OWNER'S MANUAL
Limited
11638 54
th
Street North
Clearwater, FL 33760
866-461-3123
www.lazboylimitedspa.com
Part Number 827936
La-Z-Boy is a trademark of La-Z-Boy Incorporated and is
used under license to Tatum Manufacturing, Inc.

Advertisement

Table of Contents
loading

Related Manuals for LAZBOY Limited 1304

Summary of Contents for LAZBOY Limited 1304

  • Page 1 OWNER’S MANUAL Limited 11638 54 Street North Clearwater, FL 33760 866-461-3123 www.lazboylimitedspa.com Part Number 827936 La-Z-Boy is a trademark of La-Z-Boy Incorporated and is used under license to Tatum Manufacturing, Inc.
  • Page 2 Owner’s Information Dealer: Date Purchased: __________________________ Company: __________________________ Address: __________________________ Telephone: __________________________ Installer: Date Installed: __________________________ Company: __________________________ Address: __________________________ Telephone: __________________________ Spa: Date Delivered: __________________________ Model: __________________________ Color: __________________________ Serial Number: __________________________ Your unique spa serial number is located on a data plate outside the cabinet at ground level directly below the topside control panel.

  • Page 3: Table Of Contents

    Tatum Manufacturing, Inc. Printed in the U.S.A. Part Number 827936 Version 4.17 La-Z-Boy is a trademark of La-Z-Boy Incorporated and is used under license to Tatum Manufacturing Inc.

  • Page 4: Introduction

    I n t r o d u c t i o n Your choice of a La-Z-Boy™ spa indicates that you are devoted to excellence. The management and staff appreciate your patronage and takes pride in the tradition of quality spas that our company represents.

  • Page 5: Important Safety Information

    I m p o r t a n t S a f e t y I n f o r m a t i o n Read and Follow All Instructions Avoid Risks To Children: DANGER: RISK OF CHILD DROWNING: Extreme care must be exercised, to prevent unauthorized access by children.
  • Page 6 DO NOT use a wall switch, ground fault circuit interrupter, • circuit breaker, fuse, or plugging and unplugging the spa as a means of turning your spa on or off for normal everyday use. DO NOT bring any electrical appliances into or near the spa, •...
  • Page 7 Avoid Risks of Burns Before entering a spa, measure the water temperature • with an accurate thermometer since the tolerance of temperature-regulating devices may vary by as much as ±5°F (2°C). Test the water with your hand before entering the spa to •...
  • Page 8 24/7 technical support line at 866-461-3123 for a replacement. Basic Safety Guidelines Your La-Z-Boy spa is meant to be enjoyable, healthful and relaxing. Below are some basic safety guidelines to follow every time you use your spa.

  • Page 9: Location And Installation

    L o c a t i o n a n d I n s t a l l a t i o n Proper planning is an important consideration when installing your new spa. Site selection is a critical step and requires serious thought.

  • Page 10: Electrical Specifications

    E l e c t r i c a l S p e c i f i c a t i o n s Important – Qualified and licensed electricians must perform all electrical hookups. The following specifications must be followed in order to ensure proper performance and safety.
  • Page 11 Our spas are certified by Intertek Testing, SNAa Ltd. Ontario à CAN/CSA-C22.2 No. 218.1-M89 and ANSI/UL 1563. Parts with extra low voltage not exceeding 12v must be inaccessible to a person in the spa. Earthed appliances must be permanently connected to fixed wiring. Parts incorporating electrical components must be located or fixed so that they cannot fall into the spa.
  • Page 12 US & Canada Wiring Diagram See wire size table on page 8. Important: Installation of this GFCI Circuit Breaker, including Ampere sizing and selection of conductor size and type, must be performed by a qualified electrician in accordance with the National Electrical Code, or the Canadian Electrical Code, and all federal, state, and local codes and regulations in effect at the time of installation.
  • Page 13 European 1x32A Wiring Diagram See wire size table on page 8. Jumper L1-L2-L3...
  • Page 14 European 2x16A Wiring Diagram See wire size table on page 8. Jumper L2-L3...
  • Page 15 European 3x16A Wiring Diagram See wire size table on page 8. No Jumper...

  • Page 16: Startup

    S t a r t u p Important – Read these step-by-step startup procedures before starting your spa. Failure to follow any of these steps listed may result in damage to the equipment and may void your warranty. Special Note: If you are unsure of any of the above startup procedures, please call the 24/7 technical support line at 866-461-3123.
  • Page 17 Before Adding Water Before adding water, go through these simple steps now to prevent common issues when setting up your spa for the first time. Verify that the following have all been rechecked. 1. Turn off all power to the spa at the main breaker panel. 2.
  • Page 18 Filling Your Spa Now it's time to fill your spa with water. Do not turn on the electricity yet until the spa is completely filled. To properly fill your spa: 1. Make sure that the filters (in the filtration canister) are gently screwed into place. Turn them clockwise until they stop being careful not to over-tighten them (this avoids cracking the filter).
  • Page 19 1. Turn on the breaker and test the operation of the Ground-Fault Circuit Interrupter (GFCI) breaker by pushing the small button. This should automatically trip the spa's circuit breaker. DANGER: If this breaker does not trip, immediately call your electrician. Do not use your spa! Only if pushing this button successfully trips this circuit breaker should you reset this breaker and proceed to the next step.
  • Page 20 6. Press the Pump 1 button a third time to turn Pump 1 off. A built- in timer automatically turns Pump 1 off after 20 minutes, unless the pump manually has been deactivated first. 7. Press the Pump 2 button .
  • Page 21 Topside Control Panel The topside control panel uses a paged-style menu system to access various features and options. The above display shows the normal spa mode where you control the most frequently used devices. Basic button functions are described below. Press the Mode button to display the three operating modes (Spa or Options).
  • Page 22 Spa Mode Spa mode allows you to control the basic devices of your spa plus access Standby and Economy features. To access Spa mode, first press to access the main menu and then select the Spa mode with . Press next to the feature or device you wish to operate on that page to turn it on or off.
  • Page 23 Options Mode In options mode, the system shows you which option you wish to program or alter (spa, keypad, or clock). To access Options mode, first press to access the main menu and then select the Options mode with...
  • Page 24 Spa Submenus This submenu allows you to personalize operating settings of your spa such as the total filtration time, economy times, a maintenance reminder, and to display any warning messages. Filter Purge Settings Purge Purge Since filtration runs constantly in your spa, the filter purge cycle turns on all pumps for 30 seconds to flush water and air in the lines.
  • Page 25 Start – Press +/- to set the starting hour of economy mode. Press > to select minutes. Press +/- to set the starting minute of economy mode. Press to go to the next screen. Stop – Press +/- to set the ending hour of economy mode. Press > to select minutes and +/- to set the ending minute of economy mode.
  • Page 26 Video – Press +/- to set a normal or inverse video display. Press to go to the next screen. Orientation – Press +/- to set a normal or inverted display. Press the checkmark function button to save the settings. Sound Settings These settings control how the audible beep functions.
  • Page 27 Security Setting This submenu allows you to personalize the keypad security of your spa to prevent unauthorized changes to the settings. When the keypad is locked the lock icon is displayed. A Partial keypad lock allows access to basic spa functions (pumps, blower, light) but blocks access to the temperature set point and Programming mode.
  • Page 28 Information Submenus This sub-menu allows you to view spa equipment data such as spa controller, and heater and keypad software version. Also, here it's possible to reset programmed settings back to default factory values, and finally to upgrade keypad software. Info Keypad Default This submenu allows you to reset the keypad setting to the factory default.

  • Page 29: Operating Instructions

    O p e r a t i n g I n s t r u c t i o n s Using the Remote All spa functions can be operated from the floating remote control. The buttons toggle their operation based on which mode you select. In Spa mode you can control the Blower, Pumps 1- 2, and the Light from their respective buttons.

  • Page 30: Water Management

    W a t e r M a n a g e m e n t Our enzyme-based water purification system is a perfect match for your spa. AquaClara Natural naturally solves most spa water treatment problems and dramatically reduces spa maintenance. Added monthly, it effectively stabilizes pH/alkalinity, eliminates scum lines, foam, itching and rashes and helps to alleviate dry skin, by reducing overall chemical use.

  • Page 31: Frequently Asked Questions

    F r e q u e n t l y A s k e d Q u e s t i o n s Why does my pump run all the time? Your spa is equipped with a constant filtration system that continuously filters the water keeping it as clean and clear as possible.
  • Page 32 What is the insulation made of? We use a five-step process to fully insulate all of its hot tubs. First, the bottom of each shell is blanketed with a thick layer of solid-cell, high-density insulating foam. Second, an outer layer of insulation is added.
  • Page 33 How do I bleed air from my system? When draining and refilling your spa, the pump may become air locked. An air-locked pump stops water from flowing in your spa and is easily resolved by bleeding off the trapped air. To do this: Turn off all pumps •...

  • Page 34: Troubleshooting

    T r o u b l e s h o o t i n g We offer a quality of spa that is second to none. If a problem arises, you can check this list for a quick solution. If this does not resolve your problem, please call our 24/7 technical support hotline at 866-461-3123.
  • Page 35 PROBLEM CAUSE SOLUTION Moved my Wiring error Check Neutral wiring of GFCI (see spa and at GFCI diagrams on pages 9-13) now it doesn’t No power to Reset circuit breakers on GFCI panel work and main circuit breaker panel Nothing Breaker has Check and reset breaker.
  • Page 36 Error Codes CODE DESCRIPTION CORRECTIVE ACTION Topside error Swap topside plug position (C1 to C2) • Change topside control panel • bL Er Device not • Open the access panel to spa pack CP Er detected and reseat corresponding plug (see O3 Er callouts on page 35) P1 Er...
  • Page 37 CODE DESCRIPTION CORRECTIVE ACTION SP in Input • Check incoming voltage to GFCI voltage low • Check incoming voltage to spa pack SP OH Water Open the spa cover and add cold water temperature through the filter overheat SP Ot Internal •...

  • Page 38: Maintenance And Care

    M a i n t e n a n c e a n d C a r e Important – The warranty on your spa and equipment depends on the proper use of the AquaClara Natural Water Management System™. (Refer to page 28 for more information on the AquaClara Natural Water Management System.) In addition, the following maintenance procedures must be followed periodically.
  • Page 39 Filters The filters in your spa should be removed and cleaned every week with our special Filter Cleanser and typically replaced every 4-6 months (depending upon use). You can clean your filters with the water pressure from the end of a garden hose then rinsed with warm water.

  • Page 40: Shutdown / Winterizing

    Cabinets The spa consists of a rigid polymer that combines the durability of plastic with the beauty of a wood-looking cabinet. To clean the cabinet, a mild soap and water solution easily removes residue. Spa Cover The 5-inch thick tapered cover on your spa is made from a weatherproof marine-grade vinyl.

  • Page 41: Glossary

    G l o s s a r y AquaClara An enzyme-based water purification system for your spa. AquaClara naturally solves most spa water treatment problems and dramatically reduces spa maintenance. Blower A heavy duty motor which aerates the water with millions of tiny bubbles throughout the spa providing soft tissue massage.

  • Page 42: Specifications

    S p e c i f i c a t i o n s LIMITED (MODEL 1304) Specifications* Dimensions 86”L x 86”W x 36”D Seats Water Jets Air Jets Capacity 290 USG /1098 L Dry Weight 865 Lbs/ 393 Kg Filled Weight 3280 Lbs/ 1490 Kg Electrical...
  • Page 43 LIMITED (MODEL 1304) CALLOUTS Part# Description Part# Description 820559 6-spk Jet, Clust Dir 2" (Gr) 621574 6-spk Waterfall Valve 1" (Gr) 606533 Compensator Ring 2" 612480 Drain (Gr) 606526 Body, Jet 2" 609084 Drain Valve, Economy 606530 U-gasket 612584 Suction 200GPM 2"Slip (Gr) 820555 6-spk Jet, Clust Dir Fix 2"...

  • Page 44: Conditions Of Warranties

    C o n d i t i o n s o f W a r r a n t i e s All limited warranties provided hereunder extend only to the original consumer/purchaser of the spa if purchased and installed within the boundaries of the United States or Canada and terminate upon transfer of ownership from original consumer/purchaser.
  • Page 45 Customer Service Options Option 1 – Dispatch Service Company This option can take up to 12 days. 1-2 days for part to ship* • 3-5 days for part to arrive at service company. • 1-5 days for a service company to schedule service call •...
  • Page 46 Notes:...

  • Page 47: Limited Warranty

    L i m i t e d W a r r a n t y This Limited Warranty is extended to the original purchaser of a La-Z-Boy™ spa, manufactured after January 1, 2007 and installed for residential use in the United States and Canada. It terminates with any transfer of ownership.
  • Page 48 La-Z-Boy Spas 11638 54th Street North Clearwater, FL 33760 866-461-3123 www.lazboylimitedspa.com...
