reached. "System settings" Press the Controller. "Displays" The setting is stored for the driver profile "Head-Up Display"...
  • Page 143 Turning on Functional requirements Via the Central Information Display (CID): – Steptronic Sport transmission: Manual mode M/S and, if necessary Dy- "My MINI" namic Traction Control are activated. "System settings" – Press the accelerator pedal all the way "Displays" down.
  • Page 144 CONTROLS Displays Information at a glance Icons Description "Flat Tire Monitor": Status of the flat tire monitor, refer to page 160. "Tire Pressure Monitor": sta- tus of the Tire Pressure Monitor, refer to page 155. "Engine oil level": electronic oil-level check, refer to page 275.

  • Page 145: Lights

    Lights CONTROLS Lights Vehicle features and options Icon Function Parking lights. This chapter describes all standard, coun- try-specific and optional equipment offered with the series. It also describes features Low beams. and functions that are not necessarily avail- able in the vehicle, e.g., due to the selected options or country versions.
  • Page 146 2 seconds. Setting the duration Via the Central Information Display (CID): Turning off "My MINI" Briefly press the lever to the resistance "Vehicle settings" point in the opposite direction. "Lighting"...
  • Page 147 The Automatic High Beam Assistant detects Via the Central Information Display (CID): other road users early on and automatically "My MINI" switches the high beams on or off depend- ing on the traffic situation. "Vehicle settings"...
  • Page 148 CONTROLS Lights low speed range, the high beams are not when to use the high beams. In situations switched on by the system. that require this, therefore dim manually. The system responds to light from oncom- The system is not fully functional in the ing traffic and traffic driving ahead of you, following situations, and driver intervention and to ambient lighting, for instance in...
  • Page 149 Ambient light General information Depending on the equipment version, light- ing can be adjusted for some lights in the car's interior. Activating/deactivating Via the Central Information Display (CID): "My MINI" "Vehicle settings" "Lighting" Online Edition for Part no. 01405A7DAD4 - II/23...
  • Page 150 Depending on the equipment, the bright- ness of the ambient light can be adjusted via the thumbwheel for the instrument lighting or on the control display. Via the Central Information Display (CID): "My MINI" "Vehicle settings" "Lighting" "Interior lighting" "Brightness"...

  • Page 151: Safety

    Safety CONTROLS Safety Vehicle features and options able in the vehicle, e.g., due to the selected options or country versions. This also ap- plies to safety-related functions and sys- This chapter describes all standard, coun- tems. When using these functions and sys- try-specific and optional equipment offered tems, the applicable laws and regulations with the series.
  • Page 152 CONTROLS Safety Head airbag ing wheel. Select the settings so that the shoulder rests against the backrest In the event of a side collision, the head when crossing the hands and the upper airbag protects the head. body is as far back as possible while still maintaining a comfortable grip on the Ejection Mitigation steering wheel.
  • Page 153 – The warning light illuminates continu- abilities may affect the air bag system; con- ously. tact MINI Customer Relations for further Have the vehicle checked by an authorized information. service center or another qualified service Warnings and information on the airbags center or repair shop.
  • Page 154 CONTROLS Safety deactivated in certain seat positions. In this – The indicator light illumi- case, the indicator light for the front pas- nates when a child is prop- senger airbags illuminates. erly seated in a child re- straint system or when the In this case, change the seat position so seat is empty.
  • Page 155 If the message continues to be displayed, tem is active. repeat the calibration. Via the Central Information Display (CID): If the message does not disappear after a "My MINI" repeat calibration, have the vehicle checked as soon as possible. "Vehicle status" "Tire Pressure Monitor"...
  • Page 156 Resetting the system Via the Central Information Display (CID): If a tire inflation pressure check is "My MINI" required "Vehicle status" Message "Tire Pressure Monitor" An icon with a Check Control message ap- Start the engine but do not drive off.
  • Page 157 Safety CONTROLS Measure Icon Possible cause Check the tire pressure and correct as There is a flat tire or a major tire needed. pressure loss. Reset the system. No reset was performed for the system. The system issues a warn- If the tire inflation pressure is too low ing based on the tire inflation pressures stored during the last...
  • Page 158 CONTROLS Safety tronics. In this case, have the electronics traveled may be less but may also be more if checked and replaced at the next opportu- an economical driving style is used. nity. If the vehicle is loaded with an average weight and used under favorable conditions, Runflat tires the possible distance traveled may be up to...
  • Page 159 Safety CONTROLS Sudden tire pressure loss bel. (If the vehicle has tires of a different size than the size indicated on the vehicle The system cannot indicate sudden serious placard or tire inflation pressure label, you tire damage caused by external circumstan- should determine the proper tire inflation ces.
  • Page 160 Via the Central Information Display (CID): The system does not measure the actual in- flation pressure in the tires. "My MINI" "Vehicle status" Functional requirements "Flat Tire Monitor" The following prerequisites must be met for Start the engine but do not drive off.
  • Page 161 Safety CONTROLS is a risk of accident. Do not continue driv- If tire damage cannot be identified, con- ing if the vehicle is equipped with normal tact an authorized service center or an- tires. Follow the information on runflat other qualified service center or repair tires and continued driving with these shop.
  • Page 162 CONTROLS Safety Possible distance traveled with a fore, check the tire inflation pressure depressurized tire regularly. The possible distance which may be safely – Sudden serious tire damage caused by traveled varies depending on how the vehi- external circumstances cannot be recog- cle is loaded and used, e.g., speed, road con- nized in advance.
  • Page 163 Safety CONTROLS over steering and braking at any time, and Turning on/off actively intervene where appropriate. Some Intelligent Safety systems are auto- matically active after every departure. Some Intelligent Safety systems activate accord- Warning ing to the last setting. Indicators and warnings cannot serve as Press button briefly: a substitute for the driver’s personal judg- –...
  • Page 164 CONTROLS Safety A camera at the base of the interior mirror ently react to all traffic situations. There is controls the system. a risk of accident. Adjust driving style to traffic conditions. Watch the surrounding The Forward Collision Warning is available traffic situation closely, be ready to take even if cruise control has been deactivated.
  • Page 165 – The LED goes out. Setting the warning time The warning time can be set via the Central Information Display (CID). "My MINI" "Vehicle settings" The camera is installed near the interior "Intelligent Safety" mirror. "Warning time" Keep the windshield in front of the interior Select the desired setting.
  • Page 166 CONTROLS Safety Acute warning with light braking System limits function Safety information An acute warning is displayed when there is an imminent risk of collision due to the vehicle approaching another object at Warning a high speed. Due to its limits, the system may not react, The driver must intervene actively when or it may react too late or in a manner there is an acute warning.
  • Page 167 Safety CONTROLS – During calibration of the camera imme- Detection range diately after vehicle delivery. – If there are constant blinding glares be- cause of oncoming light, for instance from the sun low in the sky. Warning sensitivity The more sensitive the warning settings are, the more warnings are displayed.
  • Page 168 CONTROLS Safety be issued late or in a manner that is not Camera consistent with their normal use. There is a risk of accident. Adjust driving style to traffic conditions. Watch surrounding traf- fic closely and actively intervene where appropriate. Warning When towing with Intelligent Safety sys- tems enabled or Cruise Control switched...
  • Page 169 Safety CONTROLS – All Intelligent Safety systems are System limits switched off. Safety information – The LED goes out. Warning with light braking Warning function Due to its limits, the system may not react, or it may react too late or in a manner Display that is not consistent with normal use.
  • Page 170 CONTROLS Safety – Up to 10 seconds after the start of the engine via the Start/Stop button. Warning – During calibration of the camera imme- Indicators and warnings cannot serve as diately after vehicle delivery. a substitute for the driver’s personal judg- ment.
  • Page 171 Safety CONTROLS Turning on/off Instrument cluster with enhanced features: display Turning on automatically Indicator light illuminates green: At The lane departure warning is automatically least one lane boundary line has activated after departure, if the function been detected and warnings may be was switched on the last time the engine issued.
  • Page 172 CONTROLS Safety Functional limitations When the vehicle speed exceeds the set speed limit, a warning is issued. The system may be limited in the following situations: No brake intervention – In heavy fog, wet conditions, or snow- If the set speed limit is reached or unin- fall.
  • Page 173 Safety CONTROLS Turning off Warning when the speed limit is exceeded Press the button on the steering wheel. Visual warning The system switches off automatically in If the set speed limit is exceeded, the LIMIT the following situations, for example: or LIM indicator flashes while the vehicle –...
  • Page 174 CONTROLS Safety Fatigue alert Break recommendation If the driver becomes less alert or fatigued, a message is displayed in the control display Principle with the recommendation to take a break. The system can detect decreasing alertness A break recommendation is displayed only or fatigue of the driver during long, monoto- once during an uninterrupted trip.
  • Page 175 Safety CONTROLS At standstill After coming to a halt, the brake is released automatically. Secure the vehicle against rolling away. Harder vehicle deceleration In certain situations, it can be necessary to bring the vehicle to a halt more quickly than the automatic braking allows.

  • Page 176: Driving Stability Control Systems

    CONTROLS Driving stability control systems Driving stability control systems Vehicle features and options Have checked immediately by an authorized service center or another qualified service center or repair shop. This chapter describes all standard, coun- try-specific and optional equipment offered with the series.
  • Page 177 Driving stability control systems CONTROLS Safety information Deactivate Dynamic Stability Control: DSC OFF Warning General information The system cannot serve as a substitute When Dynamic Stability Control is deacti- for the driver’s personal judgment in as- vated, driving stability is limited when ac- sessing the traffic situation.
  • Page 178 When the Dynamic Traction Control is acti- vated, there is maximum traction. Driving Principle stability is limited during acceleration and The MINI Driving Modes switch helps to when cornering. fine-tune the vehicle's settings and features. Drive carefully. Choose between three different programs.
  • Page 179 Activating SPORT Hold the vehicle in place with the foot Press the MINI Driving Modes switch up- brake. ward until SPORT is displayed in the instru- Release the foot brake and drive off ment cluster.
  • Page 180 CONTROLS Driving stability control systems Servotronic Servotronic is a speed-dependent power steering function. The system provides the steering force with more support at low speeds than at higher ones. This makes it easier to park, for in- stance, and makes steering firmer when driving at faster speeds.

  • Page 181: Driving Comfort

    Driving comfort CONTROLS Driving comfort Vehicle features and options General information A camera on the interior mirror is used to detect vehicles driving ahead. This chapter describes all standard, coun- try-specific and optional equipment offered Depending on the vehicle settings, the with the series.
  • Page 182 CONTROLS Driving comfort – When approaching a slowly moving Overview vehicle at speed. Buttons on the steering wheel – Vehicle suddenly swerving into own lane. Button Function – When approaching stationary vehi- cles at speed. Cruise control on/off, refer to There is a risk of injury or danger to life.
  • Page 183 Driving comfort CONTROLS Functional requirements Cruise control is active and maintains the set speed. The system is best used on well-maintained If necessary, the Dynamic Stability Control roads. will be turned on. The system is functional at speeds begin- ning at approx. 20 mph/30 km/h. Turning off With the Stop&Go function for Steptronic With the Stop&Go function for Steptronic...
  • Page 184 CONTROLS Driving comfort – Manual transmission: if the vehicle in desired speed changes by a maximum of front decelerates below a speed of ap- 5 mph/10 km/h. prox. 20 mph/30 km/h. button: hold down to repeat the – With the Stop&Go function for Step- action.
  • Page 185 Driving comfort CONTROLS Continuing cruise control Press and hold this button. General information An interrupted cruise control can be contin- The indicator light in the instrument ued by calling up the stored speed. cluster illuminates. Make sure that the difference between cur- rent speed and stored speed is not too large To switch distance control back on, press before calling up the stored speed.
  • Page 186 CONTROLS Driving comfort Distance to vehicle ahead of you – By briefly pressing the accelerator pedal. Distance display – By pressing the RES CNCL button. – By pressing the button. Distance 1 Indicator lights and warning lights Distance 2 Instrument cluster without enhanced features: Distance 3 Warning light flashes orange.
  • Page 187 Driving comfort CONTROLS System limits Merging vehicles Detection range A vehicle driving in front of you is not de- tected until it is completely within the same lane as your vehicle. The detection capability of the system and the automatic braking performance are lim- If a vehicle driving ahead of you suddenly ited.
  • Page 188 CONTROLS Driving comfort Cornering Examples of unfavorable weather or light conditions: – Wet conditions. – Snowfall. – Slush. – Fog. – Glare. Drive attentively, and react to the current surrounding traffic situation. If necessary, intervene actively, for instance by braking, When the set speed is too high for a steering or evading.
  • Page 189 Driving comfort CONTROLS Cruise Control There may be a risk of accidents or risk of damage to property. Only use the system if driving at constant speed is possible. Principle Using this system, a set speed can be ad- justed using the buttons on the steering Warning wheel.
  • Page 190 CONTROLS Driving comfort Instrument cluster without enhanced – When Dynamic Traction Control is ac- features: tivated or Dynamic Stability Control is deactivated. The current speed is adopted as the desired speed and is displayed with the icon – If Dynamic Stability Control regulates in the instrument cluster.
  • Page 191 Driving comfort CONTROLS Continuing cruise control – Display illuminates green: system is ac- tive, the display indicates the desired speed. General information – Display illuminates orange: system is An interrupted cruise control can be contin- interrupted, the display indicates the ued by calling up the stored speed.
  • Page 192 CONTROLS Driving comfort approaching slowly are indicated by signal Overview tones and a visual display. With front Park Distance Control: General information button in the vehicle The ultrasound sensors for measuring the distances are located in the bumpers. The range, depending on obstacles and environmental conditions, is approx.
  • Page 193 Via the Central Information When the distance to a detected object is Display (CID): less than approx. 10 inches/25 cm, a con- tinuous tone is sounded. "My MINI" With front Park Distance Control: when "Vehicle settings" objects are simultaneously located both in "Parking"...
  • Page 194 CONTROLS Driving comfort "Rear view camera" – With objects with a fine surface struc- ture such as fences. System limits – For objects with porous surfaces. – Low objects already displayed, for in- Safety information stance curbs, can move into the blind area of the sensors before or after a con- tinuous tone sounds.
  • Page 195 Driving comfort CONTROLS Red icon is displayed, and the detec- Overview tion range of the sensors is dimmed on the control display. Depending on the vehicle equipment: button in the vehicle Park Distance Control malfunction. Have the vehicle checked by an authorized serv- ice center or another qualified service cen- ter or repair shop.
  • Page 196 CONTROLS Driving comfort Switch the system back on, if needed. Obstacles are marked, depending on the vehicle equipment. Depending on the vehicle equipment: Pathway lines switching on/off manually Press the park assistance button. – On: the LED illuminates. – Off: the LED goes out. The parking assistance functions are shown on the control display.
  • Page 197 Driving comfort CONTROLS Obstacle marking Parking using lanes and turning circle lines Position the vehicle so that the turning circle lines lead to within the limits of the parking space. Depending on the vehicle equipment, obsta- cle markings can be faded into the image of the rearview camera.
  • Page 198 CONTROLS Driving comfort System limits The Automatic Parking Assistant calculates the best possible parking line and takes control of steering during the parking oper- Detection of objects ation. Very low obstacles or high, protruding ob- System status and instructions on required jects such as ledges may not be recognized actions are displayed on the control display.
  • Page 199 – Gaps behind an object that has a min. length of 5 ft/1.5 m. – Gap between two objects with a mini- mum length of approx. 5 ft/1.5 m. Park assistance button – Minimum length of gap between two ob- jects: own vehicle length plus approx.
  • Page 200 CONTROLS Driving comfort Display on the control display Parking using the Automatic Parking Assistant System activated/deactivated Parking Icon Meaning Press the park assistance button Gray: the system is not available. or shift into reverse gear to switch on White: the system is available but the Automatic Parking Assistant, refer not activated.
  • Page 201 Driving comfort CONTROLS Canceling automatically System limits The system is interrupted automatically in Safety information the following situations: – If the driver grasps the steering wheel or takes over steering. Warning – If a gear is selected that does not match Due to its limits, the system may not react, the instruction on the control display.
  • Page 202 CONTROLS Driving comfort – With external fault of the ultrasound, for instance from passing vehicles or loud machines. – When sensors are dirty, iced over, dam- aged or out of position. – If cargo protrudes. – Under certain weather conditions such as high moisture, wet conditions, snow- fall, extreme heat, or strong wind.

  • Page 203: Climate Control

    Climate control CONTROLS Climate control Vehicle features and options – Emission tested passenger compart- ment. – Microfilter. This chapter describes all standard, coun- – Air conditioning system to control the try-specific and optional equipment offered temperature, air flow and recirculated- with the series.
  • Page 204 CONTROLS Climate control Air conditioning system 1 Air distribution settings 6 Air recirculation mode 2 Air flow 7 Rear window defroster 3 Temperature 8 Heated windshield 4 Seat heating, right 9 Seat heating, left 5 Air conditioning Climate control functions in detail Temperature Principle Switching the system on/off...
  • Page 205 Climate control CONTROLS Air conditioning ter a certain amount of time, depending on the outside temperature. Principle With extended air recirculation mode, the air quality in the interior deteriorates and The air in the interior will be cooled and window fogging increases. dehumidified and, depending on the temper- ature setting, warmed again.
  • Page 206 CONTROLS Climate control To defrost windows and remove Rear window defroster condensation Press the button. The LED illumi- Make the following settings to defrost the nates. windows and remove condensation: The rear window defroster switches off au- – Direct the air distribution onto the win- tomatically after a certain period of time.
  • Page 207 Climate control CONTROLS 9 Maximum cooling 13 Heated windshield 10 Air conditioning 14 To defrost windows and remove conden- sation 11 Air recirculation mode 15 Seat heating, left 12 Rear window defroster Climate control functions in detail Air conditioning Principle Switching the system on/off The air in the interior will be cooled and Turning on...
  • Page 208 CONTROLS Climate control Turning on/off Turn the wheel to set the de- sired intensity from soft to in- Press the button. tensive. The LED is illuminated with the system switched on. The set intensity is displayed via the posi- Air flows out of the air vents to the upper tion of the illuminated LED segment.
  • Page 209 Climate control CONTROLS General information Turning on/off To adjust the air flow manually switch off Press the button. AUTO program first. The LED is illuminated with the system switched on. Adjusting The air flow can be adjusted with the pro- Turn the ring to set the de- gram active.
  • Page 210 Turn knob for continuous opening and Switching on/off directly closing of the air vents. Via the Central Information Display (CID): – Swivel the air vents to alter the airflow "My MINI" direction, arrows. "Vehicle settings" If necessary, "Climate functions" Pre-ventilation "Activate comfort ventilation now"...
  • Page 211 Climate control CONTROLS Activating the activation time Via the Central Information Display (CID): "My MINI" "Vehicle settings" If necessary, "Climate functions" "For start time at:" Activate the desired activation time. The icon on the automatic climate con- trol illuminates when the activation time is activated.

  • Page 212: Interior Equipment

    CONTROLS Interior equipment Interior equipment Vehicle features and options Safety information This chapter describes all standard, coun- Warning try-specific and optional equipment offered The operation of remote-controlled sys- with the series. It also describes features tems with the integrated universal remote and functions that are not necessarily avail- control, such as the garage door, may re- able in the vehicle, e.g., due to the selected...
  • Page 213 Interior equipment CONTROLS Overview down the interior mirror button and re- peatedly press and release the hand-held transmitter button for 2 seconds. 6. – The LED illuminates green: program- ming completed. Release the button. – The LED flashes fast: programming is not complete.
  • Page 214 CONTROLS Interior equipment Synchronizing the universal remote control Release the button. with the system: – The LED flashes fast: the hand-held transmitter was detected but pro- Park the vehicle within range of the re- gramming is not complete. mote-controlled system. Press the button on the interior Program the relevant button on the inte- mirror for 2 seconds and release.
  • Page 215 Interior equipment CONTROLS Deleting stored functions Mirror display All stored functions will be deleted. The The compass shows the current driving di- functions cannot be deleted individually. rection. Press and hold the two outer buttons on the Operating concept interior mirror simultaneously for approxi- mately 10 seconds until the LED on the Various functions can be called up by press- interior mirror flashes green fast.
  • Page 216 CONTROLS Interior equipment World map with magnetic zones Procedure – The wrong compass point is displayed. – The point of the compass displayed does Press and hold the adjustment knob for not change despite changing the driving approx. 3 to 4 seconds. The number of direction.
  • Page 217 Interior equipment CONTROLS Left/right-hand drive vehicle Ashtray The digital compass is already set for right In order to empty the ashtray, remove the or left-hand drive vehicle at the factory. ashtray from the cup holder. Adjusting the language Cigarette lighter Press and hold the adjustment knob for ap- Safety information prox.
  • Page 218 CONTROLS Interior equipment General information In the center console The total load of all sockets must not exceed 140 watts at 12 volts. Do not damage the socket by using unsuita- ble connectors. Safety information Warning Devices and cables in the unfolding area Remove the cover or cigarette lighter.
  • Page 219 Type C are located in the front of the NOTE center console. This device has been tested for human ex- Properties of upper USB port: posure limits and found compliant at a mini- mum distance of 4 in/10 cm during opera- – USB port Type A. tion.
  • Page 220 CONTROLS Interior equipment with the device, they may not function correctly. There is a risk of injury and risk of damage to property. When charg- ing mobile devices, make sure there are no objects on the tray together with the device.
  • Page 221 WCA. The following charging tray anymore unless the booster is paragraphs refer to this booster: permanently deactivated by your local MINI dealer. This is a CONSUMER device. You must not remove the booster from the...
  • Page 222 CONTROLS Interior equipment tennas or coupling devices will cause the cease of the booster´s operating license. The booster device fulfills the network pro- tection standards as required by the FCC, such as intermodulation limits, oscillation detection and gain limits. Booster Manufacturer: Kathrein Automotive Model Number: LTECOMPB0 Part Number: 6803145-01 FCC-ID: 2ACC7LTECOMPB0...

  • Page 223: Storage Compartments

    Storage compartments CONTROLS Storage compartments Vehicle features and options Overview This chapter describes all standard, coun- The following storage compartments are try-specific and optional equipment offered available in the interior: with the series. It also describes features – Glove compartment on the front passen- and functions that are not necessarily avail- ger side.
  • Page 224 CONTROLS Storage compartments Center armrest Opening General information The center armrest contains a storage com- partment. Opening Pull the handle. Closing Fold up the lid. Storage compartments in the Press button, arrow 1, and open center armrest upward, arrow 2. doors Adjusting the height General information...
  • Page 225 Storage compartments CONTROLS Cup holders Back Safety information Warning Unsuitable containers in the cup holders may damage the cup holders or be thrown about the car’s interior in the event of an accident, an evasive maneuver, or forceful braking. Spilled liquids can distract from For 3-door models: in front of the rear seats the surrounding traffic conditions and lead and in the side armrests.
  • Page 226 CONTROLS Storage compartments that they will not obstruct the driver's view. Warning Improper use of the coat hooks can lead to a risk of objects flying about during braking and evasive maneuvers. There is a risk of injury and risk of damage to prop- erty.

  • Page 227: Cargo Area

    Cargo area CONTROLS Cargo area Vehicle features and options objects or devices that are connected to the vehicle via a cable. This chapter describes all standard, coun- try-specific and optional equipment offered Warning with the series. It also describes features and functions that are not necessarily avail- Improperly stowed objects can slip and be thrown into the car's interior, for instance...
  • Page 228 CONTROLS Cargo area luggage load capacity is 650 lbs (1,400 - Stowing and securing cargo 750 (5 x 150) = 650 lbs) – Cover sharp edges and corners on the Determine the combined weight of lug- cargo. gage and cargo being loaded on the ve- –...
  • Page 229 Cargo area CONTROLS Cargo cover Installing Slide the cargo cover forward horizon- tally into the two side brackets until it General information audibly engages. When the tailgate is opened, the cargo Hook the left and right retaining straps cover is raised. at the tailgate.
  • Page 230 CONTROLS Cargo area General information danger to life. Make sure that the child restraint system fits securely against the The rear seat backrest is divided into two backrest. If possible, adjust the backrest parts at a ratio of 60 to 40. The left rear seat tilt for all affected backrests and correctly backrest is connected to the center section.
  • Page 231 Cargo area CONTROLS Adjusting Removing the cargo floor panel Release the backrest, and tilt it forward. Fold the frame up until it engages. On 5-door models: To change the position of the cargo floor panel, first fold up the rear part of the cargo floor panel.
  • Page 232 CONTROLS Cargo area Lower position Fold up the cargo floor panel Fold up the cargo floor panel in the lower – Larger objects can be transported. position and push it behind the locks, arrow. – Space for smaller objects remains be- You've reached the maximum cargo height.
  • Page 233 Cargo area CONTROLS Online Edition for Part no. 01405A7DAD4 - II/23...

  • Page 234: Driving Tips

    DRIVING TIPS Things to remember when driving Things to remember when driving Vehicle features and options Engine, transmission, and axle drive This chapter describes all standard, coun- Up to 1,200 miles/2,000 km try-specific and optional equipment offered with the series. It also describes features Do not exceed the maximum engine and and functions that are not necessarily avail- road speed:...
  • Page 235 Things to remember when driving DRIVING TIPS General driving notes Hot exhaust system Closing the tailgate Warning High temperatures can occur underneath Safety information the body, for instance caused by the ex- haust system, while driving. Contact with the exhaust system can cause burns. There Warning is a risk of injury.
  • Page 236 DRIVING TIPS Things to remember when driving Aquaplaning Perform emergency braking in situations that require such. To achieve the best possi- On wet or slushy roads, a wedge of water ble brake boosting, do not reduce the pres- can form between the tires and road sur- sure on the brake pedal during full braking.
  • Page 237 Things to remember when driving DRIVING TIPS Hills braking slowly - generally this cannot be corrected. General information Condensation water under the Drive long or steep downhill gradients in parked vehicle the gear that requires least braking effort. Otherwise, the brake system may overheat When using the automatic climate control, and reduce braking effect.
  • Page 238 DRIVING TIPS Things to remember when driving – Do not exceed the approved roof/axle weights and the approved gross vehicle weight. – Be sure that adequate clearance is main- tained for tilting and opening the glass sunroof. – Distribute the roof load uniformly. –...

  • Page 239: Reducing Fuel Consumption

    Reducing fuel consumption DRIVING TIPS Reducing fuel consumption Vehicle features and options Attached parts on the vehicle impair the aerodynamics and increase the fuel con- sumption. This chapter describes all standard, coun- try-specific and optional equipment offered with the series. It also describes features Close the windows and glass and functions that are not necessarily avail- sunroof...
  • Page 240 Have the vehicle maintained regularly to The fuel supply is interrupted in coast- achieve optimal vehicle efficiency and serv- ing/overrun mode. ice life. MINI recommends that mainte- nance work be performed by an authorized service center. Switch off the engine during...
  • Page 241 The achieved extended range is displayed in "Configure GREEN" the instrument cluster as bonus range. Select the desired setting. General information Activating/deactivating the functions The system includes the following MINI- The following functions can be acti- MALISM functions and MINIMALISM dis- vated/deactivated: plays: –...
  • Page 242 DRIVING TIPS Reducing fuel consumption Coasting The efficiency of your driving style is shown by the position of the mark: Efficiency can be optimized by disengaging – Mark inside the green range: efficient the engine and coasting, refer to page 243, driving style.
  • Page 243 Reducing fuel consumption DRIVING TIPS cluster using the Central Information Dis- Information is shown on the following func- play (CID): tions: – Auto Start/Stop function. "My MINI" – Energy recovery. "System settings" – Coasting. "Displays" "Instrument panel" Displaying the MINIMALISM analyzer "GREEN info"...
  • Page 244 To activate Coasting mode, actuate the Displaying MINIMALISM information right shift paddle again. Via the Central Information Display (CID): To deactivate, actuate the left shift paddle. "My MINI" Display "Technology in action" "MINIMALISM" Instrument cluster without enhanced features...
  • Page 245 Functional requirement This function is available in GREEN driving mode. Displaying the MINIMALISM analyzer Via the Central Information Display (CID): "My MINI" "Technology in action" "MINIMALISM Analyser" Display on the control display The display of the MINIMALISM analyzer consists of a fish in a water glass, a table of values and the display of the achieved bonus range.

  • Page 246: Mobility

    MOBILITY Refueling Refueling Vehicle features and options Fuel cap Opening This chapter describes all standard, coun- try-specific and optional equipment offered Grasp the fuel filler flap at the rear edge with the series. It also describes features and open it. and functions that are not necessarily avail- able in the vehicle, e.g., due to the selected options or country versions.
  • Page 247 Refueling MOBILITY Closing Safety information Warning NOTICE The retaining strap of the fuel cap can be Fuels are toxic and aggressive. Overfilling jammed and crushed during closing. The of the fuel tank can damage the fuel sys- cap cannot be correctly closed. Fuel or fuel tem.

  • Page 248: Fuel

    NOTICE Fuels that are marked on the gas pump as Fuel that does not comply with the mini- containing metal must not be used. mum quality can compromise engine func- You can fill up using fuel with a maximum tion or cause engine damage.
  • Page 249 Top Tier retailers. Failure to comply with these recommenda- tions may result in the need for additional maintenance. Recommended gas quality MINI recommends AKI 91. John Cooper Works: MINI recommends AKI 93. Minimum fuel grade MINI recommends AKI 87. John Cooper Works: MINI recommends AKI 91.

  • Page 250: Wheels And Tires

    MOBILITY Wheels and tires Wheels and tires Vehicle features and options Tire pressure specifications In the tire inflation pressure table This chapter describes all standard, coun- The tire inflation pressure table, refer to try-specific and optional equipment offered page 251, contains all tire inflation pres- with the series.
  • Page 251 Wheels and tires MOBILITY Determine the intended tire inflation pressure levels for the mounted tires. Check the tire inflation pressure in all four tires, using a pressure gage, for ex- ample. Correct the tire inflation pressure if the actual tire inflation pressure deviates from the intended tire inflation pres- sure.
  • Page 252 MOBILITY Wheels and tires Tire size Pressure specifica- Tire size Pressure specifica- tions in bar/PSI tions in bar/PSI 175/65 R 15 84 2.4 / 35 2.2 / 32 205/45 R 17 88 2.5 / 36 2.2 / 32 H A/S V XL A/S 205/45 R 17 88 205/45 R 17 88...
  • Page 253 Wheels and tires MOBILITY On 5-door models: COOPER On 5-door models: COOPER S Tire size Pressure specifica- Tire size Pressure specifica- tions in bar/PSI tions in bar/PSI Specifications in Specifications bar/PSI with in bar/PSI with cold tires cold tires 195/55 R 16 87 2.3 / 33 2.2 / 32 195/55 R 16 87...
  • Page 254 MOBILITY Wheels and tires sure values in the tire pressure table, refer On 3-door models: COOPER S to page 254, and adjust as necessary. Tire size Pressure specifica- Tire pressure values over 100 mph/ tions in bar/PSI 160 km/h Specifications in bar/PSI with On 3-door models: COOPER cold tires...
  • Page 255 Wheels and tires MOBILITY On 3-door models: JOHN COOPER Tire size Pressure specifica- WORKS tions in bar/PSI 175/65 R 15 84 2.8 / 41 2.5 / 36 Tire size Pressure specifications H A/S in bar/PSI 205/45 R 17 88 Specifications V XL A/S in bar/PSI with 205/45 R 17 88...
  • Page 256 MOBILITY Wheels and tires On 5-door models: COOPER S Maximum tire load Maximum tire load is the maximum permis- Tire size Pressure specifica- sible weight for which the tire is approved. tions in bar/PSI Locate the maximum tire load on the tire Specifications sidewall and the Gross Axle Weight Rating in bar/PSI with...
  • Page 257 Wheels and tires MOBILITY Manufacture date controlled conditions on specified govern- ment test surfaces of asphalt and concrete. You can find the manufacture date of the A tire marked C may have poor traction per- tire on the tire sidewall. formance.
  • Page 258 MOBILITY Wheels and tires Tire damage Winter and all-season tires with better cold weather performance than summer tires. General information Check your tires regularly for damage, for- eign bodies lodged in the tread, and tread Tire tread wear. Driving over rough or damaged road surfa- Summer tires ces, as well as debris, curbs and other obsta- cles can cause serious damage to wheels,...
  • Page 259 Wheels and tires MOBILITY or another qualified service center or re- Safety information pair shop. Have vehicle towed or trans- ported as needed. Do not repair damaged Warning tires, but have them replaced. Wheels and tires that are not suitable for the vehicle can damage parts of the vehi- cle.
  • Page 260 MOBILITY Wheels and tires wheels and tires, the vehicle manufacturer than summer tires but generally do not ach- recommends using star-marked tires again. ieve the performance of winter tires. The vehicle manufacturer recommends that you use tires of the same make and tread Maximum speed of winter tires design.
  • Page 261 Wheels and tires MOBILITY Always protect tires against all contact with Identification oil, grease, and solvents. Do not leave tires in plastic bags. Remove dirt from wheels or tires. Runflat tires Principle Runflat tires permit continued driving un- Runflat tires are labeled with a circular icon der limited conditions even in the event of a containing the letters RSC marked on the complete tire pressure loss.
  • Page 262 MOBILITY Wheels and tires General information 4 Sealant bottle connection – The filled in tire sealant closes the dam- 5 Wheel valve connection age from the inside when it hardens. – Follow the instructions on using the tire Compressor repair set found on the compressor and sealant bottle.
  • Page 263 Wheels and tires MOBILITY pressor and attach it in the visible area Unscrew the valve cap from the wheel in the vehicle interior. and screw the connecting piece of the filler hose onto the valve. – Remove the warning label from the tire sealant bottle and attach it to the rim.
  • Page 264 MOBILITY Wheels and tires Let the compressor run for max. 10 mi- Unscrew the valve cap. nutes to fill in the tire sealant and reach Stow the tire repair set in the cargo a tire pressure of 2.5 bar/36 psi. area.
  • Page 265 Do not continue driving unless a mini- With the Tire Pressure Monitor: using seal- mum tire pressure of 1.3 bar/19 psi is ant can damage the wheel electronics.
  • Page 266 MOBILITY Wheels and tires immediately in case of a breakdown when there is a tire pressure loss due to a flat tire. Warning If necessary, a suitable wheel change tool, Insufficiently tight snow chains may dam- e.g., a jack, is available as an accessory from age tires and vehicle components.
  • Page 267 Wheels and tires MOBILITY Warning NOTICE The jack may slip on soft, uneven, or Using an impact wrench to loosen or slippery ground, e.g., snow, ice, tiles, etc. tighten the wheel lock bolt can damage There is a risk of injury. If possible, the wheel lock bolt.
  • Page 268 MOBILITY Wheels and tires able objects, for instance rocks, under the Jacking up the vehicle wheels of both the front and rear axles against the rolling direction. Warning Hands and fingers can be jammed when Preparing the vehicle using the jack. There is a risk of injury. –...
  • Page 269 Wheels and tires MOBILITY ground and the relevant wheel is maxi- Extend the jack by turning the jack mum 1.2 inches/3 cm above ground. crank handle or lever clockwise. Mounting a wheel Mount one emergency wheel only, as re- quired. Unscrew the lug bolts.
  • Page 270 MOBILITY Wheels and tires ter or repair shop, then have the dam- Removing the emergency wheel aged tire renewed. Loosen the nut using the lug wrench from the onboard vehicle tool kit. Emergency wheel Principle In the event of a flat tire, the emergency wheel can be used in place of the wheel with the faulty tire.
  • Page 271 Wheels and tires MOBILITY Remove the spacer and emergency wheel from the well. Stow the well and spacer in the vehicle. Renewing the tires Have the damaged tire renewed. Replace the emergency wheel with the new wheel. Installing the emergency wheel Have the emergency wheel mounted back on the vehicle by an authorized service cen- ter or another qualified service center or...

  • Page 272: Engine Compartment

    MOBILITY Engine compartment Engine compartment Vehicle features and options able in the vehicle, e.g., due to the selected options or country versions. This also ap- plies to safety-related functions and sys- This chapter describes all standard, coun- tems. When using these functions and sys- try-specific and optional equipment offered tems, the applicable laws and regulations with the series.
  • Page 273 Engine compartment MOBILITY Hood Warning Body parts can be jammed when opening Safety information and closing the hood. There is a risk of in- jury. Make sure that the travel path of the Warning hood is clear during opening and closing. Improperly executed work in the engine compartment can damage vehicle compo- nents and impair vehicle functions.
  • Page 274 MOBILITY Engine compartment Indicator/warning lights When the hood is opened, a Check Control message is displayed. Closing the hood Energetically close the hood from approx. 20 in/50 cm. The hood must engage on both sides. Online Edition for Part no. 01405A7DAD4 - II/23...

  • Page 275: Engine Oil

    Engine oil MOBILITY Engine oil Vehicle features and options Safety information This chapter describes all standard, coun- try-specific and optional equipment offered NOTICE with the series. It also describes features An engine oil level that is too low causes and functions that are not necessarily avail- engine damage.
  • Page 276 30 minutes of normal driving. Performing a detailed measurement Displaying the engine oil level Via the Central Information Display (CID): Via the Central Information Display (CID): "My MINI" "My MINI" "Vehicle status" "Vehicle status" "Engine oil level" "Engine oil level"...
  • Page 277 Engine oil MOBILITY Safety information Adding engine oil Open the hood, refer to page 273. Warning Open the lid counterclockwise. Operating materials, for instance oils, greases, coolants, fuels, can contain harm- ful ingredients. There is a risk of injury or danger to life. Follow the instructions on the containers.
  • Page 278 MOBILITY Engine oil Suitable engine oil types When topping up engine oil, the following oil specification applies: Gasoline engine BMW Longlife-17 FE+. Alternative engine oil types If an engine oil suitable for continuous use is not available, up to 1 US quart/liter of an engine oil with the following oil rating can be added: Oil specification...

  • Page 279: Coolant

    Coolant MOBILITY Coolant Vehicle features and options Warning Additives are harmful and incorrect addi- This chapter describes all standard, coun- tives can damage the engine. There is a try-specific and optional equipment offered risk of injury and risk of damage to prop- with the series.
  • Page 280 MOBILITY Coolant Disposal The coolant level is correct if it lies between the minimum and maximum marks in the filler neck. Comply with the relevant environ- mental protection regulations when disposing of coolant and coolant ad- ditives. Close the lid. Adding coolant Let the engine cool down.

  • Page 281: Maintenance

    The authorized service center can read this data out and suggest a maintenance scope for MINI maintenance system the vehicle. Therefore, hand the service advisor the ve- The maintenance system provides service...
  • Page 282 MOBILITY Maintenance shop. Records of regular maintenance and Position repair work should be retained. Diagnostic socket General information Devices connected to the diagnostic socket will trigger the alarm system after locking the vehicle. Remove devices connected to the diagnostic socket before locking the ve- On the driver’s side, there is a socket for on- hicle.

  • Page 283: Replacing Components

    Replacing components MOBILITY Replacing components Vehicle features and options Wiper blades Safety information This chapter describes all standard, coun- try-specific and optional equipment offered with the series. It also describes features NOTICE and functions that are not necessarily avail- The window may sustain damage if the able in the vehicle, e.g., due to the selected options or country versions.
  • Page 284 MOBILITY Replacing components Light and bulb replacement Pull the wiper blade down out of the holder on the wiper arm, arrow 1. General information Lights and bulbs Lights and bulbs make an essential contri- bution to driving safety. Except for the reversing light, all headlights and lights are designed in LED technology.
  • Page 285 Replacing components MOBILITY Tail lights, bulb exchange Warning Overview Work on switched-on lighting systems can cause short circuits. There is a risk of in- All tail lights jury or risk of damage to property. When working on the lighting system, switch off the lights in question.
  • Page 286 MOBILITY Replacing components Bulb, reversing lights: P21W. Central brake light and license plate lights Open the tailgate. Follow the general instructions on lights Remove left or right cover. and bulbs, refer to page 284. The lights feature LED technology. In the event of a malfunction, contact an author- ized service center or another qualified service center or repair shop.
  • Page 287 Replacing components MOBILITY Registering the battery to the Charging the battery vehicle Charge the battery only when the engine is off and via the jump-start terminals, refer to The vehicle manufacturer recommends hav- page 292, in the engine compartment. ing an authorized service center or another qualified service center or repair shop regis- Power interruption ter the vehicle battery to the vehicle after...
  • Page 288 Swing the cover down, arrow. Information on the fuse layout, as well as the positions of any other fuse boxes, is available on the Internet: www.mini.com/ fusecard. Where applicable, information on the fuse layout is also found on a separate sheet in the fuse box.

  • Page 289: Breakdown Assistance

    Storage for the first-aid kit is provided in the cargo area. MINI Roadside Assistance Principle MINI Roadside Assistance can be contacted if assistance is needed in the event of a breakdown. Online Edition for Part no. 01405A7DAD4 - II/23...
  • Page 290 "MINI Assist" Depending on vehicle equipment and na- "MINI Roadside Assistance" tional-market version, the vehicle is equip- The contact to the MINI Roadside Assis- ped with an Assist system. tance is established. Only press the SOS button in an emergency.
  • Page 291 SOS button in the headliner transmitted to the MINI Response Cen- ter. Functional requirements If you can no longer hear the MINI Re- sponse Center through the loudspeakers, – The ignition is switched on. the hands-free system, for instance, may –...
  • Page 292 MOBILITY Breakdown Assistance Connecting the cables Warning To prevent personal injury or damage to If the jumper cables are connected in the both vehicles, adhere strictly to the follow- incorrect order, spark formation may oc- ing procedure. cur. There is a risk of injury. Pay attention Pull off the cover cap of the jump-start to the correct order during connection.
  • Page 293 Breakdown Assistance MOBILITY Check the battery and recharge, if needed. effort needs to be applied when braking and steering. – Larger steering wheel movements are Tow-starting and towing required. – The towing vehicle must not be lighter Safety information than the vehicle being towed; otherwise, it will not be possible to control han- dling.
  • Page 294 MOBILITY Breakdown Assistance Safety information Towing other vehicles General information NOTICE Switch on the hazard warning system, de- The vehicle can be damaged when towing pending on local regulations. the vehicle with a lifted rear axle. There is If the electrical system has failed, clearly a risk of damage to property.
  • Page 295 Breakdown Assistance MOBILITY Tow rope – Avoid lateral loading of the tow fitting, for instance do not lift the vehicle by the Observe the following notes when using the tow fitting. tow rope: – Check the attachment of the tow fitting –...
  • Page 296 MOBILITY Breakdown Assistance catalytic converter, only tow-start while the engine is cold. Switch on the hazard warning system and comply with local regulations. Switch on the ignition, refer to page 97. Engage third gear. Have the vehicle tow-started with the clutch pedal pressed and slowly release the pedal.

  • Page 297: Vehicle Care

    Vehicle Care MOBILITY Vehicle Care Vehicle features and options Steam cleaners or high pressure cleaners This chapter describes all standard, coun- Safety information try-specific and optional equipment offered with the series. It also describes features and functions that are not necessarily avail- NOTICE able in the vehicle, e.g., due to the selected When cleaning with high pressure clean-...
  • Page 298 Vehicle care products Driving into a car wash with a General information Steptronic transmission MINI recommends using vehicle care and In car washes, the vehicle must be able to cleaning agents from MINI. Suitable vehi- roll freely. cle care products are available from an au-...
  • Page 299 Vehicle Care MOBILITY Safety information Clean light-colored leather more frequently because contamination on such surfaces is substantially more visible. Warning Use leather care products; otherwise, dirt Cleaning agents can contain substances and grease will gradually break down the that are dangerous and harmful to your protective coating of the leather surface.
  • Page 300 MOBILITY Vehicle Care Caring for special components Fine wood parts Clean fine wood facing and fine wood com- Light-alloy wheels ponents only with a moist rag. Then dry with a soft cloth. When cleaning the vehicle, use only neutral rim cleaners having a pH value from 5 to Plastic components 9.
  • Page 301 Vehicle Care MOBILITY floor mats that are suitable for the vehicle Taking the vehicle out of service and can be safely attached to the floor. When the vehicle is shut down for longer Do not use loose floor mats and do not than three months, special measures must layer several floor mats.

  • Page 302: Technical Data

    The dimensions can vary depending on the The height of the vehicle can also differ, model version, equipment version or coun- e.g., due to tires and vehicle load. try-specific measurement procedure. MINI 5-door model Width with mirrors in/mm 75.9/1,928 Width without mirrors...
  • Page 303 REFERENCE MINI 3-door model Length in/mm 152.8/3,880 Wheelbase in/mm 98.2/2,495 Smallest turning radius diam. ft/m 35.4/10.8 Weights MINI Cooper, 3-door model Approved gross vehicle weight Manual transmission lbs/kg 3,505/1,590 Steptronic transmission lbs/kg 3,549/1,610 Payload Manual transmission lbs/kg 697/316 Steptronic transmission...
  • Page 304 MINI Cooper, 5-door model Steptronic transmission lbs/kg 2,116/960 Approved rear axle weight Manual transmission lbs/kg 1,863/845 Steptronic transmission lbs/kg 1,863/845 MINI Cooper S, 3-door model Approved gross vehicle weight Manual transmission lbs/kg 3,616/1,640 Steptronic transmission lbs/kg 3,627/1,645 Payload Manual transmission lbs/kg...
  • Page 305 Technical data REFERENCE MINI Cooper S, 5-door model Approved rear axle weight Manual transmission lbs/kg 1,896/860 Steptronic transmission lbs/kg 1,896/860 MINI John Cooper Works, 3-door model Approved gross vehicle weight Manual transmission lbs/kg 3,715/1,685 Steptronic transmission lbs/kg 3,770/1,710 Payload Manual transmission...

  • Page 306: Appendix

    REFERENCE Appendix Appendix Any updates to the Owner's Manual of the vehicle are listed here. Updates made after the edito- rial deadline The following chapters were updated in the printed version of the Owner's Manual af- ter the editorial deadline for the Integrated Owner's Manual in the vehicle had closed: –...
  • Page 307 Appendix REFERENCE Online Edition for Part no. 01405A7DAD4 - II/23...

  • Page 308: Everything From A To Z

    Assistance with breakdown trol Audio, see Owner's Manual for Navigation, Activated charcoal filter Entertainment and Communication Activation times, pre-ventilation Authorized service center, see MINI Road- Active Cruise Control side Assistance Active Guard, see Intelligent Safety Automatic climate control Adaptive suspension...
  • Page 309 Everything from A to Z REFERENCE Backrest, seats Cargo Bad weather light Cargo area Battery, disposing of Cargo area, adapting size Battery, vehicle Cargo area, enlarging Being towed, see Tow-starting and tow- Cargo area lid Cargo area, storage compartments Belts, see Seat belts Cargo cover Beverage holder, see Cup holders Cargo position, rear seat backrest...
  • Page 310 REFERENCE Everything from A to Z Child restraint system Control systems, driving stability Child restraint systems, mounting Convenient closing, vehicle key Child safety latch Convenient opening, vehicle key Child safety locks Cooling, maximum Child seat installation Cornering light Child seat, mounting Corrosion, brake disks Child seat mountings LATCH Cosmetic mirror...
  • Page 311 Emergency braking, see PostCrash – Driver assistance, see Intelligent iBrake Safety Emergency call Driver profiles Emergency service, see MINI Roadside As- Driver profiles, exporting profiles sistance Driver profiles, importing profiles Emergency unlocking, fuel filler flap Driving Dynamics Control, see MINI Driv-...
  • Page 312 REFERENCE Everything from A to Z Engine, automatic Start/Stop function Filler neck for engine oil Engine compartment Filter, see Microfilter Engine coolant Fine wood parts, care Engine idling when driving, see Coast- First-aid kit Fish, MINIMALISM display Engine oil Flat tire, changing wheels Engine oil filler neck Flat tire, continued driving, see Flat tire Engine oil, topping up...
  • Page 313 Everything from A to Z REFERENCE Fuel gauge Hazard warning system Fuel quality Head airbag Fuel recommendation Headlight control, automatic Fuel, saving Headlight flasher Fuel tank, see Filling capacity Headlight glass Fuses Headlights, care Headlights, turning up, dimming, see Auto- matic High Beam Assistant Headliner Head restraints and seats...
  • Page 314 REFERENCE Everything from A to Z Ignition off Ignition on Illuminated ring, central instrument clus- Jack Jacking points Indicator and warning lights, see Check Jacking points for the vehicle jack Control Jam protection system, glass sunroof Indicator light, front-seat passenger air- Jam protection system, windows Jump-starting Indicator light, see Check Control...
  • Page 315 Mobile phones, suitable Malfunction, vehicle key Mobile radio in the vehicle Manual air flow Mobile Service, see MINI Roadside Assis- Manual brake, electric, see Parking brake, tance electric Mobility System, see Tire repair set Manual brake, manual, see Parking brake,...
  • Page 316 On-board computer igation On-board diagnosis Personal data, deleting Onboard vehicle tool kit Personal profile, see Driver profiles On-call service, see MINI Roadside Assis- Physical units, see Units of measurement, tance setting Opening and closing Plastic parts, care Opening, from inside PostCrash –...
  • Page 317 Everything from A to Z REFERENCE Pressure warning, see Tire Pressure Moni- RES CNCL button, camera-based cruise con- trol Pre-ventilation RES CNCL button, Cruise Control Profiles, see Driver profiles Reserve warning, see Range Programmable memory buttons, Central In- Reset, Tire Pressure Monitor formation Display (CID) Retreaded tires Protective function, glass sunroof, see Jam...
  • Page 318 REFERENCE Everything from A to Z Servotronic Speed Limit Info, on-board computer SET button, camera-based cruise con- Speed limit, see Speed Limiter trol Speed, see Average speed SET button, Cruise Control Speed warning Set clock Split screen Set day, see Date Sport displays, Head-up display Set time, see Time Sport displays, see Driving Excitement...
  • Page 319 Everything from A to Z REFERENCE Sun visor Tire pressure, tires Switches, see Dashboard Tire pressure warning, see Flat tire moni- Switch for driving dynamics System language, setting, see Language, Tire repair set setting Tires System settings, see General settings Tire sealant, see Tire repair set Tires, run-flat Tire tread...
  • Page 320 REFERENCE Everything from A to Z Unlocking, automatic Unlocking, settings Updates made after the editorial deadline Warning and indicator lights, see Check Updating, software Control Upholstery care Warning displays, see Check Control Upper retaining strap, top tether Warning messages, see Check Control USB connection Warning triangle USB port, position in vehicle...
  • Page 321 Everything from A to Z REFERENCE Wood parts, care Wordmatch principle Word match principle, navigation Working in, engine compartment Wrench, see Onboard vehicle tool kit Online Edition for Part no. 01405A7DAD4 - II/23...
  • Page 322 01405A7DAD4 ue *BL5A7DAD400O* Online Edition for Part no. 01405A7DAD4 - II/23...
  • Page 323 California Proposition 65 Warning For vehicles sold in California: Online Edition for Part no. 01405A7DAD4 - II/23...
  • Page 324 MINI MOTORER'S GUIDE APP. YOUR DIGITAL VEHICLE INFORMATION. The MINI Motorer's Guide app explains the equipment of your vehicle and offers further scopes and functions: All information surrounding navigation, entertainment and communication Photorealistic animations for various vehicle functions Keyword search 360°...

This manual is also suitable for:

Hardtop 4 door 2023Clubman 2023CooperCooper sJohn cooper works

Table of Contents
