OWNER'S MANUAL
Limited
th
11620 54
Street North
Clearwater, FL 33760
866.461.3123
www.lazboylimitedspa.com
Part Number 8271118

Advertisement

Table of Contents
loading

Related Manuals for LAZBOY Limited

Summary of Contents for LAZBOY Limited

  • Page 1 OWNER’S MANUAL Limited 11620 54 Street North Clearwater, FL 33760 866.461.3123 www.lazboylimitedspa.com Part Number 8271118...
  • Page 2 Owner’s Information Dealer: Date Purchased: __________________________ Company: __________________________ Address: __________________________ Telephone: __________________________ Installer: Date Installed: __________________________ Company: __________________________ Address: __________________________ Telephone: __________________________ Spa: Date Delivered: __________________________ Model: __________________________ Color: __________________________ Serial Number: __________________________ Your unique spa serial number is located on a data plate outside the cabinet at ground level directly below the topside control panel.

  • Page 3: Table Of Contents

    Products is dedicated to offering you the best in customer satisfaction and service. Be sure to read, complete, sign, and send in the limited warranty card within 30 days of purchase to ensure you understand what you are entitled to in terms of service. If you have any ™...

  • Page 4: Introduction

    I n t r o d u c t i o n ™ Your choice of a La-Z-Boy spa indicates that you are devoted to excellence. The management and staff appreciate your patronage and takes pride in the tradition of quality spas that our company represents. To properly acquaint yourself with your spa, we suggest that you take time to read through this manual before hook up and operation.

  • Page 5: Features

    F e a t u r e s Premium quality loudspeakers (equipped with CD stereo and/or flat-screen monitor models) round out your sound system. Completely retractable, these speakers deliver a lush, rich, musical tone. From one touch of your floating wireless remote control, you can start up your spa, launch the CD player, tune in radio stations, or listen to your favorite music.

  • Page 6: Safety Information

    S a f e t y I n f o r m a t i o n Read and Follow All Instructions Water will splash out of the during normal use. Install an • adequate perimeter around your that provides sound footing thereby helping to avoid falls, slips, and accidents while preventing damage to fine floors and wood finishes.
  • Page 7 Risks of Burns Before entering a spa, measure the water temperature with an • accurate thermometer since the tolerance of temperature-regulating devices may vary by as much as ±5°F (±2°C). Test the water with your hand before entering the to be sure it’s •...
  • Page 8 Risks of Hyperthermia WARNING: To reduce the risk of injury, the water temperature in a should never exceed 104ºF (40ºC). Water temperatures between 100ºF (38ºC) and 104ºF (40ºC) are considered safe for a healthy adult. Lower water temperatures are recommended for young children, senior citizens, and when use exceeds 10 minutes.
  • Page 9 Important: It is extremely important that this sign be permanently placed in clear view of persons using the spa. Occasional users may not be aware of some of the dangers hot water poses to pregnant women, small children, and people under the influence of alcohol. If you did not receive a warning sign or your sign has become damaged, please call In-Touch, our 24/7 customer care center, at 866.461.3123 for a replacement.

  • Page 10: Location And Installation

    L o c a t i o n a n d I n s t a l l a t i o n Proper planning is an important consideration when installing your new spa. Site selection is a critical step and requires serious thought. Planning ahead makes the installation process easier.
  • Page 11 The topside control panel is shown at bottom of diagram for reference. Figure 2 – Conduit Entry Location Reference Points Model Dimension A Dimension B Limited 5” (13 cm) 21” (53 cm) Table 1 – Conduit Entry Location Dimensions 10) Consider positioning your out of or adequately protecting it from the wind.

  • Page 12: Electrical Specifications

    E l e c t r i c a l S p e c i f i c a t i o n s Important: Qualified and licensed electricians must perform all electrical hookups. The following specifications must be followed in order to ensure proper performance and safety.
  • Page 13 Our spas are certified by Intertek Testing, SNAa Ltd. Ontario, Canada to CSA-C22.2 No. 218.1-M89 and ANSI/UL 1563 standards. Parts with extra low voltage not exceeding 12v must be inaccessible to a person in the spa. Earthed appliances must be permanently connected to fixed wiring.
  • Page 14 Important: Installation of this GFCI Circuit Breaker, including Ampere sizing and selection of conductor size and type, must be performed by a qualified electrician in accordance with the National Electrical Code, or the Canadian Electrical Code, and all federal, state, and local codes and regulations in effect at the time of installation.
  • Page 15 Spa Receptacle Spa Plug Spa Pack 1 x 32A 1 x 32A 1 x 32A House Jumper L1-L2-L3 Jumper L1-L2-L3 Figure 5 – European 1x32A Wiring Diagram Important: Match the Breaker setting (Br) of the spa pack to the electrical phase wiring as described on page 43. Page 13 For HELP, call In-Touch at 866.461.3123...
  • Page 16 Jumper L2-L3 Figure 6 – European 2x16A Wiring Diagram Important: Match the Breaker setting (Br) of the spa pack to the electrical phase wiring as described on page 43. Page 14 For HELP, call In-Touch at 866.461.3123...
  • Page 17 No Jumper Figure 7 – European 3x16A Wiring Diagram Important: Match the Breaker setting (Br) of the spa pack to the electrical phase wiring as described on page 43. Page 15 For HELP, call In-Touch at 866.461.3123...

  • Page 18: Startup

    S t a r t u p Important: Read these step-by-step startup procedures before starting your spa. Failure to follow any of these steps listed may result in damage to the equipment and may void your warranty. Note: If you are unsure of any of the above startup procedures, please call In-Touch, our 24/7 customer care center, at 866.461.3123.
  • Page 19 Before Adding Water Before adding water, go through these simple steps now to prevent common issues when setting up your for the first time. Verify that the following have all been rechecked. 1. Turn off all power to the at the main breaker panel. 2.
  • Page 20 Filling Your Spa Now it's time to fill your with water. Do not turn on the electricity yet until the completely filled. To properly fill your spa: 1. Make sure that the filters (in the filtration canister) are gently screwed into place. Turn them clockwise until they stop being careful not to over-tighten them (this avoids cracking the filter).
  • Page 21 Operational Checks Caution: Do not turn on any pump until your spa is properly filled with water. Running any pump without water in your spa can cause IMMEDIATE damage, which is not covered under warranty! By now you have rechecked your tub’s mechanical connections and filled it with water to about 1”...
  • Page 22 4. Press the Pump 1 button again. You should hear the first pump turn on a higher speed and the icon swirl faster. Caution: If water does not flow from the jets after 2 minutes, turn power off at the main panel and bleed air from the system (see page 39).
  • Page 23 12. Press the Blower button to turn on the air blower (if equipped). Check that air goes to the air jets on the bottom of each seat. 13. Press the Blower button again to turn the Blower off. A built-in timer automatically turns the Blower off after 20 minutes.

  • Page 24: Topside Control

    T o p s i d e C o n t r o l The topside control panel uses a paged-style menu system to operate and program your spa. Basic button functions are described next. Figure 13 – Topside Callouts Press the Mode button to display the two operating modes (Spa or Options).
  • Page 25 Spa Mode Spa Mode allows you to operate the basic devices of your spa plus access Economy feature. To access Spa Mode, first press to access the mode selection menu and then select the Spa Mode with . Press next to the feature or device you wish to operate on that page. The corresponding display icon animates indicating its status.
  • Page 26 Options Mode In Options mode, the system shows you which option you wish to program or alter (Spa, Keypad, or Clock). The Info option allows you to review various information about your spa. To access Options mode, first press to access the mode selection menu and then select the Options mode with The following submenus are accessible from the Options mode choices (Spa, Keypad, Clock, and Info).
  • Page 27 Spa Submenus This submenu allows you to personalize operating settings of your spa – such as the total filtration time, economy times, and a maintenance reminder – and to display any warning messages. When your spa is in a filter cycle, the icon appears on the topside control panel.
  • Page 28 Figure 17 – Economy Screens Economy mode allows you to automatically set back your spa’s water temperature by 20ºF every day for a certain period of time to help you lower operating costs. Remember to select Economy Mode times that differ from your normal bathing times.
  • Page 29 Keypad Submenus This submenu allows you to personalize operating settings of your spa’s display. Figure 19 – Display Screens These settings allow you to adjust the properties of the display. Contrast Press +/- to set amount of contrast on the display. Press to go to the next screen.
  • Page 30 Figure 21 – Regional Screens These setting control the language, temperature units, and time format. Language Press +/- to select your language. Press to go to the next screen. Temperature Press +/- to select a temperature reading in degrees F/C. Press to go to the next screen.
  • Page 31 Clock Submenu This submenu allows you to set the time of the clock. Press +/- to set the hours. Press > to access minutes. Press +/- to set the minutes. Press to save the settings. Information Submenus These sub-menus allow you to view spa equipment data such as the spa controller, heater, and keypad software version.
  • Page 32 CD Audio Mode CD audio mode allows you to operate the CD player (if equipped) of your spa plus contour the sound to your personal preference. To access Audio mode, first press to access the main menu and then press Audio to select the Audio mode.
  • Page 33 CD Audio Mode Page 2 Used with +/- or </>, this page allows you to perform advanced audio functions and contour the sound to your personal preference. To select a function, press next to the icon you wish to operate. Press to go to the next page.
  • Page 34 CD Audio Mode Page 4 Used with +/- or </>, this page allows you to perform advanced tuner and CD functions. To select a function, press next to the icon you wish to operate. Press to go to the next page. From any CD track, press </>...

  • Page 35: Stereo System

    S t e r e o S y s t e m Figure 23 – Stereo Callouts The built-in AM/FM/Weather Band stereo CD system (if equipped) plays CDs and MP3s. Your stereo also works in conjunction with your remote control (see page 33) to control the sound through your speakers for whatever audio source you select.

  • Page 36: Remote Control

    R e m o t e C o n t r o l All spa functions can be operated from the floating remote control. The buttons toggle their operation based on which mode you select. In Spa Mode you can control Pumps 1-3 and the Light from their respective buttons.

  • Page 37: Cover

    C o v e r Place the insulated cover on your spa. Keeping the cover in place anytime the spa is not in use reduces the heating time and minimizes operating costs. The time required for initial heat-up varies depending on the starting water temperature, ambient temperature, and the capacity of your spa.

  • Page 38: Water Management

    W a t e r M a n a g e m e n t Our enzyme-based water purification system is a perfect match for your spa. AquaClara Natural naturally solves most water treatment problems and dramatically reduces spa maintenance. Added monthly, it effectively stabilizes pH/alkalinity, eliminates scum lines, foam, itching and rashes and helps to alleviate dry skin, by reducing overall chemical use.

  • Page 39: Frequently Asked Questions

    F r e q u e n t l y A s k e d Q u e s t i o n s Why Does my Pump Run all the Time? Your spa can be programmed for constant filtration (see page 25) to keep your water as clean and clear as possible.
  • Page 40 How Often Should I Drain My Spa? You should drain and refill your spa every 1-3 months depending on usage. Every other time you drain and refill, you should also replace the filters and wipe down the spa (see pages 44-47). What Is the Insulation Made Of? ™...
  • Page 41 How Do I Bleed Air from my System? When draining and refilling your spa, the pump may become air locked. Air-locked pumps stop water from flowing in your spa and is easily resolved by bleeding off the trapped air. To do this: Turn off the GFCI breaker •...

  • Page 42: Troubleshooting

    T r o u b l e s h o o t i n g If a problem arises, you can check this list for a quick solution. If this does not resolve your problem, please call In-Touch, our 24/7 customer care center, at 866.461.3123.
  • Page 43 PROBLEM CAUSE SOLUTION Moved my Wiring error Check Neutral wiring of GFCI (see spa and now at GFCI diagrams on pages 11-15) doesn’t work No power to Reset circuit breakers on GFCI panel and main circuit breaker panel Nothing Breaker has Check and reset breaker.
  • Page 44 Error Codes CODE DESCRIPTION CORRECTIVE ACTION Topside error • Swap topside plug position (C1 to C2) • Change topside control panel bL Er Device not • Open the access panel to spa pack and CP Er detected reseat corresponding plug (see callouts on O3 Er page 43) P1 Er...
  • Page 45 Select button for 5 seconds. Use the Change button Model to set LL even if it is the present value. Press Select to Limited save (breaker settings appear next). After setting LL, the breaker current setting (Br) appears. Configuration...

  • Page 46: Maintenance And Care

    M a i n t e n a n c e a n d C a r e Important: The warranty on your spa and equipment depends on proper sanitation (see page 21.) In addition, the following maintenance procedures must be followed periodically. Cabinets The spa consists of a rigid polymer that combines the durability of plastic with the beauty of a wood-looking cabinet.
  • Page 47 Draining and Refilling Figure 30 - Drain Operation 1) Turn off the GFCI breaker. 2) Remove spa cover and allow water to cool down. 3) Select a safe, suitable drainage area capable of safely assimilating 300 plus gallons of water that may contain unsanitary contaminants and chemical residue that could cause harm to plants or grass.
  • Page 48 Filters The filters in your spa should be removed and cleaned every week with our special Filter Cleanser and typically replaced every 4-6 months (depending upon use). You can clean your filters with the water pressure from the end of a garden hose then rinsed with warm water. This ensures that the water is being filtered properly.
  • Page 49 Sanitation Sanitation level is influenced by two factors: 1. Filter Cycle (filtration) time (your spa is designed to constantly filter the water) 2. How much you use your spa each week When using our recommended AquaClara Natural sanitation system (see page 36), most sanitation problems are self resolved after two days. Refer to the instructions in this kit for more information when other problems arise.

  • Page 50: Shutdown / Winterizing

    S h u t d o w n / W i n t e r i z i n g Your spa is designed to operate year round. If you plan to leave your spa unused for long periods of time in severely cold weather, you should winterize your spa to avoid accidental freezing due to a power or equipment failure.

  • Page 51: Glossary

    G l o s s a r y AquaClara An enzyme-based water purification system for your spa. AquaClara naturally solves most spa water treatment problems and dramatically reduces spa maintenance. Blower A heavy duty motor which aerates the water with millions of tiny bubbles throughout the spa providing soft tissue massage.

  • Page 52: Specifications

    S p e c i f i c a t i o n s Limited Specifications* Dimensions 86”L x 86”W x 36”D Seats Water Jets Air Jets Capacity 340 USG /1286 L Dry Weight 865 Lbs/ 393 Kg Filled Weight...
  • Page 53 Limited Callouts Part# Description Part# Description 820559 6-spk Jet, Clust Dir 2" (ss/Gr) 612584 Suction 200GPM 2"Slip (Gr) 606533 Compensator Ring 2" 606543 Comp ring 606526 Body, Jet 2" 515505 IRMR receiver 820555 6-spk Jet, Clust Dir Fix (below topside) 2"...
  • Page 54 Notes: Page 52 For HELP, call In-Touch at 866.461.3123...
  • Page 55 Notes: Page 53 For HELP, call In-Touch at 866.461.3123...

  • Page 56: Conditions Of Warranties

    C o n d i t i o n s o f W a r r a n t i e s All limited warranties provided hereunder extend only to the original consumer/purchaser of the spa if purchased and installed within the boundaries of the United States or Canada and terminate upon transfer of ownership from original consumer/purchaser.
  • Page 57 (Please stand next to your spa when calling). A credit card must be provided to secure shipment of parts. All repairs and replacements will be made in accordance with the limited warranty. The consumer/purchaser is responsible for mileage or travel charges incurred by authorized In-Touch companies.
  • Page 58 Page 56 For HELP, call In-Touch at 866.461.3123...

  • Page 59: Limited Warranty

    (i.e. wood, carpets, etc.) and cost for removal of defective product even if LWP was advised of the possibility of damage. The liability of LWP under this limited warranty, if any, shall not exceed the original amount paid for the original product.
  • Page 60 11620 54th Street North Clearwater, FL 33760 866.461.3123 www.lazboylimitedspa.com...
