BEVERAGE MERCHANDISER
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial No. (on lower left corner of
inside cabinet) here:
____________________________________________
Model No.: CL181WBV
Instruction Manual
Felix Storch, Inc.
An ISO 9001:2008 registered company
770 Garrison Avenue
Bronx, NY10474
www.summitappliance.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Classic CL181WBV and is the answer not in the manual?

Questions and answers

Related Manuals for Summit Classic CL181WBV

Summary of Contents for Summit Classic CL181WBV

  • Page 1 BEVERAGE MERCHANDISER Model No.: CL181WBV Instruction Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc. Write Serial No. (on lower left corner of An ISO 9001:2008 registered company inside cabinet) here: 770 Garrison Avenue Bronx, NY10474 ____________________________________________ www.summitappliance.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Appliance Safety Important Safeguards 3 - 4 Location of Parts Installation Instructions 6 - 8 Before Using Your Appliance Installation of Your Appliance Electrical Connection 6 - 7 Extension Cord Reversing the Door Swing of Your Appliance 7 - 8 Installing the Stainless Steel Handle Operating Your Appliance...

  • Page 3: Appliance Safety

    APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others.
  • Page 4 parts of the cooling system are damaged. Leaking coolant can ignite and may damage the eyes. In the event of any damage: - Avoid open flames and anything that creates a spark, - Disconnect from the electrical power line, - Air the room in which the appliance is located for several minutes and - Contact the Service Department for advice.

  • Page 5: Location Of Parts

    LOCATION OF PARTS Digital Control Panel Handle Shelves(3) Door Ventilation Grille Adjustable Cabinet Legs...

  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS BEFORE USING YOUR APPLIANCE  Remove the exterior and interior packing.  CAUTION: After unpacking you MUST allow this appliance to stand upright for at least 2 hours to allow the lubricant and refrigerant to drain back into the compressor and stabilize. Failure to do so may adversely affect performance and the lifetime of this unit.

  • Page 7: Extension Cord

    To prevent accidental injury, the cord should be secured behind the appliance and not left exposed or dangling. The appliance should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating label on the appliance. This provides the best performance and also prevents overloading house wiring circuits that could cause a fire hazard from overheating.

  • Page 8: Installing The Stainless Steel Handle

    hand side. 5. Screw the alternative left top hinge 8, included in the fittings, on the left hand side of cabinet. (Fig. 4) 6. Rotate the door 180° and relocate it to the designated position and screw the top hinge pin 1. Then tighten top hinge pin 1 and bottom hinge 3 after the door is leveled.

  • Page 9: Interior Light

    ºF/ºCSelector Select the temperature display setting in Fahrenheit or Celsius degrees. To change the temperature from Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the LIGHT key for 5 seconds. Setting the Temperature Control  You can set the temperature by touching the UP and DOWN symbols. When you push the two buttons for the first time, the LED readout will show the original temperature set previously.

  • Page 10: Temperature Alarm / Door Alarm

    TEMPERATURE ALARM / DOOR ALARM  An audible alarm sounds if the storage temperature is not cold enough. The temperature display flashes at the same time.  The cause of the temperature being too high may be: Warm items were placed inside Too much warm ambient air flowed in when rearranging and removing contents Power failure for some time The appliance is faulty.

  • Page 11: Care And Maintenance

    CARE AND MAINTENANCE CLEANING YOUR BEVERAGE MERCHANDISER CAUTION: Failure to unplug the appliance during cleaning could result in electrical shock or other personal injury.  Turn off the power, unplug the appliance, and remove all items, including shelves.  Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water).

  • Page 12: Troubleshooting

    TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Troubleshooting Guide PROBLEM POSSIBLE CAUSE REMEDY  Appliance is not connected to a power ...
  • Page 13  The gasket is dirty.  Clean the door gasket.  The shelves are out of position.  Check the shelves and refit correctly.  “E0”indicates a communication error for  Call for service. 3- zone models.  “E1” or “E2” indicates that the air Display “E0”, “E1”.
  • Page 14 Notes...
  • Page 15 Notes...

  • Page 16: Limited Warranty

    LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.

This manual is also suitable for:

Classic cl181wbvcss
