TW-WLAN Router

User Guide

Copyright © TeleWell Oy
4/2011
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TW-WLAN Router and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TeleWell TW-WLAN Router

  • Page 1: User Guide

    TW-WLAN Router User Guide Copyright © TeleWell Oy 4/2011...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Chapter 1 Introduction to your Router…………….…………………………………………………………..5 Package contents……………….………………………………………………………………...…..5 Hardware configuration…………….……………………………………………………………..…..6 Led indicators………………………….…….…………………………………………………….……7 How to Operate…………………………..…….………………………………………………….….…8 Chapter 2 Settings Wizard Setup Login password…………………………..…………………………………...………………11 Set up Time Zone……………………………………………………………………………..……….11 Select WAN Type…………………………………………………………………………………..….12 3G……………………………………………………………………..………………………………..13 Dynamic IP Address………………………………………………………………………………..…14 Wireless settings……………………………………………………………………….…………..….15 Additional settings……………………………………………………………………………………18 Chapter 3 Main settings Quick Start………………………………………………………………………………………...……19...
  • Page 4 Scheduling……………………………………………………………………………….………..……40 Chapter 7. Utility for printer sharing…………………………………………………………………………………...41 Chapter 8. NAS Configuration Disk Utility………………………………………………………………………………………………45 File Sharing Basic setting………………………………………………………………………………………..….45 FTP Service……………………………………………………………………………………………..46 Access Control………………………………………………………………………………46 User configuration………………………………………………………………………….46 Download assistant FTP…………………………………………………………………………………………….47 HTTP…………………………………………………………………………………………..48 Bit Torrent (BT)…..……………………………………………….……………………….49 Start BT download…………………………………………………………………………..49 BT download status………………………………………………………………………...49 Stop, Resume and Remove seed…………………………………………………………50 Download Status…………………………………………………………………………….51 Chapter 9 Tools...
  • Page 5: Introduction To Your Router

    Before you install and use this product, please read this manual carefully for fully exploiting the functions of this product. Package contents TW-WLAN Router package should contain the items listed below. If any of the items are missing, please contact your reseller. TW-WLAN Router l...
  • Page 6: Hardware Configuration

    Hardware Installation Hardware configuration Status LED Power LED USB LED WLAN LED USB Connector Reset Button WAN LED LAN LED 1 4 WPS/USB OFF Button...
  • Page 7: Led Indicators

    ANTENNA Connector Power Switch Button Power Connector WAN Port LAN Port 1 4 ANTENNA Connector LED indicators LED Status Description Status LED Green Power ON Green USB storage attached Green in flash Data access USB LED Press ‘USB off’ button till LED flashing, then Green in flash can remove USB storage when LED stop then stop...
  • Page 8: How To Operate

    How to Operate DO NOT connect TW-WLAN Router to power before performing the installation steps below. Step 1. Screw the antenna in a clockwise direction to the back panel of the unit. Step 2. Plug the RJ45 cable into LAN port 1~4 and connect with your PC or NB.
  • Page 9 Prepare a USB Storage or Printer, and then plug into the USB port. Configuring with your TW-Wlan Router Step 1. Open the web browser Step 2. Enter the IP address of your router, which by default is 192.168.0.254, and click “Go”,...
  • Page 10: Settings Wizard

    Chapter 2. SETTINGS WIZARD With wizard setting steps, you could configure the router in a very simple way. This configuration wizard includes settings of Login Password, Time Zone Setup WAN Setup Wireless Setup, Press “Next” button to start configuration.
  • Page 11: Setup Login Password

    Step 1: Allow you to change the system password. It is recommended that you change the system password into the one you prefer to on the basis of security • Key in your Old Password (if it is the first initiation, the “admin” will be the defaulted one.
  • Page 12: Select Wan Type

    Step 3 Select WAN Types will be used for Internet connection -> Next Step 3 If chosen Setup WAN type manually, configure the WAN settings • LAN IP Address: Change your LAN IP Address (Default is 192.168.0.254) • WAN Interface: Select your WAN type from dropdown menu, Wireless or Ethernet •...
  • Page 13 Step 3 If chosen Wireless WAN and 3G, configure the 3G settings • Dial-Up Profile: If you want manually configure your Dial-Up Profile select Manual. • PIN Code: Enter your SIM card PIN code here. -> Next Step 3 Configuring 3G Dial-Up Profile manually •...
  • Page 14: Dynamic Ip Address

    -> Next Step 3 If chosen Ethernet WAN and Dynamic IP Address, configure the Dynamic IP Address settings • Host Name is optional • ISP registered MAC Address: If you click the Clone MAC button, you will find the MAC address of your NIC shown in WAN's MAC Address.
  • Page 15: Wireless Settings

    Step 4: Configure the wireless settings. • Select Enabled or Disabled. The default setting is Enabled. • Network ID (SSID) will be as a default 1G-WLAN. It is recommended that you change the SSID for making it easier to identify. •...
  • Page 16 • Preshared Key: Key is by default. • WEP: Choose between 64 / 128 bits, and hexadecimals / ASCII 64 bits + HEX= 10 numbers 128 bits + HEX= 26 numbers 64 bits + ASCII= 5 letters or numbers 128 bits + ASCII= 13 letters or numbers Type your WEP password in ”Key 1”...
  • Page 17 Step 6: Summary Make sure that the settings are correctly. By clicking ”Back” you can go back to change the settings. -> Apply Settings Once settings have been saved the router will notify you “Configuration is completed. Please click “finish” to back to status page.” è...
  • Page 18: Additional Settings

    Additional settings You may first edit the settings with Settings Wizard (chapter 2), and then, if necessary, adjust them from the additional settings menu at the left sidebar. Each link opens up a submenu with further options. Status: Summary, 3G status, Wireless Status, System Logs, Statistics. Main settings: Quick Start, DHCP Server, Wireless, Change Password.
  • Page 19: Main Settings Quick Start

    NAS: Disk Utility, File Sharing, Access Control, Download Assistant, Download Status, Web HDD – section. Tools: System Info, Firmware Upgrade, Backup Settings, Reset to Default, Reboot, Miscellaneous. Status: Summary- page presents a summary of the router's status. Separate tables of each topic can be found under links 3G Status, Wireless Status and Statistics.
  • Page 20 • Choose "3G" from the WAN Type dropdown –menu • Dial-up Profile: If you want to set up Dial-up Profile manually select “Manual” (Default is Auto-Detection) • Country: Select your country from a dropdown menu. • Telecom: Select your operator from a dropdown menu. •...
  • Page 21 Example for ADSL connection (Dynamic IP Address) • Choose the Dynamic IP Address option from the WAN Type dropdown –menu • Activate WWAN for Auto-Failover: If desired, you can Enable WWAN for Auto-Failover, and setup wanted Remote Host for keep alive. •...
  • Page 22: Dhcp Server

    Main Settings > DHCP Server • DHCP Server: Choose either Disable or Enable • IP Pool Starting/Ending Address: Whenever there is a request, the DHCP server will automatically allocate an unused IP address from the IP address pool to the requesting computer.
  • Page 23 This function enables you to assign another gateway to your PC, when DHCP server offers an IP to your PC. -> Save Note! Behind “Clients List..” button you can see all devices which are connected to your router.
  • Page 24: Wireless

    Main Settings > Wireless • Wireless Module: Enabled is the default. Selecting this option will allow you to set your Wireless Access Point (WAP) settings. • Network ID (SSID): Service Set Identifier (SSID) is the name designated for a specific wireless local area network (WLAN).
  • Page 25: Change Password

    • WEP: Choose between 64 / 128 bits, and hexadecimals / ASCII 64 bits + HEX= 10 numbers 128 bits + HEX= 26 numbers 64 bits + ASCII= 5 letters or numbers 128 bits + ASCII= 13 letters or numbers Type your password in ”Key 1”...
  • Page 26: Forwarding Rules Virtual Server

    Chapter 4. Forwarding Rules > Virtual Server This product’s NAT firewall filters out unrecognized packets to protect your Intranet, so all hosts behind this product are invisible to the outside world. If you wish, you can make some of them accessible by enabling the Virtual Server Mapping. A virtual server is defined as a Service Port, and all requests to this port will be redirected to the computer specified by the Server IP.
  • Page 27: Miscellaneous

    Forwarding Rules > Miscellaneous IP Address of DMZ Host DMZ (Demilitarized Zone) Host is a host without the protection of firewall. It allows a computer to be exposed to unrestricted 2-way communication for Internet games, Video conferencing, Internet telephony and other special applications.
  • Page 28: Security Settings Packet Filters

    Chapter 5. Security Settings > Packet filters Packet Filter enables you to control what packets are allowed to pass the router. Outbound filter applies on all outbound packets. However, inbound filter applies on packets that are destined to Virtual Servers or DMZ host only. You can select one of the two filtering policies: 1.
  • Page 29 For source or destination port, you can define a single port (80) or a range of ports (1000-1999). Add prefix "T" or "U" to specify TCP or UDP protocol. For example, T80, U53, U2000-2999, No prefix indicates both TCP and UDP are defined. An empty implies all port addresses.
  • Page 30: Domain Filters

    Security Settings > Domain Filters • Domain Filter: let you prevent users under this device from accessing specific URLs. • Domain Filter Enable: Check if you want to enable Domain Filter. • Log DNS Query: Check if you want to log the action when someone accesses the specific URLs.
  • Page 31: Url Blocking

    Security Settings > URL Blocking URL Blocking will block LAN computers to connect to pre-defined Websites. The major difference between “Domain filter” and “URL Blocking” is that Domain filter requires user to input suffix (like .com or .org, etc), while URL Blocking requires user to input a keyword only. In other words, Domain filter can block specific website, while URL Blocking can block hundreds of websites by simply a keyword.
  • Page 32: Mac Control

    Security Settings > MAC Control MAC Address Control allows you to assign different access rights for different users and to assign a specific IP address to a certain MAC address. • MAC Address Control: Check “Enable” to enable the “MAC Address Control”. All of the settings on this page will take effect only when “Enable”...
  • Page 33: Miscellaneous

    Security Settings > Miscellaneous Remote Administrator Host/Port In general, only Intranet user can browse the built-in web pages to perform administration task. This feature enables you to perform administration task from remote host. If this feature is enabled, only the specified IP address can perform remote administration. If the specified IP address is 0.0.0.0, any host can connect to this product to perform administration task.
  • Page 34: Advanced Settings System Log

    Chapter 6. Advanced Settings > System Log This page supports two methods to export system logs to specific destination by means of syslog (UDP) and SMTP(TCP). • IP Address for Syslog: Host IP of destination where syslog will be sent to. •...
  • Page 35: Dynamic Dns

    Advanced Settings > Dynamic DNS To host your server on a changing IP address, you have to use dynamic domain name service (DDNS). So that anyone wishing to reach your host only needs to know the name of it. Dynamic DNS will map the name of your host to your current IP address, which changes each time you connect your Internet service provider.
  • Page 36: Qos

    Advanced Settings > QoS QoS feature allows you to set priorities to different IP addresses, and thus limit their speed. • Enable QoS by clicking on the enable box • Define preferred upstream bandwidth speed. This can not be defined as 0. •...
  • Page 37: Snmp

    Advanced Settings > SNMP In brief, SNMP, the Simple Network Management Protocol, is a protocol designed to give a user the capability to remotely manage a computer network by polling and setting terminal values and monitoring network events. • Enable SNMP: You must check either Local or Remote or both to enable SNMP function.
  • Page 38: Routing

    Advanced Settings > Routing Routing Tables Allow you to determine which physical interface address to use for outgoing IP data grams. If you have more than one routers and subnets, you will need to enable routing table to allow packets to find proper routing path and allow different subnets to communicate with each other.
  • Page 39: System Time

    Advanced Settings > System Time • Time Zone: Select a time zone where this device locates and router automatically adjusts its clock to right time. • Press “Sync with Time Server” if you want to synchronize your router’s clock with time server or press “Sync with my PC”...
  • Page 40: Scheduling

    Advanced Settings > Scheduling You can set the schedule time to decide which service will be turned on or off. Select the “Enable” item. Press “New Add” You can write a rule name and set which day and what time to schedule from “Start Time” to “End Time”.
  • Page 41: Utility For Printer Sharing

    Chapter 7. Utility for Printer Sharing Step 1. Install the Easy Setup Utility from the provided CD then follow the steps to configure the device. Step 2. Select Language then click “Next” to continue. Step 3. Please enter your information Then press next to continue.
  • Page 42 Step 5. Click Install to begin the installation. Step 6. Processing. Step 7. Install Completed. Then you can click icon at your PC to run the program of printer sharing. Once you accomplish the utility of printer sharing, you can execute the program and follow the following steps to setup the printer and start to print.
  • Page 43 Step 8. When you run the utility, you can go to ‘tool‘->‘Configuration’ to change the language you wish. Step 8-1. Select Language Step 9. Once your printer is ready to plug in router, please make sure your PC already installed the printer driver in Windows.
  • Page 44 Note: You can uninstall this utility through Windows Program files. Step 9-1. If you want your printer to connect automatically next time, you can click on the icon of ‘Auto Connect Printer’.
  • Page 45: Disk Utility

    Chapter 8 NAS > Disk Utility 1. Format This utility would format the certain partition. Please be noted! This action will clear all your data in this partition. You will not be able to recover it any more. 2. Check This utility could help you check the partition, find the lost files, try to fix some problems.
  • Page 46: Ftp Service

    NAS > File Sharing > FTP Service These settings are for FTP service. 1. FTP Port: The default port is 21, but sometimes you might want to hide your FTP service by changing it. We have the ability to receive the request on non-standard FTP port, but please be noted, some NAT router could not support non-standard FTP port, that means some of your clients might have to use passive mode to get file.
  • Page 47: Download Assistant Ftp

    NAS > File Sharing > User Configuration In this page, you can manage the user account. Key in the user name and password then press “Add” could let you add a new user. If you want to delete an account, select it and click “Delete” button. NAS >...
  • Page 48: Http

    The destination path on USB disk that you want to save files. Default value is /C/Download/FTP 4. Login method: Anonymous, you can access this site without any authentication Account, you have to enter the username and password to login. 5. Start Time: Schedule: this device will start FTP download on the time that you specified.
  • Page 49: Bit Torrent (Bt)

    NAS > Download Assistant > BT NAS > Download Assistant > BT > Start BT download NAS > Download Assistant > BT > BT download status...
  • Page 50: Stop, Resume And Remove Seed

    NAS > Download Assistant > BT > Stop, Resume and Remove seed...
  • Page 51: Download Status

    NAS > Download Status How to access data on the NAS? Windows User NAS > By network place Then start your “file manager”, type the IP with “\\” on the beginning, as follow picture shown. Then press enter. You could find a folder named “Storage”. It is what you are looking for.
  • Page 52 NAS > By Web HDD This Web HDD can allow you to enter HDD by web UI, and also can allow you to let ‘guest’ to enter the ‘public’ area only. Unix User We do not provide NFS support, so the only way for UNIX to get files is FTP. Use your FTP client to connect the FTP server.
  • Page 53: Tools System Info

    Chapter 9. Tools > System Info You can view the System log and Routing Table information in this page. With “<<Previous”, “Next>>”, “First Page” and “Last Page” buttons you can browse system logs. If desired, you may empty the system log by clicking on clear-logs button. And if needed, you can download system logs simply pressing “Download”...
  • Page 54: Firmware Upgrade

    Tools > Firmware Upgrade Newest firmware upgrade files can be found on our web page http://www.telewell.fi. Save the file on your computer, and then search for it on this page. Clicking on the upgrade button will update your firmware. You may also upload a previously saved settings file in the same way.
  • Page 55: Miscellaneous

    Tools > Miscellaneous MAC Address for Wake-on-LAN Wake-on-LAN is a technology that enables you to power up a networked device remotely. In order to enjoy this feature, the target device must be Wake-on-LAN enabled and you have to know the MAC address of this device, say 00-11-22-33-44-55.
