  • Page 1 Programmable thermostat User Manual...
  • Page 2 INTRODUCTION √ WARNINGS √ MINITOUCH MENU √ MAIN MENU ICONS LEGEND...
  • Page 3 INTRODUCTION WARNINGS Comelit Group S.p.A. declines any responsibility for improper use of the apparatus, for any alterations made by others for any reason, and for the use of non-original accessories or materials. Caution! In order to reduce the risk of faults and electric shocks: •...

  • Page 4: Minitouch Menu

    INTRODUCTION MINITOUCH MENU MAIN MENU ICONS LEGEND To access the main menu, press the screen. All thermostats inactive To navigate the menu, simply use your fi nger to touch the icon corresponding to the desired function. One or more thermostats active...
  • Page 5 CLIMATE √ CLIMATE MENU DESCRIPTION √ CLIMATE CONTROL √ CLIMATE SCHEDULING √ MANUAL CLIMATE MODE √ CLIMATE FORCING...

  • Page 6: Climate Control

    CLIMATE CLIMATE MENU DESCRIPTION CLIMATE CONTROL Press the relevant icon in the climate menu (e.g. To access the Climate menu, press the icon on the Bedroom 1). main menu screen. Mon 29/10/12 - 16:07 0W Mon 29/10/12 - 16:07 0W Bedroom 1 20°...
  • Page 7 CLIMATE CLIMATE SCHEDULING NOTE: daily climate control programming must refer to the whole 24-hour cycle; any hours not Press the icon to access the scheduling menu programmed by the user will be set by the system for the climate control system in the relevant area. automatically.

  • Page 8: Climate Forcing

    CLIMATE MANUAL CLIMATE MODE CLIMATE FORCING If necessary, it is possible to force both automatic and Press the icon to set the climate to manual manual programming for a set period of time (hours mode and use the + and – selectors to adjust the or days).
  • Page 9 SCENARIOS √ SCENARIOS MENU DESCRIPTION √ CREATING NEW SCENARIOS √ SCHEDULING SCENARIOS √ ACTIVATING SCENARIOS √ DELETING SCENARIOS √ MODIFYING SCENARIOS √ RENAMING SCENARIOS...
  • Page 10 SCENARIOS SCENARIOS MENU DESCRIPTION CREATING NEW SCENARIOS The Minitouch system timer-thermostat controls 2 Access the Scenario settings menu by pressing types of scenario. · One shot: these must be activated manually and Mon 29/10/12 - 16:07 0W perform the function for which they were programmed every time they are activated.
  • Page 11 SCENARIOS Select the operation you want to carry out (switch the Mon 29/10/12 - 16:07 0W thermostat on or off, or set its temperature). Climate Climate Mon 29/10/12 - 16:07 0W Camera 1 20,0° Camera 2 Soggiorno Select the Climate function to view the various timer- Bathroom Bathroom thermostats available.
  • Page 12 SCENARIOS SCHEDULING SCENARIOS Once all the desired functions have been set, exit the scenario creation menu by pressing the icon To schedule a new scenario, press the icon. repeatedly. You will be asked for confi rmation when exiting the scenario creation procedure. Mon 29/10/12 - 16:07 0W Mon 29/10/12 - 16:07 0W TIME...

  • Page 13: Activating Scenarios

    SCENARIOS ACTIVATING SCENARIOS Select the days of the week for which you wish to program the activity (selected days will be highlighted To access the Scenarios menu, press the icon on in red) and press the icon to add a programming the main menu screen.
  • Page 14 SCENARIOS DELETING SCENARIOS Press the icon followed by the icon corresponding to the scenario you wish to delete. To access the Scenarios menu, press the icon on the main menu screen. Mon 29/10/12 - 16:07 0W Mon 29/10/12 - 16:07 0W Scenario 1 Scenario 1 Scenario 1...
  • Page 15 SCENARIOS RENAMING SCENARIOS Access the Scenario settings menu by pressing To access the Scenarios menu, press the icon on Mon 29/10/12 - 16:07 0W the main menu screen. Mon 29/10/12 - 16:07 0W Scenario 1 Scenario 1 Scenario 1 Scenario 1 Press the icon followed by the icon corresponding to the scenario you wish to modify.
  • Page 16 SCENARIOS Change the scenario name and press the icon to confi rm. Mon 29/10/12 - 16:07 0W Scenario 1...
  • Page 17 SETUP √ SETUP MENU DESCRIPTION √ LANGUAGE √ LOCKING THE KEYPAD AND TOUCH-SCREEN √ SETTING THE DATE AND TIME √ INFORMATION √ BACKLIGHT √ BACKLIGHT COLOUR SELECTION √ SMART LIGHT FUNCTION √ BUZZER...

  • Page 18: Setup Menu Description

    SETUP SETUP MENU DESCRIPTION LANGUAGE The Minitouch menu display language can be To access the Setup menu, press the icon on the changed by selecting one of the options on the list. main menu screen. Access the menu Setup > Language.

  • Page 19: Setting The Date And Time

    To set the date and time, access the menu Setup > temporarily deactivates the Minitouch screen. The Set date and time. functions are reactivated after 60 seconds. Use the + and – icons to set the various fi elds. When To activate the function, press the “Lock keypad and...
  • Page 20 Enter the backlight colour selection menu: BUZZER Mon 29/10/12 - 16:07 0W When the Buzzer function is activated, the Minitouch will emit a tone every time the icons are pressed. Access the menu Setup > Buzzer. Mon 29/10/12 - 16:07 0W...
  • Page 21 ADVANCED √ ACCESSING ADVANCED MENUS √ ADVANCED MENUS DESCRIPTION √ CALIBRATING THE TOUCH-SCREEN √ TOTAL RESET √ RESET CONFIGURATIONS √ CONFIGURATION UPDATE √ CHANGE SKIN √ TRANSMISSION TIME √ PRODUCT UPDATE Caution!! This menu is intended for your installer. Inappropriate modifi cation of the following settings could compromise correct system operation.
  • Page 22 ADVANCED ACCESSING ADVANCED MENUS ADVANCED MENUS DESCRIPTION Access the menu Setup > Advanced. Mon 29/10/12 - 16:07 0W Enter the installer password 1961. Calibrate touch-screen Calibrate touch-screen Mon 29/10/12 - 16:07 0W Total reset Reset configurations INSERT PASSWORD Update configurations Mon 29/10/12 - 16:07 0W Update product Update product...

  • Page 23: Total Reset

    ADVANCED CALIBRATING THE TOUCH-SCREEN TOTAL RESET If the touch-screen does not respond correctly to The function deletes all settings implemented by touch commands, it can be calibrated. the user, restoring the system to its original default condition. Access the menu Setup > Advanced > Calibrate touch-screen.

  • Page 24: Reset Configurations

    ADVANCED RESET CONFIGURATIONS CONFIGURATION UPDATE If this function is used, all settings made previously on If this function is used, all modifi ed functions on the the supervisor (scenarios, scheduling) will be lost and SD card will be updated and the others left intact. the SD card programming will be reloaded.

  • Page 25: Transmission Time

    • If the value is set to 5, 5 tenths of a second will pass between one thermostat switching on and the next. PRODUCT UPDATE Please contact the Comelit Group S.p.A. service centre for product software updates.
  • Page 26 NOTES...
