VOLKTEK NWT-707 User Manual

10base-t to 10base-fl converter (multi-mode & single mode)

Advertisement

Quick Links

10Base-T
to
10Base-FL Converter
(Multi-mode & Single Mode)
User's Manual
NWT-707

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NWT-707 and is the answer not in the manual?

Questions and answers

Summary of Contents for VOLKTEK NWT-707

  • Page 1 10Base-T 10Base-FL Converter (Multi-mode & Single Mode) User’s Manual NWT-707...
  • Page 2 COPYRIGHT All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photo copying, recording or otherwise, without the prior written permission of the publisher. FCC WARNING This equipment has been tested and found to comply with the limits for class A device, pursuant to part 15 of FCC rules.
  • Page 3: Table Of Contents

    Table of Contents 1 Introduction ..............1 About This Guide ............1 Welcome..............1 Purpose ..............1 Terms/Usage ............1 Features................. 2 Specifications..............3 Package Contents ............4 2 Hardware Description..........5 Product Overview ............5 3 Installation ..............7 Installing Your Converter ..........
  • Page 4 Installing the Converter .......... 20 Rear view of Chassis and specifications....21 Appendix D ..............22 Application Diagram............. 22 Application Diagram I ..........22 Application Diagram II ..........23 Application Diagram III ........... 23...
  • Page 5: Introduction

    10Base-T to 10Base-FL Converter 1 Introduction About This Guide Welcome Thank you for choosing the 10Base-T to 10Base-FL Media Converter. This device integrates Ethernet copper and fiber segments in a highly flexible package. Purpose This guide discusses how to install and configure your 10Base-T to 10Base-FL Media Converter.
  • Page 6: Features

    10Base-T to 10Base-FL Converter Features • Complies with 802.3 10Base-T/FL standard • MDI/MDI-X push button selection for RJ-45 port connection • Support ST or SC fiber connector • Extend fiber distance up to 12km with single Mode fiber • Compatible with other 10Base-T/FL and 10/100 devices •...
  • Page 7: Specifications

    10Base-T to 10Base-FL Converter Specifications Standard: IEEE 802.3u Connector: 1 RJ-45, 1 ST for Multi-mode or SC for Single Mode Max. Distance: Twisted Pair: 100m (330ft) Multi-mode: 2km (6600feet) Single Mode: 12km (39600feet) Unit LEDs: Power - illuminated for normal operation Port LEDs: Link - illuminated when connectors are attached...
  • Page 8: Package Contents

    10Base-T to 10Base-FL Converter Package Contents The 10Base-T to 10Base-FL Converter package should include: • One converter • One AC adapter (for external power supply) • Four pieces self-adhesive pads • One user’s manual Go to Installing Your Converter...
  • Page 9: Hardware Description

    10Base-T to 10Base-FL Converter 2 Hardware Description Product Overview The Converter is primarily designed for network or data installations that require the migration of cable media between conventional coppers based wiring to Fiber based installations. These Converters have been specifically designed to support both a RJ-45 jack and a ST or SC fiber optic connector.
  • Page 10 10Base-T to 10Base-FL Converter Front Panel View with SC and RJ-45 Connectors Front Panel View with ST and RJ-45 Connectors...
  • Page 11: Installation

    10Base-T to 10Base-FL Converter 3 Installation Installing Your Converter In this chapter, we will take a look at how to install converters within its operating environment. First, it is important to unpack the Converter and ensure that all the components listed in Package Contents are present.
  • Page 12: Location

    10Base-T to 10Base-FL Converter Location The location selected for installing the Converter may greatly affect its performance. When selecting a site, we recommend considering the following rules: 1. Install the Converter in a fairly cool and dry place. See Technical Specifications for the acceptable temperature and humidity operating ranges.
  • Page 13: Mdi/Mdi-X Connection

    10Base-T to 10Base-FL Converter MDI/MDI-X Connection The MDI / MDI-X function alleviates the worry of cable type configuration used for connecting the Converter with a 10Base-T device. Simply follow the chart below when connecting the Converter, and use the push button to select MDI or MDI-X accordingly.
  • Page 14: Install The Converter

    10Base-T to 10Base-FL Converter Install the converter This Converter utilizes ports with fiber and copper port connectors functioning under the Fast Ethernet protocol. 10BASE-T Port The 10BASE-T port supports network speed of 10Mbps, and is designed to operate in half-duplex transfer mode only.
  • Page 15: Desktop Installation

    10Base-T to 10Base-FL Converter Desktop Installation Follow the instructions listed below to install the Converter onto a desktop location. 1. Locate the Converter in a clean, flat and safe position that has easy access to AC power. 2. Affix the four (4) self-adhesive rubber pads to the underside of the Converter.
  • Page 16: Powering On Unit

    10Base-T to 10Base-FL Converter Powering On Unit The Converter uses external power supply 12V DC @ 0.8A 50~60 Hz. 1. Insert the power cable plug directly into the receptacle located at the back of the device. 2. Plug the power adapter into an available socket. 3.
  • Page 17: Connecting Fiber Cable

    10Base-T to 10Base-FL Converter Connecting Fiber Cable When connecting fiber cable to a 10BASE-FL port on the Converter, be sure the correct type - ST or SC - connector is used. Follow the steps below to properly connect fiber cable: 1.
  • Page 18: Connecting Copper Cable

    10Base-T to 10Base-FL Converter Connecting Copper Cable 1. Insert one end of Category 5 twisted pair cable into an available RJ-45 port on the Converter and the other end into the port of the network node. 2. Check the corresponding port LED on the Converter to make sure that the connection is valid.
  • Page 19: Led Indicators

    10Base-T to 10Base-FL Converter 4 LED Indicators LED Table This Converter has LED indicators located at the front of the device. The LEDs have been designed to give easy at- a-glance network status, provides ‘real-time’ connectivity information. Please see below for an interpretation of their functions: LED Indicators Condition...
  • Page 20: Appendix A

    10Base-T to 10Base-FL Converter Appendix A Cables The following are some recommendations as to what you should and should not do when installing cables. Remember - cables are the deciding factor in network performance. Try to Try no t to maintain allow the a bend...
  • Page 21: Appendix B

    10Base-T to 10Base-FL Converter Appendix B About RJ-45 Cables When connecting your network devices, use standard Category 3 eight-way cables for 10Base-T configurations and Category 5 cable for 100Base-TX. The pin assignments are as follows: Pair White/Orange Pair Orange/White Pair White/Green Pair Blue/White...
  • Page 22: Appendix C

    10Base-T to 10Base-FL Converter Appendix C Mini Converter Chassis The Chassis was developed to accommodate just one media converter. The Chassis provides protection for converter units and an option of AC or DC power supplies. Now, network designers can plan their Ethernet, Fast Ethernet, ATM, or Gigabit networks without having to worry about the power source.
  • Page 23: Affixing Brackets

    10Base-T to 10Base-FL Converter Affixing Brackets We have supplied 2 special brackets that easily attaches to the Converter. This allows for the secure placement of the converter into the Chassis. It also seals off the front of Chassis and allows it to function correctly. Step 1 Using a Phillips screwdriver, remove two screws from the side panels on the converter.
  • Page 24: Installing The Converter

    10Base-T to 10Base-FL Converter Installing the Converter Once the Converter has been attached to the bracket, it can be installed into the Chassis. Special care must be taken to ensure the correct mating of the power connector. Align the Converter so that it fits between the upper and lower guide rails.
  • Page 25: Rear View Of Chassis And Specifications

    10Base-T to 10Base-FL Converter Rear view of Chassis and specifications Rear View of Chassis with AC Power Supply Power: 100 - 240V AC (Optional 12V Adapter) Dimensions: 109 x 174 x 44.3 mm (L x W x H) Rear View of Chassis with DC Power Supply Power: -48V (Optional...
  • Page 26: Appendix D

    10Base-T to 10Base-FL Converter Appendix D Application Diagram To effectively expanding an Ethernet network, position two converters back-to-back as illustrated. Application Diagram I In the figure below, the Converter is functioning as a high- speed bridge between switches creating increased capacity for each user (node) on the local area network.
  • Page 27: Application Diagram Ii

    10Base-T to 10Base-FL Converter Application Diagram II In the figure below, the Converter is functioning as a server aggregation for an enterprise or LAN configuration. It is providing a 10Mbps full duplex link to a workgroups of 10/100 switches located on separate floors within a single building.
  • Page 28 10Base-T to 10Base-FL Converter VOLKTEK CORPORATION 4F, No. 192 Lian-Cheng Road Chung-Ho, Taipei 235, Taiwan ROC TEL: +86 (2) 8242-1000 FAX: +886 (2) 8242-3333 Tech Support: +886 800-286-286 ISO 9001 Certified...
