BEVERAGE MERCHANDISER
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial No. (on back of unit) here:
________________________________
Model No.: SCR1505
Instruction Manual
Felix Storch, Inc.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCR1505 and is the answer not in the manual?

Questions and answers

Related Manuals for Summit SCR1505

Summary of Contents for Summit SCR1505

  • Page 1 BEVERAGE MERCHANDISER Model No.: SCR1505 Instruction Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc. Write Serial No. (on back of unit) here: 770 Garrison Avenue Bronx, NY 10474 ________________________________ www.summitappliance.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Appliance Safety ................. Important Safeguards ..............3 - 4 Special Cautions ................. Location of Parts ................ Handling & Transport ..............Unit Review & Inspection ............Installation Instructions ............. 7 - 9 Location .................. Installing Shelves ..............Electrical System ..............8 - 9 Refrigeration &...

  • Page 3: Appliance Safety

    APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others.
  • Page 4  Do not connect or disconnect the electric plug when your hands are wet.  Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in electrical shock or death.  Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this manual.

  • Page 5: Special Cautions

    The polyurethane in your unit contains cyclopentane gas as a foaming agent. When repairing, DO NOT use other types of polyurethane or mix the existing polyurethane with other types. SUMMIT is not responsible for changes in the refrigerator if repairs are made by the user or unauthorized technicians.

  • Page 6: Location Of Parts

    LOCATION OF PARTS Lighted header Light switch Internal fan Interior lighting (around door) Adjustable shelves (4) Handle Security lock Glass door Static condenser (on back of unit) Ventilation louvers Thermostat control Compressor and fan (behind louvers) Leveling legs HANDLING & TRANSPORT DO NOT MOVE UNIT WITH PRODUCT INSIDE as loose product can break, spill, damage the appliance, etc.

  • Page 7: Unit Review & Inspection

    UNIT REVIEW & INSPECTION This refrigerator was completely inspected before leaving the factory. Check for signs of damage when the unit is received. If there is any damage, contact your authorized distributor or manufacturer immediately. Check that the following accessories are included with your refrigerator: ...

  • Page 8: Installing Shelves

    INSTALLING SHELVES Your refrigerator contains 4 wire shelves and 16 shelf clips. To install shelves, first place the shelf clips in the slots in the pilasters in the cabinet interior. Use the numbers on the pilasters as a guide in placing the clips at the same distance from the cabinet floor, with the tab pointing up as shown.

  • Page 9: Refrigeration & Lighting System

    Wiring Diagram for model SCR1505: REFRIGERATION & LIGHTING SYSTEM The compressor in your SUMMIT refrigerator is designed to function silently. DO NOT plug in the unit immediately after moving it or changing its position. Allow a minimum of 1 hour for the pressures inside the refrigeration system to equalize and the oils in the compressor to settle.

  • Page 10: Temperature Control

    TEMPERATURE CONTROL The temperature is controlled by a thermostat which is located on the left side of the ventilation louvers, below the door. The thermostat has been factory-set to keep the product between 37.4 and 44.6°F (3 and 7°C). At night, or during long periods of inactivity, the appliance goes into an energy-saving mode, which keeps the temperature between 42.8 and 50.0°F (6 to 10°C).

  • Page 11: Cleaning The Compressor/Fan Compartment

    CLEANING THE COMPRESSOR / FAN COMPARTMENT The compressor and fan are located behind the front louvers of the appliance. DISCONNECT THE UNIT’S POWER SUPPLY BEFORE REMOVING THE FRONT LOUVER to avoid accidents that may be caused by oscillation of the blade of the fan motor. Door Front louvers Compressor...

  • Page 12: Troubleshooting

    TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Troubleshooting Guide PROBLEM POSSIBLE CAUSE The unit does not operate. Not plugged in.

  • Page 13: Limited Warranty

    Certain exclusions may apply. Certain models (including SUMMIT ranges, wall ovens, and cook tops) are manufactured for us in the U.S. and carry the manufacturer's warranty (also one year parts and on-site labor).
  • Page 14  IMPROPER USE: SUMMIT assumes no liability for parts or labor coverage for component failure or other damages resulting from improper usage or installation or failure to clean and/or maintain product as set forth in the warranty packet provided with the unit.
